AUI Pin Assignments

Note: Voltage Plus (VP) and Voltage Common (Vc) use a
single twisted-pair in the AUI cable.
Pin
3
10
11
5
12
4
8
2
9
1
6
13
14
Shell

AUI Pin Assignments

Circuit
DO-A
DO-B
DO-S
DI-A
DI-B
DI-S
CO-S
CI-A
CI-B
CI-S
Vc
VP
VS
PG
Signal Name
Data Out Circuit A
Data Out Circuit B
Data Out Circuit Shield
Data In Circuit A
Data In Circuit B
Data In Circuit Shield
Control Out Circuit Shield
Control In Circuit A
Control In Circuit B
Control In Circuit Shield
Voltage Common
Voltage Plus
Voltage Shield
Protective Ground
(Conductive Shell)
