Page 1 UPER ® AS2021M-T2R+ AS2021M-82R+ USER’S MANUAL 1.0a...
Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
Page 3: Preface
Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the 2021M-T2R+/2021M-82R+ server. Installation and maintenance should be performed by experienced techni- cians only. The 2021M-T2R+/2021M-82R+ is a high-end server based on the SC825TQ- R700LP/SC825S2-R700LP 2U rackmount chassis and the H8DME-2/H8DM8-2, a dual processor serverboard that supports AMD Opteron 2000 series processors and up to 32/32/64 GB of registered ECC DDR2-667/533/400 SDRAM.
Page 4 AS2021M-T2R+/2021M-82R+ User's Manual Chapter 4: System Safety You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the 1011S-MR2. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the H8DME-2/H8DM8-2 serverboard, including the locations and functions of connections, headers and jumpers.
Page 5 Preface Notes...
Page 6: Table Of Contents
AS2021M-T2R+/2021M-82R+ User's Manual Table of Contents Preface About This Manual ...................... iii Manual Organization ....................iii Chapter 1: Introduction Overview ......................1-1 Serverboard Features ..................1-2 Server Chassis Features ................1-4 Contacting Supermicro ................... 1-6 Chapter 2: Server Installation Overview ......................2-1 Unpacking the System ...................
Page 7 Table of Contents Chapter 5: Advanced Serverboard Setup Handling the Serverboard ................5-1 Processor and Heatsink Installation ............... 5-2 Connecting Cables ..................5-5 Connecting Data Cables ................5-5 Connecting Power Cables ............... 5-5 Connecting the Control Panel ..............5-6 I/O Ports ......................5-7 Installing Memory ...................
Page 8 AS2021M-T2R+/2021M-82R+ User's Manual Power Fail Alarm Reset Header ............5-19 Compact Flash Power Header ............... 5-19 SGPIO ....................5-19 Jumper Settings .................... 5-20 Explanation of Jumpers ................. 5-20 CMOS Clear ................... 5-20 3rd Power Supply Fail Detect Enable/Disable ........5-21 C to PCI Enable/Disable ..............
Page 9 Table of Contents Replacing the Power Supply ..............6-6 Chapter 7: BIOS Introduction ..................... 7-1 Main Menu ...................... 7-2 Advanced Settings Menu ................7-2 Boot Menu ....................7-16 Security Menu ....................7-17 Exit Menu ...................... 7-18 Appendices: Appendix A: BIOS Error Beep Codes ..............A-1 Appendix B: BIOS POST Checkpoint Codes ............
Page 10 AS2021M-T2R+/2021M-82R+ User's Manual Notes...
Page 11: Chapter 1: Introduction
Chapter 1: Introduction Chapter 1 Introduction Overview The AS2021M-T2R+/2021M-82R+ is a high-end server that is comprised of two main subsystems: the SC825TQ-R700LP/SC825S2-R700LP 2U server chassis and the H8DME-2/H8DM8-2 dual AMD processor serverboard. Please refer to our web site for information on operating systems that have been certiﬁ ed for use with the 2021M-T2R+/2021M-82R+ (www.supermicro.com).
Page 12: Serverboard Features
AS2021M-T2R+/2021M-82R+ User's Manual SCSI Accessories 2021M-82R+ only) One (1) dual-channel SCSI backplane (BPN-SCA-825S2) One (1) Ultra320 SCSI 6-in ribbon cable (CBL-037L-U320) One (1) Ultra320 SCSI 9-in round cable (CBL-0043L) Eight (8) SCSI hot-swap drive carriers [MCP-220-00001-03(01)]* One (1) CD containing drivers and utilities *The 2021M-T2R+/2021M-82R+ is available in silver and black;...
Page 13 Chapter 1: Introduction Onboard SCSI (2021M-82R+ only) An onboard Adaptec AIC-7902W dual-channel SCSI controller in integrated into the H8DM8-2, which supports eight 80-pin SCA Ultra320 SCSI hard drives. The SCSI drives are connected to an SCA backplane that provides power, bus termination and conﬁ...
