Page 15: Introduction
Introduction The VG Series of Modero input and display, USB support for extended input devices, and panel programming via a mini-USB port. The new G4 graphics and Video/RGB technology is supported by the release of the latest TPDesign4 Touch Panel Design Program. These video-capable panels support several video formats: NTSC, SECAM, and PAL (Color Active (CA) panels don’t support video).
Page 16: Product Specifications (Nxd-1200Vg And Nxt-1200Vg)
- using accessories can increase the power draw requirements 256 MB on-board memory 2GB or greater (upgradeable to 4GB - see Other AMX Equipment). Note: AMX may increase Compactflash size at any time in response to market avail- ability. 10.80 lbs (4.90 kg) •...
Page 17 1200VG Specifications (Cont.) Supported Audio Sample Rates: Certifications: Supported Transport Protocols: Supported Audio Codecs: Supported Video Codecs: Front Panel Components: Rear Panel Components: Operating / Storage Environments: Included Accessories: VG-Series Modero Touch Panels 48000Hz, 44100Hz, 32000Hz, 24000Hz, 22050Hz, 16000Hz, 12000Hz, 11025Hz, and 8000Hz.
Page 18 Introduction 1200VG Specifications (Cont.) Other AMX Equipment: • CB-TP12 Conduit/Wallbox (FG031-10) • CC-USB (Type A) to Mini-B 5-Wire programming cable (FG10-5965) • Kensington Lock Bracket (FG2259-10) (optional only with NXTs) • MAX-CSE MAX Video Encoder (FG2178-70) • MB-TP12 Universal VESA Mounting Box (FG031-50) •...
Page 19: Product Specifications (Nxd-1500Vg And Nxt-1500Vg)
- using accessories can increase the power draw requirements 256 MB on-board memory 2GB or greater (upgradeable to 4GB - see Other AMX Equipment). Note: AMX may increase Compactflash size at any time in response to market availability. • NXD-1500VG: 13.45 lbs (6.10 kg) •...
Page 20 Introduction 1500VG Specifications (Cont.) Rear Panel Components: Operating / Storage Environments: Included Accessories: • RGB Connector: Made available only by using an NXA-RGB interface card installed within the touch panel. Used with Component/RGB signals • Audio/Video Connector: RJ-45 connector for communication of differential audio/ video signals •...
Page 21 1500VG Specifications (Cont.) Other AMX Equipment: VG-Series Modero Touch Panels • CB-TP15 Conduit/Wallbox (FG032-10) • CC-USB (Type A) to Mini-B 5-Wire programming cable (FG10-5965) • Kensington Lock Bracket (FG2259-10) (optional only with NXTs) • MAX-CSE MAX Video Encoder (FG2178-70) • MB-TP15 Universal VESA Mounting Box (FG032-50) •...
Page 22: Product Specifications (Nxd-1700Vg And Nxt-1700Vg)
- using accessories can increase the power draw requirements 256 MB on-board memory 2GB or greater (upgradeable to 4GB - see Other AMX Equipment). Note: AMX may increase Compactflash size at any time in response to market avail- ability. • NXD-1700VG: 18.20 lbs (8.26 kg) •...
Page 23 1700VG Specifications (Cont.) Rear Panel Components: Operating / Storage Environments: Included Accessories: VG-Series Modero Touch Panels • RGB Connector: Made available only by using an NXA-RGB interface card installed within the touch panel. Used with Component/RGB signals • Audio/Video Connector: RJ-45 connector for communication of differential audio/ video signals •...
Page 24 Introduction 1700VG Specifications (Cont.) Other AMX Equipment: • CB-TP17 Conduit/Wallbox (FG034-10) • CC-USB (Type A) to Mini-B 5-Wire programming cable (FG10-5965) • Kensington Lock Bracket (FG2259-10) (optional only with NXTs) • MAX-CSE MAX Video Encoder (FG2178-70) • MB-TP17 Universal VESA Mounting Box (FG033-50) •...
Page 25: Nxa-Rgb Supported Resolutions And Formats
NXA-RGB Supported Resolutions and Formats The following table lists all NXA-RGB Supported Resolutions and Formats: NXA-RGB Supported Resolutions and Formats Supported Format VGA Compatible signals Apple II MAC 12" EGA HP 12" DOS machines IBM 3472 SVGA Power PC 7 and Power PC 8 WXGA WXGA SXGA...
Page 26: Connecting And Using Usb Input Devices
Introduction Connecting and Using USB Input Devices These panels can have up to two USB-capable input devices connected for use both on its different firmware and TPD4 panel pages. These input devices can consist of a keyboard or mouse. USB-connected input devices are detected and recognized by the panel upon connection.
Page 27: Touch Panel Accessories
FIG. 2 NXA-AVB/RGB Breakout Box (front and rear views) The NXA-AVB/RGB Breakout Box is available either separately or as part of AMX’s exclusive RGB Kit (NXA-RGBKIT). The RGB Breakout Box (combined with the panel’s internal NXA-RGB interface card) allows the Modero to accept and display high-bandwidth and high-quality RGB and HDTV Component video signals.
Page 28: Product Specifications
Touch Panel Accessories Product Specifications NXA-AVB/RGB Specifications Dimensions (HWD): Power Consumption: Certifications: Features: Availability: Front Components: Rear Components: Included Accessories: • 1.52" x 5.54" x 4.93" (3.86 cm x 14.07 cm x 12.52 cm) • Width when attached to mounting ears: 6.65" (16.86 cm) •...
Page 29: Rgb Rj-45 Connection And Wiring Information
AVB/RGB Breakout Box to the VG-Series Modero panel. Standard CAT5 cable can be used for this connection with short cable runs under 50 feet (15.24 m). For cable runs over 50 feet (15.24 m), AMX recommends using the Belden Brilliance VideoTwist 7987. This Belden cable is not CAT5 compliant, but is designed to control skew between the red, green, and blue video signals.
Page 30: Using The Hd-15 High-Density Connector
Touch Panel Accessories Using the HD-15 high-density connector Connect the RGB/Comp source equipment HD-15 (male) connector to the RGB/COMPONENT HD-15 high- density connector (female) on the rear of the NXA-AVB/RGB Breakout Box. The following table below lists the HD-15 connector pinouts. HD-15 Connector Pinouts Signal Function...
Page 31: Wiring The Nxa-Avb/Rgb Connectors And Cables
The breakout box unit can be mounted on either a horizontal flat surface or into an equipment rack (by removing the front screws and attaching it to an optional AC-RK). The power supply being used on the NXA-AVB/RGB is dependant on the power requirements of the target touch panel.
Page 32: Wiring The Nxa-Avb/Rgb For Unbalanced Audio
Mic Out port. This signal can be fed as a Line Level In to either an amplifier or an AMX VOL card. Either a balanced (+, -, and GND) or unbalanced (+ and GND) audio signal can be connected to this output.
Page 33: Wiring The Nxa-Avb/Rgb For Balanced Audio
AUDIO IN MIC OUT OUT- OUT+ FIG. 5 Wiring the rear AUDIO IN and MIC OUT for use with Unbalanced Audio When using unbalanced audio for the AUDIO IN connector (FIG. 5), the "-" and the "GND" terminals should be connected together and then connected to the GND of the unbalance audio signal. When connecting to an unbalanced audio input from the MIC OUT connector (FIG.
Page 34: Wiring For Pass-Thru Computer Control
Touch Panel Accessories Pass-thru must be enabled to control devices through the NXA-RGB card when using USB-compatible control devices. Refer to the following commands to enable pass-thru on the RGB card: ^MPS on page 222 for Mouse pass-thru and ^KPS on page 222 for the keyboard pass-thru.
Page 35 RGB/Component In (Type-A) 12 VDC power supply FIG. 7 Pass-thru control wiring configuration Use an HD-15 video cable to create a connection between the computer’s video output connector and the HD-15 D-Sub RGB/VGA/Component connector on the rear of the NXA-AVB/RGB. This HD-15 D-Sub RGB/VGA/Component connector on the breakout box is used to route an RGB (computer) or Component (DVD/HDTV) signal to a target Modero panel (using the internal NXA-RGB card).
Page 36: Nxa-Mtc/Rgb Combo Table Top Cable (Ca2250-70)
NXA-MTC/RGB Specifications Dimensions (HWD): Connectors: Included Accessories: Other AMX Equipment: • Length: 10 feet (3.048 m) • Ethernet RJ-45 connector (White) routes Ethernet signals between the touch panel and the AVB/RGB Breakout Box. • Audio/Video RJ-45 connector (Black) routes differential audio/video signals between the touch panel and the box.
Page 37: Wiring And Connection Information
NXA-MTC/RGB Specifications (Cont.) Other AMX Equipment: Associated Touch Panels (where used) FG2251-61RGB FG2250-61RGB FG2253-61RGB FG2252-61RGB FG2256-61RGB FG2257-61RGB FG2255-11 Wiring and Connection Information FIG. 9 shows a top view of the finished cable. 6 inches To Touch Panel Connector 1 - used for Audio/Video (Black) Connector 2 - used for Ethernet (White) FIG.
Page 38: Installing Cat5 Suppression Ferrites
Touch Panel Accessories The following table provides the wiring information for each of the four (4) available connectors on each side of the NXA-MTC/RGB Tabletop Cable. Wire Table Wire Connector 1 White/Orange Orange/White White/Green Blue/White White/Blue Green/White White/Brown Brown/White Installing CAT5 Suppression Ferrites Before connecting the RJ-45 cables to the Modero Touch Panel, install the necessary number of CAT5 Suppression Ferrites (FIG.
Page 39: Nxa-Rgb Rgb/Vga Interface Card (Fg2260)
NXA-RGB RGB/VGA Interface Card (FG2260) The NXA-RGB (FIG. 12) is an RGB/VGA plug-in interface card that allows any of AMX’s VG-Series Modero Touch Panels to accept either RGB or HDTV Component signals directly from an external source when routed through an optional NXA-AVB/RGB Breakout Box. This card is field upgradeable and works in- tandem with the RGB connector on the front of an NXA-AVB/RGB Breakout Box.
Page 40: Product Specifications
Availability: Connector: Included Accessories: Other AMX Equipment: • Included within the RGB Kit (FGxxxx-xxRGB) is the following: • 0.88" x 3.50" x 6.50" (2.22 cm x 8.89 cm x 16.51 cm) • 0.85 lbs (0.39 kg) • 240 mA @ 12 VDC •...
Page 41: Supported Component/Vga Video Resolutions And Formats
Supported Component/VGA Video Resolutions and Formats NXA-RGB Supported Resolutions and Formats Resolutions VGA Compatible signals: 560 x 192 560 x 384 640 x 350 640 x 416 640 x 480 720 x 532 800 x 600 900 x 720 1024 x 768 1280 x 768 1280 x 800 1152 x 864...
Page 42: Rgb Rj-45 Connection And Wiring Information
AVB/RGB Breakout Box to the VG-Series Modero panel. Standard CAT5 cable can be used for this connection with short cable runs under 50 feet (15.24 m). For cable runs over 50 feet (15.24 m), AMX recommends using the Belden Brilliance VideoTwist 7987. This Belden cable is not CAT5 compliant, but is designed to control skew between the red, green, and blue video signals.
Page 43: Nxa-Pci80211G Wireless Card (Fg2255-04)
NXA-PCI80211G Wireless Card (FG2255-04) The 1200V-Series and VG-Series Modero touch panels can connect to an internal NXA-PCI80211G mini-PCI Wireless Card (FIG. 13) connected to two antennas (57-2250-10). FIG. 13 NXA-PCI80211G mini-PCI Wireless Card The NXA-PCI80211G card functions using a 2.4GHz bandwidth with a maximum data transfer rate of 54Mbps.
Page 44: Product Specifications
• Operates from 2.300-2.500 GHz • Operate at ISM frequency bands (2.4GHz) with 54Mbps data rate • Pre-configured to communicate with current AMX Wireless Access Points • Support for IEEE 802.11b and 802.11g • Wired Equivalent Privacy (WEP) 64-bit and 128-bit data encryption •...
Page 45 NXA-PCI80211G Specifications (Cont.) Receiver Sensitivity: Security: Availability: VG-Series Modero Touch Panels • Using 802.11b communication: 1 Mbps: -86 dBm (max) 2 Mbps: -84 dBm (max) 5.5 Mbps: -83 dBm (max) 11 Mbps: -80 dBm (max) • Using 802.11g communication: 1 Mbps: -86 dBm (max) 2 Mbps: -84 dBm (max) 5.5 Mbps: -83 dBm (max) 11 Mbps: -80 dBm (max)
Page 46: Installation And Upgrade Of The Internal Nxt Components
Touch Panel Accessories Installation and Upgrade of the Internal NXT Components Upgrading the components within each of the Table Top panels involves removing the outer housing (with speaker plate), removing and/or installing an existing component, and then placing the outer housing back onto the NXT panel, as described in the following sections.
Page 47: Step 2: Install The 802.11G Mini-Pci Wireless Card
