Page 2: Table Of Contents
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Table of Contents Introduction ............................ 5 Using the Console CLI ........................7 Command Syntax ......................... 10 Basic Switch Commands ......................13 Modify Banner and Prompt Commands ..................28 Switch Port Commands .......................
Page 3 Debug Software Commands ..................... 520 DHCPv6 Client Commands ....................... 525 DHCPv6 Relay Commands ......................527 D-Link Unidirectional Link Detection (DULD) Commands ............533 Ethernet Ring Protection Switching (ERPS) Commands ............535 IPv6 Neighbor Discover Commands ..................545 IPv6 Route Commands ......................549...
Page 4 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Local Route Commands ......................554 MSTP Debug Enhancement Commands .................. 556 Ping Commands ......................... 560 Show Technical Support Commands ..................562 Trace Route Commands ......................565 VLAN Counter Commands ......................567 Power Saving Commands ......................
Page 5: Introduction
® The DES-3528/DES-3552 Series Layer 2 stackable Fast Ethernet Switch Series are members of the D-Link xStack family. Ranging from 10/100Mbps edge Switches to core gigabit Switches, the xStack Switch family has been future- proof designed to provide a stacking architecture with fault tolerance, flexibility, port density, robust security and maximum throughput with a user-friendly management interface for the networking professional.
Page 6 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Boot Procedure V1.00.B008 ------------------------------------------------------------------------------- Power On Self Test ........100 % MAC Address : 00-22-B0-10-8A-00 H/W Version : A2 Please wait, loading V3.00.012 Runtime image ..... 100 % UART init ..........
Page 7: Using The Console Cli
DES-3528 Fast Ethernet Switch Command Line Interface Firmware: Build 3.00.012 Copyright(C) 2013 D-Link Corporation. All rights reserved. UserName: Commands are entered at the command prompt, DES-3528:admin# .. There are a number of helpful features included in the CLI. Entering the ? command will display a list of all of the top- level commands.
Page 8 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide clear igmp_snooping data_driven_group clear igmp_snooping statistics counter clear jwac auth_state clear log clear mac_based_access_control auth_state clear mld_snooping data_driven_group CTRL+C ESC q Quit SPACE n Next Page ENTER Next Entry When users enter a command without its required parameters, the CLI will prompt users with a Next possible completions: message.
Page 9 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# The top-level commands consist of commands such as show or config. Most of these commands require one or more parameters to narrow the top-level command. This is equivalent to show what? or config what? Where the what? is the next parameter.
Page 10: Command Syntax
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Syntax The following symbols are used to describe how command entries are made and values and arguments are specified in this manual. The online help contained in the CLI and available through the console interface uses the same syntax. NOTE: All commands are case-sensitive.
Page 11 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide {braces} Purpose Encloses an optional value or set of optional arguments. Syntax reset {[config | system]} force_agree Description In the above syntax example, users have the option to specify config or system. It is not necessary to specify either optional value, however the effect of the system reset is dependent on which, if any, value is specified.
Page 12 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Multiple Page Display Control Keys Space Displays the next page. CTRL+c Stops the display of remaining pages when multiple pages are to be displayed. Stops the display of remaining pages when multiple pages are to be displayed. Displays the next page.
Page 13: Basic Switch Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Basic Switch Commands The basic Switch commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create account [admin | operator | power_user | user] <username 15>...
Page 14 Enter the new password again for confirmation:**** Success. DES-3528:admin# NOTICE: In case of lost passwords or password corruption, please refer to the D-Link website and the White Paper entitled “Password Recovery Procedure”, which will guide you through the steps necessary to resolve this issue.
Page 15 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config account Purpose Used to configure user accounts Syntax config account <username> {encrypt [plain_text | sha_1] <password>} Description When the password information is not specified in the command, the system will prompt the user to input the password interactively.
Page 16 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete account Purpose Used to delete an existing user account. Syntax delete account <username> Description This command is used to delete an existing entry. <username> − Name of the user who will be deleted. Parameters Restrictions Only Administrator-level users can issue this command.
Page 17 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable password encryption Purpose Used to disable password encryption. Syntax disable password encryption Description The user account configuration information will be stored in the configuration file, and can be applied to the system later.
Page 18 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show switch Purpose Used to display general information about the Switch. Syntax show switch Description This command displays information about the Switch. Parameters None. Restrictions None. Example usage: To display the Switch’s information: DES-3528:admin# show switch Command: show switch...
Page 19 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show serial_port Purpose Used to display the current serial port settings. Syntax show serial_port Description This command displays the current serial port settings. Parameters None. Restrictions None Example usage: To display the serial port setting: DES-3528:admin#show serial_port...
Page 20 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable clipaging Purpose Used to pause the scrolling of the console screen when a command displays more than one page. Syntax enable clipaging Description This command is used when issuing a command which causes the console screen to rapidly scroll through several pages.
Page 21 Command: telnet 172.18.168.12 tcp_port 50 Connecting to server,please wait..DES-3528 Gigabit Ethernet Switch Command Line Interface Firmware: Build 3.00.012 Copyright(C) 2013 D-Link Corporation. All rights reserved. UserName: PassWord: enable telnet Purpose Used to enable communication with and management of the Switch using the Telnet protocol.
Page 22 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable web Purpose Used to enable the HTTP-based management software on the Switch. Syntax enable web <tcp_port_number 1-65535> Description This command is used to enable the Web-based management software on the Switch. The user can specify the TCP port number the Switch will use to listen for Telnet requests.
Page 23 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# save Command: save Saving all configurations to NV-RAM... Done. DES-3528:admin# reboot Purpose Used to restart the Switch. Syntax Reboot {force_agree} Description This command is used to restart the Switch. force_agree −...
Page 24 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide login Purpose Used to log in a user to the Switch’s console. Syntax login Description This command is used to initiate the login procedure. The user will be prompted for a Username and Password.
Page 25 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config terminal width Purpose The command is used to set current terminal width. Syntax config terminal width [default | <value 80-200>] Description The usage is described as below: 1.
Page 26 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config temperature Purpose This command is used to configure the warning trap or log state of the system internal temperature. Syntax config temperature [trap | log] state [enable | disable] Description This command is used to configure the warning trap or log state of the system internal temperature.
Page 27 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#config temperature threshold high 80 Command: config temperature threshold high 80 Success. DES-3528:admin# show environment Purpose This command is used to display the device’s internal and external power and internal temperature status.
Page 28: Modify Banner And Prompt Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Modify Banner and Prompt Commands Administrator level users can modify the login banner (greeting message) and command prompt by using the commands described below. Command Parameters config command_prompt [<string 16>...
Page 29 To modify the banner: DES-3528:admin#config greeting_message Command: config greeting_message Greeting Messages Editor ================================================================================ DES-3528 Fast Ethernet Switch Command Line Interface Firmware: Build 3.00.012 Copyright(C) 2013 D-Link Corporation. All rights reserved. ================================================================================ <Function Key> <Control Key> Ctrl+C Quit without save left/right/ Ctrl+W...
Page 30 Only Administrator and Operator-level users can issue this command. Example usage: To view the currently configured greeting message: DES-3528:admin#show greeting_message Command: show greeting_message ================================================================================ DES-3528 Fast Ethernet Switch Command Line Interface Firmware: Build 3.00.012 Copyright(C) 2013 D-Link Corporation. All rights reserved. ================================================================================ DES-3528:admin#...
Page 31: Switch Port Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Switch Port Commands The Switch port commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config ports [<portlist>...
Page 32 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Example usage: To configure the speed of ports 1-3 of unit 1 to be 10 Mbps, full duplex, learning enabled, state enabled and flow control enabled: DES-3528:admin# config ports 1-3 speed 10_full learning enable state enable flow_control enable Command: config ports 1-3 speed 10_full learning enable state enable flow_control...
Page 33 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Port State/ Settings Connection Address MDIX Speed/Duplex/FlowCtrl Speed/Duplex/FlowCtrl Learning ------- -------- --------------------- ---------------------- --------- Enabled Auto/Disabled Link Down Enabled Auto Description: Enabled Auto/Disabled Link Down Enabled Auto Description: Enabled Auto/Disabled...
Page 34 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable jumbo_frame Purpose Used to enable the jumbo frame function on the Switch. Syntax enable jumbo_frame Description This command will allow ethernet frames larger than 1536 bytes to be processed by the Switch.
Page 35: Port Security Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Port Security Commands The Switch’s port security commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config port_security ports [<portlist>...
Page 36 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command: config port_security ports 1-5 admin_state enable max_learning_addr 5 lock_address_mode deleteonreset Success. DES-3528:admin# delete port_security_entry Purpose Used to delete a port security entry by MAC address, port number and VLAN ID. Syntax delete port_security_entry [vlan <vlan_name 32>...
Page 37 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show port_security Purpose Used to display the current port security configuration. Syntax show port_security {ports [<portlist> | all] {[vlan <vlan_name 32> | vlanid <vidlist>]}} Description This command is used to display port security information of the Switch’s ports. The information displayed includes port security trap/log state, admin state, maximum number of learning address and lock mode.
Page 38 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable port_security trap_log Purpose Used to disable the trap log for port security. Syntax disable port_security trap_log Description This command, along with the enable port_security trap_log, will enable and disable the sending of log messages to the Switch’s log and SNMP agent when the port security of the Switch has been triggered.
Page 39 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config port_security vlan Purpose This command sets the maximum number of port security entries that can be learned on a specific VLAN. Syntax config port_security vlan [<vlan_name 32> | vlanid <vidlist>] max_learning_addr [<max_lock_no 0-16384>...
Page 40: Stacking Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Stacking Commands The stacking configuration commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config box_priority current_box_id <value 1-8>...
Page 41 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show stack_information Purpose Used to display the stack information table. Syntax show stack_information Description This command display stack information. Parameters None. Restrictions Only Administrator and Operator and Power-User-level users can issue this command. Usage example: To display stack information: DES-3528:admin#...
Page 42 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show stacking_mode Purpose Used to view the current stacking mode. Syntax show stacking_mode Description This command will display whether the current stacking mode is enabled or disabled. Parameters None.
Page 43 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config stacking force_master_role state enable Command: config stacking force_master_role state enable Success. DES-3528:admin#...
Page 44: Network Management (Snmp) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Network Management (SNMP) Commands The Switch supports the Simple Network Management Protocol (SNMP) versions 1, 2c, and 3. Users can specify which version of the SNMP users want to use to monitor and control the Switch. The three versions of SNMP vary in the level of security provided between the management station and the network device.
Page 45 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters create trusted_host [<ipaddr> | <ipv6addr> | network <network_address> | ipv6_prefix <ipv6networkaddr>] {snmp | telnet | ssh | http | https | ping} config trusted_host [<ipaddr> | <ipv6addr> | network <network_address> | ipv6_prefix <ipv6networkaddr>] [add | delete] {snmp | telnet | ssh | http | https | ping | all} delete trusted_host [ipaddr <ipaddr>...
Page 46 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create snmp user Purpose Used to create a new SNMP user and adds the user to an SNMP group that is also created by this command. Syntax create snmp user <user_name 32>...
Page 47 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# create snmp user dlink default encrypted by_password auth md5 canadian priv none Command: create snmp user dlink default encrypted by_password auth md5 canadian priv none Success. DES-3528:admin# delete snmp user Purpose...
Page 48 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create snmp view Purpose Used to assign views to community strings to limit which MIB objects and SNMP manager can access. Syntax create snmp view <view_name 32> <oid> view_type [included | excluded] Description This command assigns views to community strings to limit which MIB objects an SNMP manager can access.
Page 49 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show snmp view Purpose Used to display an SNMP view previously created on the Switch. Syntax show snmp view {<view_name 32>} Description This command displays an SNMP view previously created on the Switch. <view_name 32>...
Page 50 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create snmp community Purpose Used to create an SNMP community string to define the relationship between the SNMP manager and an agent. The community string acts like a password to permit access to the agent on the Switch.
Page 51 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show snmp community Purpose Used to display SNMP community strings configured on the Switch. Syntax show snmp community {<community_string 32>} Description This command is used to display SNMP community strings that are configured on the Switch. <community_string 32>...
Page 52 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show snmp engineID Purpose Used to display the identification of the SNMP engine on the Switch. Syntax show snmp engineID Description This command displays the identification of the SNMP engine on the Switch. Parameters None.
Page 53 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create snmp group Purpose Used to create a new SNMP group, or a table that maps SNMP users to SNMP views. Syntax create snmp group <groupname 32> [v1 | v2c | v3 [noauth_nopriv | auth_nopriv | auth_priv]] {read_view <view_name 32>...
Page 54 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete snmp group Purpose Used to remove an SNMP group from the Switch. Syntax delete snmp group <groupname 32> Description This command is used to remove an SNMP group from the Switch. <groupname 32>...
Page 55 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create snmp host Purpose Used to create a recipient of SNMP traps generated by the Switch’s SNMP agent. Syntax create snmp host [<ipaddr> | v6host <ipv6addr>] [v1 | v2c | v3 [noauth_nopriv | auth_nopriv | auth_priv]] <auth_string 32>...
Page 56 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete snmp host Purpose Used to remove a recipient of SNMP traps generated by the Switch’s SNMP agent. Syntax delete snmp host [<ipaddr> | v6host <ipv6addr>] Description This command deletes a recipient of SNMP traps generated by the Switch’s SNMP agent.
Page 57 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show snmp v6host Purpose This command is used to display the recipient for which the traps are targeted. Syntax show snmp v6host {<ipv6addr>} Description This command is used to display the recipient for which the traps are targeted. Parameters v6host - (Optional) Specifies the IPv6 host address.
Page 58 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To create the trusted host: DES-3528:admin# create trusted_host 10.62.32.1 Command: create trusted_host 10.62.32.1 Success. config trusted_host Purpose Used to configure the access interfaces for the trusted host. Syntax config trusted_host [<ipaddr>...
Page 59 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Management Stations IP Address Access Interface ---------------------------------------------------------------- 10.62.32.1/32 10.62.32.1/16 Total Entries: 2 DES-3528:admin# delete trusted_host Purpose Used to delete a trusted host entry made using the create trusted_host command above. Syntax delete trusted_host [ipaddr <ipaddr>...
Page 60 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable snmp authenticate_traps Purpose Used to enable SNMP authentication trap support. Syntax enable snmp authenticate_traps Description This command is used to enable SNMP authentication trap support on the Switch. Parameters None.
Page 61 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# disable snmp authenticate_traps Purpose Used to disable SNMP authentication trap support. Syntax disable snmp authenticate_traps Description This command is used to disable SNMP authentication support on the Switch. Parameters None.
Page 62 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# config snmp system_name Purpose Used to configure the name for the Switch. Syntax config snmp system_name <sw_name> Description This command configures the name of the Switch. <sw_name>...
Page 63 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# disable snmp Command: disable snmp Success. DES-3528:admin#...
Page 64: Switch Utility Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Switch Utility Commands The Switch utility commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters download [firmware_fromTFTP [<ipaddr>...
Page 65 DES-3528:admin# #------------------------------------------------------------------- DES-3528:admin# # DES-3528 Configuration DES-3528:admin# # DES-3528:admin# # Firmware: Build 3.00.012 DES-3528:admin# # Copyright(C) 2013 D-Link Corporation. All rights reserved. DES-3528:admin# #------------------------------------------------------------------- DES-3528:admin# DES-3528:admin# DES-3528:admin# # BASIC DES-3528:admin# DES-3528:admin# config serial_port baud_rate 115200 auto_logout 10_minutes Command: config serial_port baud_rate 115200 auto_logout 10_minutes The download configuration command will initiate the loading of the various settings in the order listed in the configuration file.
Page 66 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show firmware information Purpose Used to display the firmware section information. Syntax show firmware information Description This command is used to display the firmware section information. Parameters None.
Page 67 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show config Purpose Used to display the current or saved version of the configuration settings of the Switch. Syntax show config [[effective | modified | current_config | config_in_nvram <config_id 1-2>] {[include | exclude | begin] <filter_string 80>...
Page 68 DES-3528:admin# show config current_config Command: show config current_config #------------------------------------------------------------------------------- DES-3528 Fast Ethernet Switch Configuration Firmware: Build 3.00.012 Copyright(C) 2013 D-Link Corporation. All rights reserved. #------------------------------------------------------------------------------- # STACK config stacking force_master_role state disable # BASIC # ACCOUNT LIST # ACCOUNT END...
Page 69 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide upload Purpose Used to upload the current Switch settings or the Switch history log to a TFTP. Syntax upload [cfg_toTFTP [<ipaddr> | <ipv6addr>] dest_file <path_filename 64> {<config_id 1-2>} {[include | exclude | begin] <filter_string 80>...
Page 70 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config configuration Purpose Used to delete the specific firmware or configure the specific firmware as boot up image. Syntax config configuration <config_id 1-2> [boot_up | delete | active] Description This command is used to delete the specific firmware or configure the specific firmware as boot up image.
Page 71: Network Monitoring Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Network Monitoring Commands The network monitoring commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters show packet ports <portlist>...
Page 72 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show packet ports Purpose Used to display statistics about the packets sent and received by the Switch. Syntax show packet ports <portlist> Description This command is used to display statistics about packets sent and received by ports specified in the <portlist>.
Page 73 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Oversize Late Collision Fragment Excessive Collision Jabber Single Collision Drop Pkts Collision Symbol Error CTRL+C ESC q Quit SPACE n Next Page Previous Page Refresh show utilization Purpose Used to display real-time port and CPU utilization statistics.
Page 74 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show utilization dram Purpose This command is used to display the DRAM utilization. Syntax show utilization dram Description This command is used to display the DRAM utilization. Parameters None.
Page 75 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To display the flash utilization: DES-3528:admin# show utilization flash Command: show utilization flash Unit 1 Flash Memory Utilization : Total Flash : 16384 Used Flash : 7662 Utilization : 46 % CTRL+C ESC q...
Page 76 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show log Purpose Used to display the Switch’s history log. Syntax show log {[index <value_list> | severity {module <module_list>} {emergency | alert | critical | error | warning | notice | informational | debug | <level_list 0-7>} | module <module_list>]} Description This command will display the contents of the Switch’s history log.
Page 77 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To the Syslog function on the Switch: DES-3528:admin# enable syslog Command: enable syslog Success. DES-3528:admin# disable syslog Purpose Used to disable the syslog sending messages. Syntax disable syslog Description This command disables the system log to be sent to a remote host.
Page 78 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create syslog host Purpose Used to create a new syslog host. Syntax create syslog host <index 1-4> ipaddress [<ipaddr> | <ipv6addr>] {severity [emergency | alert | critical | error | warning | notice | informational | debug | <level 0- 7>] | facility [local0 | local1 | local2 | local3 | local4 | local5 | local6 | local7] | udp_port <udp_port_number>...
Page 79 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create syslog host local0 − Specifies that local use 0 messages will be sent to the remote host. This corresponds to number 16 from the list above. local1 −...
Page 80 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config syslog host Purpose Used to configure the syslog protocol to send system log data to a remote host. Syntax config syslog host [<index> | all] { severity [emergency | alert | critical | error | warning | notice | informational | debug | <level 0-7>] | facility [local0 | local1 | local2 | local3 | local4 | local5 | local6 | local7] | udp_port <udp_port_number>...
Page 81 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config syslog host local0 − Specifies that local use 0 messages will be sent to the remote host. This corresponds to number 16 from the list above. local1 −...
Page 82 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete syslog host Purpose This command is used to delete the specific syslog host. Syntax delete syslog host [<index 1-4> | all] Description This command is used to remove a syslog host that has been previously configured from the Switch.
Page 83 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config log_save_timing Purpose Used to configure the method to save log. Syntax config log_save_timing [time_interval <min 1-65535> | on_demand | log_trigger] Description This command is used to set the method to save log. time_interval −...