Page 14: Server Chassis Features
AS2021M-T2R+/2021M-82R+ User's Manual Server Chassis Features The following is a general outline of the main features of the SC825TQ-R700LP/ SC825S2-R700LP server chassis. System Power The SC825TQ-R700LP/SC825S2-R700LP features a redundant 700W power sup- ply composed of two separate power modules. This power redundancy feature allows you to replace a failed power supply without shutting down the system.
Page 15: Cooling System
Chapter 1: Introduction Cooling System The SC825TQ-R700LP/SC825S2-R700LP chassis has an innovative cooling de- sign that includes three 8-cm hot-plug system cooling fans located in the middle section of the chassis. An air shroud channels the airﬂ ow from the system fans to efﬁ...
Page 16: Contacting Supermicro
AS2021M-T2R+/2021M-82R+ User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
Page 17: Chapter 2: Server Installation
Chapter 2: Server Installation Chapter 2 Server Installation 2-1 Overview This chapter provides a quick setup checklist to get your 2021M-T2R+/2021M-82R+ up and running. Following these steps in the order given should enable you to have the system operational within a minimum amount of time. This quick setup assumes that your system has come to you with the processors and memory preinstalled.
Page 18: Choosing A Setup Location
AS2021M-T2R+/2021M-82R+ User's Manual Choosing a Setup Location - Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches). - Leave approximately 30 inches of clearance in the back of the rack to allow for sufﬁ...
Page 19: Rack Mounting Considerations
Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).
Page 20: Installing The System Into A Rack
AS2021M-T2R+/2021M-82R+ User's Manual Installing the System into a Rack This section provides information on installing the 2021M-T2R+/2021M-82R+ into a rack unit. If the 2021M-T2R+/2021M-82R+ has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.
Page 21 Chapter 2: Server Installation Figure 2-1. Installing Chassis Rails...
Page 22: Installing The Rack Rails
AS2021M-T2R+/2021M-82R+ User's Manual Installing the Rack Rails: Determine where you want to place the 2021M-T2R+/2021M-82R+ in the rack. (See Rack and Server Precautions in Section 2-3.) Position the ﬁ xed rack rail/slid- ing rail guide assemblies (made up of two inter-locking sections) at the desired location in the rack, keeping the sliding rail guide facing the inside of the rack and the rollers toward the front of the rack.
Page 23 Chapter 2: Server Installation Figure 2-2. Installing the Server into a Rack...
Page 24: Checking The Serverboard Setup
AS2021M-T2R+/2021M-82R+ User's Manual Checking the Serverboard Setup After you install the 2021M-T2R+/2021M-82R+ in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. 1. Accessing the inside of the System (see Figure 2-3) First, grasp the two handles on either side and pull the unit straight out until it locks (you will hear a "click").
Page 25 Chapter 2: Server Installation Figure 2-3. Accessing the Inside of the System...
Page 26: Checking The Drive Bay Setup
AS2021M-T2R+/2021M-82R+ User's Manual Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the Serial ATA drives have been properly installed and all connections have been made. 1. Accessing the drive bays All drives are accessable from the front of the server. For servicing the DVD-ROM and ﬂ...
Page 27: Chapter 3: System Interface
Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the SATA and SCSI drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of speciﬁ c components. There are also two buttons on the chassis control panel.
Page 28: Control Panel Leds
AS2021M-T2R+/2021M-82R+ User's Manual Control Panel LEDs The control panel located on the front of the chassis has several LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.
Page 29: Hdd
Chapter 3: System Interface HDD: Indicates IDE channel activity. On the 2021M-T2R+/2021M-82R+, this LED indicates SATA/SCSI and/or DVD-ROM drive activity when ﬂ ashing. Power: Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Drive Carrier LEDs SATA Drives (2021M-T2R+) Green: Each Serial ATA drive carrier has a green LED.
Page 30 AS2021M-T2R+/2021M-82R+ User's Manual Notes...
Page 31: Chapter 4: System Safety
Chapter 4: System Safety Chapter 4 System Safety Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the 2021M-T2R+/2021M-82R+ from damage: Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.
Page 32: General Safety Precautions
AS2021M-T2R+/2021M-82R+ User's Manual The power supply power cord must include a grounding plug and must be plugged into grounded electrical outlets. Serverboard Battery: CAUTION - There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarities (see Figure 4-1).