Step 2: Install the 802.11g mini-PCI Wireless Card Discharge any static electricity from your body by touching a grounded metal object. Locate the mini-PCI card connector on the main board (FIG. 16 and FIG. 17). NXA-PCI80211G wireless card location I/O connector plate Eight Housing Screws...
Page 48: Step 3: Install The Nxa-Rgb Card Component (Nxt)
Touch Panel Accessories FIG. 18 Installation of the mini-PCI card connector on main board Locate the terminal ends of the antennas and apply downward pressure to "snap" them onto their gold- tipped counterparts on the mini-PCI card (FIG. 18). Carefully push down on each connector to verify it is securely joined to the card.
Page 49: Step 4: Install The Compact Flash Memory Card Upgrade
Step 4: Install the Compact Flash Memory Card upgrade Discharge any static electricity from your body by touching a grounded metal object and then locate the existing Compact Flash card (factory-shipped with 128 MB) on the main board (FIG. 20 for Table Top panels and FIG.
Page 50: Step 5: Close And Resecure The Nxt Panel Enclosure
Touch Panel Accessories To complete the upgrade process, close and resecure the panel enclosure using the procedures in the following step. Any new internal component upgrade is detected by the panel only after power is cycled. Step 5: Close and Resecure the NXT Panel Enclosure Obtain the new RGB I/O connector plate (similar to the original but containing the added RGB connector opening to the newly installed NXA-RGB) and slide it back into position.
Page 51: Step 2: Install The New 802.11G Mini-Pci Wireless Card (Nxd)
DO NOT REMOVE these panel securing screws FIG. 22 Location of the securing screws on an NXD panel Step 2: Install the new 802.11g mini-PCI Wireless card (NXD) Complete the procedures outlined within Step 2: Install the 802.11g mini-PCI Wireless Card section on page 33 and then continue with the following step.
Page 52: Step 5: Close And Resecure The Nxd Panel Enclosure
Touch Panel Accessories Four Pan-head Housing Screws NXA-PCI80211G wireless card location FIG. 23 Location of the Compact Flash card and I/O plate on NXD Step 5: Close and Resecure the NXD Panel Enclosure With the components securely installed, gently place the outer housing back onto the metallic panel casing (with the connector opening on the right-side of the panel) and align the four pan-head Housing Screw holes along the edges of the outer housing.
Page 53: Nxt-Bp Power Pack (Fg2255-10)
NXT-BP Power Pack (FG2255-10) The NXT-BP Power Pack (FIG. 25) is a rechargeable Lithium-Ion "smart" battery used to provide power to the NXT Modero panel through the NXA-BASE/B Battery Base. This battery incorporates an on-board battery life indicator. The NXT-BP battery can be charged through either the base (when connected to the Modero panel) or through an optional NXT-CHG Modero Power Station.
Page 54: Product Specifications
Features: Operating / Storage Environment: Other AMX Equipment: It is recommended to fully charge the batteries before their initial use. Checking the NXT-BP battery charge Press the Battery Life Indicator button (FIG. 27) once to illuminate the Battery Life LEDs and display the percent charge remaining on the battery (this indication lasts a few seconds).
Page 55 Battery Compartment pulls outwards Alignment pegs FIG. 28 NXA-BASE/B showing Panel Interface and connector locations Carefully place the Modero panel over the base alignment pegs (FIG. 28 and FIG. 29). The battery base cannot be "hot-swapped". A panel receiving power through a connected 12 VDC-compliant power supply cannot have a battery base installed onto the bottom of the panel while powered.
Page 56: Installing An Nxt-Bp Into The Nxa-Base/B
Apply a small amount of pressure to close the battery compartment until the compartment latches.  After a few seconds, the panel will turn On and the AMX logo will appear (indicating the panel is receiving power. Charging the NXT-BP batteries with the NXA-BASE/B Follow the procedures from the previous sub-section to attach the NXT touch panel to the NXA-BASE/B.
Page 57: Nxt-Chg Battery Charger Kit (Fg2255-50K)
Power Requirements: Weight: Features: Other AMX Equipment: The batteries are charged in the order they are inserted into the NXT-CHG. SLOT 1 of the NXT-CHG has the ability to completely discharge and recharge (recalibrate) a battery. Recalibration improves the reporting accuracy of the battery charge back to the Modero panel.
Page 58: Reading Nxt-Chg Led Indicator
Touch Panel Accessories Provide power to the unit by connecting the power cord (with plug) into a power outlet that meets the requirements outlined in the Specifications section for the NXT-CHG. Reading NXT-CHG LED Indicator FIG. 32 shows the components on the NXT-CHG Smart Battery Charger. Slot 1 (recalibration) Slot 1...
Page 59: Installation Procedures: 12" And 15" Panels
Inspect and confirm the contents of the shipment box to verify that you have all specified parts. Refer to the Specifications sections on page 2 and page 5 for more information about included accessories and other AMX equipment. Carefully remove the panel from the shipping box.
Page 60: Installing The Mp-Tp12/15 Back Box
Installation Procedures: 12" and 15" Panels Remove the I/O connector plate by using a grounded Phillips-head screwdriver to remove the two screws and slide the I/O connector plate away from the back box housing. Remove the four pan-head Housing Screws from the rear of the NXD unit (FIG. 33). These screws secure the back box to the internal panel casing.
Page 61: Cable Installation For The Mp-Tp12/15 Back Box
DO NOT REMOVE Twelve #6-32 securing screws Securing hole locations (3 on each side) Internal panel casing Four (pan-head) Housing Screws FIG. 34 Location of the attachment screws on the NXD back box and VESA housing Cable Installation for the MP-TP12/15 Back Box Connect the cable connectors (RJ-45, Ethernet, and any other audio/video wiring) to their respective locations along the side of the touch panel.
Page 62 Installation Procedures: 12" and 15" Panels Verify the Strain Relief Grommet is securely closed over the cables and the clip is facing the correct direction (upwards). The process of securing the strain relief grommet may require the use of pliers. Also verify the length and location of the inserted cables.
Page 63: Pre-Wall Installation Of The Conduit Boxes
Insert the four provided #8-32 screws through the VESA mount’s four holes and then into the pre-drilled holes on the rear plastic cover. When installing a VESA mount to the rear plastic cover, use only the AMX provided #8-32 screws.
Page 64: Installation Of The Nxd Touch Panel
Installation Procedures: 12" and 15" Panels Drywall/ sheetrock Mounting tabs for NXD panel should be flush with the outside of the sheetrock FIG. 38 Screw locations for conduit box attachment in a pre-wall installation Remove any necessary wiring knockouts from the (optional) conduit box (CB-TP12/15) (C in FIG.
Page 65 Mounting Tab Install the four #4-40 screws into the places indicated A - Faceplate (bezel) FIG. 39 Wall Mount panel installation configuration for pre-existing conduit/wallbox in a pre-wall construction Verify the incoming RJ-45, Ethernet, USB, and any other audio/video cables have been properly threaded through the wiring knockouts (from their terminal locations) on the conduit box.
Page 66: Installing The Nxd Into Drywall Using Expansion Clips
Installation Procedures: 12" and 15" Panels Reconnect the terminal RJ-45, Ethernet, USB, and any optional audio/video wiring to their respective locations (outside the conduit box) on either the NXA-AVB/RGB Breakout Box, Ethernet port, or NetLinx Master. Reconnect the terminal power connector on the 12 VDC-compliant power supply and apply power. Installing the NXD into drywall using Expansion Clips Expansion clips are mounted through the four oval holes located at the top and bottom of the panel.
Page 67 FIG. 41 NXD-1500VG 15-inch Wall Mount panel dimensions using expansion clips Thread the incoming RJ-45, Ethernet, USB, and any other audio/video wiring (from their terminal locations) through the cutout opening. Refer to the Wiring Guidelines for the 1200VG and 1500VG Panels section on page 59 for pinout descriptions.
Page 68 FIG. 42 Wall Mount panel (NXD) installation configuration for drywall surfaces The drywall clip set must be re-ordered from AMX if the drywall clip is bent accidentally during an installation or removed during a re-installation. Place the magnetic faceplate (A in FIG. 42) back onto the main NXD unit (B in FIG. 42). Make sure to align the Microphone, Light, and PIR Motion sensor locations to their respective openings on the front bezel/faceplate.
Page 69: Installing The Nxd Into A Flat Surface Using #4 Screws
Installing the NXD into a Flat Surface using #4 screws Mounting screws (#4, not included) are secured through circular holes located at the left and right sides of the NXD panel. The most important thing to remember when mounting the NXD is that the outer frame (Mounting Tabs) must be installed flush against the mounting surface.
Page 70 Installation Procedures: 12" and 15" Panels FIG. 44 NXD 15-inch Wall Mount panel dimensions using #4 mounting screws Thread the incoming RJ-45, Ethernet, USB, and any other audio/video wiring (from their terminal locations) through the cutout opening. Refer to the Wiring Guidelines for the 1200VG and 1500VG Panels section on page 59 for pinout descriptions.
Page 71: Installing An Nxd Into An (Optional) Rack Mount Kit (Nxa-Rk12 Or Nxa-Rk15)
Attachment is done Install the four (#4) mounting screws into the holes (screws not included) A - Faceplate (bezel) FIG. 45 Wall Mount panel installation configuration for flat/solid surfaces Reinstall the magnetic faceplate (A in FIG. 45) back onto the main NXD unit (B in FIG. 45). Make sure to align the Microphone, Light, and PIR Motion sensor locations to their respective openings on the front bezel/faceplate.
Page 72 Installation Procedures: 12" and 15" Panels Don’t disconnect the connectors from the touch panel. The unit must be installed with the necessary connectors before being inserted into the equipment rack. Insert the main 12-inch Modero unit into an NXA-RK12 (FIG. 46) or the 15-inch Modero into an NXA- RK15 (FIG.
Page 73: Wiring Guidelines For The 1200Vg And 1500Vg Panels
Place the magnet faceplate back onto the main NXD unit by gripping the faceplate and placing it on the housing with gentle force. Make sure to align the Microphone, Light, and PIR Motion sensor locations to their respective openings on the front bezel/faceplate. Reconnect the terminal RJ-45, Ethernet, USB, and any optional audio/video wiring to their respective locations on either the NXA-AVB/RGB Breakout Box, Ethernet port, or NetLinx Master.
Page 74: Audio/Video Port: Connections And Wiring
Installation Procedures: 12" and 15" Panels Audio/Video Port: Connections and Wiring The following table shows the signal and pinout/pairing information used on the RJ-45 Audio and Video connections. Audio/Video RJ-45 Pinout Information Wire Color Orange/White Orange Green/White Blue White/Blue Green White/Brown Brown 1 2 3 4 5 6 7 8...
Page 75 Installation Procedures: 12" and 15" Panels FIG. 50 diagrams the RJ-45 pinouts and signals for the Ethernet RJ-45 connector and cable. FIG. 50 RJ-45 wiring diagram VG-Series Modero Touch Panels...
Page 76 Installation Procedures: 12" and 15" Panels VG-Series Modero Touch Panels...
Page 77: Installation Procedures: 17" Panels
Unpacking the Panel Inspect and confirm the contents of the shipment box to verify that you have all specified parts. Refer to the Specifications section on page 8 for more information about included accessories and other AMX equipment. Carefully remove the panel from the shipping box.
Page 78: Installing The Mp-Tp17 Back Box
Installation Procedures: 17" Panels Remove the four pan-head Housing Screws from the rear of the NXD unit (FIG. 51). These screws secure the back box to the internal panel casing. DO NOT REMOVE these panel securing screws FIG. 51 Location of the attachment screws on the NXD back box DO NOT REMOVE THE FOUR PANEL SECURING SCREWS.
