Options - Icom iF9011S Instruction Manual

7

OPTIONS

D BATTERY PACKS
Battery pack
BP-254* 1
BP-237* 2
1
* The BP-254 meets IPX7* requirements for waterproof
protection. When it is connected, the transceiver corresponds
to IPX7.
2
* The BP-237 meets IPX4* requirements for splash resistance.
When it is connected, the transceiver corresponds to IPX4.
3
* When the power save function is turned ON, and the operating
periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
4
* Operating period depends on the alkaline cells used.
D CHARGERS
• BC-119N
desktop charger
+ BC-145
ac adapter
For rapid charging of battery pack. An AC adapter is sup-
plied with the charger depending on versions.
Charging time: approx. 4 hours when BP-254 is attached.
• BC-121N -
multi charger
pcs.)
+ BC-157
ac adapter
For rapid charging of up to 6 battery packs (six AD-110s
are required) simultaneously. An AC adapter should be pur-
chased separately.
Charging time: approx. 4 hours when BP-254 is attached.
23
Voltage Capacity Battery life*
7.4 V 3040 mAh 9.5 hrs.
Battery case for
A6 × AA (LR6) alkaline
+ AD-110
charger adapter
+ AD-110
charger adapter
D CABLES
• CP-17L
cigarette lighter cable
3
Allows charging of the battery pack through a 12 V cigarette
lighter socket. (For BC-119N)
• OPC-515L/OPC-656
—* 4
Allows charging of the battery pack using a 13.8 V power
source instead of the AC adapter.
OPC-515L : For BC-119N
OPC-656 : For BC-121N
• OPC-1870/OPC-1871
OPC-1870 : Portable to portable zone copy cable.
OPC-1871 : Portable to mobile zone copy cable.
See the operating guide for details.
D OPTIONAL UNITS
• UT-124R
man down unit
Provides a measure of safety when working in a hazardous
environment, etc.
• UT-125
aes
D ANTENNAS
• FA-S25V/FA-S65V/FA-S66V
(6
FA-S25V: Frequency range 136–148 MHz
FA-S65V: Frequency range 148–160 MHz
FA-S66V: Frequency range 160–174 MHz
• FA-S67VC
Frequency range 136–174 MHz
(Available in the near future)
dc power cables
zone copy cables
/
des encryption unit
flexible antennas
cut antenna