Page 84 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show attack_log Command: show attack_log Index Time Log Text ---- --------------- ----------------------- 00000 days 01:25:43 Possible spoofing attack from 000d01002301 port 6:3 00000 days 01:25:43 Possible spoofing attack from 000d01002301 port 6:3 DES-3528:admin# clear attack_log Purpose...
Page 85 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config system_severity Purposez Used to configure system_severity level of an alert required for log entry or trap message. Syntax config system_severity [trap | log | all] [emergency | alert | critical | error | warning | notice | information | debug | <level 0-7>] Description This command is used to configure the system_severity levels on the Switch.
Page 86 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide System Severity Trap : information System Severity Log : information DES-3528:admin#...
Page 87: Multiple Spanning Tree Protocol (Mstp) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Multiple Spanning Tree Protocol (MSTP) Commands This Switch supports three versions of the Spanning Tree Protocol: 802.1D STP, 802.1w Rapid STP and 802.1s MSTP. Multiple Spanning Tree Protocol, or MSTP, is a standard defined by the IEEE community that allows multiple VLANs to be mapped to a single spanning tree instance, which will provide multiple pathways across the network.
Page 88 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters show stp mst_config_id Each command is listed, in detail, in the following sections. enable stp Purpose Used to globally enable STP on the Switch. Syntax enable stp Description This command allows the Spanning Tree Protocol to be globally enabled on the Switch.
Page 89 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To set the Switch globally for the Multiple Spanning Tree Protocol (MSTP): DES-3528:admin# config stp version mstp Command: config stp version mstp Success DES-3528:admin# config stp Purpose Used to setup STP, RSTP and MSTP on the Switch.
Page 90 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config stp ports Purpose Used to setup STP on the port level. Syntax config stp ports <portlist> { externalCost [ auto | <value 1-200000000> ] | hellotime <value 1-2>...
Page 91 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config stp ports the port cannot maintain this status (for example if the port is forced to half-duplex operation) the p2p status changes to operate as if the p2p value were false. The default setting for this parameter is auto.
Page 92 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config stp instance_id Purpose Used to add or delete VID to/from an STP instance. Syntax config stp instance_id <value 1-15> [add_vlan | remove_vlan] <vidlist> Description This command is used to map VIDs (VLAN IDs) to previously configured STP instances on the Switch by creating an instance_id.
Page 93 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# config stp priority Purpose Used to configure the bridge priority. Syntax config stp priority <value 0-61440> instance_id <value 0-15> Description This command is used to update the STP instance configuration settings on the Switch. The MSTP will utilize the priority in selecting the root bridge, root port and designated port.
Page 94 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config stp mst_ports Purpose Used to update the port configuration for a MSTP instance. Syntax config stp mst_ports <portlist> instance_id <value 0-15> {internalCost [auto | <value 1- 200000000>] priority <value 0-240>}(1) Description This command will update the port configuration for a STP instance_id.
Page 95 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Hello Time Forward Delay : 15 Max Hops : 20 TX Hold Count Forwarding BPDU : Disabled NNI BPDU Address : dot1ad DES-3528:admin# Status 2 : STP enabled for RSTP DES-3528:admin# show stp Command: show stp STP Bridge Global Settings...
Page 96 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show stp ports Command: show stp ports MSTP Port Information ---------------------- Port Index , Hello Time: 2 /2 , Port STP : Enabled External PathCost : Auto/200000 , Edge Port : False/No , P2P : Auto /Yes Port RestrictedRole : False, Port RestrictedTCN : False...
Page 97 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show stp mst_config_id Purpose Used to display the MSTP configuration identification. Syntax show stp mst_config_id Description This command displays the Switch’s current MSTP configuration identification. Parameters None. Restrictions None.
Page 98: Forwarding Database Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Forwarding Database Commands The layer 2 forwarding database commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create fdb <vlan_name 32>...
Page 99 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create fdb vlanid Purpose Used to create a static entry to the unicast MAC address forwarding table (database). Syntax create fdb vlanid <vidlist> <macaddr> [port <port> | drop] Description This command will make an entry into the Switch’s unicast MAC address forwarding database.
Page 100 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config multicast_fdb Purpose Used to configure the Switch’s multicast MAC address forwarding database. Syntax config multicast_fdb <vlan_name 32> <macaddr> [add | delete] <portlist> Description This command configures the multicast MAC address forwarding table. <vlan_name 32>...
Page 101 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete fdb Purpose Used to delete an entry to the Switch’s forwarding database. Syntax delete fdb <vlan_name 32> <macaddr> Description This command is used to delete a previous entry to the Switch’s MAC address forwarding database.
Page 102 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show multicast_fdb Purpose Used to display the contents of the Switch’s multicast forwarding database. Syntax show multicast_fdb {[vlan <vlan_name 32> | vlanid <vidlist>] | mac_address <macaddr>} Description This command is used to display the current contents of the Switch’s multicast MAC address forwarding database.
Page 103 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide default 00-02-A5-FD-66-97 Dynamic default 00-03-09-18-10-01 Dynamic default 00-03-9D-73-32-F0 Dynamic default 00-03-B3-00-09-E9 Dynamic default 00-04-00-00-00-00 Dynamic default 00-05-5D-04-D6-A4 Dynamic default 00-05-5D-25-45-61 Dynamic default 00-05-5D-6A-A5-2C Dynamic default 00-05-5D-9A-FE-6D Dynamic default 00-05-5D-DB-BA-7C Dynamic...
Page 104 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide 100 /Sales forward_all_groups 200 /PM forward_all_groups 600 /Customer filter unregistered groups Total Entries : 3 DES-3528:admin#...
Page 105: Traffic Control Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Traffic Control Commands On a computer network, packets such as Multicast packets and Broadcast packets continually flood the network as normal procedure. At times, this traffic may increase do to a malicious endstation on the network or a malfunctioning device, such as a faulty network card.
Page 106 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config traffic control Purpose Used to configure broadcast/multicast/unicast packet storm control. The software mechanism is provided to monitor the traffic rate in addition to the hardware storm control mechanism previously provided.
Page 107 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Example usage: To configure traffic control and enable broadcast storm control for ports 1-12: DES-3528:admin# config traffic control 1-12 broadcast enable action shutdown threshold 1 countdown 10 time_interval 10 Command: config traffic control 1-12 broadcast enable action shutdown threshold 1 countdown 10 time_interval 10 Success.
Page 108 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show traffic control Purpose Used to display current traffic control settings. Syntax show traffic control { <portlist> } Description This command displays the current storm traffic control configuration on the Switch. <portlist>...
Page 109 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config traffic trap Purpose Used to configure the trap settings for the packet storm control mechanism. Syntax config traffic trap [none | storm_occurred | storm_cleared | both] Description This command is used to configure how packet storm control trap messages will be used when a packet storm is detected by the Switch.
Page 110: Qos Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide QoS Commands The Switch supports 802.1p priority queuing. The Switch has 8 priority queues, but it has 7 priority queues available . Q7 is reserved for stacking function. These priority queues are numbered from 6 (Class 6) — the highest priority queue —...
Page 111 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config bandwidth_control Purpose Used to configure bandwidth control on a port by-port basis. Syntax config bandwidth_control [<portlist> | all] {rx_rate [no_limit | <value 64-1024000>] | tx_rate [no_limit | <value 64-1024000>]}(1) Description This command is used to configure bandwidth on a port-by-port basis.
Page 112 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide No Limit No Limit No Limit No Limit No Limit No Limit No Limit No Limit No Limit No Limit No Limit No Limit No Limit No Limit No Limit No Limit DES-3528:admin#...
Page 113 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show per_queue bandwidth_control Purpose Used to display the per port per CoS queue bandwidth control setting. Syntax show per_queue bandwidth_control {<portlist>} Description This command is used to display the per port per CoS queue bandwidth control setting. <portlist>...
Page 114 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config scheduling Purpose Used to configure the traffic scheduling mechanism for each CoS queue. Syntax config scheduling {ports [<portlist> | all ]} <class_id 0-6> [strict | weight <value 1- 127>] Description The Switch contains seven hardware priority queues available.
Page 115 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To configure the traffic scheduling mechanism for each CoS queue: DES-3528:admin# config scheduling_mechanism ports 1 strict Command: config scheduling_mechanism ports 1 strict Success. DES-3528:admin# show scheduling Purpose Used to display the current configured traffic scheduling for a port or a range of ports on the Switch.
Page 116 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To display the scheduling mechanism: DES-3528:admin#show scheduling_mechanism Command: show scheduling_mechanism 1-4 Port Mode ----- ------ Strict Strict Strict Strict DES-3528:admin# config 802.1p user_priority Purpose Used to map the 802.1p user priority of an incoming packet to one of the seven hardware queues available on the Switch.
Page 117 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show 802.1p user_priority Purpose Used to display the current mapping between an incoming packet’s 802.1p priority value and one of the Switch’s seven hardware priority queues. Syntax show 802.1p user_priority {<portlist>} Description This command is used to display the current mapping of an incoming packet’s 802.1p priority...
Page 118 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config 802.1p default_priority all 5 Command: config 802.1p default_priority all 5 Success. DES-3528:admin# show 802.1 default_priority Purpose Used to display the current configured 802.1p priority value that will be assigned to an incoming, untagged packet before being forwarded to its destination.
Page 119 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# enable hol_prevention Command: enable hol_prevention Success. DES-3528:admin# disable hol_prevention Purpose Used to disable HOL prevention. Syntax disable hol_prevention Description This command is used to disable the HOL prevention function on the Switch. Parameters None.
Page 120: Port Mirroring Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Port Mirroring Commands The port mirroring commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config mirror port <port>...
Page 121 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# enable mirror Purpose Used to enable a previously entered port mirroring configuration. Syntax enable mirror Description This command, combined with the disable mirror command below, allows the user to enter a port mirroring configuration into the Switch, and then turn the port mirroring on and off without having to modify the port mirroring configuration.
Page 122 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Mirror Status: Enabled Target Port Mirrored Port RX: 2-5 TX: 2-5 DES-3528:admin#...
Page 123: Vlan Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide VLAN Commands The VLAN commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create vlan <vlan_name 32> tag <vlanid 2-4094> {type [1q_vlan | private_vlan]} {advertisement} create vlan vlanid <vidlist>...
Page 124 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters show private_vlan {[<vlan_name 32> | vlanid <vidlist>]} Each command is listed, in detail, in the following sections. create vlan Purpose Used to create a VLAN on the Switch. Syntax create vlan <vlan_name 32>...
Page 125 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete vlan Purpose Used to delete a previously configured VLAN on the Switch. Syntax delete vlan <vlan_name 32> Description This command will delete a previously configured VLAN on the Switch. <vlan_name 32>...
Page 126 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config vlan Purpose Used to add additional ports to a previously configured VLAN, and enable or disable the VLAN advertisement. Syntax config vlan <vlan_name 32> { [ add [ tagged | untagged | forbidden ] | delete ] <portlist>...
Page 127 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config vlan vlanid Purpose Used to add additional ports to a previously configured VLAN and enable or disable the VLAN advertisement. Syntax config vlan vlanid <vidlist> {[ add [ tagged | untagged | forbidden ] | delete ] <portlist> | advertisement [ enable | disable ] | name <vlan_name 32>}(1) Description This command allows you to add or delete ports of the port list of previously configured...
Page 128 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config port_vlan Purpose Used to set the ingress checking status, and the sending and receiving GVRP information. Syntax config port_vlan [<portlist> | all] { gvrp_state [enable | disable] | ingress_checking [enable | disable] | acceptable_frame[tagged_only | admit_all]pvid<vlanid 1-4094>}(1) Description This command is used to configure the Group VLAN Registration Protocol on the Switch.
Page 129 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable gvrp Purpose Used to disable the GARP VLAN Registration Protocol (GVRP). Syntax disable gvrp Description This command, along with enable gvrp, is used to enable and disable GVRP on the Switch, without changing the GVRP configuration on the Switch.
Page 130 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Static Untagged Ports : Forbidden Ports Total Static VLAN Entries : 1 Total GVRP VLAN Entries: 1 DES-3528:admin# DES-3528:admin# show vlan ports 1-4 Command: show vlan ports 1-4 Port Untagged Tagged...
Page 131 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create dot1v_protocol_group group_id Purpose Used to create a protocol group for protocol VLAN function. Syntax create dot1v_protocol_group group_id <id> {group_name <name 32>} Description This command creates a protocol group for protocol VLAN function. group_id Parameters −...
Page 132 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete dot1v_protocol_group Purpose Used to delete a protocol group. Syntax delete dot1v_protocol_group [group_id <id> | group_name <name 32> | all] Description This command deletes a protocol group group_id Parameters −...
Page 133 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config port dot1v ports Purpose Used to assign the VLAN for untagged packets which ingress from the portlist based on the protocol group configured. Syntax config port dot1v ports [<portlist> | all] [add protocol_group [group_id <id> | group_name <name 32>] [vlan <vlan_name 32>...
Page 134 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show port dot1v ports 1-2 Command: show port dot1v ports 1-2 Port : 1 Protocol Group ID VLAN Name Protocol Priority ----------------- ---------------- ----------------- default vlan_2 vlan_3 vlan_4 Port : 2...
Page 135 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# disable pvid auto_assign Command: disable pvid auto_assign Success. DES-3528:admin# show pvid auto_assign Purpose Used to show PVID auto-assigment state. Syntax show pvid auto_assign Description This command is used to show PVID auto-assigment state. Parameters None.
Page 136 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show gvrp Purpose Used to display the GVRP global setting and it’s timer’s value. Syntax show gvrp Description This command displays GVRP global setting and it’s timer’s value. Parameters None.
Page 137 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config vlan_trunk ports Purpose Used to configure a port as a VLAN trunk port. Syntax config vlan_trunk ports [<portlist> | all] state [enable | disable] Description This command is used to configure a port as a VLAN trunk port. When a port is configured as a VLAN trunk port, all tagged frames shall be able to pass through this port.
Page 138 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config private_vlan Purpose This command is used to configure the private VLAN function. Syntax config private_vlan [<vlan_name 32> | vid <vlanid 1-4094>] [add [isolated | community] | remove] [<vlan_name 32> | vlanid <vidlist> Description A private VLAN is comprised of a primary VLAN, up to one isolated VLAN, and a number of community VLANs.
Page 139 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show private_vlan Purpose This command is used to display private VLAN information on the switch. Syntax show private_vlan {[<vlan_name 32> | vlanid <vidlist>]} Description This command is used to display private VLAN information on the switch. Parameters <vlan_name 32>...
Page 140: Voice Vlan Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Voice VLAN Commands The voice VLAN commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable voice_vlan [vlan <vlan_name 32>...
Page 141 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable voice_vlan Purpose Used to disable the global voice VLAN function. Syntax disable voice_vlan Description This command disables the global voice VLAN function on the Switch. When the voice VLAN function is disabled, the voice VLAN will become unassigned.
Page 142 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config voice_vlan oui Purpose Used to configure the user defined OUI (Organizationally Unique Identifier) of Voice device for voice VLAN. Syntax config voice_vlan oui [add | delete] <macaddr> < macmask> {description <desc 32>} Description This command is used to configure the user-defined OUI for voice traffic.
Page 143 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config voice_vlan aging_time Purpose Used to config voice VLAN aging time. Syntax config voice_vlan aging_time <min 1-65535> Description This command is used to set the aging time of the voice VLAN. The aging time is used to remove a port from voice VLAN if the port is an dynamic VLAN member.
Page 144 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command: show voice_vlan Voice VLAN State : Enabled VLAN ID VLAN Name : default Priority Aging Time : 60 minutes Log State : Enabled Member Ports : 1-28 Dynamic Member Ports : DES-3528:admin# show voice_vlan oui...
Page 145 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide ----- --------- -------- Disabled Auto Disabled Auto Disabled Auto Disabled Auto Disabled Auto DES-3528:admin# show voice_vlan voice_device ports Purpose Used to show voice devices connected to the ports. Syntax show voice_vlan voice_device ports {<portlist>...
Page 146: Subnet-Based Vlan Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Subnet-based VLAN Commands The subnet-based VLAN commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create subnet_vlan [network <network_address>...
Page 147 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete subnet_vlan Purpose Use this command to delete subnet-based VLAN entries. Syntax delete subnet_vlan [network <network_address> | ipv6network <ipv6networkaddr> | vlan <vlan_name 32> | vlanid <vidlist> | all] Description This command is used to delete subnet-based VLAN entries.
Page 148 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config vlan_precedence ports Purpose Use to configure VLAN classification precedence. Syntax config vlan_precedence ports <portlist> [mac_based_vlan | subnet_vlan] Description This command is used to configure VLAN classification precedence on each port. You can specify MAC-based VLAN classification or subnet-based VLAN classification.
Page 149: Asymmetric Vlan Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Asymmetric VLAN Commands The asymmetric VLAN commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable asymmetric_vlan disable asymmetric_vlan show asymmetric_vlan Each command is listed, in detail, in the following sections.
Page 150 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show asymmetric_vlan Purpose Used to view the asymmetric VLAN state on the Switch. Syntax show asymmetric_vlan Description This command displays the asymmetric VLAN state on the Switch. Parameters None.
Page 151: Link Aggregation Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Link Aggregation Commands The link aggregation commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create link_aggregation group_id <value 1-8>...
Page 152 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete link_aggregation Purpose Used to delete a previously configured link aggregation group. Syntax delete link_aggregation group_id <value 1-8> Description This command is used to delete a previously configured link aggregation group. <value 1-8>...
Page 153 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config link_aggregation algorithm Purpose Used to configure the link aggregation algorithm. Syntax config link_aggregation algorithm [mac_source | mac_destination | mac_source_dest | ip_source | ip_destination | ip_source_dest] } Description This command configures the part of the packet examined by the Switch when selecting the egress port for transmitting load-sharing data.
Page 154 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config lacp_port Purpose Used to configure settings for LACP compliant ports. Syntax config lacp_port <portlist> mode [active | passive] Description This command is used to configure ports that have been previously designated as LACP ports (see create link_aggregation).
Page 155 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#...
Page 156: Ip-Mac-Port Binding (Impb) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide IP–MAC-Port Binding (IMPB) Commands IMPB is a security application found on edge Switches which are usually directly connected to hosts. IMPB enables administrators to configure (or snoop) pairs of MAC and IP addresses that are allowed to access networks through the Switch.
Page 157 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config address_binding ip_mac ports [<portlist> | all] {state [enable {[strict | loose] | [ipv6 | all]} | disable {[ipv6 | all]}] | mode [arp | acl] | allow_zeroip [enable | disable] | forward_dhcppkt [enable | disable] | stop_learning_threshold <int 0-500>} show address_binding...
Page 158 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create address_binding ip_mac ipaddress Purpose Used to create an IP–MAC–Port Binding entry in the white list. Syntax create address_binding ip_mac ipaddress <ipaddr> mac_address <macaddr> {ports [ <portlist> | all] | mode [ arp | acl ]} Description This command is used to create an IP–MAC–Port Binding entry.
Page 159 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create address_binding ip_mac ipv6address Purpose Used to create an IP–MAC–Port Binding entry in the white list. Syntax create address_binding ip_mac ipv6address <ipv6addr> mac_address <macaddr> {ports [<portlist> | all]} Description This command is used to create an IP–MAC–Port Binding entry.
Page 160 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config address_binding ip_mac ports Purpose Used to configure IMPB settings for specified ports. Syntax config address_binding ip_mac ports [<portlist> | all] {state [enable {[strict | loose] | [ipv6 | all]} | disable {[ipv6 | all]}] | mode [arp | acl] | allow_zeroip [enable | disable] | forward_dhcppkt [enable | disable] | stop_learning_threshold <int 0-500>} Description This command is used to configure the per-port state of IP-MAC binding on the Switch.
Page 161 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config address_binding ip_mac ports When enabled on a port, all ARP packets with a source IP address of 0.0.0.0 is forwarded; when set to disable, they are blocked. forward_dhcppkt –...