Page 79: Cable Installation For The Mp-Tp17 Back Box
DO NOT REMOVE #6-32 securing screws Securing hole locations (2 on each side) Internal panel casing Four (pan-head) Housing Screws FIG. 52 Location of the attachment screws on the NXD back box and VESA housing Cable Installation for the MP-TP17 Back Box Connect the cable connectors (RJ-45, Ethernet, and any other audio/video wiring) to their respective locations along the side of the touch panel.
Page 80 Insert the four provided #8-32 screws through the VESA mount’s four holes and then into the pre-drilled holes on the rear plastic cover. When installing a VESA mount to the rear plastic cover, use only the AMX provided #8-32 screws.
Page 81: Pre-Wall Installation Of The Cb-Tp17 Conduit Box
VG-Series Modero Touch Panels Installation Procedures: 17" Panels Rear plastic cover (rear view) Rim of the strain relief grommet should lie flush against enclosure CLIP FACING UP VESA mount connection location (USE ONLY AMX PROVIDED #8-32 screws) This gap allows the installation of...
Page 82 Installation Procedures: 17" Panels 17.07" (43.36 cm) support beam FIG. 55 CB-TP17 conduit box installation into a notched stud (showing before and after installation) The determining factor in the depth of the cut into the beam is the thickness of the drywall.
Page 83: Installation Of An Nxd-1700Vg
Stud Drywall/sheetrock Mounting tabs for NXD Wall Mount panel should be flush with the outside of the sheetrock FIG. 56 Screw locations for conduit box attachment in a pre-wall installation Installation of an NXD-1700VG The NXD-1700VG can be installed either directly into the (optional) CB-TP17 or other solid surface environment using the two different mounting options: drywall clips or solid surface screws.
Page 84 Installation Procedures: 17" Panels Four #8 flat-head Mounting Screws (not included) secure the NXD to the Conduit Box A - Faceplate (bezel) FIG. 57 Wall Mount panel installation configuration of a CB-TP17 in a pre-wall construction Verify the incoming RJ-45, Ethernet, and any other audio/video cables have been properly threaded through the wiring knockouts on the left of the conduit box.
Page 85: Installing The Nxd-1700Vg Into Drywall Using Expansion Clips
Offset vertical beam Refer to the SP2256-11 engineering drawing on www.amx.com for more detailed framing information FIG. 58 NXD-1700VG framing installation overview  With an existing wall in place, continue with steps 3 and 4 to notch one or both selected beams.
Page 86 Installation Procedures: 17" Panels INSTALLER: LEAVE A GAP BETWEEN THE SURFACE OF THE STUD AND THE BACK BOX MOUNTING RIDGE TO ACCOMMODATE THE DRYWALL/ SHEETROCK. This gap allows the installation of the drywall/sheetrock after the back box has been mounted onto the beams. Locate the edges of the two studs used in this installation.
Page 87 Install the four drywall clip sets (included) into these holes Mounting A - Faceplate (bezel) FIG. 60 Wall Mount panel (NXD) installation using expansion clips Follow the procedures outlined within Steps 1 - 5 on page 36 thru page 38 to carefully reinstall the LCD panel back into the back box housing.
Page 88: Installing The Nxd-1700Vg Into A Flat Surface Using #6 Screws
(on the right) and the connector-side of the unit pressed into the notched beam (on the left). Replacement drywall clip sets must be ordered from AMX. Tighten the drywall clip sets (screws and clips) until the Mounting Tabs are securely fastened and flush against the wall.
Page 89 Locate the edges of the two studs used in this installation. The location of the NXD is site dependant and could involve notching more than one beam. In this sample installation, the left beam is notched and the back box rests against the right beam.
Page 90 Installation Procedures: 17" Panels Install the four (#6) Mounting Screws into the holes (screws not included) A - Faceplate (bezel) FIG. 62 Wall Mount panel (NXD) installation using screws Carefully lay the separated LCD (from the main unit) onto a soft cloth resting on a level surface. This soft cloth prevents scratching during the rest of the installation procedure.
Page 91: Installing An Nxd Into An (Optional) Rack Mount Kit (Nxa-Rk17)
Don’t disconnect the connectors from the touch panel. The unit must be installed with the attached connectors before being inserted into the solid surface. Follow the procedures outlined within Steps 1 - 5 on page 36 thru page 38 to carefully reinstall the LCD panel back into the back box housing.
Page 92: Wiring Guidelines For The 1700Vg Panels
Installation Procedures: 17" Panels FIG. 63 NXD-1700VG Wall Mount panel installed into an NXA-RK17 Rack Mount Kit Secure the panel to the NXA-RK17 mount frame by first inserting and then tightening the four #4-40 screws. Insert the NXA-RK17 (with connected NXD unit) into the equipment rack, making sure to align the screw holes along the sides of the NXA-RK17 with the holes in the equipment rack.
Page 93: Preparing Captive Wires
Preparing captive wires You will need a wire stripper and flat-blade screwdriver to prepare and connect the captive wires. Never pre-tin wires for compression-type connections. Strip 0.25 inch (6.35 mm) of insulation off all wires. Insert each wire into the appropriate opening on the connector (according to the wiring diagrams and connector types described in this section).
Page 94: Audio/Video Port: Connections And Wiring
Installation Procedures: 17" Panels Audio/Video Port: Connections and Wiring The following table shows the signal and pinout/pairing information used on the RJ-45 Audio and Video connections. Audio/Video RJ-45 Pinout Information Wire Color Orange/White Orange Green/White Blue White/Blue Green White/Brown Brown 1 2 3 4 5 6 7 8 (female) RJ-45 connector - pin configurations...
Page 95 Installation Procedures: 17" Panels FIG. 66 diagrams the RJ-45 pinouts and signals for the Ethernet RJ-45 connector and cable. FIG. 66 RJ-45 wiring diagram VG-Series Modero Touch Panels...
Page 96 Installation Procedures: 17" Panels VG-Series Modero Touch Panels...
Page 97: Panel Calibration
When the panel is ready, the AMX Splash Screen is replaced by the Initial Panel Page (FIG. 67). AMX Splash Screen (appears during power-up) FIG.
Page 98: Testing Your Calibration
Panel Calibration FIG. 69 Touch Panel Calibration Screens After the "Calibration Successful." message appears, press anywhere on the screen to continue and return to the Setup page. If the calibration was improperly set and you cannot return to the Calibrate page (through the panel’s firmware);...
Page 99: Configuring Communication
G4 panel is powered-up. The panel will not detect a USB connection of this type until after the unit cycles power. Before commencing, verify you are using the latest NetLinx Master and Modero panel firmware. Verify you are using the latest versions of AMX’s NetLinx Studio and TPDesign4 programs. Modero Setup and System Connection Press the grey Front Setup Access button for 3 seconds to open the Setup page (FIG.
Page 100 Configuring Communication FIG. 71 Protected Setup page Press the on-screen Reboot button to restart the panel and incorporate any changes. Before continuing, open NetLinx Studio. This program assists in developing a System Number, Master IP/URL, and Master Port number. Refer to your NetLinx Master’s instruction manuals for more information.
Page 101: Configuring And Using Usb With A Virtual Master
Step 2: Confirming the Installation of the USB Driver on the PC The first time each AMX touch panel is connected to the PC it is detected as a new hardware device and the USBLAN driver becomes associated with it (panel specific). Each time thereafter the panel is "recognized" as a unique USBLAN device and the association to the driver is done in the background.
Page 102 Configuring Communication If the panel is already powered, continue with steps 3. The panel MUST be powered and configured for USB communication before connecting the mini-USB connector to the panel’s Program Port. Connect the terminal end of the 12 VDC-compliant power supply cable to the power connector on the rear/side of the touch panel and then apply power.
Page 103: Step 3: Confirm And View The Current Amx Usb Device Connections
 Within the Device Manager dialog, the AMX USBLAN device appears under Network Adapters (FIG. 75) and has a unique name such as AMX USB LAN LINK #2. The number changes depending on which recognized panel is currently connected. FIG. 75...
Page 104: Step 4: Using A Usb To Configure A Virtual Master (Using Netlinx Studio)
To remove the USB driver association from a previously connected touch panel, you must navigate back to the Device Manager, right-click on the panel’s USB driver (example AMX USB LAN LINK #2) and select Uninstall from the context menu and then OK.
Page 105: Step 5: Confirm And View The Current Amx Usb Device Connections
System sends out a request to the panel to respond and completes the communication (turning the System Connection icon green). Step 5: Confirm and View the current AMX USB device connections Use the CC-USB Type-A to Mini-B 5-wire programming cable (FG10-5965) to provide communication between the mini-USB Program port on the touch panel and the PC.
Page 106: Wireless Settings Page - Wireless Access Overview
Ethernet Communication from the panel can be direct (using an Ethernet cable) or indirect (through the optional NXA-PCI80211G AMX Wireless Card (FG2255-04) communicating to a Wireless Access Point such as the NXA-WAP200G). In determining the Ethernet method of communication, the panel will always default first to the direct Ethernet communication.
Page 107: Configuring A Wireless Connection
Configuring a Wireless Connection When working with a wireless card, the first step is to configure wireless communication parameters within the Wireless Settings page. This page only configures the card to communicate to a target WAP (such as the NXA-WAP200G), it is still necessary to tell the panel which Master it should be communicating with. This "pointing to a Master"...
Page 108: Wireless Communication Using A Static Ip Address
Configuring Communication Wireless Security Settings section on page 94 for detailed procedures to setup either a secure or insecure connection. Wireless communication using a Static IP Address Press the Protected Setup button (located on the lower-left of the panel page) to open the Protected Setup page and display an on-screen keypad.
Page 109 The card should be given the SSID used by the target WAP. If this field is left blank, the unit will attempt to connect to the first available WAP. By default, all WAP200Gs use AMX as their assigned SSID value.
Page 110: Configuring The Modero's Wireless Card For Secured Access To A Wap200G
The card should be given the SSID used by the target WAP. If this field is left blank, the unit will attempt to connect to the first available WAP. By default, all WAP200Gs use AMX as their assigned SSID value.
Page 111  As an example, if you use TECHPUBS as your SSID, you must match this word and the case within both the Network Name (SSID) field on the touch panel’s Network Name SSID field and on the WAP’s Basic Wireless Configuration page. Leave the Authentication field reading Open System (default).
Page 112: Configuring Multiple Wireless Moderos To Communicate To A Target Wap200G
Configuring Communication FIG. 82 WEP Key # Keyboard Write down this Current Key string value for later entry into your WAP’s WEP Key field (typically entered without colons) and into the communicating panel’s Current Key field (FIG. 80). If you are entering a Current Key generated either by your target WAP or another Modero panel, within the WEP Keys section, touch the Key # button to launch the WEP Key # keyboard (FIG.
Page 113: Configuring A Wired Ethernet Connection