Page 33: Esd Precautions
Chapter 4: System Safety After accessing the inside of the system, close the system back up and secure it to the rack unit with the retention screws after ensuring that all connections have been made. ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other.
Page 34: Operating Precautions
AS2021M-T2R+/2021M-82R+ User's Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the 2021M-T2R+/2021M-82R+ is operating to assure proper cooling. Out of warranty damage to the 2021M-T2R+/2021M-82R+ system can occur if this practice is not strictly followed.
Page 35: Chapter 5: Advanced Serverboard Setup
Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the H8DME-2/H8DM8-2 serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter.
Page 36: Processor And Heatsink Installation
AS2021M-T2R+/2021M-82R+ User's Manual Processor and Heatsink Installation Exercise extreme caution when handling and installing the proces- sor. Always connect the power cord last and always remove it be- fore adding, removing or changing any hardware components. Installing the CPU Backplates Two CPU backplates (BKT-0011L) have been preinstalled to the serverboard to prevent the CPU area of the serverboard from bending and to provide a base for attaching the heatsink retention modules.
Page 37 Chapter 5: Advanced Serverboard Setup 3. Align pin 1 of the CPU with pin 1 of the socket. Once aligned, carefully place the CPU into the socket. Do not drop the CPU on the socket, move the CPU horizontally or vertically or rub the CPU against the socket or against any pins of the socket, which may damage the CPU and/or the socket.
Page 38 AS2021M-T2R+/2021M-82R+ User's Manual Installing the Heatsink Retention Modules Two heatsink retention modules (BKT-0012L) and four screws are included in the retail box. Once installed, these are used to help attach the heatsinks to the CPUs. To install, align the module with the standoffs of the preinstalled CPU backplate and with the four feet on the module contacting the serverboard.
Page 39: Connecting Cables
Chapter 5: Advanced Serverboard Setup Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The ribbon cables used to transfer data from the peripheral devices have been carefully routed in preconﬁ...
Page 40: Connecting The Control Panel
AS2021M-T2R+/2021M-82R+ User's Manual Connecting the Control Panel JF1 contains header pins for various front control panel connectors. See Figure 5-3 for the pin locations of the various front control panel buttons and LED indi- cators. Please note that even and odd numbered pins are on opposite sides of each header.
Page 41: I/O Ports
Chapter 5: Advanced Serverboard Setup I/O Ports The I/O ports are color coded in conformance with the PC 99 speciﬁ cation. See Figure 5-4 below for the colors and locations of the various I/O ports. Figure 5-4. Rear Panel I/O Ports Installing Memory Note: Check the Supermicro web site for recommended memory modules.
Page 42 AS2021M-T2R+/2021M-82R+ User's Manual Support The H8DM8-2/H8DME-2 supports single or dual-channel, DDR2-667/533/400 registered ECC SDRAM. Both interleaved and non-interleaved memory are supported, so you may populate any number of DIMM slots (see note on previous page and charts on following page). The CPU2 DIMM slots can only be accessed when two CPUs are installed (however, the CPU2 DIMM slots are not required to be populated when two CPUs are installed).
Page 43 Chapter 5: Advanced Serverboard Setup Populating Memory Banks for 128-bit Operation CPU1 CPU1 CPU1 CPU1 CPU2 CPU2 CPU2 CPU2 DIMM1A DIMM1B DIMM2A DIMM2B DIMM1A DIMM1B DIMM2A DIMM2B Notes: X indicates a populated DIMM slot. If adding at least four DIMMs (with two CPUs installed), the conﬁ...
Page 44: Adding Pci Cards
AS2021M-T2R+/2021M-82R+ User's Manual Adding PCI Cards 1. PCI slots The H8DME-2/H8DM8-2 has six PCI expansion slots, which includes two PCI- Express x8 slots, two 64-bit 133 MHz PCI-X slots and two 64-bit 100 MHz PCI-X slots. On the H8DM8-2, one 100 MHz PCI-X slot supports Zero Channel RAID (ZCR).
