Multimedia Projector
PLC-XM100
MODEL
PLC-XM150
PLC-XM100L
PLC-XM150L
Owner's Manual
Network Supported
Refer to the Owner's Manual below for
details about network function.
Network Set-up and Operation
Projection lens is optional.

Advertisement

Table of Contents
loading

Related Manuals for Sanyo PLC-XM100

Summary of Contents for Sanyo PLC-XM100

  • Page 1 Multimedia Projector Network Supported PLC-XM100 MODEL Refer to the Owner's Manual below for details about network function. Network Set-up and Operation PLC-XM150 PLC-XM100L PLC-XM150L Projection lens is optional. Owner’s Manual...

  • Page 2: Features And Design

    Features and Design This Multimedia Projector is designed with most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 1.07 billion colors, and matrix liquid crystal display (LCD) technology. Multilanguage Menu Display Functionally Rich This projector has many useful functions such Operation menu is available in 12 languages;...

  • Page 3: Table Of Contents

    Table of Contents Features and Design ....2 Input Selection ....33 Table of Contents .

  • Page 4: To The Owner

    To The Owner Safety Precaution Before installing and operating the projector, read this manual thoroughly. WARNING: THIS APPARATUS MUST BE EARTHED. The projector provides many convenient features and TO REDUCE THE RISK OF FIRE OR functions. Operating the projector properly enables ELECTRIC SHOCK, DO NOT EXPOSE you to manage those features and maintains it in good THIS APPLIANCE TO RAIN OR...

  • Page 5: Safety Instructions

    Safety Instructions This projector should be operated only from the type of power All the safety and operating instructions should be read before source indicated on the marking label. If you are not sure of the product is operated. the type of power supplied, consult your authorized dealer or local power company.

  • Page 6: Air Circulation

    Safety Instructions Air Circulation Openings in the cabinet are provided for ventilation. To IMPORTANT! ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or Filter Maintenance!! covered. The projector uses a lamp which generates significant heat.

  • Page 7: Installing The Projector In Proper Directions

    Safety Instructions Installing the Projector in Proper Directions Use the projector properly in specified positions. Improper positioning may reduce the lamp life and result in severe accident or fire hazard. This projector can project the picture in upward, downward, or inclined position in perpendicular direction to the horizontal plane.

  • Page 8: Moving The Projector

    LENS button or LENS SHIFT button for more than 5 seconds to return the lens to the central position, and then attach the protector to protect the lens.(Only for PLC-XM100, PLC-XM150). Protector Use the handle grip when moving the projector.

  • Page 9: Compliance

    Do not make any changes or modifications to the equipment unless otherwise specified in the instructions. If such changes or modifications should be made, you could be required to stop operation of the equipment. Model Number : PLC-XM100, PLC-XM100L, PLC-XM150, PLC-XM150L Trade Name : Sanyo...

  • Page 10: Part Names And Functions

    Part Names and Functions Front Lens Release Button Indicators Lamp Cover Speaker Lens Cap (for PLC-XM100, PLC-XM150) Projection Lens (for PLC-XM100, PLC-XM150) Lens Mount Cover (for PLC-XM100L, PLC-XM150L) Infrared Remote Receiver (Front & Top) Side Controls Exhaust Vent Back CAUTION Hot air is exhausted from the exhaust vent.

  • Page 11: Rear Terminal

    Part Names and Functions Rear Terminal INFRARED REMOTE RECEIVER (Back) S-VIDEO INPUT JACK The infrared remote receiver is also located in the front and top Connect the S-VIDEO output signal from video (pp.10, 15). equipment to this jack (p.20). LAN CONNECTION TERMINAL VIDEO INPUT JACK Connect the component or the composite video Connect the LAN cable (refer to the owner’s manual of “Network...

  • Page 12: Side Control And Indicators

    Part Names and Functions Side Control and Indicators Side Control Indicators (on the top panel) ON/STAND-BY button LAMP indicator Turn the projector on or off (pp.23-24). Light red during operations. MENU button WARNING TEMP. indicator Open or close the On-Screen Menu (p.25). Blink red when the internal temperature of the SELECT button projector exceeds the operating range (pp.69,...

  • Page 13: Remote Control

    Part Names and Functions Remote Control STAND-BY button MOUSE POINTER button Turn the projector off (p.24). Move a pointer of the projector or a pointer for wireless mouse operation (p.32). WIRED REMOTE jack Connect the remote control cable (not supplied) to SELECT button this jack when using as a wired remote control.
  • Page 14 Part Names and Functions Remote Control For PIN code and remote control code. D.ZOOM button FREEZE button Select the Digital zoom +/- mode and resize the Freeze the picture on the screen (p.30). image (p.43). P-TIMER button INPUT 1- 3 buttons Operate the P-timer function (p.30).

  • Page 15: Remote Control Battery Installation

    Part Names and Functions Remote Control Battery Installation Open the battery Install new batteries into Replace the compartment lid. the compartment. compartment lid. Press the lid downward and Two AAA size batteries slide it. For correct polarity (+ and –), be sure battery terminals are in contact with pins in the compartment.

  • Page 16: Remote Control Code

    Part Names and Functions Remote Control Code The eight different remote control codes (Code 1–Code 8) are assigned to this projector. Switching the remote control codes prevents interference from other remote controls when several projectors or video equipment next to each other are operated at the same time.