Page 162 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To show IP–MAC–Port Binding global configuration: DES-3528:admin#show address_binding Command: show address_binding Trap/Log : Disabled DHCP Snoop(IPv4) : Disabled DHCP Snoop(IPv6) : Disabled ND Snoop : Disabled DES-3528:admin# To show IP–MAC–Port Binding configuration of port 1: DES-3528:admin#show address_binding ports 1 Command: show address_binding ports 1...
Page 163 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show address_binding dhcp_snoop Purpose This command is used to display the IP–MAC–Port Binding DHCP snooping. Syntax show address_binding dhcp_snoop {max_entry {ports <portlist>}} Description This command is used to display the IP–MAC–Port Binding DHCP snooping. Parameters max_entry –...
Page 164 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show address_binding ip_mac Purpose This command is used to display the IP–MAC–Port Binding entries. Syntax show address_binding ip_mac [all | ipaddress <ipaddr> mac_address <macaddr>] | ipv6address <ipv6addr> mac_address <macaddr> Description This command is used to display the IP–MAC–Port Binding entries.
Page 165 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show address_binding nd_snoop binding_entry Purpose This command is used to display the IP–MAC–Port Binding ND snoop binding entry. Syntax show address_binding nd_snoop binding_entry {port <port>} Description This command is used to display the IP–MAC–Port Binding ND snoop binding entry. Parameters ports –...
Page 166 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete address_binding ip_mac Purpose This command is used to delete IP–MAC–Port Binding entries. Syntax delete address_binding ip_mac [all | ipaddress <ipaddr> mac_address <macaddr>] | ipv6address <ipv6addr> mac_address <macaddr> Description This command is used to delete IP–MAC–Port Binding entries.
Page 167 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To disable address binding trap log on the Switch: DES-3528:admin# disable address_binding trap_log Command: disable address_binding trap_log Success. DES-3528:admin# debug address_binding Purpose Used to configure the address binding debugging feature on the Switch. Syntax debug address_binding [event | dhcp | all] state [enable | disable] Description...
Page 168 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable address_binding dhcp_snoop Purpose Used to enable the DHCP snooping option for IMPB. Syntax enable address_binding dhcp_snoop {[ipv6 | all]} Description If DHCP snooping is enabled, the Switch learns IP-MAC pairs by snooping DHCP packets automatically and then saves them to the IP-MAC-Port Binding white list.
Page 169 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable address_binding nd_snoop Purpose This command is used to enable ND snooping on the Switch. Syntax enable address_binding nd_snoop Description This command is used to enable ND snooping on the Switch. Parameters None.
Page 170 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# clear address_binding nd_snoop binding_entry ports Purpose This command is used to clear the ND snooping entries on specified ports. Syntax clear address_binding nd_snoop binding_entry ports [<portlist> | all] Description This command is used to clear the ND snooping entries on specified ports.
Page 171 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config address_binding nd_snoop ports Purpose This command is used to specify the maximum number of entries which can be learned with ND snooping. Syntax config address_binding nd_snoop ports [<portlist> | all] max_entry [<value 1-10> | no_limit] Description This command is used to specify the maximum number of entries which can be learned...
Page 172: Limited Ip Multicast Address Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Limited IP Multicast Address Commands The Limited IP Multicast command allows the administrator to permit or deny access to a port or range of ports by specifying a range of multicast addresses. The Limited IP Multicast Commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.
Page 173 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mcast_filter_profile Purpose Used to add or delete a range of multicast addresses to the profile. Syntax config mcast_filter_profile [profile_id < value 1-24> | profile_name <name 1-32> ] { profile_name <name 1-32>...
Page 174 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# show mcast_filter_profile Purpose Used to display the defined multicast address profiles. Syntax show mcast_filter_profile {[profile_id <value 1-24> | profile_name <name 1-32>]} Description This command displays the defined multicast address profiles. profile_id −...
Page 175 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show limited_multicast_addr Purpose Used to show per-port Limited IP multicast address range. Syntax show limited_multicast_addr [ports <portlist> | vlanid <vidlist>] Description This command shows limited multicast address on a per port or per VID basis. When the function is configured on a port or VLAN, it limits the multicast groups that hosts can join through the operation of IGMP snooping function and layer 3 function.
Page 176 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show max_mcast_group Purpose Used to display the max number of multicast groups that a port can join. Syntax show max_mcast_group [ports <portlist> | vlanid <vidlist>] Description This command display the max number of multicast groups that a port can join.
Page 177: Basic Ip Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Basic IP Commands The IP interface commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config ipif <ipif_name 12>...
Page 178 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config ipif Purpose Used to configure the IP interface. Syntax config ipif <ipif_name 12> [{ipaddress <network_address> | vlan <vlan_name 32> | proxy_arp [enable | disable] {local [enable | disable]} | state [enable | disable]} | bootp | dhcp | ipv6 [ipv6address <ipv6networkaddr>...
Page 179 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# create ipif Purpose Used to create a L3 interface. Syntax create ipif <ipif_name 12> {<network_address>} <vlan_name 32> {state [enable | disable] | proxy_arp[enable | disable] {local [enable | disable]}} Description This command creates a L3 interface.
Page 180 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command: delete ipif if2 Success. DES-3528:admin# enable ipif Purpose Used to enable the admin state for an interface. Syntax enable ipif [<ipif_name 12> | all] Description This command enables the state for an IPIF. When the state is enabled, the IPv4 processing will be started.
Page 181 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To display IP interface settings. DES-3528:admin# show ipif System Command: show ipif System IP Interface : System VLAN Name : default Interface Admin State : Enabled IPv4 Address : 10.24.73.21/8 (Manual) Primary Proxy ARP...
Page 182 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show ipif_ipv6_link_local_auto Purpose Display the link local address automatic configuration state. Syntax show ipif_ipv6_link_local_auto {<ipif_name 12>} Description Display the link local address automatic configuration state. Parameters <ipif_name 12> - Specifies the IP interface name used. This name can be up to 12 characters long.
Page 183: Multicast Vlan Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Multicast VLAN Commands The Multicast VLAN commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create igmp_snooping multicast_vlan <vlan_name 32>...
Page 184 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters show mld_snooping {< vlan_name 32> } multicast_vlan_group delete mld_snooping multicat_vlan <vlan_name 32> enable mld_snooping multicast_vlan disable mld_snooping multicast_vlan show mld_snooping multicast_vlan {<vlan_name 32>} config mld_snooping multicast_vlan [disable | enable] forward_unmatched Each command is listed, in detail, in the following sections.
Page 185 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config igmp_snooping multicast_vlan Purpose Used to configure the parameter of the specific multicast VLAN. Syntax config igmp_snooping multicast_vlan <vlan_name 32> {[add | delete] [member_port <portlist> | [source_port <portlist> | untag_source_port <portlist>] | tag_member_port <portlist>] | state [enable | disable] | replace_source_ip <ipaddr>...
Page 186 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To display the multicast groups configured for a multicast VLAN. DES-3528:admin# show igmp_snooping multicast_vlan_group v1 Command: show igmp_snooping multicast_vlan_group v1 VLAN Name VLAN ID Multicast Group Profiles ------------------------------- ------- ---------------------------------...
Page 187 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable igmp_snooping multicast_vlan Purpose Used to disable the multicast VLAN function. Syntax disable igmp_snooping multicast_vlan Description This command is used to disable the IGMP snooping multicast VLAN function. Parameters None.
Page 188 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config igmp_snooping multicast_vlan forward_unmatched Purpose Used to configure forwarding or dropping of the multicast VLAN unmatched packet. Syntax config igmp_snooping multicast_vlan forward_unmatched [disable | enable] Description When the Switch receives a tagged IGMP group packet, if the VID in the tagged packet belongs to a multicast VLAN and the group does not match all profiles, then the configuration takes effect and the packet will be forwarded or dropped based on the setting.
Page 189 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config igmp_snooping multicast_vlan_group_profile Purpose Used to configure an IGMP snooping multicast group profile on the Switch, and to add or delete multicast address for the profile. Syntax config igmp_snooping multicast_vlan_group_profile <profile_name 1-32>...
Page 190 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show igmp_snooping multicast_vlan_group_profile Purpose Used to show the information about an IGMP multicast VLAN group profile on the Switch. Syntax show igmp_snooping multicast_vlan_group_profile {<profile_name 1-32>} Description This command is used to show the information about an IGMP multicast VLAN group profile on the Switch.
Page 191 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show igmp_snooping multicast_vlan_group Purpose Used to display the multicast group profiles configured for the specified IGMP multicast VLAN. Syntax show igmp_snooping multicast_vlan_group {< vlan_name 32> } Description This command is used to display the multicast group profiles configured for the specified IGMP multicast VLAN.
Page 192 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mld_snooping multicast_vlan Purpose Used to configure the parameter of the specific MLD multicast VLAN. Syntax config mld_snooping multicast_vlan <vlan_name 32> {[add | delete] [member_port <portlist> | [source_port <portlist> | untag_source_port <portlist>] | tag_member_port <portlist>] | state [enable | disable] | replace_source_ip <ipv6addr>...
Page 193 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To create an MLD multicast VLAN group profile "g1": DES-3528:admin# create mld_snooping multicast_vlan_group_profile g1 Command: create mld_snooping multicast_vlan_group_profile g1 Success. DES-3528:admin# config mld_snooping multicast_vlan_group_profile Purpose Used to configure an MLD multicast VLAN group profile on the Switch, to add or delete multicast address for the profile.
Page 194 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show mld_snooping multicast_vlan_group_profile Purpose Used to show the information about an MLD multicast VLAN group profile on the Switch. Syntax show mld_snooping multicast_vlan_group_profile {<profile_name 1-32>} Description This command is used to show the information about an MLD multicast VLAN group profile on the Switch.
Page 195 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show mld_snooping multicast_vlan_group Purpose Used to display the multicast group profiles configured for the specified MLD multicast VLAN. Syntax show mld_snooping multicast_vlan_group {< vlan_name 32> } Description This command is used to display the multicast group profiles configured for the specified MLD multicast VLAN.
Page 196 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# disable mld_snooping multicast_vlan Purpose Used to disable the MLD Multicast VLAN function. Syntax disable mld_snooping multicast_vlan Description This command is used to disable the MLD Multicast VLAN function. Parameters None.
Page 197 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#show mld_snooping multicast_vlan new Command: show mld_snooping multicast_vlan new MLD Multicast VLAN Global State : Disabled MLD Multicast VLAN Forward Unmatched : Enabled VLAN Name :new Member(Untagged) Ports Tagged Member Ports Source Ports Untagged Source Ports...
Page 198: Igmp / Mld Snooping Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide IGMP / MLD Snooping Commands The IGMP / MLD Snooping commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config igmp_snooping...
Page 199 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters show mld_snooping mrouter_ports [vlan <vlan_name 32> | vlanid <vlanid_list> | all] {[static | dynamic | forbidden]} create mld_snooping static_group [vlan <vlan_name 32> | vlanid <vlanid_list>] <ipv6addr> delete mld_snooping static_group [vlan <vlan_name 32>...
Page 200 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config igmp_snooping Purpose The config igmp_snooping command configures IGMP snooping on the Switch. Syntax config igmp_snooping [vlan_name <vlan_name 32> | vlanid <vlanid_list> | all] {state [enable | disable] | fast_leave [enable | disable] | report_suppression [enable | disable]}(1) Description The config igmp_snooping command configures IGMP snooping on the Switch.
Page 201 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config igmp_snooping rate_limit Purpose The command configures the rate of IGMP control packet that is allowed per port or per VLAN. Syntax config igmp_snooping rate_limit [ports <portlist> | vlanid <vlanid_list>] [<value 1- 1000>...
Page 202 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config igmp_snooping querier Purpose This command is used to configure the IGPM snooping querier. Syntax config igmp_snooping querier [vlan_name <vlan_name 32> | vlanid <vlanid_list> | all] {query_interval <sec 1-65535> | max_response_time <sec 1-25> | robustness_variable <value 1-7>...
Page 203 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config igmp_snooping querier enable - Enter enable to enable this state. disable - Enter disable to disable this state. version - (Optional) Specify the version of IGMP packet that will be sent by this port. If an IGMP packet received by the interface has a version higher than the specified version, this packet will be dropped.
Page 204 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config router_ports_forbidden Purpose This command allows you to designate a range of ports as being not connected to multicast- enabled routers. Syntax config router_ports_forbidden [ <vlan_name 32> | vlanid <vlanid_list> ] [add | delete] <portlist>...
Page 205 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# create igmp_snooping static_group vlan default 239.1.1.1 Command: create igmp_snooping static_group vlan default 239.1.1.1 Success. DES-3528:admin# delete igmp_snooping static_group Purpose Used to delete a IGMP snooping multicast static group. Syntax delete igmp_snooping static_group [vlan<vlan_name 32>...
Page 206 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config igmp_snooping static_group vlan default 239.1.1.1 delete 2:9- 2:10 Command: create igmp_snooping static_group vlan default 239.1.1.1 delete 2:9-2:10 Success. DES-3528:admin# show igmp_snooping static_group Purpose This command is used to display the IGMP snooping multicast group static members. Syntax show igmp_snooping static_group {[vlan <vlan_name 32>...
Page 207 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config igmp_snooping data_driven_learning Purpose This command is used to enable or disable the data driven learning of an IGMP snooping group. Syntax config igmp_snooping data_driven_learning max_learned_entry <value 1-1024> [vlan_name <vlan_name>...
Page 208 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show igmp_snooping Purpose This command will display the current IGMP snooping configuration on the Switch. Syntax show igmp_snooping {[vlan <vlan_name 32> | vlanid <vlanid_list>]} Description This command will display the current IGMP snooping configuration on the Switch. Parameters vlan - (Optional) Specify the name of the VLAN for which you want to view the IGMP snooping configuration.
Page 209 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To display the IGMP snooping rate limit for ports 1 to 5: DES-3528:admin# show igmp_snooping rate_limit ports 1:1-1:5 Command: show igmp_snooping rate_limit ports 1:1-1:5 Port Rate Limit -------- ----------- No Limit...
Page 210 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show igmp_snooping group Command: show igmp_snooping group Source/Group : 10.0.0.2/225.0.0.2 VLAN Name/VID : default/1 Member Ports : 1-2 UP Time : 280 Expiry Time : 120 Filter Mode : INCLUDE Source/Group...
Page 211 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show igmp_snooping forwarding Purpose This command displays the Switch’s current IGMP snooping forwarding table. Syntax show igmp_snooping forwarding {[vlan <vlan_name 32> | vlanid <vlanid_list>]} Description It provides an easy way for users to check the list of ports that the multicast group that comes from a specific sources will be forwarded to.
Page 212 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show router_ports Purpose This command displays the currently configured router ports on the Switch. Syntax show router_ports {[vlan <vlan_name 32> | vlanid <vlanid_list> | all]} {static | dynamic | forbidden} Description This command displays the currently configured router ports on the Switch.
Page 213 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show igmp_snooping statistics counter Purpose This command displays the statistics counter for IGMP protocol packets that are received by the Switch since IGMP snooping was enabled. Syntax show igmp_snooping statistic counter [vlan <vlan_name>...
Page 214 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To display the IGMP snooping statistics counter for a port: DES-3528:admin# show igmp_snooping statistics counter ports 1 Command: show igmp_snooping statistics counter ports 1 ： 1 Port # ------------------------------------------------ Total Groups : 10...
Page 215 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# clear igmp_snooping statistic counter Command: clear igmp_snooping statistic counter Success. DES-3528:admin# config mld_snooping Purpose This command is used to configure MLD snooping on the Switch. Syntax config mld_snooping [vlan_name <vlan_name 32>...
Page 216 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mld_snooping querier Purpose This command is used to configure the MLD snooping querier. Syntax config mld_snooping querier [vlan_name <vlan_name 32> | vlanid <vlanid_list> | all] {query_interval <sec 1-65535> | max_response_time <sec 1-25> | robustness_variable <value 1-7>...
Page 217 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mld_snooping querier <value 1-2> - Enter the version number value here. This value must be between 1 and 2. Restrictions Only Administrator and Operator and Power-User-level users can issue this command. Example usage: To configure the MLD snooping querier: DES-3528:admin# config mld_snooping querier vlan_name default query_interval 125 state...
Page 218 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mld_snooping router_ports_forbidden Purpose This command allows you to designate a range of ports as being not connected to multicast- enabled routers. Syntax config mld_snooping mrouter_ports_forbidden [vlan <vlan_name 32> | vlanid <vlanid_list>] [add | delete] <portlist>...
Page 219 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show mld_snooping Command: show mld_snooping MLD Snooping Global State : Disabled Data Driven Learning Max Entries : 128 VLAN Name : default Query Interval : 125 Max Response Time : 10 Robustness Value...
Page 220 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide The fourth item is a data-driven learned entry. The member port list is empty. The multicast packets will be forwarded to the router ports. If the router port list is empty, the packet will be dropped. DES-3528:admin# show mld_snooping group Command: show mld_snooping group...
Page 221 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show mld_snooping forwarding Purpose This command displays the Switch’s current MLD snooping forwarding table. Syntax show mld_snooping forwarding {[vlan <vlan_name 32> | vlanid <vlanid_list>]} Description It provides an easy way for users to check the list of ports that the multicast group that comes from specific sources will be forwarded to.
Page 222 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show mld_snooping mrouter_ports Purpose This command displays the currently configured router ports on the Switch. Syntax show mld_snooping mrouter_ports [vlan <vlan_name 32> | vlanid <vlanid_list> | all] {[static | dynamic | forbidden]} Description This command displays the currently configured router ports on the Switch.
Page 223 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create mld_snooping static_group Purpose This command allows you to create an MLD snooping static group. Syntax create mld_snooping static_group [vlan <vlan_name 32> | vlanid <vlanid_list>] <ipv6addr> Description Member ports can be added to the static group.
Page 224 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mld_snooping static_group Purpose Used to configure an MLD snooping multicast group static member port. Syntax config mld_snooping static_group [vlan <vlan_name 32> | vlanid <vlanid_list>] <ipv6addr> [add | delete] <portlist> Description When a port is configured as a static member port, the MLD protocol will not operate on this port.
Page 225 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mld_snooping data_driven_learning Purpose This command is used to enable or disable the data-driven learning of an MLD snooping group. Syntax config mld_snooping data_driven_learning max_learned_entry <value 1-1024> [vlan_name <vlan_name>...
Page 226 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide clear mld_snooping data_driven_group Purpose Used to delete the MLD snooping groups learned by data driven. Syntax clear mld_snooping data_driven_group [all | [vlan_name <vlan_name> | vlanid <vlanid_list>] [<ipv6addr> | all]] Description Used to delete the MLD snooping groups learned by data driven.
Page 227 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show mld_snooping statistics counter vlanid 1 Command: show mld_snooping statistics counter vlanid 1 VLAN Name : default ----------------------------------------------- Group Number : 10 Receive Statistics Query MLD v1 Query MLD v2 Query Total Dropped By Rate Limitation...
Page 228 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mld_snooping rate_limit Purpose The command configures the rate limit of MLD control packets that are allowed by each port or VLAN. Syntax config mld_snooping rate_limit [ports <portlist> | vlanid <vlanid_list>] [<value 1-1000> | no_limit] Description The command configures the rate limit of MLD control packets that are allowed by each port...
Page 229 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config igmp access_authentication ports Purpose This command is used to enable or disable the IGMP Access Control function for the specified ports. Syntax config igmp access_authentication ports [all | <portlist>] state [enable | disable] Description If the IGMP Access Control function is enabled and the Switch receives an IGMP JOIN message, the Switch will send the access request to the RADIUS server for authentication.
Page 230 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#show igmp access_authentication ports all Command: show igmp access_authentication ports all Port State ----- --------- Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled 1:10 Enabled 1:11 Enabled 1:12 Enabled...