Page 45: Serverboard Details
Chapter 5: Advanced Serverboard Setup Serverboard Details Figure 5-6. H8DM8-2/H8DME-2 Serverboard Layout (not drawn to scale) PWRI FAN5 JPW1 JPW2 Mouse DIMMA 1B FAN8/CPU2 FAN USB0/1 DIMMA 1A DIMMA 2B CPU2 DIMMA 2A COM1 DIMMA 3B DIMMA 3A DIMMA 4B DIMMA 4A DIMMB 4A FAN2...
Page 46: H8Dme-2/H8Dm8-2 Quick Reference
AS2021M-T2R+/2021M-82R+ User's Manual H8DM8-2/H8DME-2 Quick Reference Jumpers Description Default Setting 3rd Power Fail Detect En/Dis Closed (Enabled) JBT1 CMOS Clear See Section 5-9 JCF1 Compact Flash Master/Slave Closed (Master) C1/2 C to PCI Enable/Disable Closed (Enabled) JPA1* SCSI Enable/Disable Pins 1-2 (Enabled) JPA2/JPA3* SCSI Channel A/B Term.
Page 47: Atx Power Connector
Chapter 5: Advanced Serverboard Setup Connecting Cables ATX Power 24-pin Connector Pin Deﬁ nitions (JPW1) ATX Power Connector Pin# Deﬁ nition Pin # Deﬁ nition +3.3V +3.3V The primary ATX power supply con- -12V +3.3V nector (JPW1) meets the SSI (Super- set ATX) 24-pin speciﬁ...
Page 48: Hdd Led
AS2021M-T2R+/2021M-82R+ User's Manual HDD LED HDD LED The HDD (IDE Hard Disk Drive) LED Pin Deﬁ nitions (JF1) connection is located on pins 13 and Pin# Deﬁ nition 14 of JF1. Attach the IDE hard drive LED cable to display disk activity. HD Active Refer to the table on the right for pin deﬁ...
Page 49: Reset Button
Chapter 5: Advanced Serverboard Setup Reset Button Reset Button Pin Deﬁ nitions (JF1) The Reset Button connection is lo- Pin# Deﬁ nition cated on pins 3 and 4 of JF1. Attach it to the hardware reset switch on the Reset computer case.
Page 50: Atx Ps/2 Keyboard And Mouse Ports
AS2021M-T2R+/2021M-82R+ User's Manual ATX PS/2 Keyboard and PS/2 Keyboard and Mouse Port Pin PS/2 Mouse Ports Deﬁ nitions Pin# Deﬁ nition The ATX PS/2 keyboard and the Data PS/2 mouse ports are located on the IO backplane. The mouse is the top Ground (green) port.
Page 51: Power Led/Speaker
Chapter 5: Advanced Serverboard Setup Power LED/Speaker PWR LED Connector Pin Deﬁ nitions (JD1) Pin# Deﬁ nition On JD1, pins 1, 2, and 3 are for the +Vcc power LED and pins 4 through 7 are for the speaker. See the tables on the Control right for pin deﬁ...
Page 52: Wake-On-Ring
AS2021M-T2R+/2021M-82R+ User's Manual Wake-On-Ring Wake-On-Ring Pin Deﬁ nitions (JWOR) The Wake-On-Ring header is desig- Pin# Deﬁ nition nated JWOR. This function allows Ground (Black) your computer to receive and "wake- Wake-up up" by an incoming call to the modem when in suspend state. See the table on the right for pin deﬁ...
Page 53: Power Fail Alarm Reset Header
Chapter 5: Advanced Serverboard Setup Power Fail Alarm Reset Alarm Reset Header Header Pin Deﬁ nitions (JAR) Pin# Deﬁ nition Connect JAR to the alarm reset but- Ground ton on your chassis (if available) or to Reset Signal a microswitch to allow you to turn off the alarm that sounds when a power supply module fails.
Page 54: Jumper Settings
AS2021M-T2R+/2021M-82R+ User's Manual Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identiﬁ ed with a square solder pad on the printed circuit board.
Page 55: 3Rd Power Supply Fail Detect Enable/Disable
Chapter 5: Advanced Serverboard Setup 3rd Power Supply Fail Detect Enable/Disable The system can notify you in the event 3rd Power Supply Fail Detect of a power supply failure. This feature Jumper Settings (J3P) assumes that three redundant power Jumper Setting Deﬁ...