  • Page 17: Installation

    Positioning the Projector For projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen. (for PLC-XM100 and PLC-XM150) Note: • The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image.

  • Page 18: Lens Installation

    Installation Lens Installation When replacing the lens or using an optional lens, install the lens by following the instructions below. Ask the sales dealer for detailed information of the optional lens specifications. Removing the lens Shift the lens to the center position by using the Lens Lens release button shift function (p.27).

  • Page 19: Connecting To A Computer (Digital And Analog Rgb)19

    Installation Connecting to a Computer (Digital and Analog RGB) Cables used for connection ( = Cables not supplied with this projector.) • VGA Cable (One cable is supplied.) • Serial Cross cable • DVI-Digital cable • USB cable • BNC cable Monitor Output Serial out Monitor Input...

  • Page 20: Connecting To Video Equipment (Video, S-Video)

    Installation Connecting to Video Equipment (Video, S-video) Cables used for connection ( = Cables not supplied with this projector.) Analog Out Signal Table • Video cable (RCA x 1 or RCA x 3) • BNC cable (BNC x 1 or BNC x 3) Input Terminal Monitor Out Cable...

  • Page 21: Connecting For Audio Signal

    Installation Connecting for Audio Signal Cables used for connection ( = Cables not supplied with this projector.) • Audio cable External Audio Equipment Audio Output Audio Output (R) (L) Audio Input Audio Audio Audio cable cable cable (stereo) (stereo) Audio cable (stereo) (R) (L)

  • Page 22: Connecting The Ac Power Cord

    Installation Connecting the AC Power Cord This projector uses nominal input voltages of 100–120 V or 200– 240 V AC and it automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system.

  • Page 23: Basic Operation

    Basic Operation Turning On the Projector Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. Connect the projector’s AC power cord into an AC outlet. The LAMP indicator lights red and the POWER indicator lights green. Press the ON/STAND-BY button on the side control or the ON The preparation display will disappear after 30 seconds.

  • Page 24: Turning Off The Projector

    Basic Operation What is PIN code? PIN (Personal Identification Number) code is a security code that allows the person who knows it to operate the projector. Setting a PIN code prevents unauthorized use of the projector. A PIN code consists of a four-digit number. Refer to the PIN code lock function in the Setting Menu on page 59-60 for locking operation of the projector with your PIN code.

  • Page 25: How To Operate The On-Screen Menu

    Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Menu. Side Control The menus have a hierarchical structure, with a main menu that is divided into submenus, which are further divided into other MENU button submenus.

  • Page 26: Menu Bar

    Basic Operation Menu Bar For detailed functions of each menu, see “Menu Tree” on pages 73-75. Main Menu Sub-Menu Input Used to select an input source (Input 1, Input 2, Input 3 or Network) (p.33). Note: Network will be not displayed when optional PJ-Net Organizer is not attached. PC adjust Used to adjust the parameters to match with the input signal format (pp.37-39).

  • Page 27: Operating With Projector Control

    Basic Operation Operating with Projector Control Lens Operation Side Control The following lens operation can be made with the Lens button on the side control. Press the LENS button to enter each lens operation mode. The selected adjustment display appears on the screen. •...

  • Page 28: Sound Adjustment

    Basic Operation Sound Adjustment Side Control Direct Operation VOLUME +/– buttons Volume Press the VOLUME+/– buttons on the side control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute On to temporarily turn off the sound.

  • Page 29: Operating With Remote Control

    Basic Operation Operating with Remote Control Using the remote control for some frequently used operations is advisable. Just pressing one of the buttons enables you to make the desired operation quickly without calling up the On-Screen Menu. AUTO PC button Remote Control Press the AUTO PC button on the remote control to operate the Auto PC adj.
  • Page 30 Basic Operation Remote Control MOUSE POINTER button Move the pointer on the screen with this button. POINTER button Press POINTER button on the remote control to display the Pointer on the screen. P-TIMER button MOUSE POINTER button Press the P-TIMER button on the remote control to operate the Count up/Count down function.

  • Page 31: Keystone Correction

    Basic Operation Keystone Correction If a projected picture still has keystone distortion after pressing Remote Control the AUTO PC button on the remote control, correct the image manually as follows: Press the KEYSTONE button on the remote control to switch the POINT buttons Standard (for Vertical/Horizontal) /Corner correction adjustment.

  • Page 32: Pointer Function

    Basic Operation Pointer Function You can move the Pointer of the projector with the remote control to emphasize a part of the projected image. Press the POINTER button to activate the Pointer function. MOUSE POINTER button Use the MOUSE POINTER button to move the Pointer. To cancel the Pointer function, press the POINTER button again or press any other button.

  • Page 33: Input Selection

    Input Selection Direct Operation Side Control/Remote Control Operation Side Control Remote Control INPUT button INPUT button * Only the Input button function is set Mode 1 in the Setting menu, the INPUT button is used for switching input source. The input source changes each time you press the INPUT button on the side control or the remote control as follows: Before using the INPUT button on the side control or the remote control, you must select a correct input source by On- Screen Menu and the latest input source will be displayed.

