Table 15 Top N Segments Report Charts (continued)
Report
Section Chart Title
Utilization
History
Utilization
Health Chart
1.2 Top Segments
By Errors
Protocol
Distribution Of
Top Segments
Protocol
Distribution By
Octets
Error History
Error Health
Chart
2 Detail For Top
Segments
2.1 Protocol
Distribution Of
Segment By
Octets
Top Hosts
Protocol
Distribution By
Octets With
Packets Overlaid
(continued)
Description
A multiple line chart showing the history of the
utilization for each of the N segments over the report
period.
An alternative way of viewing the utilization history.
Utilization values are shown as cells with the cell color
indicating the band of utilization.
A bar chart containing the top N segments as measured
by percentage of error to total packets.
A pie chart showing the top 10 protocols seen across all
of the N segments. If more than 10 protocols are seen,
the remainder are grouped as other.
A stacked bar chart showing the protocol breakdown of
each of the N segments by octets. The order of the bars
is the same as the errors bar chart. Because errors are
not the same as octets, the bars in this chart may not
always appear in descending order. For example, the
errors on a 10Mbps Ethernet segment may be higher
than those on a 100Mbps segment but the octet count
on the 100Mbps segment may be considerably higher.
A multiple line chart showing the history of the errors
for each of the N segments over the report period.
An alternative way of viewing the error history. Error
values are shown as cells with the cell color indicating
the error percentage.
A pie chart showing the top 10 protocols seen on the
segment.
A stacked bar chart showing the top 10 hosts on the
segment by total octets sent and received. The octets
are broken down by protocol.
A stacked bar chart showing the octets over the report
time period broken down by protocol. The left hand axis
refers to the octet totals. The right hand axis refers to
the packet totals, shown as a line.