Page 56: Onboard Speaker Enable/Disable
AS2021M-T2R+/2021M-82R+ User's Manual Onboard Speaker Enable/ Disable Onboard Speaker Enable/Disable The JD1 header allows you to use Pin Deﬁ nitions (JD1) either an external speaker or the in- Pins Deﬁ nition ternal (onboard) speaker. To use the 6 and 7 Jump for onboard speaker internal onboard speaker, close pins 4 and 7...
Page 57: Scsi Termination Enable/Disable
Chapter 5: Advanced Serverboard Setup SCSI Termination Enable/ Disable (H8DM8-2 only) SCSI Term. Enable/Disable Jumper Settings (JPA2, JPA3) Jumper Setting Deﬁ nition Jumpers JPA2 and JPA3 are used to Open Enabled enable or disable termination for the Closed Disabled SCSI Channel A and B connector, re- spectively.
Page 58: 5-10 Onboard Indicators
AS2021M-T2R+/2021M-82R+ User's Manual 5-10 Onboard Indicators JLAN1/JLAN2 LEDs JLAN LED (Connection Speed Indicator) The Ethernet ports (located beside LED Color Deﬁ nition the VGA port) have two LEDs. On 10/100 Mb/s each Gb LAN port, one LED indicates Amber 1 Gb/s activity when blinking while the other LED may be amber or off to indicate the speed of the connection.
Page 59: 5-11 Floppy, Ide, Scsi And Sata Drive Connections
Chapter 5: Advanced Serverboard Setup 5-11 Floppy, IDE, SCSI and SATA Drive Connections Use the following information to connect the ﬂ oppy and hard disk drive cables. The ﬂ oppy disk drive cable has seven twisted wires. A red mark on a wire typically designates the location of pin 1. A single ﬂ...
Page 60: Ide Connector
AS2021M-T2R+/2021M-82R+ User's Manual IDE Connector IDE Drive Connectors Pin Deﬁ nitions (IDE#1) Pin# Deﬁ nition Pin # Deﬁ nition There are no jumpers to con- ﬁ gure the onboard IDE#1 con- Reset IDE Ground nector unless using it for a Host Data 7 Host Data 8 compact flash device.
Page 61: Scsi Connectors
Chapter 5: Advanced Serverboard Setup SCSI Connectors Ultra320 SCSI Drive Connectors Pin Deﬁ nitions (JA1/JB2) (H8DM8-2 only) Pin# Deﬁ nition Pin # Deﬁ nition Refer to the table at right for +DB (12) -DB (12) pin deﬁ nitions for the Ultra320 +DB (13) -DB (13) SCSI connectors located at...
Page 62: 5-12 Enabling Sata Raid
AS2021M-T2R+/2021M-82R+ User's Manual 5-12 Enabling SATA RAID Now that the hardware is set up, you must now install the operating system and the SATA RAID drivers, if you wish to use RAID with your SATA drives. The installation procedure differs depending on whether you wish to have the operating system installed on a RAID array or on a separate non-RAID drive.
Page 63 Chapter 5: Advanced Serverboard Setup 2. Use the arrow keys to move to Advanced > Floppy/IDE/SATA Conﬁ guration > nVidia RAID Setup and press the <Enter> key. Once in the submenu, enable the "nVidia RAID Function" setting, which will cause the SATA0/1/2 Primary/Secondary settings to appear.
Page 64: 5-13 Installing Additional Drivers
AS2021M-T2R+/2021M-82R+ User's Manual 5-13 Installing Additional Drivers The CD that came bundled with the system contains software drivers, some of which must be installed, such as the chipset driver. After inserting this CD into your CD- ROM drive, the display shown in Figure 5-7 should appear. (If this display does not appear, click on the My Computer icon and then on the icon representing your CD-ROM drive.
Page 65: Chapter 6: Advanced Chassis Setup
Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC825TQ-R700LP/SC825S2-R700LP chassis. For component instal- lation, follow the steps in the order given to eliminate the most common problems encountered.