  • Page 34: Computer Input Source Selection

    Input Selection Computer Input Source Selection INPUT MENU Menu Operation Press the MENU button to display the On-Screen Menu. Use Input and then press the then press the SELECT button. Input 1 RGB(PC analog) Input 2 Input 3 Video WHEN SELECTING INPUT 1 (COMPUTER INPUT TERMINALS ) RGB(PC analog) When your computer is connected to the INPUT 1 (ANALOG)

  • Page 35: Video Input Source Selection

    Input Selection Video Input Source Selection Menu Operation Press the MENU button to display the On-Screen Menu. Use Input and then press the then press the SELECT button. WHEN SELECTING INPUT 1 (COMPUTER INPUT INPUT 1 MENU TERMINALS ) When connecting to video equipment, select the type of Video source in the Source Select Menu.

  • Page 36: Computer Input

    Computer Input Computer System Selection Automatic Multi-Scan System This projector automatically tunes to various types of computers with its Multi-scan system and Auto PC adjustment. If a computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional settings.

  • Page 37: Auto Pc Adjustment

    Computer Input Auto PC Adjustment Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Position H and Position V positions to conform to your computer. Direct Operation Remote Control The Auto PC adjustment function can be operated directly by pressing the AUTO PC button on the remote control.

  • Page 38: Manual Pc Adjustment

    Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-Scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those special signal formats. The projector has 10 independent memory areas to store those parameters manually adjusted.
  • Page 39 Computer Input Reset To reset the adjusted data, select Reset and press the SELECT button. A confirmation box appears and then select Yes. All adjustments will return to their previous figures. Mode free Auto PC adj. Mode free Fine sync Total dots 1366 Position H...

  • Page 40: Image Level Selection

    Computer Input Image Level Selection Menu Operation Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Image select and then press the Point or the SELECT button. Use the Point buttons to select the desired item and then press the SELECT button.

  • Page 41: Image Adjustment

    Computer Input Image Adjustment Press the MENU button to display the On-Screen Menu. Image adjust Menu Use the Point buttons to select Image adjust and then press the Point button. the SELECT Use the Point buttons to select the desired item and then press the SELECT button to display the adjustment dialog box.

  • Page 42: Screen Size Adjustment

    Computer Input Store Reset To reset the adjusted data, select Reset and press the SELECT button. A confirmation box appears and then select Yes. All adjustments will return to their previous figures. Store To store the adjusted data, select Store Image 1 to 10 and press the SELECT button.
  • Page 43 Computer Input Full Provides the full screen image. Custom Custom Adjust the screen scale and position manually with this function. Custom and the Custom is to choose the item you want to adjust. Scale H/V..... Adjust the Horizontal/Vertical screen scale. H&V......
  • Page 44 Computer Input Keystone This function is used to adjust keystone distortion of the projected image. Use the Point buttons to choose the item you want to adjust. Keystone Standard Adjust the Horizontal/Vertical keystone distortion of the projected image. Corner correction Adjust the corner distortion of the projected image.

  • Page 45: Video Input

    Video Input Video System Selection Press the MENU button to display the On-Screen Menu. Use AV System Menu (Video or S-video) Input and then press the Point Video, S-video or Computer 1(Component) and then press the SELECT button. System and then press to select the desired system and then press the SELECT button.

  • Page 46: Image Level Selection

    Video Input Image Level Selection Menu Operation Press the MENU button to display the On-Screen Menu. Use Image select and then press then press the SELECT button. Image select Menu Standard Standard Cinema Normal picture level preset on the projector. Image 1 Image 2 Image 3...

  • Page 47: Image Adjustment

    Video Input Image Adjustment Press the MENU button to display the On-Screen Menu. Use Image adjust Menu Image adjust and then press press the SELECT button to display the adjustment dialog Contrast Selected Image mode Brightness Contrast Brightness Color Tint Color temp.
  • Page 48 Video Input Offset(Red/Green/Blue) green/blue tone of the black level of an image (from 0 to 63). Sharpness (from 0 to 31). Gamma better balance of contrast (from 0 to 15). Noise reduction Noise interference on the screen can be reduced. Press the Point Off ...

  • Page 49: Screen Size Adjustment

    Video Input Screen Size Adjustment Press the MENU button to display the On-Screen Menu. Use Screen and then press the and then press the SELECT button. Normal Provide the image to fit the screen size while maintaining the aspect ratio of input signal. Wide Provide the image at the 16:9 wide screen ratio.
  • Page 50 Video Input Keystone Keystone This function is used to adjust keystone distortion of the projected image. Use the Point buttons to choose the item you want to adjust. Standard Adjust the Horizontal/Vertical keystone distortion of the projected image. Corner correction Adjust the corner distortion of the projected image.

  • Page 51: Setting

    Setting Setting This projector has a Setting menu that allows you to set up the Setting Menu other various functions described below. Language English Menu position Press the MENU button to display the On-Screen Menu. Input button Mode 1 Setting and press the Display Background Blue...
  • Page 52 Setting Display This function decides whether to display On-Screen Displays. On ....... Show all the On-Screen displays. Use this function when you want to project images after the lamp becomes bright enough. The factory default setting is in this option. Countdown Off ..
  • Page 53 Setting Capture This function enables you to capture an image being projected to Capture use it for a starting-up display or interval of presentations. Select Capture and press the SELECT button. A confirmation box appears and select Yes to capture the projected image.
  • Page 54 Setting Enter a Logo PIN code Enter a Logo PIN code Use the Point buttons to enter a number. Press the Point button to fix the number and move the red frame pointer to the next box. The number changes to .
  • Page 55 Setting Lamp control Lamp life control Lamp control This function allows you to change brightness of the screen. Auto ..Brightness according to the input signal. Normal . . . Normal brightness. Eco 1 ..Lower brightness and decrease of fan speed. Lower brightness reduces the lamp power consumption and extends the lamp life.
  • Page 56 Setting Filter control Filter control button at Filter control starts to scroll. Note: • Filter replacement icon and Please wait... message appear on the screen Back automatically set to 0. Fan control Choose the running speed of cooling fans from the following options. Normal..
  • Page 57 Setting RC sensor Select a location of the infrared remote receiver of the remote control. See “Remote Control Receivers and Operating Range” on page 15 for details. All.... Activate all of the receivers. Front & Top ..Activate both the front and top receivers. Top &...
  • Page 58 Setting On start When this function is set to On, the projector will be automatically turned on just by connecting the AC power cord to the wall outlet. Note: Be sure to turn off the projector properly (see “Turning Off the Projector”...

