Secondary Hanging System

Insert the looped end of the
braided cable through the ceiling
bracket and one of the holes in the
outlet box into the ceiling. Access
the support brace in the ceiling.
You may not be able to do this from
below the ceiling depending on
your installation site.
3mm (1/8")
Support
Brace
Outlet Box Ceiling
Drive the wood screw and
washer found in the bag
into the side of the support
brace that holds the outlet box.
Leave 3 mm (1/8") of space
between the support brace
and the washer.
10
M3546-01 • 11/13/13 • © Hunter Fan Company
www.HunterFan.com
Braided
Cable
Wrap the braided cable around
the support brace once
creating a complete circle.
Hook the looped end of the
cable over the wood screw so
that the cable lies between the
washer and the support brace.
1.866.268.1936
Tighten the loop and secure the
screw and washer all the way
down to the support brace. Coil
up the excess cable.