Configuring a Wired Ethernet Connection It is necessary to tell the panel which Master it should be communicating with. This "pointing to a Master" is done via the System Settings page where you configure the IP Address, System Number and Username/Password information assigned to the target Master.
Page 114: Step 2: Choosing A Master Connection Mode Setting
Configuring Communication Press the IP Address field to open a Keyboard and enter the Static IP Address (provided by your System Administrator). Press Done after you are finished entering the IP information. Repeat the same process for the Subnet Mask and Gateway fields. Press the optional Host Name field to open the Keyboard and enter the Host Name information.
Page 115: Master Connection - Virtual Master Communication Over Ethernet
Verify the panel has been configured to communicate either through an Ethernet cable (connected from either the panel to a valid Ethernet Hub) or wireless to the Wireless Access Point. Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx Studio 2 > NetLinx Studio 2).
Page 116 Configuring Communication IP Addresses of computer (also obtained by using the Start > Run > cmd command) Enter this IP into the Master IP/URL field on the System Settings page FIG. 84 Assigning Communication Settings and TCP/IP Settings for a Virtual Master Click the Communications Settings button to open the Communications Settings dialog.
Page 117: Master Connection Section - Netlinx Master Ethernet Ip Address - Url Mode
By selecting URL, the System Number field becomes read-only (grey) because the panel pulls this value directly from the communicating target Master (virtual or not). A Virtual Master system value can be set within the active AMX software applications such as: NetLinx Studio, TPD4, or IREdit.
Page 118: Master Connection Section - Netlinx Master Ethernet Ip Address - Listen Mode
Configuring Communication Master Connection section - NetLinx Master Ethernet IP Address - Listen Mode In this mode, you must add the Modero panel IP Address into the URL List of the Master (using NetLinx Studio). This mode sets the Modero panel to "listen" for broadcasts from the Master (using the panel IP from its URL list).
Page 119: Using G4 Web Control To Interact With A G4 Panel
Refer to the G4 Web Control Settings section on page 153 for more detailed field information. Verify your NetLinx Master (ME260/64 or NI-Series) has been installed with the latest firmware KIT file from www.amx.com. Refer to your NetLinx Master Instruction Manual for more detailed information on the use of the new web-based NetLinx Security.
Page 120 Configuring Communication The Network Interface Select field is read-only and displays the method of communication to the web. Verify you have selected the proper interface connection as this field does not auto-detect the connection type being used (see below).  Wired is used when a direct Ethernet connection is being used for communication to the web.
Page 121: Using Your Netlinx Master To Control The G4 Panels
 If the Master has been previously configured for secured communication, click OK to accept the AMX SSL certificate (if SSL is enabled) and then enter a valid username and password into the fields within the Login dialog. Click OK to enter the information and proceed to the Master’s Manage WebControl Connections window.
Page 122 Configuring Communication FIG. 90 Web Control VNC installation and Password entry screens Click Yes from the Security Alert popup window to agree to the installation of the G4 WebControl application on your computer. This application contains the necessary Active X and VNC client applications necessary to properly view and control the panel pages from your computer.
Page 123: Upgrading Modero Firmware
Upgrading Modero Firmware Overview Before beginning the Upgrade process:  Setup and configure your NetLinx Master. Refer to your particular NetLinx Master instruction manual for detailed setup procedures.  Calibrate and prepare the communication pages on the Modero panel for use. Refer to the Panel Calibration section on page 83.
Page 124: Step 2: Prepare Netlinx Studio For Communication Via The Usb Port
Navigate back to the System Settings page. Step 2: Prepare NetLinx Studio for communication via the USB port Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx Studio 2 > NetLinx Studio 2).
Page 125: Step 3: Confirm And Upgrade The Firmware Via The Usb Port
If the panel firmware being used is not current, download the latest Kit file by first logging in to www.amx.com and then navigate to Tech Center > Firmware Files and from within the Modero section of the web page locate your Modero panel.
Page 126 Upgrading Modero Firmware FIG. 94 Using USB for a Virtual Master transfer Select the panel’s KIT file from the Files section. Enter the Device value associated with the panel and the System number associated with the Master (listed in the OnLine Tree tab of the Workspace window). The Port field is greyed-out. Click the Reboot Device checkbox.
Page 127: Upgrading The Modero Firmware Via An Ip Address
 Note the IP Address and Gateway information. Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx Studio 2 > NetLinx Studio 2). Select Settings > Master Communication Settings from the Main menu to open the Master Communication Settings dialog (FIG.
Page 128: Step 2: Prepare The Panel For Communication Via An Ip
By selecting URL, the System Number field becomes read-only (grey) because the panel pulls this value directly from the communicating target Master (virtual or not). A Virtual Master system value can be set within the active AMX software applications such as: NetLinx Studio, TPD4, or IREdit.
Page 129 If the panel firmware being used is not current, download the latest Kit file by first logging in to www.amx.com and then navigate to Tech Center > Firmware Files and from within the Modero section of the web page locate your Modero panel.
Page 130: Upgrading Accessory Devices Via An Ip Address
Upgrading Modero Firmware Enter the Device value associated with the panel and the System number associated with the Master (listed in the OnLine Tree tab of the Workspace window). The Port field is greyed-out. Click the Reboot Device checkbox. This causes the touch panel to reboot after the firmware update process is complete.
Page 131: Step 1: Prepare The Nxa-Base/B For Firmware Transfer
Modero panel value is 10001. The NXA-BASE/B will not appear on the system listing. Locate the latest Kit file by first logging in to www.amx.com and then navigate to Tech Center > Firmware Files and from within the Modero section of the web page locate the Modero Battery Base section of the website.
Page 132 Upgrading Modero Firmware Click on the desired Kit file link and after you’ve accepted the Licensing Agreement, verify you have downloaded the Modero Battery Base Kit file to a known location. From within Studio, select Tools > Firmware Transfers > Send to NetLinx Device from the Main menu to open the Send to NetLinx Device dialog (FIG.
Page 133: Upgrading The Nxa-Rgb And Nxa-Avb/Rgb Firmware
If the Base Version field displays 0.00, this means there was an error in the firmware download process. Re-install the base firmware and re-confirm that the new base version no longer reads 0.00. Upgrading the NXA-RGB and NXA-AVB/RGB Firmware Identify the Device number of the target panel being used for firmware routing to the accessories. Complete the instructions for configuring the NetLinx Master for IP communication found in the Step 1: Prepare the Master for communication via an IP section on page 113.
Page 134 Upgrading Modero Firmware VG-Series Modero Touch Panels...
Page 135: Firmware Pages And Descriptions
Firmware Pages and Descriptions Overview This section describes each firmware page and their specific functional elements. Setup Navigation Buttons The Setup Navigation Buttons (FIG. 102) appear on-screen when the Setup page is active. Modero Setup Navigation Buttons FIG. 102 Setup Navigation Buttons These Navigation Buttons are specific to these Modero panels and include the specific elements described in the following table: Setup Navigation Button Elements...
Page 136: Setup Page
Firmware Pages and Descriptions Setup Navigation Button Elements (Cont.) Audio: Video: Battery Base: Setup Page This page (FIG. 103) centers around basic Modero panel properties such as: Connection Status of the panel, Display Timeout, Inactivity Page Flip Time, Inactivity page file, and the Panel Brightness. FIG.
Page 137 Setup Page Elements (Cont.) Connection Status: Display/Panel Timeout: Inactivity Page Flip Timeout: Panel Brightness: VG-Series Modero Touch Panels Displays whether the panel is communicating externally, the encryption status of the communicating Master, what connection type is being used (Ethernet or USB), and what System the panel is a part of.
Page 138: Panel Information Page
Displays the model of the Modero panel being used. Displays the G4 firmware version being used by the panel. • Verify you have the latest version from www.amx.com. Displays the setup port information/value being used by the panel. Displays the high port (port count) value for the panel.
Page 139: Project Information Page
Panel Information Page Elements (Cont.) Power Up Pages: Start Up String: Wake Up String: Sleep String: File System: RAM: Panel Start Time Project Information Page The Project Information page displays the TPDesign4 (TPD4) project file properties currently loaded on the selected Modero panel (FIG. 105). Refer to the TPDesign4 Touch Panel Program instruction manual for more specific information on uploading TPDesign4 files to a panel.
Page 140: Time & Date Settings Page
Firmware Pages and Descriptions Project Information Page Elements (Cont.) Creation Date: Revision Date: Last Save Date: Blink Rate: Job Comments: Time & Date Settings Page The Time & Date Settings page (FIG. 106) allows you to alter/set the time and date information on the NetLinx Master.
Page 141 Time & Date Settings Page Elements (Cont.) Set Date/Time: Modero touch panels do not have an on-board clock. This page both receives and sets the time/date of the NetLinx Master. VG-Series Modero Touch Panels This section provides a user with both UP/DN arrow buttons to alter the Master’s calendar date and time.
Page 142: Audio Settings Page
Firmware Pages and Descriptions Audio Settings Page The Audio Settings page (FIG. 107) allows you to adjust the master volume parameters and default panel sounds on the panel. FIG. 107 Audio Settings page The elements of the Audio Settings page are described in the table below: Audio Settings Page Elements Back: Connection Status icon:...
Page 143: Supported Sampling Rates For Wav
Audio Settings Page Elements (Cont.) Mic Out Level: Supported sampling rates for WAV The following is a listing of supported sampling rates associated for WAV files played on these panels. Some WAV files currently played on Modero's may not work on these panels. The supported sampling rates for WAV files are: Supported WAV Sampling Rates •...
Page 144: Video Slide-Out Menu
Firmware Pages and Descriptions Video Slide-Out Menu Pressing the on-screen Video button causes an option menu to slide outwards from the Navigation buttons (FIG. 109). This option menu provides you with three choices: Video Adjustment, RGB Adjustment, and Streaming Adjustment. Each of these options corresponds to an on-board slot position where the related components reside (as seen below).
Page 145: Video - Rgb Settings Page
Video Settings Page Elements (Cont.) Video Settings: Status: Format: Brightness: Contrast: Saturation: Hue: Video - RGB Settings Page The RGB Settings page (FIG. 111) sets the RGB properties for the detected NXA-RGB card located within the target panel on Slot 2 where pass-thru occurs. FIG.
Page 146 Firmware Pages and Descriptions RGB Settings Page Elements (Cont.) Settings: Version: BOB Version: Status: Cable Variance: RGB Input Resolution: Phase: Geometry: H Position H Size V Position • The Default Settings button sets the RGB settings to their default values (indicated in this table).