  • Page 59: Key Lock And Pin Code Lock

    Setting Key lock Security (Key lock and PIN code lock) This function allows you to use the Key lock and PIN code lock function to set the security for the projector operation. Key lock This function locks the side control and remote control buttons to prevent operation by unauthorized persons.
  • Page 60 Setting Enter a PIN code Enter a PIN code button to fix the number and move the red frame pointer to the next box. The number changes to . If you fixed an incorrect number you want to correct, and then enter the correct number. Repeat this step to complete entering a four-digit number.
  • Page 61 Setting Shutter Shutter Shutter function is available to block out light to the screen, so that the screen can be used for the other presenters. Protection Prohibit the shutter operation from the remote control and the projector's side control. Remote control . . Selecting On prohibits the shutter operation from the remote control.

  • Page 62: Factory Default

    Setting Filter counter Filter counter This function is used to set a frequency for the filter replacement. Filter counter and then press the Point or the SELECT button to access the submenu items. Filter counter..Show the total accumulated time of the filter use timer setting.

  • Page 63: Maintenance And Care

    Maintenance and Care Filter Instructions Filter prevents dust from accumulating on the optical elements inside the projector. Should the filter becomes clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in internal heat buildup and adversely affect the life of the projector.

  • Page 64: Replacing The Filter Cartridge

    ORDER REPLACEMENT FILTER CARTRIDGE Replacement filter cartridge can be ordered through your dealer. When ordering, give the following information to the dealer. Model No. of your projector PLC-XM100, PLC-XM150, PLC-XM100L, PLC-XM150L Replacement Filter Cartridge Type No. POA-FIL-080 (Service Parts No. 610 346 9034)

  • Page 65: Resetting The Filter Counter

    Maintenance and Care Resetting the Filter Counter Be sure to reset the Filter counter after cleaning or replacing the Filter counter filter. Press the MENU button to display the On-Screen Menu. Use Setting and then press the Filter counter and to select Filter counter Reset and then press the SELECT button.

  • Page 66: Lamp Replacement

    Maintenance and Care Lamp Replacement When the projection lamp of the projector reaches its end of life, the Lamp replacement icon appears on the screen and LAMP REPLACE indicator lights orange. Replace the lamp with a new one promptly. The timing when the LAMP REPLACE indicator should light is depending on the lamp mode.

  • Page 67: Lamp Handling Precautions

    Replacement lamp can be ordered through your dealer. When ordering, give the following information to the dealer. Model No. of your projector PLC-XM100, PLC-XM150 PLC-XM100L, PLC-XM150L Replacement Lamp Type No. POA-LMP137 (For PLC-XM100 / XM100L) (Service Parts No. 610 347 5158) POA-LMP136 (For PLC-XM150 / XM150L) (Service Parts No. 610 346 9607)

  • Page 68: Cleaning The Projection Lens

    Maintenance and Care Cleaning the Projection Lens Unplug the AC power cord before cleaning. Gently wipe the projection lens with a cleaning cloth that contains a small amount of non-abrasive camera lens cleaner, or use a lens cleaning paper or commercially available air blower to clean the lens.

  • Page 69: Warning Indicators

    Maintenance and Care Warning Indicators The WARNING indicators show the state of the function which protects the projector. Check the state of the WARNING indicators and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING Top Panel TEMP.

  • Page 70: Appendix

    Appendix Troubleshooting Before calling your dealer or service center for assistance, check the items below once again. 1. Make sure you have properly connected the projector to peripheral equipment as described on pages 19-21. 2. Check the cable connection. Make sure that all computers, video equipment, and power cords are properly connected. 3.
  • Page 71 Appendix – Filter is out of scroll. Replace the filter cartridge with a new one promptly. (See pages 64-65) appears on the screen – Adjust the focus of the projector. – Check Projection Lens to see if it needs cleaning. Note: Moving the projector from a cool temperature location to a warm temperature location may result in moisture condensation on Projection Lens.
  • Page 72 Appendix – Power management function runs by initial setting. Check “Setting” section on page – When the filter cartridge replacement icon keeps appearing on the screen at turning on the projector for some time and no action is taken to replace the filter cartridge, the projector will be automatically shut down in 3 minutes after turning on to protect the The power is turned off projector.

  • Page 73: Menu Tree

    Appendix Menu Tree Computer Input/Video Input Sound Input Sound Volume 0–63 Input Input 1 RGB (PC analog) On/Off Built-in SP RGB (Scart) Mute On/Off RGB (PC digital) Information RGB (AV HDCP) Information Input Input 2 Video H-sync freq. Y, Pb/Cb,Pr/Cr V-sync freq.

