Before you use the Vigor modem, please get acquainted with the LED indicators and
connectors first.
LED
Power
ACT
LAN
DSL
INTERNET
Vigor120 Series User's Guide
a
t
o
r
s
a
n
d
C
o
n
a
t
o
r
s
a
n
d
C
o
n
Status
On
Off
Off
Blinking
On
Off
Blinking
On
Blinking
On
Off
Blinking
n
e
c
t
o
r
s
n
e
c
t
o
r
s
Explanation
The modem is powered on.
The modem is powered off.
The system is not ready or is failed.
The system is ready and can work normally.
A normal connection is through its corresponding
port.
LAN is disconnected.
Data is transmitting (sending/receiving).
DSL connection synchronized.
DSL connection is synchronizing.
Internet connection is established.
Internet connection is not established.
Data is transmitting (sending/receiving).