Page 231: Dhcp Relay Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DHCP Relay Commands The DHCP relay commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config dhcp_relay {hops <value 1-16>...
Page 232 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcp_relay Purpose Used to configure the DHCP/BOOTP relay feature of the Switch. Syntax config dhcp_relay {hops <value 1-16> | time <sec 0-65535>}(1) Description This command is used to configure the DHCP/BOOTP relay feature. hops <value 1-16>...
Page 233 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config dhcp_relay delete ipif System 10.58.44.6 Command: config dhcp_relay delete ipif System 10.58.44.6 Success. DES-3528:admin# config dhcp_relay option_82 state Purpose Used to configure the state of DHCP relay agent information option 82 of the Switch. Syntax config dhcp_relay option_82 state [enable | disable] Description...
Page 234 Only Administrator and Operator and Power-User-level users can issue this command. Example usage: To configure DHCP relay option 82 remote ID: DES-3528:admin# config dhcp_relay option_82 remote_id user_define D-Link L2 Switch Command: config dhcp_relay option_82 remote_id user_define D-Link L2 Switch Success. DES-3528:admin#...
Page 235 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show dhcp_relay Purpose Used to display the current DHCP/BOOTP relay configuration. Syntax show dhcp_relay {ipif <ipif_name 12>} Description This command will display the current DHCP relay configuration for the Switch, or if an IP interface name is specified, the DHCP relay configuration for that IP interface.
Page 236 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable dhcp_relay Purpose Used to enable the DHCP/BOOTP relay function on the Switch. Syntax enable dhcp_relay Description This command is used to enable the DHCP/BOOTP relay function on the Switch. Parameters None.
Page 237 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config dhcp_relay option_60 state enable Command: config dhcp_relay option_60 state enable Success. DES-3528:admin# config dhcp_relay option_60 add Purpose This command is used to add a entry for dhcp_relay option_60 Syntax config dhcp_relay option_60 add string <mutiword 255>...
Page 238 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcp_relay option_60 delete Purpose This command is used to delete dhcp_relay option_60 entry. Syntax config dhcp_relay option_60 delete [string <mutiword 255> {relay <ipaddr>} | ipaddress <ipaddr> | all | default {<ipaddr>}] Description This command can delete the entry specifed by user.
Page 239 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcp_relay option_61 state Purpose This command is used to configure the DHCP relay option 61 state. Syntax config dhcp_relay option_61 state [enable | disable] Description This command decides whether DHCP relay will process the DHCP option 61 or not. When enabled, if packets do not have option 61, then the relay servers cannot be determined based on option 61.
Page 240 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcp_relay option_61 default Purpose Used to determine the default action for option 61. Syntax config dhcp_relay option_61 default [relay <ipaddr> | drop] Description This command is used to determine the rule to process those packets that have no option 61 matching rules.
Page 241 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Matching Rules: Client-ID Type Relay Rule ----------- ---- --------- 00-01-22-33-44-55 MAC Address Drop Total Entries : 1 DES-3528:admin# config dhcp_local_relay vlan Purpose Used to enable or disable DHCP local relay function to the vlan. Syntax config dhcp_local_relay vlan <vlan_name 32>...
Page 242 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable dhcp_local_relay Purpose Used to disable the DHCP local relay function on the Switch. Syntax disable dhcp_local_relay Description This command is used to disable the DHCP local relay function on the Switch. Parameters None.
Page 243 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config dhcp_relay add vlanid 1-10 10.43.21.12 Command: config dhcp_relay add vlanid 1-10 10.43.21.12 Success. DES-3528:admin# # To display the DHCP relay status: DES-3528:admin# show dhcp_relay Command: show dhcp_relay DHCP/BOOTP Relay Status : Disabled DHCP/BOOTP Hops Count Limit...
Page 244: Commands (Including Guest Vlans)
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide 802.1X Commands (Including Guest VLANs) The Switch implements the server-side of the IEEE 802.1X Port-based and Host-based Network Access Control. This mechanism is intended to allow only authorized users, or other network devices, access to network resources by establishing criteria for each port on the Switch that a user or network device must meet before allowing that port to forward or receive frames.
Page 245 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters show auth_session_statistics {ports <portlist>} show auth_client show acct_client config accounting service [network | shell | system] state [enable | disable] show accounting service Each command is listed, in detail, in the following sections: enable 802.1x Purpose Used to enable the 802.1X server on the Switch.
Page 246 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create 802.1x user Purpose Used to create 802.1X user. Syntax create 802.1x user <username 15> Description This command creates an 802.1X user. <username 15> − Specifies adding user name Parameters Restrictions Only Administrator-level users can issue this command.
Page 247 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Total Entries:1 DES-3528:admin# config 802.1x auth_protocol Purpose Used to configure the 802.1X auth protocol Syntax config 802.1x auth_protocol [local | radius_eap] Description This command configures the 802.1X auth protocol. local −...
Page 248 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config 802.1x authorization attributes Purpose Used to enable or disable the accepting of authorized configuration. Syntax config 802.1x authorization attributes radius [enable | disable] Description This command is used to enable or disable the accepting of authorized configuration. When the authorization is enabled for 802.1x’s radius, the authorized data assigned by the RADUIS server will be accepted by the Switch if the global authorization network is enabled.
Page 249 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show 802.1x Purpose Used to display the 802.1X state or configurations. Syntax show 802.1x { [auth_state | auth_configuration] ports {<portlist>} } Description This command displays the 802.1X state or configurations. auth_state −...
Page 250 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config 802.1x capability Purpose Used to configure the port capability. Syntax config 802.1x capability ports [<portlist> | all] [authenticator | none] Description This command configures the port capability. portlist −...
Page 251 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config 802.1x auth_parameter Purpose Used to configure the parameters that control the operation of the authenticator associated with a port. Syntax config 802.1x auth_parameter ports [<portlist> | all] [default | {direction [both | in] | port_control [force_unauth | auto | force_auth] | quiet_period <sec 0-65535>...
Page 252 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config 802.1x init Purpose Used to initialize the authentication state machine of some or all ports. Syntax config 802.1x init [port_based ports [<portlist | all>] | mac_based ports [<portlist> | all] {mac_address <macaddr>}] Description This command is used to initialize the authentication state machine of some or all.
Page 253 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create 802.1x guest_vlan Purpose Used to configure a pre-existing VLAN as an 802.1X Guest VLAN. Syntax create 802.1x guest_vlan <vlan_name 32> Description This command is used to configure a pre-defined VLAN as a 802.1X Guest VLAN. 802.1X Guest VLAN clients are those who have not been authorized for 802.1X or they haven’t yet installed the necessary 802.1X software, yet would still like limited access rights on the Switch.
Page 254 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show 802.1x guest_vlan Purpose Used to view the configurations for an 802.1X Guest VLAN. Syntax show 802.1x guest_vlan Description This command is used to display the settings for the VLAN that has been enabled as an 802.1X Guest VLAN.
Page 255 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config radius add Purpose Used to configure the settings the Switch will use to communicate with a RADIUS server. Syntax config radius add <server_index 1-3> [<server_ip> | <ipv6addr>] key <passwd 32> [default | {auth_port <udp_port_number 1-65535>...
Page 256 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config radius Purpose Used to configure the Switch’s RADIUS settings. Syntax config radius <server_index 1-3> {ipaddress [<server_ip> | <ipv6addr>] | key <passwd 32> | auth_port [<udp_port_number 1-65535> | default] | acct_port [<udp_port_number 1-65535>...
Page 257 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Total Entries : 1 DES-3528:admin# show auth_statistics Purpose Used to display authenticator statistics information. Syntax show auth_statistics {ports <portlist>} Description This command displays authenticator statistics information. portlist − Specifies a range of ports to be shown. Parameters all −...
Page 258 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show auth_diagnostics ports 1 Command: show auth_diagnostics ports 1 Port number : 1 Original RX VID MAC Address 00-05-5D-F9-16-76 EntersConnecting EapLogoffsWhileConnecting EntersAuthenticating SuccessWhileAuthenticating TimeoutsWhileAuthenticating FailWhileAuthenticating ReauthsWhileAuthenticating EapStartsWhileAuthenticating EapLogoffWhileAuthenticating ReauthsWhileAuthenticated...
Page 259 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show auth_client Purpose Used to display authentication client information Syntax show auth_client Description This command displays authentication client information Parameters None. Restrictions None. Example usage: To display authentication client information: DES-3528:admin# show auth_client Command: show auth_client radiusAuthClient ==>...
Page 260 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide radiusAccClientServerPortNumber radiusAccClientRoundTripTime radiusAccClientRequests radiusAccClientRetransmissions radiusAccClientResponses radiusAccClientMalformedResponses radiusAccClientBadAuthenticators radiusAccClientPendingRequests radiusAccClientTimeouts radiusAccClientUnknownTypes radiusAccClientPacketsDropped CTRL+C ESC q Quit SPACE n Next Page Previous Page Refresh config accounting service Purpose Used to configure the state of the specified RADIUS accounting service. Syntax config accounting service [network | shell | system] state [enable | disable] Description...
Page 261 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Accounting Service ------------------- Network : Enabled Shell : Enabled System : Enabled DES-3528:admin#...
Page 262: Access Control List (Acl) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Access Control List (ACL) Commands The Switch implements Access Control Lists that enable the Switch to deny network access to specific devices or device groups based on IP settings and MAC address. Access profiles allows establishment of a criteria to determine whether or not the Switch will forward packets based on the information contained in each packet’s header.
Page 263 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters delete access_profile [profile_id <value 1-14> | profile_name <name 1-32> | all] config access_profile [profile_id <value 1-14> | profile_name <name 1-32>] [add access_id [auto_assign | <value 1-128>] [ethernet {[vlan <vlan_name 32> | vlan_id <vlanid 1-4094>] {mask <hex 0x0-0x0fff>} | source_mac <macaddr>...
Page 264 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters 0xffffffff> | offset_64-79 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> } | ipv6 {class <value 0-255> | flowlabel <hex 0x0-0xfffff> | source_ipv6 <ipv6addr> | destination_ipv6 <ipv6addr>}] port [<portlist> | all] [permit | deny] {time_range <range_name 32>} | delete access_id <value 1-100>] show cpu profile_id <value 1-5>...
Page 265 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create access_profile Purpose Used to create an access profile on the Switch and to define which parts of each incoming frame’s header the Switch will examine. Masks can be entered that will be combined with the values the Switch finds in the specified frame header fields.
Page 266 With this advanced unique Packet Content Mask (also known as Packet Content Access Control List - ACL), D-Link xStack Switch family can effectively mitigate some network attacks like the common ARP Spoofing attack that is wide spread today. This is the reason why Packet Content ACL is able to inspect any specified content of a packet in different protocol layers.
Page 267 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide 00-00-00-00-00-01 destination_mac 00-00-00-00-00-02 802.1p ethernet_type Success. DES-3528:admin# delete access_profile Purpose Used to delete a previously created access profile. Syntax delete access_profile [profile_id <value 1-14> | profile_name <name 1-32> | all] Description This command is used to delete a previously created access profile on the Switch.
Page 268 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config access_profile Purpose Used to configure an access profile on the Switch and to define specific values that will be used to by the Switch to determine if a given packet should be forwarded or filtered. Masks entered using the create access_profile command will be combined, using a logical AND operational method, with the values the Switch finds in the specified frame header fields.
Page 269 • With this advanced unique Packet Content Mask (also known as Packet Content Access Control List - ACL), D-Link xStack Switch family can effectively mitigate some network attacks like the common ARP Spoofing attack that is wide spread today. This is the reason that Packet Content ACL is able to inspect any specified content of a packet in different protocol layers.
Page 270 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config access_profile tcp – Specifies that the Switch will examine each frame’s Transmission Control Protocol (TCP) field. − • src_port_mask <hex 0x0-0xffff> Specifies a TCP port mask for the source port. •...
Page 271 ARP spoofing attack). For a more detailed explaination on how ARP protocol works and how to employ D-Link’s advanced unique Packet Content ACL to prevent an ARP spoofing attack, please see Appendix B, at the end of this manual.
Page 272 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create cpu access_profile Used to create an access profile specifically for CPU Interface Filtering on the Switch and Purpose to define which parts of each incoming frame’s header the Switch will examine. Masks can be entered that will be combined with the values the Switch finds in the specified frame header fields.
Page 273 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create cpu access_profile and fin (finish). udp − Specifies that the Switch will examine each frame’s User Datagram Protocol • (UDP) field. src_port_mask <hex 0x0-0xffff> − Specifies a UDP port mask for the source port. •...
Page 274 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete cpu access_profile Purpose Used to delete a previously created CPU access profile. Syntax delete cpu access_profile [profile_id <value 1-5 | all] Description This command is used to delete a previously created CPU access profile. profile_id <value 1-5>...
Page 275 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config cpu access_profile Purpose Used to configure a CPU access profile used for CPU Interface Filtering and to define specific values that will be used to by the Switch to determine if a given packet should be forwarded or filtered.
Page 276 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config cpu access_profile value. • code <value 0-255> − Specifies that the access profile will apply to this ICMP code value. igmp − Specifies that the Switch will examine the Internet Group Management Protocol (IGMP) field within each packet.
Page 277 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config cpu access_profile time_range – Specifies the time range profile that has been associated with the ACL entries. delete access_id <value 1-100> − Use this to remove a previously created access rule in a profile ID.
Page 278 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable cpu_interface_filtering Purpose Used to enable CPU interface filtering on the Switch. Syntax enable cpu_interface_filtering Description This command is used, in conjunction with the disable cpu_interface_filtering command below, to enable and disable CPU interface filtering on the Switch.
Page 279 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config flow_meter Purpose Used to configure packet flow-based metering based on an access profile and rule. Syntax config flow_meter [profile_id <value 1-14> | profile_name <name 1-32>] access_id <value 1-128>...
Page 280 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config flow_meter pbs - (Optional) Specifies the “Peak Burst Size”. The unit is in Kbytes. This parameter is an optional parameter. The default value is 4Kbyte. <value 0-16384> - Enter the peak burst size value here. conform - (Optional) Specifies the action when a packet is mapped to the “green”...
Page 281 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config flow_meter <value 0-63> - Enter the replace DSCP value here. drop - Drops the packet. counter - (Optional) Specifies the ACL counter. This is optional. The default is “disable”. The resource may be limited so that a counter cannot be turned on.
Page 282 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Conform : Permit Replace DSCP: 11 Counter: Enabled Exceed : Permit Replace DSCP: 22 Counter: Enabled Violate : Drop Counter: Disabled ------------------------------------------------------------------------------ Profile ID:1 Aceess ID:2 Mode : srTCM CIR(Kbps):2500 CBS(Kbyte):2000 EBS(Kbyte):3500...
Page 283 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show time_range Purpose Used to display current access list table. Syntax show time_range Description This command displays current time range setting. Parameters None. Restrictions None. Example usage: To show the time range on the Switch: DES-3528:admin# show time_range Command: show time_range...
Page 284: Safeguard Engine Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Safeguard Engine Commands Periodically, malicious hosts on the network will attack the Switch by utilizing packet flooding (ARP Storm) or other methods. These attacks may increase the CPU utilization beyond its capability. To alleviate this problem, the Safeguard Engine function was added to the Switch’s software.
Page 285 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config safeguard_engine Purpose Used to configure ARP storm control for system. Syntax config safeguard_engine { state [enable | disable] | utilization { rising <value 20-100> | falling <value 20-100>} | trap_log [enable | disable] | mode [ strict | fuzzy] }(1) Description This command is used to configure Safeguard Engine to minimize the effects of an ARP storm.
Page 286 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide CPU Utilization Information: Rising Threshold Falling Threshold : Trap/Log State Enabled Mode Strict DES-3528:admin#...
Page 287: Filter Commands (Dhcp Server / Netbios)
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Filter Commands (DHCP Server / NetBIOS) DHCP Server Screening Settings This function allows you not only to restrict all DHCP Server packets but also to receive any specified DHCP server packets by any specified DHCP client.
Page 288 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config filter dhcp_server Purpose DHCP server packets except those that have been IP/client MAC bound will be filtered. This command is used to configure the state of the function for filtering of DHCP server packet and to add/delete the DHCP server/client binding entry.
Page 289 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success DES-3528:admin# To configure the DHCP filter state: DES-3528:admin# config filter dhcp_server ports 1-10 state enable Command: config filter dhcp_server ports 1-10 state enable Success DES-3528:admin# show filter dhcp_server Purpose Used to display current DHCP server/client filter list created on the Switch.
Page 290 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config filter netbios 1-10 state enable Command: config filter netbios 1-10 state enable Success. DES-3528:admin# show filter netbios Purpose Used to display the Switch settings to filter NetBIOS packets from specified ports. Syntax show filter netbios Description...
Page 291 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show filter extensive_netbios Purpose Used to display the Switch settings to filter NetBIOS packets from specified ports. Syntax show filter extensive_netbios Description This command will display the Switch settings to filter NetBIOS packets from the specified ports.
Page 292: Layer 3 Cpu Filter Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Layer 3 CPU Filter Commands The L3 CPU Filter commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. When the Switch receives a packet such as PIM, DVMRP or IGMP query, the L3 CPU filter mode will determine how the packet is handled.
Page 293 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Port IGMP Query DVMRP ---- ---------- -------- ----------- Disabled Disabled Disabled Disabled Disabled Disabled DES-3528:admin#...
Page 294: Loop-Back Detection Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Loop-back Detection Commands The Loop-back Detection commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config loopdetect {recover_timer [0 | <sec 60-1000000>] | interval <sec 1-32767>...
Page 295 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config loopdetect recover_timer 0 interval 20 mode vlan-based Command: config loopdetect recover_timer 0 interval 20 mode vlan-based Success DES-3528:admin# config loopdetect ports Purpose Used to configure loop-back detection on the Switch. Syntax config loopdetect ports [<portlist>...
Page 296 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable loopdetect Purpose Used to globally enable loop-back detection on the Switch. Syntax enable loopdetect Description This command is used to globally enable loop-back detection on the Switch. Parameters None.
Page 297 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#show loopdetect Command: show loopdetect LBD Global Settings --------------------------- Status : Disabled Mode : Port-based Interval : 10 sec Recover Time : 60 sec Trap State : None Log State : Enabled Function Version : 4.04...
Page 298 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#...
Page 299: Traffic Segmentation Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Traffic Segmentation Commands Traffic segmentation allows users to further sub-divide VLANs into smaller groups of ports that will help to reduce traffic on the VLAN. The VLAN rules take precedence, and then the traffic segmentation rules are applied. Command Parameters config traffic_segmentation...
Page 300 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide ---- ---------------------------- 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 1-26 CTRL+C ESC q Quit SPACE n Next Page ENTER Next Entry...
Page 301: Sflow Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide sFlow Commands The sFlow commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable sflow disable sflow show sflow create sflow flow_sampler [<portlist>...
Page 302 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable sflow Purpose Used to disable the sFlow function. Syntax disable sflow Description This command disables the sFlow function. Parameters None. Restrictions Only Administrator and Operator-level users can issue this command. Example usage: To disable sflow: DES-3528:admin# disable sflow...
Page 303 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create sflow flow_sampler ports Purpose Used to create the sflow flow_sampler. Syntax create sflow flow_sampler ports [<portlist> | all] analyzer_server_id < value 1-4> { rate <value 0- 65535> | maxheadersize < value 18-256>} Description This command is used to create the sFlow flow_sampler.
Page 304 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete sflow flow_sampler ports Purpose Used to delete the sflow flow_sampler. Syntax delete sflow flow_sampler ports [<portlist> | all] Description This command is used to delete the sflow flow_sampler that has been configured for the specified port.
Page 305 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create sflow counter_poller ports Purpose Used to create the counter poller for the sFlow function of the Switch. Syntax create sflow counter_poller ports [<portlist> | all] analyzer_server_id < value 1-4> {interval [disable | <sec 20-120>]} Description This command is used to configure the settings for the Switch’s counter poller.