  • Page 74: Image Adjust

    Appendix Screen Screen Normal True Wide Full Scale H / V Custom H & V On/Off Position H / V Common Reset Digital zoom + Digital zoom - Keystone Store Reset Ceiling On/Off Rear On/Off Reset Video Input System System Auto Auto 1080i...
  • Page 75 Appendix Computer Input/Video Input Setting Setting Language 12 languages provided. Menu position Input button Mode 1/Mode 2/Mode 3 Display On/Countdown Off/Off Background Blue/User/Black Logo select Logo User Default Capture Yes/No Logo PIN code lock Off/On Logo PIN code change Lamp control Lamp control Auto/Normal/Eco 1/Eco 2 Lamp life control...

  • Page 76: Indicators And Projector Condition

    Appendix Indicators and Projector Condition Check the indicators for the projector condition. The projector is operating normally. Indicators Projector Condition WARNING WARNING LAMP POWER LAMP SHUTTER TEMP. FILTER REPLACE green blue orange orange The projector is off. (The AC power cord is unplugged.) The projector is in stand-by mode.
  • Page 77 Appendix The projector is detecting abnormal condition. Indicators Projector Condition WARNING WARNING LAMP POWER LAMP SHUTTER TEMP. FILTER REPLACE green blue orange orange The temperature inside the projector is elevated close to the abnormally high level. The temperature inside the projector is abnormally high. The projector cannot be turned on.
  • Page 78 Appendix The projector is detecting abnormal condition. Indicators Projector Condition WARNING WARNING LAMP POWER LAMP SHUTTER TEMP. FILTER REPLACE green blue orange orange If the Filter counter reached a time set in the timer setting, a Filter replacement icon (Fig.2) appears on the screen and the WARNING FILTER indicator on the top panel lights up.

  • Page 79: Compatible Computer Specifications

    Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V- and H-Frequency mentioned below and less than 180 MHz of Dot Clock. ON-SCREEN RESOLUTION H-Freq. V-Freq.(Hz) ON-SCREEN RESOLUTION H-Freq. V-Freq.(Hz) DISPLAY (kHz) DISPLAY (kHz) 1280x1024 VGA 1...
  • Page 80 Appendix When an input signal is digital from the DVI terminal, refer to the chart below. ON-SCREEN RESOLUTION H-Freq. V-Freq.(Hz) ON-SCREEN RESOLUTION H-Freq. V-Freq.(Hz) DISPLAY (kHz) DISPLAY (kHz) D-VGA 640x480 31.470 59.940 D-SXGA+ 6 1400x1050 64.744 59.948 D-480p 720x480 31.470 59.880 D-SXGA+ 7 1400x1050...

  • Page 81: Technical Specifications

    Scanning Frequency H-sync. 15 kHz–100 kHz, V-sync. 48 Hz–100 Hz Optical Information Projection Image Size (Diagonal) Adjustable from 40” to 300” (PLC-XM100/PLC-XM150) Throw Distance 4.3' (1.30m) - 56.5' (17.23m) (PLC-XM100/PLC-XM150) Projection Lens F1.74–2.37 lens with f=26.85 mm–45.43 mm with motor zoom and focus...

  • Page 82: Optional Parts

    Appendix Optional Parts The parts listed below are optionally available. When ordering those parts, specify the item name and Model No. to the sales dealer. Model No. Standard Zoom Lens : LNS-S20 Long Zoom Lens : LNS-T20 Ultra Long Zoom Lens : LNS-T21 Short Zoom Lens : LNS-W20...

  • Page 83: Configurations Of Terminals

    Appendix Configurations of Terminals ANALOG/ MONITOR OUT (Mini D-sub 15 pin) Input Red Input +5V Power Green Input Ground (Vert.sync.) Blue Input Ground No Connect DDC Data Ground (Horiz.sync.) Horiz. sync. Input (Composite H/V sync.) Ground (Red) Vert. sync. Input Ground (Green) DDC Clock Ground (Blue)

  • Page 84: Pin Code Number Memo

    Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No. Factory default set No: 1 2 3 4* Logo PIN Code Lock No.

  • Page 85: Dimensions

    Appendix Dimensions Unit: inch (mm) PLC-XM100L, PLC-XM150L Screw Holes for 6.25(158.8) 3.78(96.0) Ceiling Mount Screw: M6 Depth: 0.393 (10.0) (18.58)472.0 (19.27)489.5 º 4 MAX PLC-XM100, PLC-XM150 6.25(158.8) 3.78(96.0) (18.58)472.0 (19.27)489.5 º 4 MAX...

  • Page 86: Serial Control Interface

    Appendix Serial Control Interface This projector provides a function to control and monitor the projector's operations by using the RS-232C serial port. Operation Connect a RS-232C serial cross cable to CONTROL PORT on the projector and serial port on the PC. (See p.19) Launch a communication software provided with PC and setup the communication condition as follows: Baud rate...
  • Page 87 Appendix Functional Execution Command Format The command is sent from PC to the projector with the format below; 'C' [Command] 'CR' Command: two characters (refer to the command table below. -The projector decodes the command and returns the 'ACK' with the format below; 'ACK' 'CR' -When the projector can not decode the command, it returns with format below.
  • Page 88 Appendix Status Read Command Format The command is sent from PC to the projector with the format below; 'CR' [Command] 'CR' Command: one character (refer to the command table below. The projector decodes the command and returns the 'Character string' with the format below; Projector Command Function...
  • Page 89 KA8AL...
  • Page 90 Owner’s Manual Network Set-up and Operation Wired Setting Projector Set-up and Operation This is the manual for the Network function. Read this manual thoroughly to operate the Network function. First, read the owner's manual of the projector to understand the basic operation of the projector and the safety instructions.

