- Page 1 WIRELESS HOME MONITORING SYSTEM USER’S GUIDE ENGLISH VERSION 1.0 www.lorextechnology.com LW2730/LW2930 SERIES...
- Page 2 Thank you for purchasing the Lorex wireless video monitoring system. This manual refers to the following models: • LW2730 Series (7‘‘ wireless monitoring system) • LW2930 Series (9‘‘ wireless monitoring system) For the latest online manual, downloads, and product updates, and to learn about our complete line of accessory products, please visit our website at: www.lorextechnology.com...
-
Page 3: Need Help
For all other matters, visit www.lorextechnology.com By Phone: North America: : 1-888-425-6739 Customer Service (for warranty matters) (1-888-42-LOREX) : 1-877-755-6739 Tech Support (for technical/installation issues) (1-877-75-LOREX) Mexico: 001-800-681-9263, 001-800-514-6739 International: +800-425-6739-0 (Example: From the UK, dial 00 instead of +) - Page 4 1-888-425-6739 (1-888-42-LOREX) Asistencia técnica Soutien technique (para asuntos técnicos o de instalación) (pour les questions d’ordre technique ou relatives à 1-877-755-6739 (1-877-75-LOREX) : 1-877-755-6739 (1-877-75-LOREX) l’installation) Mexique : 001-800-681-9263, 001-800-514-6739 Mexico: 001-800-681-9263, 001-800-514-6739 Internacional: +800-425-6739-0 International : +800-425-6739-0 (par exemple : à partir du Royaume-Uni, composez le 00 au lieu de +)
- Page 5 Please make sure to register your product at www.lorextechnology.com to receive product updates and technical support THIS PRODUCT MAY REQUIRE PROFESSIONAL INSTALLATION LOREX IS COMMITTED TO FULFILLING YOUR SECURITY NEEDS • We have developed user friendly products and documentation. Please read the Quick Start Guide and User Manual before you install this product.
- Page 6 ESTE PRODUCTO PUEDE EXIGIR UNA IN- CE PRODUIT PEUT NÉCESSITER UNE STALACIÓN PROFESIONAL INSTALLATION PROFESSIONNELLE LOREX S’ENGAGE À RÉPONDRE À VOS LOREX SE COMPROMETE A SATISFACER BESOINS EN MATIÈRE DE SÉCURITÉ SUS NECESIDADES EN SEGURIDAD • Favor de leer la guía de instalación rápida y la •...
-
Page 7: Important Safeguards
Important Safeguards In addition to the careful attention devoted to quality standards in the manufacture process of your product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to ensure your enjoyment and proper use of the product and accessory equipment. - Page 8 Installation (Continued) Service Ventilation Servicing - Slots and openings in the case are - Do not attempt to service this video provided for ventilation to ensure reliable operation equipment yourself, as opening or removing covers of the product and to protect it from overheating. may expose you to dangerous voltage or other These openings must not be blocked or covered.
- Page 9 WARNING STRANGULATION HAZARD: Infants have STRANGLED in power cords. Keep power cords more than 3 feet away from cribs, bassinets, play yards, and other safe sleep environments for infants. NOTICES FCC Notice: Industry Canada Notice: This equipment has been certified and found to This device complies with...
- Page 10 Features • 7"/9” digital LCD display • Simple installation. No video cables required • Integrated digital video recorder • Multiple recording options: manual, motion or schedule • Time and date stamped recordings for easy retrieval • Front panel feather touch controls •...
-
Page 11: Table Of Contents
Table of Contents Getting started............1 Installing the camera . - Page 12 Screen Saver (digital picture frame) mode ......28 Uploading images to the SD card (PC only) ........28 Configuring Screen Saver mode .
-
Page 13: Getting Started
Getting started The system includes the following components: Two way audio outdoor SD memory card** LCD monitor / wireless camera* receiver* USB cable AV cable Power adapters for receiver and camera* Camera mounting stand* Under the counter Wireless antennas (for mounting kit receiver and camera)* Mounting kit(s)*... -
Page 14: Installing The Camera
Installing the camera Cameras are suitable for outdoor installation, but are weather resistant, not weather proof. Cameras are not intended for direct exposure to rain or snow. For outdoor applications, install under shelter protected from the elements, such as beneath roof eaves. The diagram below shows an example of an ideal location for outdoor placement. - Page 15 Twist the antenna clockwise onto the antenna port on the side of the camera. Connect antenna Attach the camera to the mounting stand. Adjust the angle of the camera until the desired view is set. Tighten the thumbscrews to secure the desired camera position. Connect camera stand Tighten thumb screws...