Page 66: Control Panel
AS2021M-T2R+/2021M-82R+ User's Manual Figure 6-1. Front and Rear Chassis Views 3.5" Drive Bays (2) Slim DVD-ROM Drive USB Ports (2), COM Port Control Panel SATA/SCSI Drives (8) Floppy Drive (optional) System Reset Main Power Keyboard/Mouse Ports 7 Low-Proﬁ le PCI Slots USB Ports COM1 Port VGA Port...
Page 67: System Fans
Chapter 6: Advanced Chassis Setup System Fans Three 8-cm hot-swap fans provide the cooling for the 2021M-T2R+/2021M-82R+. It is very important that the chassis top cover is properly installed and making a good seal in order for the cooling air to circulate properly through the chassis and cool the components.
Page 68: Drive Bay Installation/Removal
AS2021M-T2R+/2021M-82R+ User's Manual Figure 6-2. Removing System Cooling Fans Drive Bay Installation/Removal Accessing the Drive Bays SATA/SCSI Drives: You do not need to access the inside of the chassis or remove power to replace or swap SATA/SCSI drives. Proceed to the next step for instruc- tions.
Page 69: Sata/Scsi Drive Installation
Chapter 6: Advanced Chassis Setup SATA/SCSI Drive Installation 1. Mounting a SATA/SCSI drive in a drive carrier The SATA/SCSI drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airﬂ ow for the drives.
Page 70 AS2021M-T2R+/2021M-82R+ User's Manual 2. Installing/removing hot-swap SATA/SCSI drives The SATA/SCSI drive carriers are all easily accessible at the front of the chassis. These hard drives are hot-pluggable, meaning they can be removed and installed without powering down the system. To remove a carrier, push the release button located beside the drive LEDs.
Page 71: Dvd-Rom And Floppy Drive Installation
Chapter 6: Advanced Chassis Setup Hard Drive Backplane The SATA/SCSI drives plug into a backplane that provides power, drive ID and bus termination. A RAID controller can be used with the backplane to provide data security. The operating system you use must have RAID support to enable the hot- swap capability of the Serial ATA drives.
Page 72: Power Supply
AS2021M-T2R+/2021M-82R+ User's Manual Power Supply The 2021M-T2R+/2021M-82R+ has a 700 watt redundant power supply consisting of two power modules. Each power supply module has an auto-switching capabil- ity, which enables it to automatically sense and operate at a 100V - 240V input voltage.
Page 73: Chapter 7: Bios
Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMIBIOS™ Setup utility for the H8DM8-2/H8DME-2. The AMI ROM BIOS is stored in a ﬂ ash chip and can be easily upgraded using a ﬂ oppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.
Page 74: Main Menu
AS2021M-T2R+/2021M-82R+ User's Manual Main Menu When you ﬁ rst enter AMI BIOS Setup Utility, you will see the Main Menu screen. You can always return to the Main Menu by selecting the Main tab on the top of the screen with the arrow keys. The Main Menu screen provides you with a system overview, which includes the version, built date and ID of the AMIBIOS, the type, speed and number of the processors in the system and the amount of memory installed in the system.
Page 75 Chapter 7: BIOS Advanced ACPI Conﬁ guration ACPI Version Features Use this setting the determine which ACPI version to use. Options are ACPI v1.0, ACPI v2.0 and ACPI v3.0. ACPI APIC Support Determines whether to include the ACPI APIC table pointer in the RSDT pointer list.
Page 76 AS2021M-T2R+/2021M-82R+ User's Manual Floppy/IDE/SATA Conﬁ guration Onboard Floppy Controller Use this setting to Enable or Disable the onboard ﬂ oppy controller. Floppy A Move the cursor to these ﬁ elds via up and down <arrow> keys to select the ﬂ oppy type.
Page 77 Chapter 7: BIOS Primary IDE Master/Slave Highlight one of the items above and press <Enter> to access the submenu for that item. Type Select the type of device connected to the system. The options are Not Installed, Auto, CDROM and ARMD. LBA/Large Mode LBA (Logical Block Addressing) is a method of addressing data on a disk drive.