  • Page 91: Federal Communications Commission Notice

    Do not make any changes or modifications to the equipment unless otherwise speci- fied in the instructions. If such changes or modifications should be made, you could be required to stop operation of the equipment. Model Numbers : PLC-XM100, PLC-XM100L, PLC-XM150, PLC-XM150L Trade Name : Sanyo Responsible party...
  • Page 92 CAUTION IN USING NETWORK FUNCTION SANYO Electric Co., Ltd. assumes no responsibility for the loss or damage of data, or damage of the computer caused by using this projector. Making back- up copies of valuable data in your computer is recommended.
  • Page 93 Table of contents Compliance....................................2 Federal Communications Commission Notice....................2 Safety instructions..................................3 Table of contents..................................4 Chapter 1 Preparation ....................5 Features....................................6 Required operating environment for computers ..................7 Network specifications of the projector......................7 Flow of installation................................9 Chapter 2 Setup Procedures.................. 11 Connecting to the LAN line............................ 12 Network configuration...............................

  • Page 94: Chapter 1 Preparation

    Chapter 1 Preparation Describes features and operating environment of this projector.

  • Page 95: Features

    Chapter 1 Preparation Features Web Management function ( p.31) With this func tion, you can monitor projector functions such as power status, lamp s t at us , inp u t m o d e, si gna l condition, lamp-use time, etc. through the network by using the web browser installed on Turn ON PJ2...

  • Page 96: Required Operating Environment For Computers

    Features Required operating environment for computers When operating the projector via networks, computers should meet the operating envi- ronment below. Windows 98, Windows Me, Windows NT4.0 Operating System Windows 2000, Windows XP, Windows Vista (32bit version) Mac OS X v 10.4 or later Windows: Higher than Pentium III 900MHz Recommended CPU Macintosh : 800 MHz PowerPC G4 or faster,or 1.8 GHz Intel Core...
  • Page 97 Chapter 1 Preparation The limitation of connection between the projector and hub or computer Suitable LAN cables are limited by length and type as follows; Connection Type of usable LAN cable Maximum length Projector - Hub UTP Straight Cable with category 3 or 5 * 100m Projector - Computer UTP Cross Cable with category 3 or 5*...

  • Page 98: Flow Of Installation

    Flow of installation Flow of installation To use the projector via the networks, follow the setup procedures below. STEP 1 Connect the LAN and set the configuration. Decide depending on the LAN environment. “2. Setup Procedures” (pp.11–16). Detailed LAN configurations need to be done with a browser later. First, complete the Wired LAN connection between computers and projec- tors, then start browser configurations.
  • Page 99 Chapter 1 Preparation...

  • Page 100: Chapter 2 Setup Procedures

    Chapter 2 Setup Procedures Describes how to configure the network.

  • Page 101: Connecting To The Lan Line

    Chapter 2 Setup Procedures Setting procedures and contents differ depending on the LAN installation location. When installing, consult your system administrator to set up the LAN appropriately. Connecting to the LAN line Connect the LAN cable to the LAN connection terminal of the projector. LAN Connection Terminal ACT Lamp (Orange) Blink orange when the...
  • Page 102 Network configuration 3. Select "Network setting" in the Network menu and press SELECT button, and then the LAN setting screen will appear and selected LAN settings will be displayed. Adjust each item to the setting environment. Consult your system administrator about the detailed settings.

  • Page 103: Network Pin Code

    Chapter 2 Setup Procedures Network PIN code The Network PIN code is to restrict the access to the projector through the network. After setting the Network PIN code, you need to enter it to operate the projector via the networks. 1.

  • Page 104: Network Factory Default

    Network factory default Network factory default 1. Select “Network factory default” in the Network menu and press SELECT button. 2. A confirmation box appears and select "Yes" and then press SELECT button. 3. Another confirmation box appears and select "Yes" and then press SELECT button. 4.
  • Page 105 Chapter 2 Setup Procedures...

  • Page 106: Chapter 3 Basic Setting And Operation

    Chapter 3 Basic Setting and Operation Describes basic operations and settings for controlling the projec- tor by using the web browser. It is required that computer and projector is connected to the network and the network address is properly configured.

  • Page 107: Login The Setting Page Of The Projector

    Chapter 3 Basic Setting and Operation Login the setting page of the projector [1] Enter the IP address Launch the web browser installed in your computer, enter the IP address into the "Address" on the browser and then press "Enter" key. Enter the address that you configured in item "Network configuration"...

  • Page 108: Display Of Main Setting Page

    Login the setting page of the projector [3] Display of main setting page The following main setting page will be displayed according to your display mode selection. Perform various kinds of settings through this page. Click on the menus to dis- play the control and setting pages.

  • Page 109: How To Use The Setting Page

    Chapter 3 Basic Setting and Operation How to use the setting page To control and set up the projector, use the setting menus on the web browser. Describes the basic operation and procedures commonly used on this manual. Example of the setting page The setting menu appears when clicking the sub menu tab.
  • Page 110 How to use the setting page Radio button setting Select an item by selecting a radio button. Check box setting Select items by ticking on check boxes.

