SPLIT-TYPE AIR CONDITIONERS
OPERATING INSTRUCTIONS
MSZ-A09NA
MSZ-A12NA
MSZ-A15NA
MSZ-A17NA
For customers
Thank you very much for purchasing this Mitsubishi room air conditioner.
• To use this unit correctly and safely, be sure to read this operating instructions before use. Keep this manual carefully for
later reference.
• Be sure to receive a guarantee card from your dealer and check that the purchased date and shop name, etc. are entered
correctly.
• This air conditioner should not be installed by the customer. (Safety and performance functions cannot be assured.)
CONTENTS
.........................................................................................................................2
NAME OF EACH PART ....................................................................................................................................3
PREPARATION BEFORE OPERATION .........................................................................................................4
AUTO CHANGEOVER... AUTO MODE OPERATION ...............................................................................6
MANUAL OPERATION (COOL, DRY, HEAT)...............................................................................................7
AIR FLOW VELOCITY AND DIRECTION ADJUSTMENT .........................................................................7
POWERFUL OPERATION ...............................................................................................................................9
ECONO COOL OPERATION ..........................................................................................................................9
TIMER OPERATION (ON/OFF TIMER) ......................................................................................................10
FOR A LONG TIME .........................................................................................................................................10
MAINTENANCE ..............................................................................................................................................10
CLEANING THE FRONT PANEL .................................................................................................................. 11
CLEANING THE AIR FILTER (CATECHIN) ................................................................................................. 11
CLEANING THE AIR CLEANING FILTER....................................................................................................12
REPLACEMENT OF THE AIR CLEANING FILTER....................................................................................12
CHECK THE FOLLOWING AGAIN ..............................................................................................................13
WHEN YOU THINK THAT TROUBLE HAS OCCURRED........................................................................13
INSTALLATION, RELOCATION AND INSPECTION................................................................................14
English
Español
Advertisement
Table of Contents
Related Manuals for Mitsubishi Mr.Slim MSZ-A09NA
Summary of Contents for Mitsubishi Mr.Slim MSZ-A09NA
-
Page 1: Table Of Contents
MSZ-A15NA MSZ-A17NA For customers Thank you very much for purchasing this Mitsubishi room air conditioner. • To use this unit correctly and safely, be sure to read this operating instructions before use. Keep this manual carefully for later reference. • Be sure to receive a guarantee card from your dealer and check that the purchased date and shop name, etc. are entered correctly. -
Page 2: Safety Precautions
SAFETY PRECAUTIONS • • Since rotating parts and parts which could cause an electric shock are used in this product, be sure to read This air conditioner is NOT intended for use by children or infirm persons without supervisions. these “Safety Precautions” before use. WARNING •... -
Page 3: Name Of Each Part
SAFETY PRECAUTIONS NAME OF EACH PART Indoor unit CAUTION Do not operate the unit at low outside temperature (less than 14°F) in the cooling mode. • In the cooling mode, if the unit is operated at low outside temperature (less than 14°F), water con- Air inlet densed in the air conditioner may drop and wet or damage furniture, etc. -
Page 4: Preparation Before Operation
NAME OF EACH PART PREPARATION BEFORE OPERATION Remote controller Auto restart function These models are equipped with an auto restart function. If you do not want to use this function, Signal transmitting section please consult the service representative because the setting of the unit needs to be changed. Auto restart function is ... - Page 5 PREPARATION BEFORE OPERATION Remote controller Handling of the remote controller When the remote controller cannot be used (emergency operation) • The range that the signal can reach is about 20 ft. when the remote controller is pointed at the front of How to set the batteries and the current time When the batteries of the remote controller run out or the remote controller malfunctions, the emergency operation the indoor unit.
-
Page 6: Auto Changeover
AUTO CHANGEOVER... AUTO MODE OPERATION An automatic cooling and heating changeover operation system ensures easy control and year-round Description of “AUTO RESTART FUNCTION” air conditioning. Once the desired temperature is set, unit operation is switched automatically between cooling and • These units are equipped with an auto restart function. When the main power is turned on, the air conditioner will start heating according to the room temperature. -
Page 7: Manual Operation (Cool, Dry, Heat)
MANUAL OPERATION (COOL, DRY, HEAT) AIR FLOW VELOCITY AND DIRECTION ADJUSTMENT AIR FLOW velocity and direction can be selected as required. To select the COOL, DRY or HEAT mode: To change the AIR FLOW velocity, press the button. ON/OFF Press the button. - Page 8 AIR FLOW VELOCITY AND DIRECTION ADJUSTMENT Movement of the horizontal vane To change the horizontal direction of the air flow, move the vertical vane manually. COOL/DRY HEAT At the start of heating operation When air becomes Horizontal Very small warm… position air flow Horizontal position...
-
Page 9: Powerful Operation
POWERFUL OPERATION ECONO COOL OPERATION Use this operation when you want to cool/heat your room within a short time period. Use this operation when you want to be comfortable in COOL mode even with energy saved. Perform the following operations while the unit is operat- Perform the following operations while the unit is operat- ing in the MANUAL COOL/HEAT mode. -
Page 10: Timer Operation (On/Off Timer)
TIMER OPERATION (ON/OFF TIMER) WHEN THE AIR CONDITIONER IS NOT GOING TO BE USED FOR A LONG TIME It is convenient to set the timer when you go to bed, when you get home, when you get up, etc. How to set the ON timer How to set the OFF timer When it is not going to be used for a long When the air conditioner is to be used... -
Page 11: Cleaning The Front Panel
CLEANING THE FRONT PANEL CLEANING THE AIR FILTER (CATECHIN) Front panel Wipe the front panel with a soft dry cloth or Cleaning the air filter (about once every 2 weeks) wash it with water. Hold both ends of the front panel and lift the After washing the panel, wipe up the remain- Remove the air filter. -
Page 12: Cleaning The Air Cleaning Filter
CLEANING THE AIR CLEANING FILTER REPLACEMENT OF THE AIR CLEANING FILTER When the capacity is lowered because of dirt, etc., it is necessary to replace the air cleaning filter. Cleaning the air cleaning filter (about once every 3 months) Remove the air filter (left one). Soak the filter together with its frame in luke- Air cleaning filter replacement (about once every year) warm water and wash it. -
Page 13: Before Contacting The Service Representative, Check The Following Again
BEFORE CONTACTING THE SERVICE REPRE- WHEN YOU THINK THAT TROUBLE HAS OCCURRED SENTATIVE, CHECK THE FOLLOWING AGAIN Question Answer (not a malfunction) Question Answer (not a malfunction) The air conditioner cannot • This protects the air conditioner according to in- The air flow direction •... -
Page 14: Installation, Relocation And Inspection