Page 306 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete sflow counter_poller ports Purpose Used to delete the sflow counter_poller. Syntax delete sflow counter_poller ports [<portlist> | all] Description This command deletes the sflow counter_poller from the specified port . Parameters ports –...
Page 307 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create sflow analyzer_server Purpose Used to create the analyzer_server. Syntax create sflow analyzer_server < value 1-4 > owner<name 16> { timeout [<sec 1- 2000000> | infinite] | collectoraddress <ipaddr> | collectorport <udp_port_number 1- 65535>...
Page 308 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# delete sflow analyzer_server Purpose Used to delete the analyzer_server. Syntax delete sflow analyzer_server < value 1-4 > Description This command deletes the analyzer_server. Parameters value – analyzer_server ID. Restrictions Only Administrator and Operator-level users can issue this command.
Page 309: Time And Sntp Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Time and SNTP Commands The Simple Network Time Protocol (SNTP) (an adaptation of the Network Time Protocol (NTP)) commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config sntp...
Page 310 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config sntp ipv6server Purpose This command is used to configure the SNTP IPv6 server information. Syntax config sntp ipv6server {primary <ipv6addr> | secondary <ipv6addr>} Description If both SNTP IPv4 and IPv6 servers are configured, the SNTP IPv4 server has higher priority, the Switch’s time syncs with the IPv4 server’s time first.
Page 311 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable sntp Purpose Used to enable SNTP server support. Syntax enable sntp Description This command enables SNTP support. SNTP service must be separately configured (see config sntp). Enabling and configuring SNTP support will override any manually configured system time settings.
Page 312 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To manually set system time and date settings: DES-3528:admin# config time 30jul2013 16:30:30 Command: config time 30jul2013 16:30:30 Success. DES-3528:admin# config time_zone Purpose Used to determine the time zone used in order to adjust the system clock. Syntax config time_zone {operator [+ | -] | hour <gmt_hour 0-13>...
Page 313 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dst Purpose Used to enable and configure time adjustments to allow for the use of Daylight Savings Time (DST). Syntax config dst [disable | repeating {s_week <start_week 1-4,last> | s_day <start_day sun- sat>...
Page 314 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To configure daylight savings time on the Switch: DES-3528:admin# config dst repeating s_week 2 s_day tue s_mth 4 s_time 15:00 e_week 2 e_day wed e_mth 10 e_time 15:30 offset 30 Command: config dst repeating s_week 2 s_day tue s_mth 4 s_time 15:00 e_week 2 e_day wed e_mth 10 e_time 15:30 offset 30 Success.
Page 315: Arp And Gratuitous Arp Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide ARP and Gratuitous ARP Commands The ARP commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create arpentry <ipaddr>...
Page 316 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config arpentry Purpose Used to configure a static entry in the ARP table. Syntax config arpentry <ipaddr> <macaddr> Description This command is used to configure a static entry in the ARP Table. The user may specify the IP address and the corresponding MAC address of an entry in the Switch’s ARP table.
Page 317 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config arp_aging time 30 Command: config arp_aging time 30 Success. DES-3528:admin# show arpentry Purpose Used to display the ARP table. Syntax show arpentry {ipif <ipif_name 12> | ipaddress <ipaddr> | static | mac_address <macaddr>} Description This command is used to display the current contents of the Switch’s ARP table.
Page 318 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide clear arptable Purpose Used to remove all dynamic ARP table entries. Syntax clear arptable Description This command is used to remove dynamic ARP table entries from the Switch’s ARP table. Static ARP table entries are not affected.
Page 319 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config gratuitous_arp send dup_ip_detected Purpose Used to enable/disable the sending of gratuitous ARP requests while a duplicate IP address is being detected. Syntax config gratuitous_arp send duplicate_ip_detected [enable | disable] Description The command is used to enable/disable the sending of gratuitous ARP request packets when a duplicate IP has been detected.
Page 320 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable gratuitous_arp Purpose Used to enable gratuitous ARP trap and log state. Syntax enable gratuitous_arp {ipif <ipif_name 12>} {trap | log }(1) Description The command is used to enable gratuitous ARP trap and log state. The Switch can trap and log the IP conflict event to inform the administrator.
Page 321 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command: config gratuitous_arp send periodically ipif System interval 5 Success. DES-3528:admin# show gratuitous arp Purpose Used to display gratuitous ARP configuration. Syntax show gratuitous_arp {ipif <ipif_name>} Description This command is used to display gratuitous ARP configuration.
Page 322: Routing Table Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Routing Table Commands The routing table commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create iproute [default | <network_address>] <ipaddr>...
Page 323 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show iproute Purpose Used to display the Switch’s current IP routing table. Syntax show iproute {<network_address> | <ipaddr>} {static} Description This command will display the Switch’s current IP routing table. Parameters <network_address>...
Page 324: Mac Notification Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide MAC Notification Commands The MAC notification commands in the Command Line Interface (CLI) are listed, in the following table, along with their appropriate parameters. Command Parameters enable mac_notification disable mac_notification config mac_notification {interval <int 1-2147483647>...
Page 325 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mac_notification Purpose Used to configure MAC address notification. Syntax config mac_notification {interval <int 1-2147483647> | historysize <int 1-500>}(1) Description This command is used to monitor MAC addresses learned and entered into the FDB. interval <sec 1-2147483647>...
Page 326 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command: show mac_notification Global MAC Notification Settings State : Enabled Interval History Size DES-3528:admin# show mac_notification ports Used to display the Switch’s MAC address table notification status settings. Purpose show mac_notification ports {<portlist>} Syntax...
Page 327: Access Authentication Control Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Access Authentication Control Commands The TACACS / XTACACS / TACACS+ / RADIUS commands allows secure access to the Switch using the TACACS / XTACACS / TACACS+ / RADIUS protocols. When a user logs in to the Switch or tries to access the administrator level privilege, he or she is prompted for a password.
Page 328 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide The Access Authentication Control commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable authen_policy disable authen_policy show authen_policy create authen_login <string 15>...
Page 329 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable authen_policy Purpose Used to enable system access authentication policy. Syntax enable authen_policy Description This command will enable an administrator-defined authentication policy for users trying to access the Switch. When enabled, the device will check the method list and choose a technique for user authentication upon login.
Page 330 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Authentication Policy: Enabled DES-3528:admin# create authen_login method_list_name Purpose Used to create a user-defined method list of authentication methods for user login. Syntax create authen_login method_list_name <string 15> Description This command is used to create a list for authentication techniques for user login.
Page 331 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authen_login Purpose Used to configure a user-defined or default method list of authentication methods for user login. Syntax config authen_login [default | method_list_name <string 15>] method {tacacs | xtacacs | tacacs+ | radius | server_group <string 15>...
Page 332 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authen_login  none – Adding this parameter will require no authentication to access the Switch. NOTE: Entering none or local as an authentication protocol will override any other authentication that follows it on a method list or on the default method list.
Page 333 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show authen_login Purpose Used to show a user-defined or default or all method lists of authentication methods for user login. Syntax show authen_login [default | method_list_name <string 15> | all] Description This command is used to show a list of authentication methods for user login.
Page 334 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create authen_enable method_list_name Purpose Used to create a user-defined method list of authentication methods for promoting user's privilege to Admin level. Syntax create authen_enable method_list_name <string 15> Description This command is used to promote users with normal level privileges to Administrator level privileges using authentication methods on the Switch.
Page 335 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authen_enable Purpose Used to configure a user-defined or default method list of authentication methods for promoting user's privilege to Admin level. Syntax config authen_enable [default | method_list_name <string 15>] method {tacacs | xtacacs | tacacs+ | radius | server_group <string 15>...
Page 336 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authen_enable local_enable − Adding this parameter will require the user to be authenticated using  the local user account database on the Switch. The local enable password of the device can be configured using the “config admin local_enable”...
Page 337 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show authen_enable Purpose Used to show a user-defined or default or all method lists for promoting user's privilege to Admin level. Syntax show authen_enable [default | method_list_name <string 15> | all] Description This command is used to display a user-defined method list of authentication methods for promoting user level privileges to Administrator level privileges.
Page 338 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authen application Purpose Used to configure login or enable method list for all or the specified application. Syntax config authen application [console | telnet | ssh | http | all] [login | enable] [default | method_list_name <string 15>] Description This command is used to configure Switch configuration applications (console, telnet, ssh,...
Page 339 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide -------------- ---------------- ----------------------- Console default default Telnet Trinity default default default HTTP default default DES-3528:admin# create authen server_host Purpose Used to create an authentication server host. Syntax create authen server_host <ipaddr>...
Page 340 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authen server_host Purpose Used to configure an authentication server host. Syntax config authen server_host <ipaddr> protocol [tacacs | xtacacs | tacacs+ | radius] {port <int 1-65535> | key [<key_string 254> | none] | timeout <int 1-255> | retransmit <int 1- 20>}(1) Description This command will configure a user-defined authentication server host for the...
Page 341 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete authen server_host Purpose Used to delete an authentication server host. Syntax delete authen server_host <ipaddr> protocol [tacacs | xtacacs | tacacs+ | radius] Description This command is used to delete a user-defined authentication server host previously created on the Switch.
Page 342 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# create authen server_group Purpose Used to create a user-defined authentication server group. Syntax create authen server_group <string 15> Description This command will create an authentication server group. A server group is a technique used to group TACACS/XTACACS/TACACS+/RADIUS server hosts into user defined categories for authentication using method lists.
Page 343 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authen server_group Purpose Used to add or remove an authentication server host to or from the specified server group. Syntax config authen server_group [tacacs | xtacacs | tacacs+ | radius | <string 15>] [add | delete] server_host <ipaddr>...
Page 344 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete authen server_group Purpose Used to delete a user-defined authentication server group. Syntax delete authen server_group <string 15> Description This command will delete an authentication server group. <string 15>...
Page 345 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authen parameter response_timeout Purpose Used to configure the time in second waiting for user input. Syntax config authen parameter response_timeout <int 0-255> Description This command will set the time the Switch will wait for a response of authentication from the user.
Page 346 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show authen parameter Purpose Used to show the authentication parameters. Syntax show authen parameter Description This command will display the authentication parameters currently configured on the Switch, including the response timeout and user authentication attempts.
Page 347 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config admin local_enable Purpose Used to configure the local enable password for administrator level privileges. Syntax config admin local_enable Description This command will configure the locally enabled password for the enable admin command. When a user chooses the local_enable method to promote user level privileges to administrator privileges, he or she will be prompted to enter the password configured here that is set locally on the Switch.
Page 348: Secure Shell (Ssh) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Secure Shell (SSH) Commands The steps required to use the Secure Shell (SSH) protocol for secure communication between a remote PC (the SSH Client) and the Switch (the SSH Server), are as follows: Create a user account with admin-level access using the create account admin <username>...
Page 349 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable ssh Purpose Used to disable SSH. Syntax disable ssh Description This command allows users to disable SSH on the Switch. Parameters None. Restrictions Only Administrator and Operator and Power-User-level users can issue this command. Usage example: To disable SSH: DES-3528:admin# disable ssh...
Page 350 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show ssh authmode Purpose Used to display the SSH authentication mode setting. Syntax show ssh authmode Description This command will allow users to display the current SSH authentication setting on the Switch.
Page 351 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show ssh server Purpose Used to display the SSH server setting. Syntax show ssh server Description This command allows users to display the current SSH server setting. Parameters None.
Page 352 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show ssh user authmode Purpose Used to display the SSH user setting. Syntax show ssh user authmode Description This command allows users to display the current SSH user setting. Parameters None.
Page 353 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config ssh algorithm Purpose Used to configure the SSH algorithm. Syntax config ssh algorithm [3DES | AES128 | AES192 | AES256 | arcfour | blowfish | cast128 | twofish128 | twofish192 | twofish256 | MD5 | SHA1 | RSA | DSA] [enable | disable] Description This command allows users to configure the desired type of SSH algorithm used for...
Page 354 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide AES192 : Enabled AES256 : Enabled Arcfour : Enabled Blowfish : Enabled Cast128 : Enabled Twofish128 : Enabled Twofish192 : Enabled Twofish256 : Enabled Data Integrity Algorithm -------------------------- : Enabled SHA1...
Page 355: Secure Sockets Layer (Ssl) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Secure Sockets Layer (SSL) Commands Secure Sockets Layer or SSL is a security feature that will provide a secure communication path between a host and client through the use of authentication, digital signatures and encryption. These security functions are implemented through the use of a ciphersuite, which is a security string that determines the exact cryptographic parameters, specific encryption algorithms and key sizes to be used for an authentication session and consists of three levels: Key Exchange: The first part of the cyphersuite string specifies the public key algorithm to be used.
Page 356 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable ssl Purpose Used to enable the SSL function on the Switch. Syntax enable ssl {ciphersuite {RSA_with_RC4_128_MD5 | RSA_with_3DES_EDE_CBC_SHA | DHE_DSS_with_3DES_EDE_CBC_SHA | RSA_EXPORT_with_RC4_40_MD5}} Description This command will enable SSL on the Switch by implementing any one or combination of listed ciphersuites on the Switch.
Page 357 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable ssl Purpose Used to disable the SSL function on the Switch. Syntax disable ssl {ciphersuite {RSA_with_RC4_128_MD5 | RSA_with_3DES_EDE_CBC_SHA | DHE_DSS_with_3DES_EDE_CBC_SHA | RSA_EXPORT_with_RC4_40_MD5}} Description This command will disable SSL on the Switch and can be used to disable any one or combination of listed ciphersuites on the Switch.
Page 358 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# show ssl cachetimeout Purpose Used to show the SSL cache timeout. Syntax show ssl cachetimeout Description This command allows the user to view the SSL cache timeout currently implemented on the Switch.
Page 359 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command: show ssl certificate Loaded with RSA Certificate! DES-3528:admin# download ssl certificate Purpose Used to download a certificate file for the SSL function on the Switch. Syntax download ssl certificate <ipaddr>...
Page 360: D-Link Single Ip Management Commands
D-Link Single IP Management Commands Simply put, D-Link Single IP Management is a concept that will stack Switches together over Ethernet instead of using stacking ports or modules. Switches using D-Link Single IP Management (labeled here as SIM) must conform to the following rules: SIM is an optional feature on the Switch and can easily be enabled or disabled.
Page 361 Log – The Switch now supports uploading multiple MS log files to a TFTP server. NOTE: For more details regarding improvements made in SIMv1.6, please refer to the White Paper located on the D-Link website. The SIM commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.
Page 362 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable sim Purpose Used to enable Single IP Management (SIM) on the Switch Syntax enable sim Description This command will enable SIM globally on the Switch. SIM features and functions will not function properly unless this function is enabled.
Page 363 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show sim Purpose Used to view the current information regarding the SIM group on the Switch. Syntax show sim {[candidates {<candidate_id 1-100>} | members {<member_id 1-32>} | group {commander_mac <macaddr>}] | neighbor]} Description This command will display the current information regarding the SIM group on the Switch,...
Page 364 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To show the candidate information in summary, if the candidate ID is specified: DES-3528:admin# show sim candidates Command: show sim candidates MAC Address Platform / Hold Firmware Device Name Capability Time...
Page 365 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide reconfig Purpose Used to connect to a member Switch, through the commander Switch, using Telnet. Syntax reconfig [member_id <value 1-32> | exit] Description This command is used to reconnect to a member Switch using Telnet. member_id <value 1-32>...
Page 366 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config sim Purpose Used to configure role parameters for the SIM protocol on the Switch. Syntax config sim [{[commander {group_name <groupname 64> | candidate] | dp_interval <30-90> | hold_time <sec 100-255>}] Description This command is used to configure parameters of Switches of the SIM.
Page 367 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To update the name of a group: DES-3528:admin# config sim commander group_name Trinity Command: config sim commander group_name Trinity Success. DES-3528:admin# download sim_ms Purpose Used to download firmware or configuration file to an indicated device. Syntax download sim_ms [firmware_from_tftp | configuration_from_tftp] <ipaddr>...
Page 368 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide upload sim_ms Purpose User to upload a configuration file to a TFTP server from a specified member of a SIM group. Syntax upload sim_ms [configuration_to_tftp | log_to_tftp] <ipaddr> <path_filename> {[ members <mslist>...
Page 369: Jwac Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide JWAC Commands The Japanese Web-based Access Control commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable jwac disable jwac enable jwac redirect...
Page 370 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters show jwac authenticate_page config jwac authentication_page [japanese | english] [default | page_title <desc 128> | login_window_title element <desc 32> | user_name_title <desc 16> | password_title <desc 16> | logout_window_title <desc 32>...
Page 371 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable jwac redirect Purpose Used to enable JWAC redirect function. Syntax enable jwac redirect Description This command is for the unauthenticated host to be redirected to the Quarantine Server when it tries to access a random URL, or JWAC login page in the Switch.
Page 372 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# disable jwac forcible_logout Purpose Used to disable JWAC forcible logout function. Syntax disable jwac forcible_logout Description This command is used to disable JWAC forcible logout function. Parameters None.
Page 373 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# enable jwac quarantine_server_monitor Purpose Used to enable JWAC quarantine server monitor. Syntax enable jwac quarantine_server_monitor Description This command is for the JWAC Switch to monitor the quarantine server ensuring that the server is okay.
Page 374 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config jwac quarantine_server_error_timeout 60 Command: config jwac quarantine_server_error_timeout 60 Success. DES-3528:admin# config jwac redirect Purpose Used to configure redirect destination and delay time before an unauthenticated host is redirected to the Quarantine Server or the JWAC login web page.
Page 375 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config jwac Purpose Used to configure JWAC Quarantine Server URL Syntax config jwac [quarantine_server_url <string 128> | clear_quarantine_server_url] Description This command allows you to configure the URL of the Quarantine Server. If the redirect is enabled and the redirect destination is the Quarantine Server, when an HTTP request from unauthenticated host not to the Quarantine Server reaches the JWAC Switch, the Switch will handle this HTTP packet and send back a message to the host to make it access the...
Page 376 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config jwac update_server Purpose Used to configure the servers that PC may need to connect to in order to complete the JWAC authentication Syntax config jwac update_server [add | delete] ipaddress <network_address> {[tcp_port <port_number 1-65535>...
Page 377 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config jwac switch_http_port Purpose Used to configure the TCP port which the JWAC Switch listens to. Syntax config jwac switch_http_port < tcp_port_number 1-65535> {[http | https]} Description This command allows you to configure the TCP port which the JWAC Switch listens to.
Page 378 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config jwac ports Purpose Used to configure port state of JWAC. Syntax config jwac ports [<portlist> | all] {state [enable | disable] | max_authenticating_host <value 0–n> | aging_time [infinite | <min 1–1440>] | idle_time [infinite | <min 1– 1440>] | block_time [<sec 0–300>]}(1) Description This command allows you to configure port state of JWAC.
Page 379 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config jwac radius_protocol Purpose Used to configure radius protocol used by JWAC. Syntax config jwac radius_protocol [local | eap_md5 | pap | chap | ms_chap | ms_chapv2] Description This command allows you to specify the RADIUS protocol used by JWAC to complete RADIUS authentication.
Page 380 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config jwac user Purpose Used to update local user DB. Syntax config jwac user <username 15> {vlan <vlanid 1-4094>} Description This command updates the local user DB. Only the created user can be configured. <username 15>...
Page 381 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Username Password ---------------- ---------- ---------------- twatanabe Total Entries:1 DES-3528:admin# clear jwac auth_state Purpose Used to delete hosts on JWAC enabled ports Syntax clear jwac auth_state [ports [all | <portlist>] {authenticated | authenticating | blocked} | mac_addr <macaddr>] Description This command allows you to delete JWAC host.