  • Page 111: Initial Setting

    Chapter 3 Basic Setting and Operation Initial setting After installing the projector, perform the following basic initial setting. Click Initial Setting on the main menu to display the initial setting page. * The serial number in the figure is used for an example. Item Description Language....Switches display language on the setting page.

  • Page 112: Network Pin Code Setting

    Initial setting Network PIN code setting This is to set the Network PIN code to restrict the access from an unauthorized person through the network. Enter a 4-digit number as the Network PIN code onto the text box and click Set button. The projector begins restarting and it takes about 10 seconds.

  • Page 113: Network Configuration

    Chapter 3 Basic Setting and Operation Network configuration Click Network on the main menu. The following setting page is displayed. The IP Address, Subnet Mask, Default Gateway, DNS (Domain Name Server) and projector name are set up on this menu. The IP address and Subnet Mask have been configured already in chapter "Installation".

  • Page 114: E-Mail Setting

    E-mail setting E-mail setting This projector has an E-mail function which can send an alert message to users or an administrator if it detects an abnormality on the projector or run out of the life span of the lamp. Click E-mail Setting on the main menu and follow the below steps.
  • Page 115 Chapter 3 Basic Setting and Operation Registering and deleting E-mail addresses Click "Add address" and type the e-mail address onto the text box and click Set button. To check the registered addresses, click Check/Delete sub menu tab. The addresses are listed as the figure on the right.

  • Page 116: Examples: Type And Contents Of Alert Mail

    E-mail setting Examples: Type and contents of alert mail When the projector has an abnormality, the following alert messages are sent to the regis- tered E-mail address according to your selected condition. Administrator or user can take an efficient action quickly by receiving this message. This is very useful to maintain and service the projector.
  • Page 117 Chapter 3 Basic Setting and Operation When PJ lamp replacement time is reached: TITLE: Message from projector Projector Model Name: model name TCP/IP: 192.168.1.201 Projector Name: Proj05 It sends you following message. *The projector lamp has reached replacement time. Lamp ON 2000 h Replace it with a new lamp immediately and reset the lamp counter.

  • Page 118: Snmp Setting

    SNMP setting SNMP setting This projector provides a SNMP (Simple Network Management Protocol) agent function. The SNMP consists of a manager and agents. The group which communicates information each other with SNMP is called "Community". There are two access modes in a community, Refer (read only) and Set (read- write).
  • Page 119 Chapter 3 Basic Setting and Operation Trap check/delete Check and delete the trap address Checking the registered trap address and deleting the address. To delete the address, tick check box in front of the IP address and click Delete button. Up to 10 trap addresses can be registered.

  • Page 120: Chapter 4 Controlling The Projector

    Chapter 4 Controlling the Projector Describes controlling and setting of the projector by using the web browser.

  • Page 121: Power Control And Status Check

    Chapter 4 Controlling the Projector Power control and status check Click Power & Status on the main menu. The control page will be dis- played. By clicking ON or Standby button on the page, the power of the projector can be con- trolled.
  • Page 122 Power control and status check About projector condition Status Description Normal............... Projector is operating normally. Power management in operation... Power management is operating Lamp failure........... Lamp failure is occurring Abnormal Temperature......The temperature of the projector became too high Standby after Abnormal Temp..Projector detects abnormal temp. and sets into standby mode. Power failure ..........

  • Page 123: Control

    Chapter 4 Controlling the Projector Control Click Control on the main menu. The setting method differs depending on the contents of the page. Click on the page number to change pages and select desired setting items. Please see the owner's manual of the projector to have the further information of each control item.

  • Page 124: System

    Control System This function is to select the system of signal input to the projector. The available system mode are listed on the pull-down menu but- ton according to the input signal. Select a system and then click Set button. Available selection at the RGB(PC analog) input Item Description...

  • Page 125: Sound

    Chapter 4 Controlling the Projector Sound This function is to adjust the sound of the projector. The values in the text box repre- sent the current control value or status. Item Description Volume ....Adjusts the sound volume from the speaker. (0 ~ 63) Mute......Suppresses the sound.

  • Page 126: Image Adjustment

    Control Image adjustment This function is to adjust the projected picture image and save the image mode. To store the adjusted value, click Store button, and to load the adjusted value, click Load button. Item Description Contrast ......Adjusts picture con- trast.

  • Page 127: Pc Adjustment

    Chapter 4 Controlling the Projector PC adjustment Click PC Adj. on the main menu. This function is to adjust the signal from the computer connected to the projector to obtain the proper picture image on the screen. Item Description Current mode..Displays a current mode like VGA, SVGA, XGA. SXGA, UXGA, WXGA, etc. or Mode1 - Mode10 which are the customized mode created by using the "Mode Store"...

  • Page 128: Setting Up The Projector

    Setting up the projector Setting up the projector Click Setting on the main menu. This function is to set up the projector. Select the sub menu [Screen setting] or [Setting] and then set up each set- ting. Screen setting This function is to adjust the screen mode of the projector.

  • Page 129: Setting 1

    Chapter 4 Controlling the Projector Setting 1 Item Description Input button..Sets the input search mode by pressing the INPUT button of the projector and the remote control. (Mode1, Mode2, Mode3) Background..Sets the screen background when no signal input. (Blue, User, Black) Display....Switches on or off the on-screen menu display on the screen.