Page 147 RGB Settings Page Elements (Cont.) All Brightness: Red Brightness Green Brightness Blue Brightness All Contrast: Red Contrast Green Contrast Blue Contrast VG-Series Modero Touch Panels Provides an on-screen RGB Brightness popup dialog that allows you to select from several brightness level adjustment settings.The bargraph only serves to give the user a visual indication of the individual brightness levels and launch the RGB Brightness popup dialog.
Page 148: Adjusting The Incoming Signal On The Rgb Settings Page
30 nano-seconds @ 200ft, and that can be more than enough to cause the image to appear "off" or blurry. For this reason, AMX recommends using the Belden Brilliance VideoTwist 7987 cable. Although this cable is not CAT5 compliant, it is designed to control skew between the red, green, and blue video signals.
Page 149 To adjust these properties: 1. Press the incoming signal area of the RGB Settings page to launch the Full Screen Edit mode, display the incoming image at full screen, and place a grey RGB Adjustments bar on the bottom of the screen.
Page 150 Firmware Pages and Descriptions 8. Use the UP/DN Contrast buttons (from the RGB Contrast popup dialog) to adjust the overall or individual Red, Green, and Blue contrast of the incoming image/video. Increasing the value can increase sharpness. This All Contrast bargraph gives a visual representation of the overall contrast level and cycles through an entire turn.
Page 151: Video - Streaming Settings Page
Video - Streaming Settings Page The Streaming Settings page (FIG. 110) adjusts the Video properties of the incoming MPEG video streaming from the external content server. Refer to the Displaying Stream Content section on page 169 for the procedures used to configure the TPD4 touch panel pages and media stream source (using MAX-CSE for example purposes).
Page 152 Firmware Pages and Descriptions Streaming Settings Page Elements (Cont.) Resolution Scaling Audio: Codec (Short for enCOder/ DECoder or COmpressor/ DECompressor) Sampling Rate This relates to the display size/resolution used by the incoming video stream. • Available resolutions: D1 (default) or SIF: •...
Page 153 Streaming Video Adjustment Page Elements (Cont.) Audio Channels Brightness: Contrast: Saturation: Hue: Refer to the Displaying Stream Content section on page 169 for the procedures used to configure the TPD4 touch panel pages and media stream source (using MAX-CSE for example purposes). VG-Series Modero Touch Panels The number of audio channels encoded within the incoming audio stream.
Page 154: Battery Base Page
Firmware Pages and Descriptions Battery Base Page This page (FIG. 115) allows you to alter/set the power warning preferences, monitor battery status information, and alter the display times for the battery warnings. The fields on this page are populated with information after the panel is connected to an optional NXA-BASE/B Battery Base containing up to two NXT-BP batteries.
Page 155 Battery Base Page Elements (Cont.) Very Low Battery Warning: The Very Low Battery Warning UP/DN buttons alter the time value Battery Status fields: Battery Power Brightness Limit: The term "quality" (in the context of a battery), refers to the current capacity relative to the batteries’...
Page 156: Protected Setup Navigation Buttons
Firmware Pages and Descriptions Protected Setup Navigation Buttons The Protected Setup Navigation Buttons (FIG. 116) appear on the left of the panel screen when the Protected Setup page is currently active. Modero Protected Setup Navigation Buttons FIG. 116 Protected Setup Navigation Buttons These Navigation Buttons are specific to these Modero panels and include the panel specific elements described in the following table: Protected Setup Navigation Button Elements...
Page 157: Protected Setup Page
Protected Setup Navigation Button Elements (Cont.) Tools: Wireless Settings: Protected Setup Page The Protected Setup page (FIG. 117) centers around the properties used by the panel to properly communicate with the NetLinx Master. Enter the factory default password (1988) into the password keypad to access this page.
Page 158 Firmware Pages and Descriptions Protected Setup Page Elements (Cont.) Keyboard Layout: Options: Displays the listing of supported international keyboard settings. The following list allows the end-user to specify which international keyboard is being connected to the Modero touch panel and then which characters should be reflected within the G4 Computer Control and TakeNote applications: - None (default), Spanish, Italian, French, German, Swiss, UK, and US Note: You must be using a standard 101 button keyboard to accurately...
Page 159: Security Settings
• The Remove User Pages button allows you remove all current TPD4 touch panel pages currently on the panel (including the pre-installed AMX Demo pages). - Pressing this button launches a Confirmation dialog which asks you to confirm your selection.
Page 160 The correct case must be followed with the username: "AMX" or "Amx" will not work. For more information on configuring AMX devices for a secure environment, please refer to the guide Security Profiles: Configuring AMX Devices For Installation Into a Secure Environment, available at www.amx.com.
Page 161: System Settings Page
System Settings Page The System Settings page (FIG. 119) sets the Secondary DNS Address information with its corresponding IP communication parameters, NetLinx Master communication settings, and reads the device number assigned to the Modero panel. FIG. 119 System Settings page showing default values (reads and assigns values to the panel and Master) The elements of the System Settings page are described in the table below: System Settings Page Elements Back:...
Page 162 • Choices are: Auto, 10 Half Duplex, 10 Full Duplex, 100 Half Duplex, or 100 Full Duplex. Displays a read-only field that is factory set by AMX for the built-in Ethernet interface. Sets the NetLinx Master to communicate with the panel via either USB or Ethernet.
Page 163: Sensor Settings Page
Sensor Settings Page The Sensor Settings page (FIG. 120) allows you to adjust the Light and Motion Sensor parameters on a Modero touch panel. FIG. 120 Sensor Settings page A light level value between the Minimum and Maximum DIM Mode values delivers an average light level.
Page 164: Using The Automated Brightness Control Feature (Dim Mode)
Firmware Pages and Descriptions Sensor Settings Page Elements (Cont.) Motion Sensor: Wake Panel On Motion Sense: Dim Mode Minimum Brightness: There is a relationship between the motion sensor and the panel sleep feature. If a panel is set to Sleep Mode, there is a time delay before the motion sensor is activated to detect motion.
Page 165 3. Open the Sensor Settings page (FIG. 120 on page 149) from the Protected Setup menu sections. 4. Move around the panel and block the direct or indirect light from the room fixtures with your body. Take note of the drop in the lighting level being detected by the panel in response to your movements.
Page 166: Calibration Page
Firmware Pages and Descriptions Calibration Page This page (FIG. 121) allows you to calibrate the input touch device (touch panel) using the pre-selected touch driver.  Press and hold the grey Front Setup Access button (below the Modero LCD) for 6 seconds to access the Calibration page.
Page 167: G4 Web Control Settings
G4 Web Control Settings The G4 Web Control Settings page (FIG. 122) centers around enabling and disabling both the display and control of your panel (via the web). An external PC running a VNC client (installed during the initial communication to the G4 panel) makes this possible. FIG.
Page 168 Firmware Pages and Descriptions G4 Web Control Page Elements (Cont.) Web Control Port Maximum Number of Connections Current Connection Count G4 Web Control Timeout: FIG. 123 Sample relationship between G4 Web Control and Mange WebControl Connections window Refer to the Using G4 Web Control to Interact with a G4 Panel section on page 105 for more detailed instructions on how to use the G4 Web Control Settings page with the new web-based NetLinx Security application.
Page 169: Other Settings Slide-Out Menu
Other Settings Slide-Out Menu Pressing the Other Settings button causes an option men to slide outwards from the Protected Setup buttons (FIG. 124). This option menu contains buttons to access the Cache Settings and Password Settings pages. Select any button to open its page. FIG.
Page 170 Firmware Pages and Descriptions The elements on this page include: Cache Settings Page Elements Back: Connection Status icon: Image Cache Settings: Flash Cache Size Flash/RAM Cache Expires Enable: Clear Cache: Image Cache Status: RAM Max Size RAM Current Size RAM Hit Rate Items in Cache (RAM) Flash Current Size Flash Hit Rate...
Page 171: Setting The Image Cache
Setting the image cache In the Protected Setup page: 1. Press the Cache button in the Protected Setup Navigation Buttons section. This opens the Cache Settings page. 2. Set the cache expiration in the field Flash/RAM Cache Expires. The Up and Down arrows increment through the available time frames.
Page 172: Password Settings Page
Firmware Pages and Descriptions Password Settings Page The Password Settings page (FIG. 126) centers around the properties used to assign passwords for the Modero panel pages. FIG. 126 Password Settings page The elements of the Password Settings page are described in the table below: Password Settings Page Elements Back: Connection Status icon:...
Page 173: Tools Slide-Out Menu
Tools Slide-out Menu Pressing the Tools button causes an option men to slide outwards from the Protected Setup buttons (FIG. 124). This option menu contains buttons to access the Panel Logs and Panel Statistics pages, as well as the Connection Utility popup window. Select any button to open its page. FIG.
Page 174: Checking The Panel Connection Logs
Firmware Pages and Descriptions Checking the Panel Connection Logs 1. Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools menu. 2. Within the Tools menu, press the Panel Logs button. All connection data is contained in the section Connection Logs.
Page 175: Panel Statistics Page Elements
Panel Statistics The options on the Panel Statistics page (FIG. 129) allow you to track the connection status for the panel. The Panel Statistics page tracks ICSP messages, Blink messages, Ethernet connection statistics, and Wireless connection statistics. FIG. 129 Panel Statistics page Features on this page include: Panel Statistics Page Elements Back:...
Page 176: Checking The Panel Statistics
Firmware Pages and Descriptions Panel Statistics Page Elements (Cont.) Clear Refresh Checking the Panel Statistics 1. Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools menu. 2. Within the Tools menu, press the Panel Statistics button. All connection statistics are contained on this page, e.g., Received, Processed, and Dropped ICSP Messages.
Page 177: Connection Utility
Connection Utility The options on the Connection Utility popup window (FIG. 130) allow you to utilize your panel as a site survey tool. While in this page, move around your wireless network coverage area and see if there are any weak points within the spaces between your WAPs. FIG.
Page 178: Using The Connection Utility
Firmware Pages and Descriptions Using the Connection Utility 1. Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools menu. 2. Within the Tools menu, press the Connection Utility button. This launches the Connection Utility popup.
Page 179: Wireless Settings Page
Wireless Settings Page The Wireless Settings page (FIG. 131) sets the communication information for the installed wireless interface card. This information includes its corresponding IP communication parameters, wireless communication settings, and read the device number assigned to the Modero panel. These panels can use the optional NXA-PCI80211G wireless card for wireless communication.