Page 382 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Q-Srv Error Timeout : 30 Seconds RADIUS Auth-Protocol : PAP Authentication Failover : Disabled RADIUS Authorization : Enabled Local Authorization : Enabled Update Server :172.18.202.1/32 172.18.202.0/24 10.1.1.0/24 DES-3528:admin# show jwac auth_state ports Purpose...
Page 383 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show jwac ports Purpose Used to display port configuration of JWAC Syntax show jwac ports {<portlist>} Description The show jwac port command allows you to display port configuration of JWAC Parameters <portlist>...
Page 384 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config jwac authorization attributes Purpose Used to enable or disable the accepting of authorized configuration. Syntax config jwac authorization attributes {radius [enable | disable] | local[enable | disable]}(1) Description This command allows the administrator to configure authorization network for JWAC.
Page 385 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command: show jwac authenticate_page Current Page : Japanese Version English page element ------------------------------------------------------------ Page Title Login Window Title : Authentication Login User Name Title : User Name Password Title : Password Login Out Window Title...
Page 386: Link Layer Discovery Protocol (Lldp) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Link Layer Discovery Protocol (LLDP) Commands The Link Layer Discovery Protocol (LLDP) commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable lldp...
Page 387 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters show lldp_med local_ports {<portlist>} show lldp_med ports {<portlist>} show lldp_med remote_ports {<portlist>} Each command is listed, in detail, in the following sections. enable lldp Purpose Used to enable LLDP operation on the Switch.
Page 388 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config lldp Purpose Used to change the packet transmission interval. Syntax config lldp message_tx_interval <sec 5 – 32768> Description This interval controls how often active ports retransmit advertisements to their neighbors. Parameters message_tx_interval –...
Page 389 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config lldp Purpose Used to change the minimum time (delay-interval) any LLDP port will delay advertising successive LLDP advertisements due to a change in LLDP MIB content. The tx_delay defines the minimum interval between sending of LLDP messages due to constantly change of MIB content.
Page 390 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To change the notification interval to 10 seconds: DES-3528:admin# config lldp notification_interval 10 Command: config lldp notification_interval 10 Success. DES-3528:admin# config lldp ports Purpose Used to configure each port for sending notification to configured SNMP trap receiver(s). Syntax config lldp ports [<portlist>...
Page 391 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config lldp ports Purpose Used to enable or disable port(s) specified for advertising indicated management address instance. Syntax config lldp ports [<portlist> | all] [mgt_addr [ipv4 <ipaddr> | ipv6 <ipv6addr>] [enable | disable]] Description This command specifies whether the system’s IP address needs to be advertised from the...
Page 392 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config lldp ports Purpose Used to configure an individual port or group of ports to exclude one or more optional TLV data types from outbound LLDP advertisements. Syntax config lldp ports [<portlist>...
Page 393 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config lldp port Purpose Used to configure an individual port or group of ports to exclude one or more of IEEE 802.1 Organizationally port and protocol VLAN ID TLV data types from outbound LLDP advertisements.
Page 394 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config lldp port Purpose Used to configure an individual port or group of ports to exclude one or more of IEEE 802.1 Organizationally protocol identity TLV data types from outbound LLDP advertisements. Syntax config lldp ports [<portlist>...
Page 395 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config lldp ports Purpose Used to configure an individual port or group of ports to exclude one or more of IEEE 802.3 Organizationally Specific TLV data types from outbound LLDP advertisements. Syntax config lldp ports [<portlist>...
Page 396 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show lldp Purpose Used to display the Switch’s general LLDP configuration status. Syntax show lldp Description This command displays the Switch’s general LLDP configuration status. Parameters None. Restrictions None.
Page 397 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show lldp ports Purpose Used to display the LLDP per port configuration for advertisement options. Syntax show lldp ports {<portlist>} Description This command displays the LLDP per port configuration for advertisement options. Parameters <portlist>...
Page 398 DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Port ID : 1/1 Port Description : D-Link DES-3528 R2.60.017 Port 1 on Unit 1 Port PVID Management Address Count PPVID Entries Count VLAN Name Entries Count...
Page 399 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show lldp statistics Purpose Used to display the system LLDP statistics information. Syntax show lldp statistics Description This command displays an overview of neighbor detection activity on the Switch. Parameters None.
Page 400 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config lldp_med fast_start repeat_count Purpose This command is used to configure the fast start repeat count. Syntax config lldp_med fast_start repeat_count <value 1-10> Description When an LLDP-MED Capabilities TLV is detected for an MSAP identifier not associated with an existing LLDP remote system MIB, the application layer shall start the fast start mechanism and set the ‘medFastStart’...
Page 401 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config lldp_med notification topo_change ports Purpose This command is used to enable or disable each port for sending topology change notification to configured SNMP trap receiver(s) if an endpoint device is removed or moved to another port.
Page 402 : A5 Firmware Revision : 1.00.B008 Software Revision : 3.00.005 Serial Number : PVZU1BB000141 Manufacturer Name : D-Link Model Name : DES-3528 Fast Ethernet Switch Asset ID PoE Device Type : PSE Device PoE PSE Power Source : Primary LLDP-MED Configuration:...
Page 403 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide ----------------------------------------------------------------- LLDP-MED Capabilities Support: Capabilities :Support Network Policy :Support Location Identification :Not Support Extended Power Via MDI PSE :Not Support Extended Power Via MDI PD :Not Support Inventory :Support Network Policy:...
Page 404 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Remote Entities Count : 1 Entity 1 Chassis ID Subtype : MAC Address Chassis ID : 00-01-02-03-04-00 Port ID Subtype : Net Address Port ID : 172.18.10.11 LLDP-MED capabilities: LLDP-MED Device Class: Endpoint Device Class III LLDP-MED Capabilities Support:...
Page 405: Q-In-Q Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Q-in-Q Commands The Q-in-Q commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable qinq disable qinq show qinq show qinq inner_tpid config qinq ports...
Page 406 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable qinq Purpose Used to disable the Q-in-Q mode. Syntax disable qinq Description This command disables the Q-in-Q mode. All dynamically learned L2 address will be cleared. All dynamically registered VLAN entries will be cleared.
Page 407 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide configure qinq ports Purpose Used to configure Q-in-Q port. Syntax config qinq ports [<portlist> | all] {role [uni | nni] | missdrop [enable | disable] | outer_tpid <hex 0x1-0xffff>| use_inner_priority [enable | disable] | add_inner_tag [<hex 0x1-0xffff>...
Page 408 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Port ID: --------------------------------------------------------- Role: Miss Drop: Disabled Outer Tpid: 0x8100 Use Inner Priority: Disabled Add Inner Tag: Disabled Port ID: --------------------------------------------------------- Role: Miss Drop: Disabled Outer Tpid: 0x8100 Use Inner Priority: Disabled...
Page 409 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create vlan_translation ports Purpose Used to create VLAN translation rule. Syntax create vlan_translation ports [<portlist> | all] [add cvid <vidlist> | replace cvid <vlanid 1-4094>] svid <vlanid 1-4094> {priority <value 0-7>} Description This command can be used to add translation relationship between C-VLAN and SP-VLAN.
Page 410 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show vlan_translation Purpose Used to show pre-created C-VLAN based SP-VLAN assignment rules. Syntax show vlan_translation {[ports <portlist> | cvid <vidlist>]} Description The command is used to show pre-created C-VLAN based SP-VLAN assignment rules. ports −...
Page 411: Rspan Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide RSPAN Commands The Remote Switched Port Analyzer (RSPAN) commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable rspan disable rspan...
Page 412 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# disable rspan Command: disable rspan Success. DES-3528:admin# create rspan vlan Purpose Used to create an RSPAN VLAN. Syntax create rspan vlan [vlan_name <vlan_name> | vlan_id <value 1-4094>] Description This command is used to create the RSPAN VLAN.
Page 413 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config rspan vlan Purpose Used by the source Switch to configure the source and redirect settings for the RSPAN VLAN. Syntax config rspan vlan [vlan_name <vlan_name> | vlan_id <vlanid 1-4094>] [redirect [add | delete] port <port>...
Page 414 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show rspan Purpose Used to display RSPAN configuration. Syntax show rspan {[vlan_name <vlan_name> | vlan_id <vlanid 1-4094>]} Description This command displays the RSPAN configuration. Parameters vlan_name – Specify the RSPAN VLAN by VLAN name. vlan_id –...
Page 415: Static Mac-Based Vlan Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Static MAC-Based VLAN Commands The Static MAC-Based VLAN commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create mac_based_vlan mac_address <macaddr>...
Page 416 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# delete mac_based_vlan mac_address 00-00-00-00-00-01 vlan default Command: delete mac_based_vlan mac mac_address 00-00-00-00-00-01 vlan default Success. DES-3528:admin# show mac_based_vlan Purpose Used to show the static or dynamic MAC-based VLAN entry. Syntax show mac_based_vlan {mac_address <macaddr>...
Page 417: Simple Red Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Simple RED Commands The Simple RED commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable sred disable sred config sred [<portlist>...
Page 418 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# disable sred Command: disable sred Success. DES-3528:admin# config sred Purpose Used to config the simple RED paremeter. Syntax config sred [<portlist> | all] [<class_id 0-7> | all] { threshold {low <value 0-100> | high<value 0-100>}(1) | drop_rate {low<value 1-8>...
Page 419 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show sred Purpose Used to display the simple RED configure parameter. Syntax show sred { <portlist>{ <class_id 0-7>}} Description This command displays the current threshold(per port and per queue) parameters in use on the Switch portlist −...
Page 420 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config dscp trust Purpose Used to enable/disable DSCP trust state on selected portlist. Syntax config dscp trust [<portlist> | all] state [enable | disable] Description This command is used to configure port DSCP trust state. When DSCP is not trusted, 1p is trusted.
Page 421 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dscp map Purpose Used to configure DSCP, the mapping of DSCP to priority, and the packet’s initial color,and DSCP to DSCP. Syntax config dscp map {[<portlist> | all]} [dscp_priority <dscp_list> to <priority 0-7> | dscp_dscp <dscp_list>...
Page 422 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DSCP to Color mapping Port 1 DSCP 0 – 7 is mapped to Green DSCP 8 – 15, 17 is mapped to Yellow DSCP 16, 18 – 63 is mapped to Red DES-3528:admin# config 802.1p map...
Page 423 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green Green...
Page 424: Mac-Based Access Control Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide MAC-based Access Control Commands The MAC-based Access Control Commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable mac_based_access_control disable mac_based_access_control...
Page 425 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable mac_based_access_control Purpose Used to enable MAC-based Access Control. Syntax enable mac_based_access_control Description This command will enable the MAC-based AC function. Parameters None. Restrictions Only Administrator and Operator and Power-User-level users can issue this command. Example usage To enable MAC-based AC function: DES-3528:admin# enable mac_based_access_control...
Page 426 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mac_based_access_control method Purpose Use to configure the MAC-based AC authenticating method. Syntax config mac_based_access_control method [local | radius] Description This command is used to specify to authenticate via local database or via RADIUS server. Parameters local –...
Page 427 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mac_based_access_control ports Purpose Used to configure the parameter of the MAC-based AC. Syntax config mac_based_access_control ports [<portlist> | all] {state [enable | disable] | aging_time [infinite | <min 1-1440>] | block_time <sec 0-300> | max_users [<value 1- 1000>...
Page 428 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config mac_based_access_control log state Purpose This command is used to enable or disable generating of MAC-based Access Control logs. Syntax config mac_based_access_control log state [enable | disable] Description This command is used to enable or disable generating of MAC-based Access Control logs.
Page 429 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete mac_based_access_control Purpose Used to delete MAC-based access control guest VLAN. Syntax delete mac_based_access_control [guest_vlan <vlan_name 32> | guest_vlanid <vlanid 1–4094>] Description This command is used to de–assign the guest VLAN. When the guest VLAN is de– assgined, the guest VLAN function is disabled.
Page 430 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create mac_based_access_control_local mac Purpose Used to create the local database entry. Syntax create mac_based_access_control_local mac <macaddr> [vlan <vlan_name 32> | vlanid <vlanid 1–4094>] Description This command is used to create a database entry. Parameters mac –...
Page 431 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete mac_based_access_control_local Purpose Used to delete the local database entry. Syntax delete mac_based_access_control_local [mac <macaddr> | [vlan <vlan_name 32> | vlanid <vlanid 1–4094>]] Description This command is used to delete a database entry. Parameters mac –...
Page 432 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show mac_based_access_control_local Purpose Used to display mac_based_access_control local database. Syntax show mac_based_access_control_local {[mac<macaddr> | [vlan <vlan_name 32> | vlanid <vlanid 1–4094>]]} Description This command is used to display mac_based_access_control local database. Parameters mac –...
Page 433 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show mac_based_access_control auth_state ports Purpose Used to display mac_based_access_control authentication status. Syntax show mac_based_access_control auth_state ports {<portlist>} Description This command is used to display mac_based_access_control authentication status. Parameters ports –...
Page 434 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config mac_based_access_control max_users Purpose Used to configure the maximum number of authorized clients. Syntax config mac_based_access_control max_users [<value 1-1000> | no_limit] Description The setting is a global limitation on the maximum number of users that can be learned via MAC-based AC.
Page 435: Web-Based Access Control Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Web-based Access Control Commands The Web-based Access Control commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable wac disable wac...
Page 436 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide disable wac Purpose Used to disable the WAC function. Syntax disable wac Description This command will disable the WAC function. Parameters None. Restrictions Only Administrator and Operator and Power-User-level users can issue this command. Example usage: To disable the WAC function: DES-3528:admin# disable wac...
Page 437 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# config wac default_redirpath Purpose Used to config wac default redirect path. Syntax config wac default_redirpath <string 128> Description If the default redirect path is configured, the user will be redirected to the default redirect path after successful authentication.
Page 438 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config wac ports Purpose Used to configure WAC port level settings on the Switch. Syntax config wac ports [<portlist> | all] {state [enable | disable ] | aging_time [infinite | <min 1-1440>] | idle_time [infinite | <min 1-1440>] | block_time [<sec 0-300>]}(1) Description This command is used to configure WAC port level settings on the Switch.
Page 439 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config wac user Purpose Used to configure the VLAN ID of the user account. Syntax config wac user <username 15> [vlan <vlan_name 32> | vlanid <vlanid 1-4094>] | clear_vlan] Description This command allows you to configure Web-based-function user setting.
Page 440 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show wac auth_state Purpose Used to display the authentication state of a port. Syntax show wac auth_state ports {<portlist>} Description Used to display the authentication state for ports. If port 1 is in host-based mode: (1) MAC 00-00-00-00-00-01 is authenticated without VLAN assigned (may be the specified target VLAN does not exist or the target VLAN has not been specified), the ID...
Page 441 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create wac user Purpose Used to create local user accountd for Web-based Access Control. Syntax create wac user <username 15>{[vlan <vlan_name 32> | vlanid <vlanid 1-4094>]} Description This command allows you to create local user accounts for Web-based Access Control.
Page 442 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide State : Enable Method : Local Authentication Failover : Disabled Redirect Path Virtual IP : 0.0.0.0 Switch HTTP Port : 80 (HTTP) RADIUS Authorization : Enabled Local Authorization : Enabled DES-3528:admin# show wac ports...
Page 443 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# clear wac auth_state Purpose Used to clear the authentication state of a port. Syntax clear wac auth_state [ports [<portlist> | all] {authenticated | authenticating | blocked} | macaddr <macaddr>] Description This command is used to clear the authentication state of a port.
Page 444: Power Over Ethernet (Poe) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Power over Ethernet (PoE) Commands The Power over Ethernet (PoE) commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config poe system...
Page 445 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528P:admin# config poe system power_limit 250 power_disconnect_method deny_low_priority_port Command: config poe system power_limit 250 power_disconnect_method deny_low_priority_port Success. DES-3528P:admin#...
Page 446 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config poe ports Purpose Used to configure the PoE port settings. Syntax config poe ports [all | <portlist>] { state [enable | disable] [time_range <range_name 32> | clear_time_range] | priority [critical | high | low] | power_limit [class_0 | class_1 | class_2 | class_3 | user_define <value 1000-35000>] }(1) Description This command is used to configure the PoE port settings.
Page 447 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528P:admin# config poe ports 5 state enable priority critical power_limit user_define 1000 Command: config poe ports 5 state enable priority critical power_limit user_define 1000 Power limit has been set to 1000 Success.
Page 448 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Enabled Critical 4200 (Class 1) : Interim state during line detection Enabled Critical 4200 (Class 1) : Interim state during line detection Enabled Critical 4200 (Class 1) : Interim state during line detection Enabled Critical...
Page 449: Pppoe Circuit Id Insertion Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide PPPoE Circuit ID Insertion Commands The PPPoE Circuit ID Insertion commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config pppoe circuit_id_insertion state...
Page 450 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config pppoe circuit_id_insertion ports Purpose This command is used to configure port’s PPPoE Circuit ID insertion function. Syntax config pppoe circuit_id_insertion ports <portlist> {state [enable | disable] | circuit_id [mac | ip | udf <string 32>]} Description When the port’s state and the global state are enabled, the system will insert the Circuit ID...
Page 451: Dns Relay Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DNS Relay Commands The DNS Relay commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config dnsr [[primary | secondary] nameserver <ipaddr>...
Page 452 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# disable dnsr Purpose Used to disable DNS relay function. Syntax disable dnsr {[cache | static]} Description This command is used to disable DNS relay function. Parameters cache - The buffer cache which records the name of the server and IP address of the corresponding.
Page 453 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config pppoe circuit_id_insertion ports Purpose This command is used to configure port’s PPPoE Circuit ID insertion function. Syntax config pppoe circuit_id_insertion ports <portlist> {state [enable | disable] | circuit_id [mac | ip | udf <string 32>]} Description When the port’s state and the global state are enabled, the system will insert the Circuit ID...
Page 454: Policy Route Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Policy Route Commands The Policy Route commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create policy_route name <policyroute_name 32>...
Page 455 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config policy_route Purpose Used to config policy route rule. Syntax config policy_route name <policyroute_name 32>acl profile_id <value 1-14> access_id <value 1-128>nexthop <ipaddr> state [enable | disable] Description This command allows you to config the different fields for a policy route entry.
Page 456 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show policy_route Purpose Used to display policy route rule. Syntax show policy_route Description This command is used to display policy route rule. Parameters None. Restrictions None. Example usage: To show available policy routes: DES-3528:admin#show policy_route Command: show policy_route...
Page 457: Bpdu Attack Protection Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide BPDU Attack Protection Commands The BPDU Attack Protection commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. NOTE: The BPDU Attack Protection commands and STP Function commands are mutually exclusivly.
Page 458 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config bpdu_protection recovery_timer Purpose Used to configure the BPDU Attack Protection recovery timer. Syntax config bpdu_protection recovery_timer [<sec 60-1000000> | infinite] Description When a port enters under_attack state, it can be disabled or blocked based on the configuration.
Page 459 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable bpdu_protection Purpose Used to enable BPDU Attack Protection globally. Syntax enable bpdu_protection Description This command allows the BPDU Attack Protection to be globally enabled on the Switch. Parameters None.
Page 460 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To display the BPDU Attack Protection status for ports 1-4 of the Switch: DES-3528:admin# show bpdu_protection ports 1-4 Command: show bpdu_protection ports 1-4 Port State Mode Status ------ ----------- ---------- ---------- Enabled...
Page 461: Ethernet Oam Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Ethernet OAM Commands The Ethernet OAM commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config ethernet_oam ports [<portlist>...
Page 462 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config ethernet_oam ports state Purpose Used to enable or disable Ethernet OAM. Syntax config ethernet_oam ports [<portlist> | all] state [enable | disable] Description This command used to enable or disable the port’s Ethernet OAM function. Enabling a port’s OAM will cause the port to start OAM discovery.