Page 78 AS2021M-T2R+/2021M-82R+ User's Manual DMA Mode Selects the DMA Mode. Options are SWDMA0, SWDMA1, SWDMA2, MWDMA0. MDWDMA1, MWDMA2, UDMA0. UDMA1, UDMA2, UDMA3, UDMA4 and UDMA5. (SWDMA=Single Word DMA, MWDMA=Multi Word DMA, UDMA=UltraDMA.) S.M.A.R.T. Self-Monitoring Analysis and Reporting Technology (SMART) can help predict impending drive failures.
Page 79 Chapter 7: BIOS decreases. The options are Auto, 0, 1, 2, 3, and 4. Select Auto to allow AMI BIOS to auto detect the PIO mode. Use this value if the IDE disk drive support cannot be determined. Select 0 to allow AMI BIOS to use PIO mode 0. It has a data transfer rate of 3.3 MBs.
Page 80 AS2021M-T2R+/2021M-82R+ User's Manual PCI/PnP Conﬁ guration Load Onboard LAN Option ROM Use this setting to Enable or Disable the onboard option ROM. Clear NVRAM Select Yes to clear NVRAM during boot-up. The options are Yes and No. Plug & Play OS Select Yes to allow the OS to conﬁ...
Page 81: Advanced Chipset Control
Chapter 7: BIOS Advanced Chipset Control NorthBridge Conﬁ guration Memory Conﬁ guration Memclock Mode This setting determines how the memory clock is set. Auto has the memory clock by code and Limit allows the user to set a standard value. MCT Timing Mode Sets the timing mode for memory.
Page 82 AS2021M-T2R+/2021M-82R+ User's Manual ECC Conﬁ guration DRAM ECC Enable DRAM ECC allows hardware to report and correct memory errors automati- cally. Options are Enabled and Disabled. 4-Bit ECC Mode Allows the user to enabled 4-bit ECC mode (also known as ECC Chipkill).
Page 83 Chapter 7: BIOS SouthBridge Conﬁ guration USB 1.1 Controller Enable or disable the USB 1.1 controller. USB 2.0 Controller Enable or disable the USB 2.0 controller. MAC0 LAN0 Settings are Auto and Disabled for MAC0 LAN0. MAC0 LAN0 Bridge Settings are Enabled and Disabled for MAC0 LAN0 bridge. MAC1 LAN1 Settings are Auto and Disabled for MAC1 LAN1.
Page 84: Dmi Event Logging
AS2021M-T2R+/2021M-82R+ User's Manual Processor & Clock Options This submenu lists CPU information and the following settings: MTRR Mapping This determines the method used for programming CPU MTRRs when 4 GB or more memory is present. The options are Continuous, which makes the PCI hole non- cacheable, and Discrete, which places the PCI hole below the 4 GB boundary.
Page 85: Console Redirection
Chapter 7: BIOS Mark All Events as Read Highlight this item and press <Enter> to mark all events as read. Clear Event Log Select Yes and press <Enter> to clear all event logs. The options are Yes and No to verify. Console Redirection Remote Access Allows you to Enable or Disable remote access.
Page 86: Hardware Health Monitor
AS2021M-T2R+/2021M-82R+ User's Manual Sredir Memory Display Delay Use this setting to set the delay in seconds to display memory information. Op- tions are No Delay, 1 sec, 2 secs and 4 secs. Hardware Health Monitor CPU Overheat Alarm Use the "+" and "-" keys to set the CPU temperature threshold to between 65 and 90 C.
Page 87 Chapter 7: BIOS IPMI Conﬁ guration View BMC System Event Log Pressing the Enter key will open the following settings. Use the "+" and "-" keys to navigate through the system event log. Clear BMC System Event Log Selecting this and pressing the Enter key will clear the BMC system event log. Set LAN Conﬁ...
Page 88: Boot Menu
AS2021M-T2R+/2021M-82R+ User's Manual Startup Delay Use this setting to Enable or Disable the startup delay. Event Message for PEF Action Use this setting to Enable or Disable event messages for a PEF action. BMC Watch Dog Timer Action This setting is used to set the Watch Dog function. The options are Disabled, Reset System, Power Down and Power Cycle.
Page 89: Security Menu
Chapter 7: BIOS Security Menu AMI BIOS provides a Supervisor and a User password. If you use both passwords, the Supervisor password must be set ﬁ rst. Change Supervisor Password Select this option and press <Enter> to access the sub menu, and then type in the password.