Page 180 Firmware Pages and Descriptions Wireless Settings Page Elements (Cont.) IP Settings (Cont.): Host Name Primary DNS Secondary DNS Domain MAC Address Access Point MAC Address: Wireless Settings: Network Name (SSID) Authentication Encryption Sets the host name of the panel. • PRIMARY DNS sets the address of the primary DNS server being used by the Modero panel for host name lookups.
Page 181 3rd-party Wireless Access Point, it comes back with 1a:2b:3c:4d:etc. Entering the same apple in the Passphrase generator of any Modero panel generates a different key: a1:b2:c3:d4:etc. Only AMX Modero panels generate the same Current Key by using a unique Passphrase key generation technology.
Page 182 Firmware Pages and Descriptions Wireless Settings Page Elements (Cont.) Wireless Settings (Cont.): Channel Link Quality Signal Strength Data Rate: Refer to both the Wireless Settings Page - Wireless Access Overview section on page 92 and Configuring a Wireless Connection section on page 93 for more detailed information of setting up the Modero panel for wireless network access.
Page 183: Displaying Stream Content
Displaying Stream Content Overview The current build of Modero firmware currently supports the display of both MPEG-2 and MPEG-4 media streams via the TPDesign touch panel pages. These incoming media signals can utilize either a UDP or RTP Transport protocol. For the purposes of these instructions, we will be setting up a Modero touch panel to display an incoming media stream sent from a MAX Video Encoder.
Page 184: Requirements For Receiving Streamed Content
Verify you have installed the latest version of TPDesign4 on your PC. Updates are available from the www.amx.com > Tech Center > Application Files > Touch Panel Design Tools section of the website. This application is needed to create the necessary page (popup page) used to display the incoming MPEG audio/video stream, identify the IP of the source MAX-CSE, and define the target audio/video ports on the panel.
Page 185: Setting Up A Modero Panel To Receive And Display A Stream
Setting up a Modero Panel to Receive and Display a Stream The MAX-CSE must first be prepared to stream to the target Modero panel prior to creating the necessary TPDesign4 panel pages (later be uploaded to the panel). Step 1: Obtaining the IP Address of the target panel Press the grey Front Setup Access button for 3 seconds to open the Setup page (FIG.
Page 186 Displaying Stream Content Click OK to enter the information and proceed to the Administration page which provides both a descriptive overview of the program stream and lists the currently used firmware. Determine the data throughput available on the network being used by the source encoder. This information determines which Encoder Profile and Transport Protocol will be used to encode the outgoing media stream.
Page 187: Step 3: Configuring The Max-Cse Audio/Video Inputs
It is recommended that this value not currently be used by another port on the target device. It is recommended that the following ports also not be used: 21, 22, 23, 80, 443, and 1319.  For the purposes of these procedures, we’ve chosen to use 5000 as the video Target Port. If using RTP as a Transport Protocol, enter a value into the Target Audio Port field.
Page 188: Step 4: Setup A Streaming Page Within Tpdesign4
Click the Apply button to save the encoding profiles to the MAX-CSE. Step 4: Setup a streaming page within TPDesign4 Launch TPDesign4 (default location is Start > Programs > AMX Control Disc > TPDesign4 > TPDesign4). Refer to the TPDesign4 Instruction Manual for more detailed instructions of these procedures.
Page 189 FIG. 137 Sample VG-Series TPD4 panel project Fill in the fields within the remaining New Project Wizard dialogs and click Next at the end of each dialog to proceed final dialog. Click the Finish button in the last dialog to close the wizard and proceed to the first generic page which is ready for you to start adding pages, popup pages, and buttons.
Page 190 Displaying Stream Content Click the States tab of the Button Properties Control window to show a list of all states associated with the selected button. Each state represented in the States tab is a collapsed folder containing the state properties for that particular state (On/Off/All). Double-click the All States + symbol to expand this folder (FIG.
Page 191: Step 5: Establishing The Final Connection Between The Two Units
Step 5: Establishing the final connection between the two units Start playing the media at its source (DVD, VCR, camera, etc.) While in the UI pages (log back in if not already connected), navigate to the Administration page by clicking on the Admin link from the left Navigation frame. Locate the Mode section of this page and click the Play button to begin streaming the incoming media content to the targeted Modero panel.
Page 192 Displaying Stream Content VG-Series Modero Touch Panels...
Page 193: Programming
Programming Overview You can program the touch panel, using the commands in this section, to perform a wide variety of operations using Send_Commands and variable text commands. A device must first be defined in the NetLinx programming language with values for the Device: Port: System (in all programming examples - Panel is used in place of these values and represents all Modero panels).
Page 194: Dpg
Programming Page Commands (Cont.) @DPG Syntax: Delete a specific popup page from Variable: specified popup group if it exists. Example: Deletes the popup page ’Popup1’ from the popup group ’Group1’. @PDR If the flag is set, the popup will return to its default location on show instead of its last drag location.
Page 195: Ppa
Page Commands (Cont.) @PPA If the page name is empty, the current page is used. Same as the ’Clear Page’ command in TPDesign4. Close all popups Syntax: on a specified page. "'@PPA-<page name>'" Variable: page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On. Example: SEND_COMMAND Panel,"'@PPA-Page1'"...
Page 196: Ppm
Programming Page Commands (Cont.) @PPM A Modal popup page, when active, only allows you to use the buttons and features on that popup page. All other buttons on the panel page are inactivated. Set the modality Syntax: of a specific popup page to Modal or Variable:...
Page 197: Psp
Page Commands (Cont.) @PSP Only 1 coordinate is ever needed for an effect; however, the command will specify both. This command sets the location at which the effect will begin at. Set the show Syntax: effect position. "'@PSP-<popup page name>;<x coordinate>,<y coordinate>'" Variable: popup page name = 1 - 50 ASCII characters.
Page 198: Programming Numbers
Programming Page Commands (Cont.) PPOG If the page name is empty, the current page is used (see example 2). Toggling refers to the activating/deactivating (On/Off) of a popup page. This command works in the same way Toggle a as the ’Toggle Popup’ command in TPDesign4. specific popup Syntax: page on either a...
Page 199 RGB Values for all 88 Basic Colors (Cont.) Index No. Name Dark Yellow Very Dark Yellow Very Light Lime Light Lime Lime Medium Lime Dark Lime Very Dark Lime Very Light Green Light Green Green Medium Green Dark Green Very Dark Green Very Light Mint Light Mint Mint...
Page 200: Font Styles And Id Numbers
The TPDesign4 Touch Panel Design program has pre-set border styles that are user selectable. TPD4 border styles can ONLY be changed by using the name. TPD4 Border Styles by Name Border styles None AMX Elite -L AMX Elite -M AMX Elite -S Bevel -L Bevel -M...
Page 201 TPD4 Border Styles by Name (Cont.) Border styles Bevel -S Circle 15 Circle 25 Circle 35 Circle 45 Circle 55 Circle 65 Circle 75 Circle 85 Circle 95 Circle 105 Circle 115 Circle 125 Circle 135 Circle 145 Circle 155 Circle 165 Circle 175 Circle 185...
Page 202: Button Commands
Programming TPD4 Border Styles by Name (Cont.) Border styles Menu Right Rounded 145 Menu Right Rounded 155 Menu Right Rounded 165 Menu Right Rounded 175 Menu Right Rounded 185 Menu Right Rounded 195 Menu Rounded Spacer - Vertical Menu Rounded Spacer - Horizontal Menu Top Rounded 55 Menu Top Rounded 65 "^"...
Page 203: Bat
"^" Button Commands (Cont.) ^BAT Syntax: "'^BAT-<vt addr range>,<button states range>,<new text>'" Append non-unicode text. Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
Page 204: Bcf
Programming "^" Button Commands (Cont.) ^BCF Only if the specified fill color is not the same as the current color. Note: Color can be assigned by color name (without spaces), number or R,G,B value Set the fill color to (RRGGBB or RRGGBBAA). the specified color.
Page 205: Bfb
"^" Button Commands (Cont.) ^BFB ONLY works on General-type buttons. Syntax: Set the feedback type of the button. "'^BFB-<vt addr range>,<feedback type>'" Variable: variable text address range = 1 - 4000. feedback type = (None, Channel, Invert, On (Always on), Momentary, and Blink). Example: SEND_COMMAND Panel,"'^BFB-500,Momentary'"...
Page 206: Bmc
Programming "^" Button Commands (Cont.) ^BMC Note that the source is a single button state. Each state must be copied as a separate command. The <codes> section represents what attributes will be copied. All codes are Button copy 2 char pairs that can be separated by comma, space, percent or just ran together. command.
Page 207 "^" Button Commands (Cont.) ^BMF (Cont.) ’%F’,<font 1-8,10,11,20-29,32-xx> = Set the font. See theDefault Font Styles and ID Numbers table on page 186. ’%F<font 01-08,10,11,20-29,32-xx>’ = Set the font. See theDefault Font Styles and ID Numbers table on page 186. ’%MI<mask image>’...
Page 208: Bmi
Programming "^" Button Commands (Cont.) ^BMF (Cont.) Example: Sets the button OFF state as well as the Border, Fill Color, Border Color, Text Color, and Bitmap. ^BMI Mask image is used to crop a borderless button to a non-square shape. This is typically used with a bitmap.
Page 209: Bnc
"^" Button Commands (Cont.) ^BNC Syntax: "'^BNC-<vt addr range>,<command value>'" Clear current TakeNote Variable: annotations. variable text address range = 1 - 4000. command value = (0= clear, 1= clear all). Example: SEND_COMMAND Panel,"'^BNC-973,0'" Clears the annotation of the TakeNote button with variable text 973. ^BNN Syntax: "'^BNN-<vt addr range>,<network name>'"...
Page 210: Bor
Sets the border by number (#10) to those buttons with the variable text range of 500-504 & 510-515. Sets the border by name (AMX Elite) to those buttons with the variable text range of 500-504 & 510-515. The border style is available through the TPDesign4 border-style drop-down list. Refer to theTPD4 Border Styles by Name table on page 186 for more information.
Page 211: Brd
"^" Button Commands (Cont.) ^BRD Only if the specified border is not the same as the current border. The border names are available through the TPDesign4 border-name drop-down list. Set the border of Syntax: a button state/ states. "'^BRD-<vt addr range>,<button states range>,<border name>'" Variable: variable text address range = 1 - 4000.
Page 212: Bvn
Programming "^" Button Commands (Cont.) ^BVN Syntax: Set the computer control remote Variables: host for the specified address. Example: Sets the remote host to '191.191.191.191' for the specific computer control button. ^BVP Syntax: Set the network password for the Variable: specified address.
Page 213: Dpf
"^" Button Commands (Cont.) ^DPF Syntax: "'^DFP-<vt addr range>,<actions>,<page name>'" Delete page flips from button if it Variable: already exists. variable text address range = 1 - 4000. actions = Stan[dardPage] - Flip to standard page Prev[iousPage] - Flip to previous page Show[Popup] - Show Popup page Hide[Popup] - Hide Popup page Togg[lePopup] - Toggle popup state...
Page 214: Giv
Programming "^" Button Commands (Cont.) ^GIV Parameters 1,2, and 3 will cause a bargraph or slider to be inverted regardless of orientation. Their effect will be as described for joysticks. Invert the Syntax: joystick axis and move the origin to another corner.