Page 463 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config ethernet_oam ports link_monitor error_frame Purpose Used to configure Ethernet OAM link monitoring error frame Syntax config ethernet_oam ports [<portlist> | all ] link_monitor error_frame{ threshold <range 0 - 4294967295> | window <millisecond 1000-60000> | notify_state [enable | disable]}(1) Description The command used to configure ports Ethernet OAM link monitoring error frames.
Page 464 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config ethernet_oam ports 1 link_monitor error_frame_seconds threshold 2 window 10000 notify_state enable Command: config ethernet_oam ports 1 link_monitor error_frame_seconds threshold 2 window 10000 notify_state enable Success. DES-3528:admin# config ethernet_oam ports link_monitor error_frame_period Purpose...
Page 465 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config ethernet_oam ports critical_link_event Purpose Used to configure Ethernet OAM critical link event. Syntax config ethernet_oam ports [<portlist> | all ] critical_link_event [ dying_gasp | critical_event ] notify_state [enable | disable] Description This command is used to configure the capability of Ethernet OAM critical link event.
Page 466 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config ethernet_oam ports received_remote_loopback Purpose Used to configure the method to process the received Ethernet OAM remote loop-back command. Syntax config ethernet_oam ports [<portlist> | all ] received_remote_loopback [process | ignore ] Description This command is used to configure the client to process or to ignore the received Ethernet...
Page 467 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show ethernet_oam ports status Purpose Used to show primary controls and status information for Ethernet OAM. Syntax show ethernet_oam ports {<portlist>} status Description This command is used to show primary controls and status information for Ethernet OAM on specified ports.
Page 468 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Remote Loopback : Supported Unidirection : Supported Link Monitoring : Supported Variable Request : Not Supported PDU Revision Operation Status : Disable Loopback Status : No Loopback There is no peer entry information exist.
Page 469 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show ethernet_oam ports statistics Purpose Used to show Ethernet OAM statistics. Syntax show ethernet_oam ports {<portlist>} statistics Description This command is used to show ports Ethernet OAM statistics information. Parameters portlist –...
Page 470 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Local Event Statistics Error Symbol Event Error Frame Event Error Frame Period Event Errored Frame Seconds Event Dying Gasp Critical Event Remote Event Statistics Error Symbol Event Error Frame Event Error Frame Period Event Errored Frame Seconds Event...
Page 471: Dhcp Server Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DHCP Server Commands The DHCP Server commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create dhcp excluded_address begin_address <ipaddr>...
Page 472 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create dhcp excluded_address Purpose Used to specify the IP addresses that the DHCP server will not assign to DHCP client. Syntax create dhcp excluded_address begin_address < ipaddr > end_address < ipaddr > Description The DHCP server assumes that all IP addresses in a DHCP pool subnet are available for assigning to DHCP clients.
Page 473 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show dhcp excluded_address Command: show dhcp excluded_address Index Begin Address End Address ----- ------------ ------------ 10.10.10.1 10.10.10.10 Total Entries: 1 DES-3528:admin# create dhcp pool Purpose Used to create a DHCP pool. Syntax create dhcp pool <pool name 12>...
Page 474 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcp pool network_addr Purpose Used to specify the network for the DHCP pool. Syntax config dhcp pool network_addr <pool_name 12> <network_address> Description This command Specifies the network for the DHCP pool. The addresses in the network are free to be assigned to the DHCP client.
Page 475 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcp pool dns_server Purpose Used to specify the IP address of a DNS server that is available to a DHCP client. Up to three IP addresses can be specified in one command line. Syntax config dhcp pool dns_server <pool_name 12>...
Page 476 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcp pool netbios_node_type Purpose Used to specify the NetBIOS node type for a Microsoft DHCP client. Syntax config dhcp pool netbios_node_type <pool_name 12> [broadcast | peer_to_peer | mixed | hybrid] Description The NetBIOS node type for Microsoft DHCP clients can be one of four settings: broadcast,...
Page 477 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcp pool lease Purpose Used to specify the duration of the lease. Syntax config dhcp pool lease <pool_name 12> [<day 0-365> <hour 0-23><minute 0-59> | infinite] Description By default, each IP address assigned by a DHCP server comes with a one-day lease, which is the amount of time that the address is valid.
Page 478 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcp pool next_server Purpose Used to specify the next server to be used in the DHCP client boot process. Syntax config dhcp pool next_server <pool_name 12> {< ipaddr>} Description The next server used by the DHCP client boot process is typically a TFTP server.
Page 479 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To configure the timeout value for ping packets: DES-3528:admin# config dhcp ping_timeout 100 Command: config dhcp ping_timeout 100 Success. DES-3528:admin# create dhcp pool manual_binding Purpose Used to specify the distinct identification of the client in dotted-hexadecimal notation or hardware address, for example, 0122.b708.1388,where 01 represents the Ethernet media type and the IP address pair.
Page 480 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete dhcp pool manual_binding Purpose Used to specify the distinct identification of the client in dotted-hexadecimal notation or hardware address to delete. Syntax delete dhcp pool manual_binding <pool_name 12> [<ipaddr> | all] Description An address binding is a mapping between the IP address and MAC address of a client.
Page 481 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show dhcp binding accounting Command: show dhcp binding accounting Pool Name IP Address Hardware Address Type Status Lifetime ----------- -------------- ---------------- ------- -------- ----------- accounting 192.168.0.1 00-08-C8-08-13-88 Ethernet Manual 86400 Total Entries: 1...
Page 482 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# enable dhcp_server Purpose Used to enable the DHCP server function. Syntax enable dhcp_server Description If the DHCP relay is enabled, the DHCP server cannot be enabled. The opposite is also true. Parameters None.
Page 483 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide clear dhcp conflict_ip Purpose Used to clear an entry or all entries from the conflict IP database. Syntax clear dhcp conflict_ip [<ipaddr> | all] Description This command clears an entry or all entries from the conflict IP database. Parameters <ipaddr>...
Page 484: Cable Diagnostics Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Cable Diagnostics Commands The Cable Diagnostics commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters cable_diag ports [<portlist>...
Page 485: Connectivity Fault Management Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Connectivity Fault Management Commands The Connectivity Fault Management commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create cfm md <string 22>...
Page 486 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Parameters config cfm mp_ltr_all [enable | disable] show cfm mp_ltr_all cfm lock md <string 22> ma <string 22> mepid <int 1-8191> remote_mepid <int 1-8191> action [start | stop] config cfm ais md <string 22>...
Page 487 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config cfm md Purpose Used to configure parameters of a maintenance domain. Syntax config cfm md <string 22> {mip [none | auto | explicit] | sender_id [none | chassis | manage | chassis_manage]} (1) Description Creation of MIPs on a MA is useful for tracing the link MIP by MIP.
Page 488 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config cfm ma Purpose Used to configure a maintenance association. Syntax config cfm ma <string 22> md <string 22> {vlanid <vlanid 1-4094> | mip [none | auto | explicit | defer] | sender_id [none | chassis | manage | chassis_manage | defer] | ccm_interval [10ms | 100ms | 1sec | 10sec | 1min | 10min] | mepid_list [add | delete] <mepid_list>}(1)
Page 489 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide create cfm mep Purpose Used to create a cfm MEP. Syntax create cfm mep <string 32> mepid <int 1-8191> md <string 22> ma <string 22> direction [inward | outward] port <port> Description Different MEP in the same MA must have different MEP ID.
Page 490 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config cfm mep Purpose Used to configure parameters of a MEP. Syntax config cfm mep [mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>] {state [enable | disable] | ccm [enable | disable] | pdu_priority <int 0-7>...
Page 491 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete cfm mep Purpose Used to delete a created MEP. Syntax delete cfm mep [mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>] Description This command is used to delete a created MEP.
Page 492 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# enable cfm Purpose Used to enable CFM globally. Syntax enable cfm Description This command is used to enable CFM globally. Parameters None. Restrictions Only Administrator and Operator and Power-User-level users can issue this command. Example usage: To enable cfm: DES-3528:admin# enable cfm...
Page 493 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command: config cfm ports 2-5 state enable Success. DES-3528:admin# show cfm ports Purpose Used to show cfm state of specified ports. Syntax show cfm ports <portlist> Description CFM state of speicified ports will be shown.
Page 494 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide MD Level MIP Creation: Explicit SenderID TLV: None MA Name ---- ---------- DES-3528:admin# Example usage: To display CFM MEP: DES-3528:admin#show cfm mepname MEP Command: show cfm mepname MEP Name : MEP MEPID...
Page 495 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show cfm remote_mep Purpose Used to show special remote MEP’s information. Syntax show cfm remote_mep [mepname <string 32> | md <string 22> ma <string 22> mepid <int 1-8191>] remote_mepid <int 1-8191> Description This command is used to show special remote MEP’s information.
Page 496 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show cfm port Purpose Used to show MEPs and MIPs created on a port. Syntax show cfm port <port> {level <int 0-7> | direction [inward | outward] | vlanid <vlanid 1- 4094>} Description This command is used to show MEPs and MIPs created on a port.
Page 497 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide cfm linktrace Purpose Used to transmit a CFM linktrack message. Syntax cfm linktrace <macaddr> [mepname <string 32> | mepid <int 1-8191> md <string 22> ma <string 22>] {ttl <int 2-255> | pdu_priority <int 0-7>} Description This command is used to issue a CFM linktrack message.
Page 498 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# show cfm linktrace mepname op-mep4 Command: show cfm linktrace mepname op-mep4 Trans ID Source MEP Dstination -------- ---------------- ----------------- DES-3528:admin# show cfm linktrace mepname op-mep4 trans_id 0 Command: show cfm linktrace mepname op-mep4 trans_id 0 Transaction ID: 0 From MEP op-mep4 to 00-25-3C-11-2B-F3...
Page 499 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config cfm ccm_fwd Purpose Used to configure CCM PDUs forwarding mode. Syntax config cfm ccm_fwd [software | hardware] Description This command is for test purposes. For ordinary user, it is not suggested to use this command.
Page 500 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Request timed out. CFM loopback statistics for 00-01-02-03-04-05: Packets: Sent=4, Received=1, Lost=3(75% loss). DES-3528:admin# show cfm pkt_cnt Purpose Used to show CFM packet RX/TX counters. Syntax show cfm pkt_cnt {[ports <portlist> {[rx | tx]} | [rx | tx] | ccm]} Description CFM packet counters will be shown.
Page 501 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide clear cfm pkt_cnt Purpose Used to clear the CFM packet RX/TX counters. Syntax clear cfm pkt_cnt {[ports <portlist> {[rx | tx]} | [rx | tx] | ccm]} Description This command clears CFM packet counters.
Page 502 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide cfm lock md Purpose This command is used to start/stop cfm management lock. This command will result in the MEP sends a LCK PDU to client level MEP. Syntax cfm lock md <string 22>...
Page 503 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config cfm ais md Purpose This command is used to configure the parameters of the AIS function on a MEP. Syntax config cfm ais md <string 22> ma <string 22> mepid <int 1-8191> {period [1sec | 1min] | level <int 0-7>...
Page 504 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config cfm lock md Purpose This command is used to configure the parameters of the LCK function on a MEP. Syntax config cfm lock md <string 22> ma <string 22> mepid <int 1-8191> {period [1sec | 1min] | level <int 0-7>...
Page 505: Command History Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command History Commands The Switch history commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config command_history <value 1-40>...
Page 506 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config stp instance_id config stp mst_config_id config stp mst_ports config stp ports config stp priority config stp version DES-3528:admin# config command_history Purpose Used to configure the command history. Syntax config command_history <value 1-40>...
Page 507: Arp Spoofing Prevention Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide ARP Spoofing Prevention Commands The ARP Spoofing Prevention commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config arp_spoofing_prevention [add gateway_ip <ipaddr>...
Page 508 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To display the ARP spoofing prevention entries: DES-3528:admin#show arp_spoofing_prevention Command: show arp_spoofing_prevention ARP Spoofing Prevention Table Gateway IP Address Gateway MAC Address Port ------------------ ------------------- -------------------- 192.168.69.1 00-11-11-11-11-11 1-28 Total Entries: 1...
Page 509: Auto-Configuration Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Auto-Configuration Commands The Auto-Configuration commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable autoconfig disable autoconfig show autoconfig Each command is listed, in detail, in the following sections.
Page 510 DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528 Fast Ethernet Switch Command Line Interface Firmware: Build 3.00.012 Copyright(C) 2013 D-Link Corporation. All rights reserved. DES-3528:admin# DES-3528:admin# DES-3528:admin# download configuration 10.41.44.44 c:\cfg\setting.txt Command: download configuration 10.41.44.44 c:\cfg\setting.txt Connecting to server....
Page 511 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show autoconfig Purpose This command is used to display if the auto-configuration is enabled or disabled. Syntax show autoconfig Description This command is used to display if the auto-configuration is enabled or disabled. Parameters None.
Page 512: Compound Authentication Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Compound Authentication Commands The Compound Authentication commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create authentication guest_vlan [vlan <vlan_name 32>...
Page 513 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete authentication guest_vlan Purpose This command allows the user to delete guest VLAN setting, but won’t delete the static VLAN. Syntax delete authentication guest_vlan [vlan <vlan_name 32> | vlanid <vlanid 1-4094>] Description All ports which enable guest VLAN will move to original VLAN after deleting guest VLAN.
Page 514 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authentication mac_format Purpose This command will set the MAC address format that will be used for authentication username via the RADIUS server. Syntax config authentication mac_format {case [lowercase | uppercase] | delimiter {[hyphen | colon | dot | none]| number [1 | 2 | 5]}} Description This command will set the MAC address format that will be used for authentication username...
Page 515 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authentication ports Purpose This command is used to configure security port(s). Syntax config authentication ports [<portlist> | all] {auth_mode [port_based | host_based {vlanid <vidlist> state [enable | disable]}] | multi_authen_methods [none | any | dot1x_impb | impb_jwac | impb_wac | mac_impb]}(1) Description This command is used to configure security port(s).
Page 516 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show authentication guest_vlan Purpose This command is used to show guest VLAN setting. Syntax show authentication guest_vlan Description This command is used to show guest VLAN setting. Parameters None.
Page 517 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable authorization Purpose This command is used to enable authorization. Syntax enable authorization attributes Description This command is used to enable authorization. Parameters None. Restrictions Only Administrator and Operator-level users can issue this command. Example usage: This example sets authorization global state enabled: DES-3528:admin#...
Page 518 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config authentication server failover Purpose This command is used to configure authentication server failover function. Syntax config authentication server failover [local | permit | block] Description This command is used to configure authentication server failover function. Parameters local - If RADIUS server can’t reach, use local DB to authenticate the client.
Page 519 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#show authentication mac_format Command: show authentication mac_format Case : Uppercase Delimiter : None Delimiter Number DES-3528:admin#...
Page 520: Debug Software Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Debug Software Commands The Debug Software commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters debug error_log [dump | clear | upload_toTFTP [<ipaddr>...
Page 521 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide ->8018C814 ->8028FF44 ->8028352C ->801D703C ->8013B8A4 ->802AE754 ->802A5E0C To clear the error log: DES-3528:admin# debug error_log clear Command: debug error_log clear Success. DES-3528:admin# To upload the error log to TFTP server: DES-3528:admin# debug error_log upload_toTFTP 10.0.0.90 debug-log.txt Command: debug error_log upload_toTFTP 10.0.0.90 debug-log.txt...
Page 522 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# debug buffer clear Command: debug buffer clear Success. DES-3528:admin# To upload the messages stored in debug buffer to TFTP server: DES-3528:admin# debug buffer upload_toTFTP 10.0.0.90 debugcontent.txt Command: debug buffer upload_toTFTP 10.0.0.90 debugcontent.txt Connecting to server....
Page 523 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command: debug config all disable Success. DES-3528:admin# debug config error_reboot Purpose This command is used to set if the Switch needs to be rebooted when a fatal error occurs. Syntax debug config error_reboot [enable | disable] Description...
Page 524 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide MSTP : Enable : Disable : Enable SNMP : Disable IGMP : Enable DES-3528:admin# debug config state Purpose Use the command to set the state of the debug. Syntax debug config state [enable | disable] Description...
Page 525: Dhcpv6 Client Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DHCPv6 Client Commands The DHCPv6 Client commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config ipif <ipif_name 12>...
Page 526 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# debug dhcpv6_client state enable Command: debug dhcpv6_client state enable Success. DES-3528:admin# debug dhcpv6_client output Purpose Used to set debug message to output to buffer or console. Syntax debug dhcpv6_client output [buffer | console] Description...
Page 527: Dhcpv6 Relay Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DHCPv6 Relay Commands The DHCPv6 Relay commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config dhcpv6_relay hop_count <value 1-32>...
Page 528 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config dhcpv6_relay Purpose The command could add/delete an IPv6 address which is a destination to forward (relay) DHCPv6 packets. Syntax config dhcpv6_relay [add | delete] ipif <ipif_name 12> <ipv6addr> Description The command could add/delete an IPv6 address which is a destination to forward (relay) DHCPv6 packets.
Page 529 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Success. DES-3528:admin# config dhcpv6_relay ipif Purpose The command is used to configure the DHCPv6 relay state of one specific interface or all interfaces. Syntax config dhcpv6_relay ipif [<ipif_name 12> | all] state [enable | disable] Description The command is used to configure the DHCPv6 relay state of one specific interface or all interfaces.
Page 530 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#show dhcpv6_relay Command: show dhcpv6_relay DHCPv6 Relay Global State : Enabled DHCPv6 Hops Count Limit --------------------------------------------------------------- IP Interface : System DHCPv6 Relay Status : Enabled Server Address Total Entries DES-3528:admin# To show the DHCPv6 relay configuration of System interfaces:...
Page 531 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide debug dhcpv6_relay output Purpose Used to set debug message to output to buffer or console. Syntax debug dhcpv6_relay output [buffer | console] Description Used to set debug message to output to buffer or console. Parameters output - Specifies the location of the debug message output.
Page 532 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# debug dhcpv6_relay hop_count state enable Command: debug dhcpv6_relay hop_count state enable Success. DES-3528:admin#...
Page 533: D-Link Unidirectional Link Detection (Duld) Commands
DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide D-Link Unidirectional Link Detection (DULD) Commands The D-Link Unidirectional Link Detection (DULD) commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command...
Page 534 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show duld Purpose This command is used to show unidirectional link detection information. Syntax show duld ports {<portlist>} Description This command is used to show unidirectional link detection information. Parameters ports - (Optional) Specify a range of ports to be display.
Page 535: Ethernet Ring Protection Switching (Erps) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Ethernet Ring Protection Switching (ERPS) Commands The Ethernet Ring Protection Switching (ERPS) commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable erps...
Page 536 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# enable erps Command: enable erps Success. DES-3528:admin# disable erps Purpose This command is used to disable the global ERPS function on a Switch. Syntax disable erps Description This command is used to disable the global ERPS function on a Switch.
Page 537 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# delete erps raps_vlan 4094 Command: delete erps raps_vlan 4094 Success. DES-3528:admin# config erps raps_vlan ring mel Purpose This command is used to configure the ring MEL for an R-APS VLAN. Syntax config erps raps_vlan <vlanid>...
Page 538 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config erps raps_vlan 4094 ring_port west 5 Command: config erps raps_vlan 4094 ring_port west 5 Success. DES-3528:admin# config erps raps_vlan rpl_port Purpose This command is used to configure the RPL port. Syntax config erps raps_vlan <vlanid>...
Page 539 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config erps raps_vlan 4094 rpl_owner enable Command: config erps raps_vlan 4094 rpl_owner enable Success. DES-3528:admin# config erps raps_vlan protected_vlan Purpose This command is used to configure the VLANs that are protected by the ERPS function. Syntax config erps raps_vlan <vlanid>...
