TECHNICAL SPECIFICATIONS
MONITOR
Picture Tube
Horizontal resolution
Camera Capable
Camera Input
Control
Input signal
Power Source
Power Consumption
Operating Temperature
Color
STANDARD CAMERA
Image Device
Resolution
Shutter control
Power requirement
Operating Temperature 14°F – 122°F (-10°C to 50°C)
Weight:
Dimensions:
Housings:
Because our product are subject to continuous improvement, SVC reserves the right to modify product design and specifications without
notice and without incurring any obligation. E&OE
12" B&W
600 lines
Up to four (4 DIN)
4 6 pin DIN
power, seq, Talk, VCR, brightness,
Contrast,volume,time,alarm set.
1 V p-p at 75 ohms terminated
Multi-voltage (AC100V – 240 V)
40 watts
32ºF 104°F (0° C – 40°C)
White – Metal cabinet
1/3" CCD image sensor
380 TV Lines
Auto 1/60 - 1/100,000
Powered from monitor via cable
12 oz (340 Grams)
2.76" (W) x 3.35"(D) x 2.90"(H)
(7.0cm (W) x 8.5cm (D) x 5.3cm(H))
White
-13-