Page 215: Gsc
"^" Button Commands (Cont.) ^GSC A user can also assign the color by Name and R,G,B value (RRGGBB or RRGGBBAA). Syntax: Change the bargraph slider "'^GSC-<vt addr range>,<color value>'" color or joystick Variable: cursor color. variable text address range = 1 - 4000. color value = Refer to theRGB Values for all 88 Basic Colors table on page 184.
Page 216: Jsb
Programming "^" Button Commands (Cont.) ^JSB The alignment of 0 is followed by ',<left>,<top>'. The left and top coordinates are relative to the upper left corner of the button. Set bitmap/ Syntax: picture alignment using a numeric keypad layout for those buttons with Variable: a defined address...
Page 217: Jst
"^" Button Commands (Cont.) ^JST The alignment of 0 is followed by ',<left>,<top>'. The left and top coordinates are relative to the upper left corner of the button. Set text Syntax: alignment using a numeric keypad "'^JST-<vt addr range>,<button states range>,<new text layout for those alignment>'"...
Page 218: Skt
Programming "^" Button Commands (Cont.) ^SKT Syntax: Receive touch information on specified socket. Only socket values equal to or greater than 1024 are valid. The panel will open up a TCP listening socket on the port specified. User or 3rd party program can connect to the panel using this port/socket number and receive touch/release/move strings.
Page 219: Uni
"^" Button Commands (Cont.) ^TXT Sets Non-Unicode text. Syntax: Assign a text string to those "'^TXT-<vt addr range>,<button states range>,<new text>'" buttons with a Variable: defined address variable text address range = 1 - 4000. range. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
Page 220: Text Effect Names
Programming Text Effects (Cont.) • Soft Drop Shadow 7 • Soft Drop Shadow 8 • Medium Drop Shadow 1 • Medium Drop Shadow 2 • Medium Drop Shadow 3 • Medium Drop Shadow 4 • Medium Drop Shadow 5 • Medium Drop Shadow 6 •...
Page 221: Bbv
All custom events have the following 6 fields: Custom Event Fields Field Uint Flag slong value1 slong value2 slong value3 string text text length (string encode) These fields are populated differently for each query command. The text length (String Encode) field is not used in any command.
Page 222: Bcf
Programming Button Query Commands (Cont.) ?BCF Syntax: Get the current fill color. Variable: Example: Gets the button 'OFF state' fill color information. The result sent to the Master would be: ?BCT Syntax: Get the current text color. Variable: Example: Gets the button 'OFF state' text color information. The result sent to Master would be: "'?BCF-<vt addr range>,<button states range>'"...
Page 223: Bmp
Button Query Commands (Cont.) ?BMP Syntax: "'?BMP-<vt addr range>,<button states range>'" Get the current bitmap name. Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
Page 224: Brd
Programming Button Query Commands (Cont.) ?BRD Syntax: Get the current border name. Variable: Example: Gets the button 'OFF state' border information. The result sent to the Master would be: ?BRT Returned in Custom event. Value1=panel brightness value Show the Panel Brightness setting.
Page 225: Chr
Button Query Commands (Cont.) ?CHR Returned in Custom event. Value1=status(0=not charging,1=charging) Get the current charging status. Value2=current (combined) battery level ?DTO Returned in Custom event. Value1=display timeout value (in seconds) Show the display timeout. ?FBC Returned in Custom event. Get the frame buffer CRC.
Page 226 Programming Button Query Commands (Cont.) ?ICO Syntax: Get the current icon index. Variable: Example: Gets the button 'OFF state' icon index information. The result sent to the Master would be: ?JSB Syntax: Get the current bitmap Variable: justification. Example: Gets the button 'OFF state' bitmap justification information. The result sent to the Master would be: "'?ICO-<vt addr range>,<button states range>'"...
Page 227 Button Query Commands (Cont.) ?JSI Syntax: "'?JSI-<vt addr range>,<button states range>'" Get the current icon Variable: justification. variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
Page 228: Mut
Programming Button Query Commands (Cont.) ?MUT Returned in Custom event Value1=button state(0=off, 1=on) Get the Mute function. ?PIF Returned in Custom event. Text=<Filesystem Info>,<RAM Info>,<Panel Start Time> Get the current Panel Information. ?STA Returned in MULTIPLE Custom events (size of strings are limited per message). Values in Custom event will say for example, 1 of 5 messages and how many total bytes of xml Get the current data.
Page 229: Tec
Button Query Commands (Cont.) ?TEC Syntax: "'?TEC-<vt addr range>,<button states range>'" Get the current text effect color. Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
Page 230: Txt
Programming Button Query Commands (Cont.) ?TXT Syntax: Get the current text information. Variable: Example: Gets the button 'OFF state' text information. The result sent to the Master would be: ?VOL Returned in Custom event. Value1=master volume value Get the Master Volume.
Page 231: Abeep
Panel Runtime Operations Serial Commands are used in the AxcessX Terminal Emulator mode. These commands are case insensitive. Panel Runtime Operation Commands ABEEP Syntax: Output a single "'ABEEP'" beep even if beep Example: is Off. SEND COMMAND Panel,"'ABEEP'" Outputs a beep of duration 1 beep even if beep is Off. ADBEEP Syntax: Output a double...
Page 232: Akp
Programming Panel Runtime Operation Commands (Cont.) @AKP Keypad string is set to null on power up and is stored until power is lost. The Prompt Text is optional. Pop up the Syntax: keypad icon and initialize the text string to that Variables: specified.
Page 233: Ekp
Panel Runtime Operation Commands (Cont.) @EKP Pops up the keypad icon and initializes the text string to that specified. The Prompt Text is optional. Extend the Syntax: Keypad. "'@EKP-<initial text>;<prompt text>'" Variables: initial text = 1 - 50 ASCII characters. prompt text = 1 - 50 ASCII characters.
Page 234: Sou
Programming Panel Runtime Operation Commands (Cont.) @SOU Syntax: Play a sound file. Variables: Example: Plays the 'Music.wav' file. @TKP Pops up the keypad icon and initializes the text string to that specified. The Prompt Text is optional. Present a Syntax: telephone keypad.
Page 235: Cal
Input Commands These Send Commands are case insensitive. Input Commands ^CAL Syntax: Put panel in "'^CAL'" calibration mode. Example: SEND COMMAND Panel,"'^CAL'" Puts the panel in calibration mode. ^KPS Syntax: Set keyboard "'^KPS-<passs data>'" pass-thru via the Variables: RGB card. pass data: <blank/empty>...
Page 236: Slt
Programming Input Commands (Cont.) ^SLT These commands are directed at the video card subsystems. Slot commands contain a series of name/value pairs separated by commas. These commands are case insensitive. Send a command Syntax: to a given slot. Variables: Example: Enables Interlace on the incoming Composite video signal.
Page 237 Embedded Codes The following is a list of G4 compatible embedded codes: Embedded Codes Decimal numbers Hexidecimal values VG-Series Modero Touch Panels Virtual keystroke ($08) Backspace ($0D) Enter ($1B) ($80) CTRL key down ($81) ALT key down ($82) Shift key down ($83) ($84) ($85)
Page 238: Panel Setup Commands
Programming Panel Setup Commands These commands are case insensitive. Panel Setup Commands ^MUT Syntax: Set the panel mute state. Variable: Example: Sets the panel’s master volume to mute. @PWD @PWD sets the level 1 password only. Syntax: Set the page flip password.
Page 239: Dynamic Image Commands
Adds a new resource. • The resource name is ’New Image’ • %P (protocol) is an HTTP • %H (host name) is AMX.COM • %A (file path) is Lab/Test_file • %F (file name) is test.jpg. Note that the %%5F in the file path is actually encoded as %5F.
Page 240: Raf, ^Rmf - Embedded Codes
Programming Dynamic Image Commands (Cont.) ^RMF Modifies any and all resource parameters by sending embedded codes and data. Since the embedded codes are preceded by a '%' character, any '%' character contained Modify an in the URL must be escaped with a second '%' character (see example). existing resource.
Page 241: Escape Sequences
Channel port Level code Level port X Resolution of Current button Y Resolution of Current button Name of Button For instance, http://www.amx.com/img.asp?device=$DV would become http://www.amx.com/img.asp?device=10001. VG-Series Modero Touch Panels Description The number of seconds between refreshes in which the resource is downloaded again. Refreshing a resource causes the button displaying that resource to refresh also.
Page 242 Programming VG-Series Modero Touch Panels...
Page 243 Programming VG-Series Modero Touch Panels...
Page 244 Programming VG-Series Modero Touch Panels...
Page 245: Troubleshooting
• The panel can take a few minutes to detect the connection to the PC. • Make sure you have installed the latest USB driver for the AMX LAN. • Even if you have loaded the latest NetLinx Studio, it is recommended...
Page 246 • This is due to the graphics controller settings in the firmware. • Update firmware to the latest v2.XX. firmware. • Visit the www.amx.com > Tech Center > Downloadable Files > Firmware Files > Modero panels. Then Download the KIT file to your computer.
Page 247 • The NXA-BASE/B Battery base should be updated with the latest firmware (part of the Modero firmware KIT file) from www.amx.com. • The base can only charge batteries while the NXT panel is in Sleep Mode. If the panel parameters are set to their highest values, the priority for the power draw becomes the active panel functions and no power is routed to the base for charging.
Page 248 "graphics hierarchy" errors, etc.… indicating problems with the Compact Flash. • Panel will not boot, or gets stuck on "AMX" splash screen. • Other problems also started after downloading to a new panel or a panel with a TPD4 file that takes up a considerable amount of the available Compact Flash.
Page 249: Appendix
Appendix Text Formatting Codes for Bargraphs/Joysticks Text formatting codes for bargraphs provide a mechanism to allow a portion of a bargraphs text to be dynamically provided information about the current status of the level (multistate and traditional). These codes would be entered into the text field along with any other text. The following is a code list used for bargraphs: Bargraph Text Code Inputs Code...
Page 250: Text Area Input Masking
Appendix Text Area Input Masking Text Area Input Masking can be used to limit the allowed/correct characters that are entered into a text area. For example, in working with a zip code, a user could limit the entry to a max length of only 5 characters but, with input masking, you could limit them to 5 mandatory numerical digits and 4 optional numerical digits.
Page 251: Input Mask Ranges
Input mask ranges These ranges allow a user to specify the minimum and maximum numeric value for a field. Only one range is allowed per field. Using a range implies a numeric entry ONLY. Input Mask Ranges Character Meaning Start range End range Range Separator An example from the above table:...
Page 252: Input Mask Output Examples
This URL indicates that the protocol in use is http (HyperText Transport Protocol) and that the information resides on a host machine named www.amx.com. The image on that host machine is given an assignment (by the program) name of company-info-home.asp (Active Server Page).
Page 253: Special Escape Sequences
However; the system will parse the URL looking for special escape codes. When it finds an escape code it replaces that code with a particular piece of panel, button, or state information. For example, "http://www.amx.com/img.asp?device=$DV" would become "http://www.amx.com/ img.asp?device=10001". Other used escape sequences include:...
Page 254 Appendix VG-Series Modero Touch Panels...
Page 255 Appendix 7" Modero Widescreen Touch Panels...
Page 256 It’s Your World - Take Control™ 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...