Page 540 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config erps raps_vlan timer Purpose This command is used to configure the protocol timers. Syntax config erps raps_vlan <vlanid> timer {holdoff_time <millisecond 0-10000> | guard_time <millisecond 10-2000 > | wtr_time <min 5-12>}(1) Description Holdoff timer The Holdoff timer is used to filter out intermittent link faults when link failures occur during the...
Page 541 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config erps log Purpose This command is used to configure the log state of ERPS events. Syntax config erps log [enable | disable] Description This command is used to configure the log state of ERPS events. Parameters log - Specifies to enable or disable the ERPS log state.
Page 542 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Current Ring State : Idle ------------------------ R-APS VLAN : 4093 Ring Status : Enabled West Port : Virtual Channel East Port : 10 (Forwarding) RPL Port : None RPL Owner : Disabled Protected VLANs...
Page 543 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config erps raps_vlan state Purpose This command is used to configure ring state of the specified ring. Syntax config erps raps_vlan <vlanid> state [enable | disable] Description When both the global state and the specified ring ERPS state are enabled, the specified ring will be activated.
Page 544 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config erps raps_vlan sub_ring raps_vlan tc_propagation state Purpose This command is used to configure the state of topology change propagation for the sub-ring. Syntax config erps raps_vlan <vlanid> sub_ring raps_vlan <vlanid> tc_propagation state [enable | disable] Description This command is applied on the interconnection node.
Page 545: Ipv6 Neighbor Discover Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide IPv6 Neighbor Discover Commands The IPv6 Neighbor Discover commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create ipv6 neighbor_cache ipif <ipif_name 12>...
Page 546 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete ipv6 neighbor_cache Purpose Delete a neighbor cache entry or static neighbor cache entries from the address cache or all address cache entries on this IP interface. Syntax delete ipv6 neighbor_cache ipif [<ipif_name 12>...
Page 547 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#show ipv6 neighbor_cache ipif System all Command: show ipv6 neighbor_cache ipif System all Neighbor Link Layer Address Interface State -------------------------------------- ------------------ ------------ ----- 2001::3001 00-50-BA-1A-FF-55 System FE80::21F:CAFF:FE73:D6C1 00-1F-CA-73-D6-C1 System FE80::250:BAFF:FE1A:FF55...
Page 548 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config ipv6 nd ns ipif System retrans_time 1000000 Command: config ipv6 nd ns ipif System retrans_time 1000000 Success. DES-3528:admin# show ipv6 nd Purpose Used to display information regarding neighbor detection on the Switch. Syntax show ipv6 nd {ipif <ipif_name 12>} Description...
Page 549: Ipv6 Route Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide IPv6 Route Commands The IPv6 Route commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create ipv6route [default | <ipv6networkaddr>] [<ipif_name 12>...
Page 550 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete ipv6route Purpose This command is used to delete an IPv6 static route. Syntax delete ipv6route [[default | <ipv6networkaddr>] [<ipif_name 12> <ipv6addr> | <ipv6addr>] | all] Description Delete an IPv6 static route.
Page 551: Layer 2 Protocol Tunneling (L2Pt) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Layer 2 Protocol Tunneling (L2PT) Commands The Layer 2 Protocol Tunneling (L2PT) commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config l2protocol_tunnel...
Page 552 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin# config l2protocol_tunnel ports 1-4 type uni tunneled_protocol stp Command: config l2protocol_tunnel ports 1-4 type uni tunneled_protocol stp Success. DES-3528:admin# show l2protocol_tunnel Purpose This command is used to show Layer 2 protocol tunneling information. Syntax show l2protocol_tunnel {[uni | nni]} Description...
Page 553 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide enable l2protocol_tunnel Purpose Used to enable the Layer 2 protocol tunneling function. Syntax enable l2protocol_tunnel Description Used to enable the Layer 2 protocol tunneling function. Parameters None. Restrictions Only Administrator and Operator-level users can issue this command.
Page 554: Local Route Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Local Route Commands The Local Route commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable local_route [ipv4 | ipv6] disable local_route [ipv4 | ipv6]...
Page 555 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show local_route Purpose This command is used to display the local route configuration. Syntax show local_route Description The show local route command displays the local route configuration. Parameters None.
Page 556: Mstp Debug Enhancement Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide MSTP Debug Enhancement Commands The MSTP Debug Enhancement Commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters debug stp config ports [<portlist>...
Page 557 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide debug stp show information Purpose This command used to display STP detailed information, such as the hardware tables, the STP state machine, etc. Syntax debug stp show information Description This command used to display STP detailed information, such as the hardware tables, the STP state machine, etc.
Page 558 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide ---------------------------------------------------------- Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled...
Page 559 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide debug stp clear counter Purpose This command used to clear the STP counters. Syntax debug stp clear counter {ports [<portlist> | all]} Description This command used to clear the STP counters. Parameters ports - Specifies the port range.
Page 560: Ping Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Ping Commands The Ping commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters ping <ipaddr> {times <value 1-255> | timeout <sec 1-99>} ping6 <ipv6addr>...
Page 561 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide ping6 Purpose The ping6 command sends IPv6 Internet Control Message Protocol (ICMP) echo messages to a remote IPv6 address. Syntax ping6 <ipv6addr> {times <value 1-255> | size <value 1-6000> | timeout <sec 1-99>} Description The remote IPv6 address will then “echo”...
Page 562: Show Technical Support Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Show Technical Support Commands The Show Technical Support commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters show tech_support upload tech_support_toTFTP...
Page 563 DES-3528:admin# show tech_support Command: show tech_support #------------------------------------------------------------------------------- DES-3528 Fast Ethernet Switch Technical Support Information Firmware: Build 3.00.012 Copyright(C) 2013 D-Link Corporation. All rights reserved. #------------------------------------------------------------------------------- ******************** Basic System Information ******************** [SYS 2000-1-4 22:36:24] Boot Time : 4 Jan 2000 16:50:46...
Page 564 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide upload tech_support_toTFTP Purpose The upload tech_support_toTFTP command is used to upload the information of technique’s support to TFTP server. Syntax upload tech_support_toTFTP <ipaddr> <path_filename 64> Description The information is project dependent and includes the following information. •...
Page 565: Trace Route Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Trace Route Commands The Trace Route commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters traceroute <ipaddr>...
Page 566 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide traceroute6 Purpose Used to trace the IPv6 routed path between the Switch and a destination end station. Syntax traceroute6 <ipv6addr> {ttl <value 1-60> | port <value 30000-64900> | timeout <sec 1- 65535>...
Page 567: Vlan Counter Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide VLAN Counter Commands The VLAN Counter commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create vlan_counter [vlan <vlan_name>...
Page 568 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide delete vlan_counter Purpose This command deletes the control entry for VLAN traffic flow statistics. Syntax delete vlan_counter [ all | [vlan <vlan_name> | vlanid < vidlist > ] [all | ports <portlist> [all | [all_frame | broadcast | multicast | unicast][packet | byte] ] ] ] Description This command deletes the control entry for VLAN traffic flow statistics.
Page 569 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show vlan_counter Purpose This commands displays the statistic control entries created for VLANs. Syntax show vlan_counter {[vlan <vlan_name> | vlanid < vidlist > ]} Description This commands displays the statistic control entries created for VLANs. Parameters vlan_name –...
Page 570: Power Saving Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Power Saving Commands The Power Saving Commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config power_saving {state [enable | disable] | length_detection [enable | disable]} config power_saving [[add | delete] time_range <range_name 32>...
Page 571 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#config power_saving state enable Command: config power_saving state enable Success. DES-3528:admin# config power_saving hibernation Purpose This command is used to add or delete the power saving schedule on system hibernation. Syntax config power_saving hibernation [[add | delete] time_range <range_name 32>...
Page 572 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#config power_saving hibernation delete time_range range_2 Command: config power_saving hibernation delete time_range range_2 Success. DES-3528:admin# config power_saving led Purpose This command is used to add or delete the power saving schedule on the LED of all ports. Syntax config power_saving led [[add | delete] time_range <range_name 32>...
Page 573 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#config power_saving led delete time_range range_2 Command: config power_saving led delete time_range range_2 Success. DES-3528:admin# config power_saving port Purpose This command is used to add or delete the power saving schedule on the port. Syntax config power_saving port [<portlist>...
Page 574 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#config power_saving port 1:1 delete time_range range_2 Command: config power_saving port 1:1 delete time_range range_2 Success. DES-3528:admin# config power_saving mode Purpose This command is used to configure the power saving state. Syntax config power_saving mode {length_detection | link_detection | led | port | hibernation} [enable | disable]...
Page 575 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#config power_saving mode port hibernation enable Command: config power_saving mode port hibernation enable Success. DES-3528:admin# show power_saving Purpose This command is used to display the setting of power saving function. Syntax show power_saving {length_detection | link_detection | led | port | hibernation} Description...
Page 576 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#show power_saving hibernation Command: show power_saving hibernation Power Saving Configuration On System Hibernation ---------------------------------------------------- State: Enabled Time Range -------------------------------- range_1 DES-3528:admin# To display power saving configuration on port LED: DES-3528:admin#show power_saving led Command: show power_saving led Power Saving Configuration On Port LED...
Page 577 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#show power_saving length_detection Command: show power_saving length_detection Length Detection State: Enabled DES-3528:admin# config led state Purpose This command is used to configure the LED admin state of all ports. Syntax config led state [enable | disable] Description...
Page 578: Digital Diagnostic Monitoring (Ddm) Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Digital Diagnostic Monitoring (DDM) Commands The Digital Diagnostic Monitoring (DDM) Commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config ddm...
Page 579 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To configure DDM log state to enable: DES-3528:admin#config ddm log enable Command: config ddm log enable Success. DES-3528:admin# To configure DDM trap state to enable: DES-3528:admin#config ddm trap enable Command: config ddm trap enable Success.
Page 580 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config ddm ports low_warning - (Optional) Specify the low threshold for the warning. When the operating parameter falls below this value, the action associated with the warning is taken. <voltage>...
Page 581 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide config ddm ports reload_threshold - Specify to reload the DDM threshold configuration. Restrictions Only Administrator and Operator-level users can issue this command. Example usage:...
Page 582 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To configure the port 25’s temperature threshold: DES-3528:admin#config ddm ports 1:25 temperature_threshold high_alarm 84.9555 low_alarm -10 high_warning 70 low_warning 2.25251 Command: config ddm ports 1:25 temperature_threshold high_alarm 84.9555 low_alarm - 10 high_warning 70 low_warning 2.25251 Success.
Page 583 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#config ddm ports 1:25 reload_threshold Command: config ddm ports 1:25 reload_threshold Success. DES-3528:admin# config ddm power_unit Purpose The command is used to configure the unit of DDM TX and RX power. Syntax config ddm power_unit [mw | dbm] Description...
Page 584 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide To display the DDM global settings: DES-3528:admin#show ddm Command: show ddm DDM Log : Enabled DDM Trap : Enabled DDM Tx/Rx Power Unit : dBm DES-3528:admin# show ddm ports Purpose This command is used to show the current operating DDM parameters and configuration values of the optic module of the specified ports.
Page 585: Command Logging Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Command Logging Commands The Command Logging Commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable command logging disable command logging show command logging Each command is listed, in detail, in the following sections.
Page 586 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide show command logging Purpose This command displays the switch’s general command logging configuration status. Syntax show command logging Description This command displays the switch’s general command logging configuration status. Parameters None.
Page 587: Udp Helper Commands
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide UDP Helper Commands The UDP Helper Commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config udp_helper add ipif <ipif_name 12>...
Page 588 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#config udp_helper delete ipif System 20.0.0.90 Command: config udp_helper delete ipif System 20.0.0.90 Success. DES-3528:admin# config udp_helper udp_port add Purpose This command is used to add a UDP port for UDP helper function on the Switch. Syntax config udp_helper udp_port add [time | tacacs | dns | tftp | netbios-ns | netbios-ds | <port_number 0-65535>]...
Page 589 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#config udp_helper udp_port delete 55 Command: config udp_helper udp_port delete 55 Success. DES-3528:admin# enable udp_helper Purpose This command is used to enable the UDP helper function on the Switch. Syntax enable udp_helper Description...
Page 590 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide DES-3528:admin#show udp_helper Command: show udp_helper UDP Helper Status : Enabled Application UDP Port ------------ --------------- User App1 Interface Server ------------ --------------- System 20.0.0.90 DES-3528:admin#...
Page 591: Appendix A - Password Recovery Procedure
This document will explain how the Password Recovery feature can help network administrators reach this goal. The following steps explain how to use the Password Recovery feature on D-Link devices to easily recover passwords.
Page 592: Appendix B - System Log Entries
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Appendix B - System Log Entries The following table lists all possible entries and their corresponding meanings that will appear in the System Log. Category Event Description Log Information Severity System...
Page 593 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Login failed through Telnet Login failed through Telnet (Username: <username>, IP: <ipaddr>) Warning Logout through Telnet Logout through Telnet (Username: <username>, IP: <ipaddr>) Informational Telnet session timed out Telnet session timed out (Username: <username>, IP: <ipaddr>) Informational SNMP...
Page 594 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Successful login through Telnet Successful login through Telnet from <userIP> authenticated by AAA Informational authenticated by AAA none none method (Username: <username>) method Successful login through SSH Successful login through SSH from <userIP>...
Page 595 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Successful Enable Admin through Successful Enable Admin through SSH from <userIP> authenticated by Informational SSH authenticated by AAA none AAA none method (Username: <username>) method Successful Enable Admin through Successful Enable Admin through Console authenticated by AAA server Informational Console authenticated by AAA...
Page 596 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Safeguard Engine is in filtering Safeguard Engine enters EXHAUSTED mode Warning packet mode Packet Storm Broadcast storm occurrence Port <portNum> Broadcast storm is occurring Warning Broadcast storm cleared Port <portNum>...
Page 597 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide IP and IP Address change activity Unit <unitID>,Management IP address was changed by (Username: Informational Password <username>) //console Unit <unitID>,Management IP Changed address was changed by (Username: <username>,IP:<ipaddr>)//remote Password change activity Unit <unitID>,Password was changed by (Username: Informational...
Page 598: Appendix C - Trap Entries
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Appendix C - Trap Entries Trap Name/OID Variable Bind Format MIB Name Severity coldStart None RFC1907 Warning 1.3.6.1.6.3.1.1.5.1 (SNMPv2-MIB) warmStart None RFC1907 Warning 1.3.6.1.6.3.1.1.5.2 (SNMPv2-MIB) linkDown None RFC1907 Warning 1.3.6.1.6.3.1.1.5.3...
Page 599 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide 1.3.6.1.4.1.171.12.23.5.0.1 1.3.6.1.4.1.171.12.23.3.2.1.1 swIpMacBindingViolationIP 1.3.6.1.4.1.171.12.23.5.2.1 swIpMacBindingViolationMac 1.3.6.1.4.1.171.12.23.5.2.2 agentGratuitousARPTrap agentGratuitousARPIpAddr AGENT- Warning 1.3.6.1.4.1.171.12.1.7.2.0.5 GENERAL-MIB 1.3.6.1.4.1.171.12.1.7.2.1.3 agentGratuitousARPMacAddr 1.3.6.1.4.1.171.12.1.7.2.1.4 agentGratuitousARPPortNumber 1.3.6.1.4.1.171.12.1.7.2.1.5 agentGratuitousARPInterfaceName 1.3.6.1.4.1.171.12.1.2.12.2.4.1.1 agentFirmwareUpgrade swMultiImageVersion AGENT- Warning 1.3.6.1.4.1.171.12.1.7.2.0.7 GENERAL-MIB 1.3.6.1.4.1.171.12.1.2.7.1.2 agentCfgOperCompleteTrap unitID AGENT- Warning...
Page 600 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide 1.3.6.1.4.1.171.12.37.100.2.2 swPortLoopOccurred swLoopDetectPortIndex LOOPBACK- Warning 1.3.6.1.4.1.171.12.41.10.0.1 DETECT-MIB 1.3.6.1.4.1.171.12.41.3.1.1.1 swPortLoopRestart swLoopDetectPortIndex LOOPBACK- Warning 1.3.6.1.4.1.171.12.41.10.0.2 DETECT-MIB 1.3.6.1.4.1.171.12.41.3.1.1.1 swVlanLoopOccurred swLoopDetectPortIndex LOOPBACK- Warning 1.3.6.1.4.1.171.12.41.10.0.3 DETECT-MIB 1.3.6.1.4.1.171.12.41.3.1.1.1 swVlanLoopDetectVID 1.3.6.1.4.1.171.12.41.10.1.1 swVlanLoopRestart swLoopDetectPortIndex LOOPBACK- Warning 1.3.6.1.4.1.171.12.41.10.0.4 DETECT-MIB...
Page 601 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide 1.3.6.1.4.1.171.12.11.2.2.3.0.2 1.3.6.1.4.1.171.12.11.1.7.1.1 swFanID 1.3.6.1.4.1.171.12.11.1.7.1.2 swPowerStatusChg swPowerUnitIndex EQUIPMENT-MIB Warning 1.3.6.1.4.1.171.12.11.2.2.2.0.1 1.3.6.1.4.1.171.12.11.1.6.1.1 swPowerID 1.3.6.1.4.1.171.12.11.1.6.1.2 swPowerStatus 1.3.6.1.4.1.171.12.11.1.6.1.3 swPowerFailure swPowerUnitIndex EQUIPMENT-MIB Warning 1.3.6.1.4.1.171.12.11.2.2.2.0.2 1.3.6.1.4.1.171.12.11.1.6.1.1 swPowerID 1.3.6.1.4.1.171.12.11.1.6.1.2 swPowerStatus 1.3.6.1.4.1.171.12.11.1.6.1.3 swPowerRecover swPowerUnitIndex EQUIPMENT-MIB Warning 1.3.6.1.4.1.171.12.11.2.2.2.0.3 1.3.6.1.4.1.171.12.11.1.6.1.1...
Page 602 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide ifIndex 1.3.6.1.2.1.2.2.1.1 swSingleIPMSLinkUp swSingleIPMSID SINGLE-IP-MIB Warning 1.3.6.1.4.1.171.12.8.6.0.14 1.3.6.1.4.1.171.12.8.1.3.1.1 swSingleIPMSMacAddr 1.3.6.1.4.1.171.12.8.1.3.1.3 ifIndex 1.3.6.1.2.1.2.2.1.1 swSingleIPMSAuthFail swSingleIPMSID SINGLE-IP-MIB Warning 1.3.6.1.4.1.171.12.8.6.0.15 1.3.6.1.4.1.171.12.8.1.3.1.1 swSingleIPMSMacAddr 1.3.6.1.4.1.171.12.8.1.3.1.3 swSingleIPMSnewRoot swSingleIPMSID SINGLE-IP-MIB Warning 1.3.6.1.4.1.171.12.8.6.0.16 1.3.6.1.4.1.171.12.8.1.3.1.1 swSingleIPMSMacAddr 1.3.6.1.4.1.171.12.8.1.3.1.3 swSingleIPMSTopologyChange swSingleIPMSID...
Page 603: Appendix D - Radius Attributes Assignment
xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide Appendix D - RADIUS Attributes Assignment The RADIUS Attributes Assignment on the Switch is used in the following modules: 802.1X (Port-based and Host- based), Japanese Web-based Access Control, Web-based Access Control, and MAC-based Access Control. The description that follows explains the following RADIUS Attributes Assignment types: •...
Page 604 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide If the user has configured the 802.1p priority attribute of the RADIUS server (for example, priority 7) and the 802.1X, or MAC based authentication is successful, the device will assign the 802.1p default priority (according to the RADIUS server) to the port.
Page 605 xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide If the user has configured the VLAN attribute of the RADIUS server (for example, VID 3) and the 802.1X, MAC based Access Control, or WAC authentication is successful, the port will be assigned to VLAN 3. However, if the user does not configure the VLAN attributes, when the port is not a guest VLAN member, it will be kept in its current authentication VLAN.
