THANK YOU FOR BUYING A RYOBI CORDLESS STRING TRIMMER.
Your new cordless string trimmer has been engineered and manufactured to Ryobi's high standard for dependability,
ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
CAUTION: Carefully read through this entire operator's manual before using your new cordless string trimmer.
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions. If you use your cordless string trimmer
properly and only for what it is intended, you will enjoy years of safe, reliable service.
Thank you again for buying Ryobi string trimmer.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
CORDLESS STRING TRIMMER
MODEL NO. CLT1223

Advertisement

Table of Contents
loading

Related Manuals for Ryobi CLT1223

Summary of Contents for Ryobi CLT1223

  • Page 1 THANK YOU FOR BUYING A RYOBI CORDLESS STRING TRIMMER. Your new cordless string trimmer has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
  • Page 2 Fig. 2 Fig. 1 Fig. 3 Fig. 5 Fig. 4...
  • Page 3 Fig. 6a Fig. 6b Fig. 7 Fig. 8 Fig. 9 Fig. 10...
  • Page 4 30º Fig. 11 Fig. 12 Fig. 13...

  • Page 5: Rules For Safe Operation

    RULES FOR SAFE OPERATION Clear the area of children, bystanders, and WARNING: pets. At a minimum, keep all children, When using battery operated tools basic bystanders and pets outside a 15 m radius; safety precaution should always be followed to there still may be a risk to bystanders from reduce the risk of fire, leaking batteries and thrown objects.
  • Page 6 RULES FOR SAFE OPERATION Do not force the trimmer. It will do the job Keep these instructions. Refer to them often better and with less likelihood of a risk of and use them to instruct other users. If you injury at the rate for which it was designed. loan someone this unit, also loan them these Always hold the unit with both hands when instructions.

  • Page 7: Product Specifications

    PRODUCT SPECIFICATIONS Model CLT1223 Motor 12V DC No load speed 8000 m String Head Bump Head Cutting Line Diameter 1,65 mm Cutting Path Diameter 229 mm Weight with Battery pack 2,4 kg Charger Input 240V, 50Hz, AC only Charge Rate...

  • Page 8: Operation

    ASSEMBLY WARNING: INSTALLING GRASS SHIELD If any parts are missing, do not operate unit until Remove both screws on the motor housing. the missing parts are replaced. Failure to do so Orient grass shield on the motor housing and could result in possible serious personal injury. twist to lock in place as shown.
  • Page 9 OPERATION head on your string trimmer should be CAUTION: parallel to the ground and should easily When placing battery pack in your string contact the material being cut without the trimmer, be sure raised rib on battery pack aligns operator having to bend over. A simple shaft with groove in string trimmer and latches snap in adjustment accommodates most user’s place properly.

  • Page 10: Operating Tips

    OPERATION OPERATING TIPS Clear the area to be cut before each use. Remove all objects such as rocks, broken glass, nails wire, or string which can be thrown or become entangled in the string head. Keep the string trimmer tilted toward the area being cut.

  • Page 11: Maintenance And Repair

    MAINTENANCE AND REPAIR CAUTION WARNING: Use only 1.65 mm (0.065 in) diameter Do not at any time let brake fluids, genuine replacement line. Never use metal- gasoline, petroleum based products, penetrating reinforced line, wire, or rope, etc. These can break oils, etc., come in contact with plastic parts.
  • Page 12 MAINTENANCE AND REPAIR CLEANING THE STRING TRIMMER WARNING: To prevent serious personal injury, remove the battery pack before servicing, cleaning, or removing material from the unit. Remove the battery pack. Clean the unit using a damp cloth with a mild detergent.
  • Page 13 RYOBI NEW ZEALAND PTY. LTD. AUCKLAND: 503 Mt Wellington Highway, Mt Wellington, N.Z. Tel: (09) 573 0230 - Free Call: 0800 279 624 - Fax: (09) 573 0231 - Email: info@ryobi.co.nz Contact during normal business hours. This Guarantee Form Should Be Retained By The Customer At All Times For your record and to assist in establishing date of purchase (necessary for in-guarantee service) please keep your purchase docket and this form completed with the following particulars.
