- Page 1 CLT1830B/CLT1830P CORDLESS STRING TRIMMER OPERATOR’S MANUAL (Original Instructions) Important ! It is essential that you read the instructions in this manual before operating this machine. Subject to technical modifications.
- Page 2 Fig. 2 Fig. 1 Fig. 3 Fig. 4 Fig. 5 Fig. 6...
- Page 3 Fig. 8 Fig. 7 Fig. 9b Fig. 9a Fig. 11 Fig. 10...
- Page 4 ˚ Fig. 12 Fig. 13 Fig. 15 Fig. 14...
-
Page 5: Rules For Safe Operation
ENGLISH (Original Instructions) RULES FOR SAFE OPERATION while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating WARNING: power tools may result in serious personal injury. n Use personal protective equipment. Always wear eye The tool should be operated with a ONE+ battery protection. - Page 6 ENGLISH (Original Instructions) n Clear the area of children, bystanders, and pets. At a n Use the power tool, accessories and tool bits etc. in minimum, keep all children, bystanders and pets outside accordance with these instructions, taking into account a 15 m radius;...
- Page 7 ENGLISH (Original Instructions) n Before starting the unit, make sure the string head will BATTERY TOOL AND CARE not come in contact with anything. n Ensure the switch is in the off position before inserting battery pack. Inserting the battery pack into power tools n If you strike or become entangled with foreign objects, that have the switch on invites accidents.
-
Page 8: Product Specifications
ENGLISH (Original Instructions) PRODUCT SPECIFICATIONS Model CLT1830B CLT1830P Voltage No Load Speed 9000 min String Head Bump Head Cutting Line Diameter 1.65 mm Cutting Path Diameter 230 mm Weight with Battery Pack 2.6 kg Sound pressure level =67dB(A),K =0.77 dB(A) -
Page 9: Operation
ENGLISH (Original Instructions) n Rotate shaft adjustment collar to the “Lock” position and Fig. 6 tighten securely . See Figure 6. A. SHAFT ADJUSTMENT COLLAR B. LOWER PORTION OF SHAFT ADJUSTMENT WARNING: COLLAR C. TO LOCK COLLAR If any parts are missing, do not operate unit until the missing parts are replaced. -
Page 10: Maintenance And Repair
ENGLISH (Original Instructions) n Cut tall grass from the top down. This will prevent grass from wrapping around the string head that may cause HOLDING THE STRING TRIMMER damage from overheating. If grass or other debris WARNING: becomes wrapped around the string head, STOP THE Dress properly to reduce the risk of injury when MOTOR by releasing the trigger and allow the string operating this unit. - Page 11 ENGLISH (Original Instructions) n Completely assembled string head should appear as NOTE: If the spring falls off the spool housing during this shown . See Figure 15. procedure, reinstall the spring before installing the spool and spool cap. n Inspect the string head for damaged or worn parts and CLEANING THE STRING TRIMMER clean thoroughly.
- Page 12 SL7 1TB-UNITED KINGDOM Herewith we declare that the product Category CORDLESS STRING TRIMMER ......................Model ..................... CLT1830B/CLT1830P Serial number ..................See product rating label Year of Construction ................See product rating label is in conformity with the relevant provisions of the Machinery Directive (2006/42/EC)
- Page 13 Marlow, Bucks Schinitzgasse 13 SL7 1TB-UNITED KINGDOM A-8605 Kapfenberg Tel.: + 43 (0) 3862 23590-0 RYOBI TECHNOLOGIES (UK) LIMITED. Fax: + 43 (0) 3862 23590-25 Medina House, Field house Lane, Marlow, Bucks SL7 1TB-UNITED KINGDOM TECHTRONIC INDUSTRIES AUSTRALIA PTY LIMITED.