  • Page 130: Setting 3

    Setting up the projector Setting 3 Item Description Filter counter(h) ....Displays the filter counter. Reset the time after filter cartridge replacement. Click "Reset", a confirmation display appears, and then click "OK", the time will be reset. * Do not reset the Filter counter when the filter cartridge is not replaced.

  • Page 131: Information

    Chapter 4 Controlling the Projector Information This page is to display the basic information of the projector status. Click Information on the main menu. Click this button to update the information. Items Description Input Displays selected input and source. System Displays selected signal system.
  • Page 132 Information Indication of the lamp status Icon display/background Status Lamp on (Normal) White/Blue Lamp on (Lamp is being used over a specified use time, replace lamp White/Red immediately) Lamp off (Normal) Gray/Blue Lamp off (Lamp is being used over a specified use time, replace lamp Gray/Red immediately) Lamp failure (Lamp failure, check lamp condition)
  • Page 133 Chapter 4 Controlling the Projector...

  • Page 134: Chapter 5 Appendix

    Chapter 5 Appendix Connection examples Use of telnet Web browser setting Technical data Q & A...

  • Page 135: Examples Of Connection

    Chapter 5 Appendix Examples of connection Peer-To-Peer connection Connecting the projector (PJ01) to the control computer (PC05) directly. * UTP cross cable Computer Name: PC05 Projector Name: PJ01 IP Address : 192.168.0.5 IP Address : 192.168.0.2 Subnet Mask : 255.255.255.0 Subnet Mask : 255.255.255.0 Default Gateway :...
  • Page 136 Examples of connection The gateway (Router) installed in the network Connecting the projector (PJ01) to the control computer (PC05) via the gateway. Entrance hall Computer Name : PC205 IP Address : 192.168.200.5 Subnet Mask : 255.255.255.0 Default Gateway : 192.168.200.1 : 192.168.201.1 Projector Name: PJ01 IP Address...

  • Page 137: Use Of Telnet

    Chapter 5 Appendix Use of telnet You can control the projector by using the telnet application installed on your computer. Normally, the telnet application is available on your computer. * The telnet 10000 port is used to control the projector. Control (For example, in case of using the telnet (For example, in case of using the telnet...
  • Page 138 Use of telnet 3. When communication is established correctly, the word "PASSWORD:" appears on the window. Type the login password (Network PIN code ) for the projector and then press "Enter" key on the keyboard. If you do not set up the Network PIN code, just press "Enter" key.

  • Page 139: Web Browser Setting

    Chapter 5 Appendix Web browser setting This projector is designed to be set up and controlled from an Internet web browser. Depending on the preference settings of the web browser, some control functions may not be available. Please make sure that the following functions are set up properly in the web browser.

  • Page 140: Examples: Os/Browsers

    Web browser setting Examples: OS/Browsers Windows XP Professional Internet Explorer v.6.0 ActiveScript setting Select Internet Options from Tools menu on the web browser and then select Security tab and click Customize Level… button. On the security setting window, scroll down and find the Scripting item, make sure that "Enable"...
  • Page 141 Chapter 5 Appendix Proxy setting Select Internet Options from Tools menu on the web browser and then select Connection tab and click LAN Settings button. Properly set up your web browser's the proxy server settings according to the local area network environment to which the pro- jector is connected.
  • Page 142 Web browser setting Netscape Navigator v.7.1 JavaScript Setting Select Preference from Edit menu on the web browser a n d t h e n s e l e c t t h e i t e m Advanced/Scripts & Plugins in the Category column.
  • Page 143 Chapter 5 Appendix MAC OS X v 10.4 Safari v.3.2.1 JavaScript enable setting Selec t Preferences... from Safari on the web browser and then select S e c u r i t y t a b a n d c h e c k E n a b l e JavaScript.

  • Page 144: Q&A

    Q&A Q&A Installation/Access Why doesn’t the setting page appear in my web browser? Following causes are possible. Please check them. 1. The projector does not connect to the network. Check LED indicators status ( p.12). - Check the connection of LAN cable if the LINK Lamp does not light green. - Check the network configuration of the projector if the ACT Lamp does not blink orange.
  • Page 145 Chapter 5 Appendix We use the DHCP/BOOTP server to assign the IP address. Is it possible to use the projector in this network environment? Possible. This projector supports the DHCP/BOOTP server. To use this projector in this network environment, set it up so that the DHCP/BOOTP server does not assign the IP address configured to this projector for another device on the network.
  • Page 146 Q&A Operation Why can't be turned on/off with web browser? Please make sure the settings of the projector are correct to use the projector. Please set the Standby mode of the projector's Setting menu to "Network". Refer to "4. Controlling the Projector" "Power control and status check"...
  • Page 147 Chapter 5 Appendix Others What are the rules for IP address assignment? If the network is constructed with TCP/IP protocol, a unique IP address is required for each piece of network equipment. The following are basic rules of the assign- ment.
  • Page 148 Q&A Can I update the firmware of the projector. It is possible to update the firmware through the network. It is required to have a special tool for the updating. For further information please consult your local deal- er. The version number of the firmware is indicated on the lower part of the "Initial setting"...
  • Page 149 NETWORK OWNER'S MANUAL SO-KA8AL SANYO Electric Co., Ltd.

This manual is also suitable for:

Plc-xm150Plc-xm100lPlc-xm150l

Table of Contents