-
Page 16: Setting Up The Receiver
Getting started Setting up the receiver Step 1 of 3: Installing the antenna Twist the antenna clockwise onto the receiver’s antenna jack located on the back of the receiver. Connect antenna to receiver Step 2 of 3: Turning on the receiver Connect the cable from the power adapter to the 5V DC port on the bottom panel of the receiver. -
Page 17: Camera Overview
Camera overview Camera overview Microphone: Built-in microphone. Lens: Camera lens. PIR Sensor: Passive IR motion sensor. Speaker: Speaker for intercom. Night Vision IR: Night vision IR LEDs. Pair: Pairing button. For more details, see “Pairing/adding cameras” on page 33. Antenna: Wireless antenna. Power Cable: Connect the included power adapter to the cable extending from the camera. -
Page 18: Receiver Overview
Receiver overview Receiver overview Front panel buttons Front panel buttons Button Function : Motion Recording Activate/deactivate Motion Recording. : Manual Recording Start/stop Manual Recording. : Menu Open Main Menu. Return to previous menu / exit menus. Increase / decrease volume on receiver. Scroll left / right : Volume Control in menus. -
Page 19: Back Of Receiver
Receiver overview Back of receiver *LW2930 Series uses a slide switch located on the side LW2730 Series panel Wireless Antenna: Position the antenna as needed for best reception. Mounting Hole: Attach the included under-the-counter mount to mount the LCD receiver underneath a counter/cupboard or to a wall. -
Page 20: Led Indicators On The Lcd Receiver
Receiver overview LED Indicators on the LCD receiver Use the LED indicators on the LCD receiver to observe the status of the receiver, cameras, and SD card. FULL MOTION SCAN LED indicators The blue lights indicate the following: • NEW: A new video file has been recorded to the SD card. •... -
Page 21: Using The System
Using the system Using the system By default, the camera(s) included with your system are automatically paired to the wireless receiver. The camera(s) and receiver will communicate with each other once they are powered NOTE: Power on the cameras before powering on the receiver. Understanding the on-screen display With camera 1 properly connected and powered on, the system displays a single channel full-screen live view of the camera. -
Page 22: Navigating Menu Screens
Using the system Signal Indicator: The signal indicator shows the strength of the signal being received from the camera. The number of bars in the Signal Indicator shows the strength of the signal. One, or no bars indicates the signal is poor, and 4 bars indicate a very strong signal. The signal indicator is not shown during quad mode. -
Page 23: Viewing Modes
Using the system Viewing modes There are four different viewing modes available on the system: single channel viewing, Auto Sequence Viewing mode (view individual channels automatically in sequence), Quad mode, and Screen Saver mode (for details, see “Screen Saver (digital picture frame) mode” on page 28). To change viewing modes: •... -
Page 24: Digital Zoom
Using the system Digital Zoom The Digital Zoom feature allows you to zoom in 2x on your cameras during live viewing. This is useful if you need a closer look at something happening far away from the cameras. To use digital zoom: Select the desired camera in full-screen mode (press UP/DOWN to select the channel) and press the ZOOM button on the rear panel of the wireless receiver to zoom in. -
Page 25: Two-Way Audio Volume
Using the system Two-way audio volume The two-way audio volume is different from the alarm/buzzer volume found in the Main Menu >Settings>Alarm Volume). To change two-way audio volume: • From live viewing, press to increase the system volume or press to decrease the system volume. -
Page 26: Setting The Time
Setting the time Setting the time It is highly recommended to set the time on the system prior to recording. You need to set the correct date and time in order to use Schedule Recording. To set the time: 2012/09/22 Press to open the main menu. -
Page 27: Recording
Recording Recording The following recording modes are available on the system: Manual Recording, Schedule Recording, and Motion Recording. The system can record video to an SD card one channel at a time or record the entire screen in Quad mode. Recording prerequisites •... -
Page 28: Recording Mode Summary
Recording Recording mode summary Mode Description How to Operate MANUAL • Continuous recording from • Press the Record button ( RECORDING one camera or entire screen to start/stop manual in Quad mode recording SCHEDULE • Continuous recording from •... -
Page 29: Manual Recording