Page 90: Exit Menu
AS2021M-T2R+/2021M-82R+ User's Manual Exit Menu Select the Exit tab from AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Save Changes and Exit When you have completed the system conﬁ guration changes, select this option to leave BIOS Setup and reboot the computer, so the new system conﬁ guration parameters can take effect.
Page 91: Appendix A: Bios Error Beep Codes
Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
Page 92 AS2021M-T2R+/2021M-82R+ User's Manual Notes...
Page 93: Appendix B: Bios Post Checkpoint Codes
Appendix B: BIOS POST Checkpoint Codes Appendix B BIOS POST Checkpoint Codes When AMIBIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, diagnostic equipment can be attached to the computer to read I/O port 0080h. Uncompressed Initialization Codes The uncompressed initialization checkpoint codes are listed in order of execution: Checkpoint...
Page 94 AS2021M-T2R+/2021M-82R+ User's Manual Bootblock Recovery Codes The bootblock recovery checkpoint codes are listed in order of execution: Checkpoint Code Description The onboard ﬂ oppy controller if available is initialized. Next, beginning the base 512 KB memory test. Initializing the interrupt vector table next. Initializing the DMA and Interrupt controllers next.
Page 95 Appendix B: BIOS POST Checkpoint Codes Uncompressed Initialization Codes The following runtime checkpoint codes are listed in order of execution. These codes are uncompressed in F0000h shadow RAM. Checkpoint Code Description The NMI is disabled. Next, checking for a soft reset or a power on condition. The BIOS stack has been built.
Page 96 AS2021M-T2R+/2021M-82R+ User's Manual Checkpoint Code Description Interrupt vector initialization is done. Clearing the password if the POST DIAG switch is on. Any initialization before setting video mode will be done next. Initialization before setting the video mode is complete. Conﬁ guring the mono- chrome mode and color mode settings next.
Page 97 Appendix B: BIOS POST Checkpoint Codes Checkpoint Code Description The memory below 1 MB has been cleared via a soft reset. Clearing the memory above 1 MB next. The memory above 1 MB has been cleared via a soft reset. Saving the memory size next.
Page 98 AS2021M-T2R+/2021M-82R+ User's Manual Checkpoint Code Description The password was checked. Performing any required programming before WIN- BIOS Setup next. The programming before WINBIOS Setup has completed. Uncompressing the WINBIOS Setup code and executing the AMIBIOS Setup or WINBIOS Setup utility next.
Page 99 Appendix B: BIOS POST Checkpoint Codes Checkpoint Code Description Returned from adaptor ROM at E000h control. Performing any initialization required after the E000 option ROM had control next. Initialization after E000 option ROM control has completed. Displaying the system conﬁ guration next. Uncompressing the DMI data and executing DMI POST initialization next.
Page 100 AS2021M-T2R+/2021M-82R+ User's Manual Notes...
Page 101: Appendix C: System Speciﬁ Cations
Appendix C: System Speciﬁ cations Appendix C System Speciﬁ cations Processors Single or dual AMD Opteron 2000 series (Socket F) type processors Note: Please refer to our web site for a complete listing of supported processors. Chipset nVidia MCP55 Pro and NEC 720400 chipset BIOS 8 Mb AMI®...
Page 102 AS2021M-T2R+/2021M-82R+ User's Manual Expansion Slots Two PCI-Express x8 slots, two 64-bit 133 MHz PCI-X slots and two 64-bit 100 MHz PCI-X slots (supports ZCR) all with low-proﬁ le cards Serverboard 2021M-T2R+: H8DME-2 (Extended ATX form factor) Dimensions: 12 x 13.05 in (305 x 331 mm) 2021M-82R+: H8DM8-2 (Extended ATX form factor) Dimensions: 12 x 13.05 in (305 x 331 mm) Chassis...
Page 103 Appendix C: System Speciﬁ cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3-3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: EN 60950/IEC 60950-Compliant, UL Listed (USA), CUL Listed (Canada), TUV Certiﬁ...
Page 104 AS2021M-T2R+/2021M-82R+ User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signiﬁ...
