9. System Testing
1. Follow each instruction below.
2. Verify that the system operates as indicated under each instruction. Refer to the system owners manual.
3. Check the appropriate wire connections and/or fuses if the unit fails to perform a specific function. Also
check that any options pertaining to the function are programmed properly.
Security Operation
Press LOCK once
1. Doors lock.
2. Courtesy lights (if on) shut off.
3. Unit checks to see if doors, hood or trunk are open. If open, siren (or horn) sounds once, parking lights
flash once, and system enters pre-arm mode.
Pre-arm mode:
1. The unit will wait for the open door, hood or trunk to be closed.
The LED is solid during pre-arm.
2. If the entrance is secured, the siren/horn will sound again, parking lights will flash once, and the system
will arm.
3. If the entrance is not secured after 4 minutes, the siren/horn will sound again, parking lights will flash
once, the system will arm, and the defective trigger or entrance will be ignored.
Note: If entrance is secured after 4 minutes, the system will immediately begin to monitor the entrance for
intrusion.
If the above conditions are not present:
1. Vehicle starter is disabled.
2. Siren (or horn) sounds twice / parking lights flash twice.
3. LED (Blue light) flashes slowly for duration of arm cycle.
4. After 5 seconds, unit monitors all entrances and sensors.
If door, sensor, hood/trunk or ignition input is triggered:
1. Siren/horn sounds for 30 seconds or until UNLOCK is pressed.
2. Parking lights flash
3. If the alarm system is triggered, pressing DISARM (once) will end the 30-second cycle.
The LED flashes a number of times to indicate which input triggered the alarm:
Number of flashes:
1 - Interior Theft Sensor (Shock Sensor)
2 -Hood/Trunk input
3 - Door Input