Recording Manual recording Manual recording allows you to manually start/stop recording from one channel at a time or the entire screen in Quad mode. You can also record while in Digital Zoom mode. For details on using Digital Zoom, see “Digital Zoom” on page 12. NOTE: During manual recording, you cannot change channels and Auto Sequence mode will stop automatically changing the channel. -
Page 30: Stopping Schedule Recording
Recording Move the cursor RIGHT/LEFT to select ON to enable the schedule or OFF to disable the schedule and press OK to save. Repeat steps 3 through 5 for any additional days you would like to configure. When you are finished, press until all menus are closed. -
Page 31: Motion Recording
Recording Motion recording Use motion recording to have the system record only when motion is detected by one of the cameras. The system can be set to record only from the camera that detects motion or from the entire screen when the system is in Quad mode. The system records motion in two ways. -
Page 32: Configuring Motion Recording Duration
Recording • Enable Auto Sequence Viewing mode: Press until a single channel is shown. When motion is detected, the system will display and record the triggered camera on-screen. When motion recording is over, Auto Sequence Viewing mode will continue as normal. •... -
Page 33: Selecting Single Channel Or 4 Channel Motion Recording
Recording Selecting Single Channel or 4 Channel motion recording Use the Mode menu to select between single channel and 4 Channel motion recording. When single channel recording is activated, the monitor will switch to the camera that detects motion and record from that channel only. 4 Channel recording will record the entire screen during Quad mode (4-way-split). -
Page 34: Configuring The Recording Quality
Recording To configure video motion detection: Press , then select Video Motion Detection and press OK. Select the camera you would like to configure and press OK. Under Day, select Off to disable video motion detection, or select Low, Medium, or High sensitivity. -
Page 35: Playback
Playback Playback Playback mode allows you to playback the recorded video files or view images that you have uploaded to the SD card (for details, see “Uploading images to the SD card (PC only)” on page 28). You can view videos or images directly on the system or by connecting the SD card to your computer. -
Page 36: Controlling Playback
Playback Controlling playback Use UP/DOWN/LEFT/RIGHT to control video playback. Current video time / 00:00:00/00:00:50 Playback status length of video File name 1-112402 Playback controls To control playback: • LEFT: Rewind video / increase rewind speed. When you reach the beginning of the video, playback is stopped, and you can press LEFT to skip to the previous video in the list. -
Page 37: Image Playback
Playback Image playback If you have uploaded images to the SD card using PhotoRun, you can open them in Playback mode. For instructions on how to upload files to the SD card, see “Uploading images to the SD card (PC only)” on page 28. NOTE: Recording and PIP mode is not available during image playback. - Page 38 Playback A delete confirmation message appears, highlight YES and then press OK to delete the file. 091252_1 980KB DELETE FILE 091430_1 8112KB 091430_1? 100341_3 091252_1 8112KB 100341_3 Repeat the steps above for other files on the SD card. NOTE: You cannot delete folders on the SD card using the system. ATTENTION Do NOT delete folders on the SD card using your computer.
- Page 39 Playback Click Open folder to view files or open the folder in Computer. You should see a folder labeled "VIDEO." Open the VIDEO folder and then open one of the Date folders (yyyymmdd). The AVI file list appears. Double-click any of the AVI files. The video will begin playing in your default AVI media player. ATTENTION Additional codecs are required if attempting to view AVI files in QuickTime.
-
Page 40: Screen Saver (Digital Picture Frame) Mode
Screen Saver (digital picture frame) mode Screen Saver (digital picture frame) mode Use the Screen Saver mode to conceal the fact that the wireless receiver is actually a surveillance recorder. Screen Saver mode has two options: blank screen or digital picture frame mode. •... - Page 41 Screen Saver (digital picture frame) mode An Autorun window appears. Click Open folder to view files. Open folder to view files Double-click the PHOTORUN file. The PhotoRun application opens. PHOTORUN Click then select the folder where the Click to select images you would like to image folder upload are stored and...
- Page 42 Screen Saver (digital picture frame) mode All images in the folder are added to the top area of the screen. Check ALL to select Select all all the images in the folder or images in check any images you would folder like to add and click upload them to the SD card.
