Getting started

Setting up the receiver

Step 1 of 3: Installing the antenna

Twist the antenna clockwise onto the receiver's antenna jack located on the back of the
receiver.

Step 2 of 3: Turning on the receiver

1 Connect the cable from the power adapter to the 5V DC port on the bottom panel of the
receiver. Plug in the power adapter to an outlet or surge protector.
2 Slide the power switch on the rear panel to the "
Tips:
• Place the receiver in a location that will have a clear reception to your camera. Try to maintain
line-of-sight and minimize the number of obstructions between the camera and receiver.
• Adjust the antenna on the receiver as necessary to provide the clearest reception.

Step 3 of 3: Inserting the SD card

The SD card allows you to store video footage captured by the camera. Push the SD card into
the SD card slot on the LCD receiver until you hear a "click." The card will not be flush when
completely inserted.
NOTE: The receiver is compatible with most major brands of SD card up to 32 GB. For
recording times on SD cards, see "Minimum recording times on SD cards" on
page 15.
4
Connect antenna to receiver
ON
" position.