This manual is also suitable for:

Modero nxd/nxt-1500vg Modero nxd/nxt-1700vg Modero nxd-1200vg Modero nxt-1200vg Modero nxd-1500vg Modero nxt-1500vg ... Show all

AMX Modero NXD/NXT-1200VG Operation/Reference Manual

Introduction

Multimedia Streaming Video Touch Panels (VG-Series)

VG-Series Modero Connectors

Connecting and Using USB Input Devices

Cleaning the Touch Overlay

Touch Panel Accessories

Overview

NXA-AVB/RGB Breakout Box (FG2254-11)

NXA-MTC/RGB Combo Table Top Cable (CA2250-70)

NXA-RGB RGB/VGA Interface Card (FG2260)

NXA-CFTP Compact Flash (FG2116-22)

NXA-PCI80211G Wireless Card (FG2255-04)

Installation and Upgrade of the Internal NXT Components

Installation and Upgrade of the Internal NXD Components

NXT-BP Power Pack (FG2255-10)

NXA-BASE/B Battery Base Kit (FG2255K)

NXT-CHG Battery Charger Kit (FG2255-50K)

Installation Procedures: 12" and 15" Panels

Overview

Unpacking the Panel

Installing Internal Components

Upgrading to the MB-TP12/MB-TP15 VESA Mounting Kit

Pre-Wall Installation of the Conduit Boxes

Installation of the NXD Touch Panel

Wiring Guidelines for the 1200VG and 1500VG Panels

Ethernet/Rj-45 Port: Connections and Wiring

Audio/Video Port: Connections and Wiring

Installation Procedures: 17" Panels

Overview

Unpacking the Panel

Installing the Internal Components

Upgrading the Back Box with the MB-TP17 VESA Housing

Pre-Wall Installation of the CB-TP17 Conduit Box

Installation of an NXD-1700VG

Wiring Guidelines for the 1700VG Panels

Audio/Video Port: Connections and Wiring

Ethernet/Rj-45 Port: Connections and Wiring

Panel Calibration

Overview

Calibrating the Modero Panel

Configuring Communication

Overview

Modero Setup and System Connection

Configuring and Using USB with a Virtual Master

Wireless Settings Page - Wireless Access Overview

Configuring a Wireless Connection

Step 1: Configuring the Panel's Wireless IP Settings

Step 2: Configuring the Card's Wireless Security Settings

Configuring a Wired Ethernet Connection

Step 1: Configuring the Panel's Wired IP Settings

Step 2: Choosing a Master Connection Mode Setting

Step 3: Configuring the Ethernet Connection Type

Using G4 Web Control to Interact with a G4 Panel

Using Your Netlinx Master to Control the G4 Panels

Upgrading Modero Firmware

Overview

Upgrading the Modero Firmware Via the USB Port

Upgrading the Modero Firmware Via an IP Address

Upgrading Accessory Devices Via an IP Address

Upgrading the NXA-RGB and NXA-AVB/RGB Firmware

Firmware Pages and Descriptions

Overview

Setup Navigation Buttons

Setup Page

Protected Setup Navigation Buttons

Protected Setup Page

Displaying Stream Content

Overview

Requirements for Receiving Streamed Content

Setting up a Modero Panel to Receive and Display a Stream

Programming

Overview

Button Assignments

Page Commands

Programming Numbers

Button Commands

Bln

^Bmc

Bmc