-
Page 43: Configuring Screen Saver Mode
Screen Saver (digital picture frame) mode Configuring Screen Saver mode By default, Screen Saver mode is in Blank Screen mode. You can enable digital picture frame mode and configure transition options for digital picture frame mode (PC only). Prerequisites: • To use digital picture frame mode, you must upload images onto the SD card. see “Uploading images to the SD card (PC only)”... -
Page 44: Activating Screen Saver Mode
Screen Saver (digital picture frame) mode Activating Screen Saver mode • In live view, press to activate Screen Saver mode. The "SCAN" icon lights up and the monitor displays your images or a blank screen, depending on settings. NOTE: You cannot activate Screen Saver mode when the system is in Quad mode. To exit Quad mode, press •... -
Page 45: Pairing/Adding Cameras
Pairing/adding cameras Pairing/adding cameras If you have purchased additional cameras, it is highly IMPORTANT recommended to pair the cameras to the receiver before permanent installation. "Pairing" is an electronic handshake between wireless devices. Wireless devices and components need to be paired in order to communicate with each other. The camera(s) provided with the system have already been paired to the LCD receiver. -
Page 46: Settings
Settings • If using AV out, changing the system alarm volume will also affect the level of audio output. Settings Use the Settings menu to set the system time, change display options, and format the SD card. To increase/decrease alarm volume: Press , then press RIGHT/LEFT to... -
Page 47: Auto Mute
Settings To select the TV system: Format Memory Press , then press RIGHT/LEFT to select Settings and press OK. From the Settings menu, select Video Output and press OK. Select NTSC (North America) or PAL (UK/ Europe) and press OK to save. Press until all menus are closed. -
Page 48: Default Settings
Settings Default Settings Use the Default Settings menu to restore the system to factory settings. NOTE: Restore factory settings DOES NOT delete video files on the SD card, nor does it reset the date and time on the system. To restore default settings: Press , then press RIGHT/LEFT to select Settings and press OK. -
Page 49: Camera On/Off
Camera On/Off Camera On/Off Brightness Use the Camera On/Off menu to show/hide Use the Brightness menu to adjust the camera channels on the main display brightness level of video coming from your screen. For example, if you disable camera cameras. 3, it will not appear in any viewing mode. -
Page 50: Viewing Your Camera Remotely Using Skype
Viewing your camera remotely using Skype™ Viewing your camera remotely using Skype™ Connecting to your system through Skype is a convenient and free* method to view your camera from anywhere with an Internet connection. NOTE: When remotely connecting to your video monitor using Skype, audio monitoring and recording are disabled. -
Page 51: Connecting To Skype On A Pc
To install the camera drivers: Insert the software CD into your computer. An Autoplay window opens. Click Run Lorex.exe. Run Lorex.exe Click the USB Driver button, and then click USB Driver for PC. The driver appears on your desktop. -
Page 52: Step 2 Of 6: Connecting The Video Monitor To The Pc
In order to connect to your video monitor using Skype, you will need two accounts—one for the camera (e.g Lorex Camera) and one for yourself (e.g. Tom Smith). NOTE: The Skype illustrations and instructions below serve as a guideline only. Skype may change their website / product interface without prior notice. - Page 53 Viewing your camera remotely using Skype™ From the Skype Login window, click Create a new account. Click Create a new account Follow the on-screen instructions to create a new account. Upon login, the Setting up Skype wizard starts. Click Continue. Under Video, you will see an image from the camera. If no image appears, make sure the monitor is connected to the computer via the USB cable.
-
Page 54: Step 4 Of 6: Configuring Skype
Viewing your camera remotely using Skype™ Click Continue. In the next page, click Add later to not include a profile picture for the camera’s Skype account, or click Continue and follow the instructions to add a profile picture for the camera’s Skype account. -
Page 55: Step 5 Of 6: Send A Contact Request
Viewing your camera remotely using Skype™ Check Answer incoming calls automatically and Start my video automatically when I am in a call. Click Save. Save Step 5 of 6: Send a contact request Next, you have to send a friend request to your personal account (e.g. Tom Smith). Click the Add a contact button ( Add a contact Search for the name of your personal account (e.g. -
Page 56: Step 6 Of 6: Test The Connection
Viewing your camera remotely using Skype™ Click Send Request. Send contact request Step 6 of 6: Test the connection NOTE: This step requires you to log in to Skype from a different computer or compatible mobile device. Log in to your personal account (e.g. Tom Smith). A "new contact"... -
Page 57: Connecting To Skype On A Mac
Viewing your camera remotely using Skype™ From the contact list, right-click on your camera’s account name (e.g. Lorex Camera), and click Call. The video call begins automatically. Please allow around 15 to 25 seconds for the video connection to be established. -
Page 58: Step 3 Of 6: Creating A Skype Account
In order to connect to your video monitor using Skype, you will need two accounts—one for the camera (e.g. Lorex Camera) and one for yourself (e.g. Tom Smith). NOTE: The Skype illustrations and instructions below serve as a guideline only. Skype may change their website / product interface without prior notice. -
Page 59: Step 4 Of 6: Configuring Skype
Viewing your camera remotely using Skype™ Step 4 of 6: Configuring Skype Upon login, click Skype>Preferences. Select the Audio/Video tab. Calls tab Audio/Video tab Under Camera, select Wireless Monitoring System if it is not already selected. You will see live video from your camera if your device is connected. •... -
Page 60: Step 5 Of 6: Send A Contact Request
Viewing your camera remotely using Skype™ Select Answer automatically with video. Click Done. Select Answer automatically with video Select the Privacy tab. Under Allow calls from, select Contacts. This will prevent the device from accepting Skype calls from anyone who is not in the contact list for its account. Privacy tab Allow calls from Contacts... -
Page 61: Step 6 Of 6: Test The Connection
Viewing your camera remotely using Skype™ Under Add Contact, enter the Skype account name (e.g. Tom Smith) or email address for your personal Skype account. Click Find. Your personal Skype account should appear below the search bar. Enter the account name or email address for your personal Skype account Click Find... -
Page 62: If You Do Not Have A Skype Account
If you do not have a Skype account... Create your personal account first (e.g. Tom Smith), then create a second account for your camera (e.g. Lorex Camera). Create a personal account (i.e. Tom Smith): Go to www.skype.com, and click on Join Skype. -
Page 63: Changing The Camera View On Skype
Viewing your camera remotely using Skype™ My Skype Account Information "Camera" Skype account "Personal" Skype account (e.g. Lorex Camera) (e.g. Tom Smith) Skype Name: Skype Name: Password: Password: Email address used to register this Email address used to register this... -
Page 64: Viewing A Camera On Your Smart Phone Or Tablet
Viewing your camera remotely using Skype™ Viewing a camera on your smart phone or tablet You can remotely monitor your camera using Skype on supported smart phones or tablets. Supported apps & devices For the latest device compatibility list, visit www.lorextechnology.com. iPhone / iPad / iPod touch Skype •... -
Page 65: Viewing Your Camera On Ipad
Viewing your camera remotely using Skype™ Viewing your camera on iPad Download and install the Skype for iPad application from the App Store. NOTE: Skype for iPad is a free application, but it requires a valid iTunes account to download. Launch Skype and sign in using your personal account. -
Page 66: Technical Specifications
Technical specifications Technical specifications General Description Specification Transmission Frequency 2,400~2,483.5MHz Transmission Power 16dBm Unobstructed Effective 650ft / 200m (line of sight) Range Spread Spectrum FHSS Modulation Mode GFSK Operating Temperature 14 ~ 122° Fahrenheit / -10 ~ +50° Celsius Operating Humidity <... -
Page 67: Strengthening The Range Of The Wireless Signal
Strengthening the range of the wireless signal Strengthening the range of the wireless signal DISCLAIMER: Certain accessories are not available in all markets. There are several ways to boost your wireless signal as well as options to help you extend the range of the wireless signal. -
Page 68: Ghz Directional Wireless Panel Antenna
Strengthening the range of the wireless signal 2.4 GHZ Directional Wireless Panel Antenna Use the 2.4GHz Directional Wireless Panel Antenna (model #: ACCANTD9) to focus a wireless signal onto one specific camera in order to increase range of transmission (clear line-of-sight between the camera and the antenna is required). -
Page 69: Power Failure Indicator
Power failure indicator Power failure indicator A power failure may interrupt recording modes on the system. After power is restored, the following will occur: • The system will restart in Auto Sequence mode + Motion Recording - this ensures that some form of recording will be immediately active on the system. -
Page 70: Mounting The Lcd Receiver
Mounting the LCD receiver Mounting the LCD receiver The LCD Receiver can mounted to a wall or underneath a counter or cupboard. To mount the LCD receiver: Select a location to mount the receiver. The location should have a clear reception to your camera(s). -
Page 71: Troubleshooting
Troubleshooting Troubleshooting Problem Solution There is no picture from a • Check power to the camera Camera • Make sure that the cameras and receiver are both ON • Make sure that the camera is in range of the receiver The picture is dropping •... -
Page 72: Frequently Asked Questions
Frequently asked questions Frequently asked questions Q: How do I install USB drivers for remote viewing using Skype™? A: USB drivers for Skype™ remote viewing on PC and Mac are available on the CD or as a free download from www.lorextechnology.com. To install USB Driver for Windows: •... - Page 73 Frequently asked questions Q: My computer already has a webcam. How do I get Skype™ to use the video monitor instead? A: Follow the steps below to change the primary camera in Skype to the video monitor. To change the primary camera to the video monitor in Skype on PC: Click Tools>Options.
- Page 74 Frequently asked questions Under Camera, select Wireless Monitoring System. Audio/Video tab Select Wireless Monitoring System Close the Preferences window to return to the main Skype window. NOTE: You will have to reselect your webcam under Camera to use it for regular Skype video calls.
- Page 76 LW2730/LW2930 Series Version 1.0 www.lorextechnology.com Copyright © 2012 Lorex Technology Inc.
