Pin Alternate Harness - Code Alarm CA 5051 Installation Manual

5 RED/WHITE
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED/WHITE wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
6 PINK
Locate the vehicle's ignition wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position. The voltage does not drop out when the key is turned to the
START (or CRANK) position.
Connect the PINK wire to the vehicle's Ignition wire.
This wire is also used for Ignition 1 Output.

4 Pin Alternate Harness

1 LT GREEN/BLACK
This wire will supply a ( - ) 200mA pulse both upon disarming the system and
when the remote start feature is activated. Locate the factory perimeter alarm
disarm wire from the key cylinder inside the drivers door.
Verification: This wire registers ground if the key is turned to the unlock
position in the driver's door cylinder.
Connect the LIGHT GREEN/BLACK wire to the factory alarm disarm wire.
2 LT BLUE
This wire will supply a ( - ) 200mA pulse both upon arming the system and upon
successful completion of the remote start activation sequence and is typically
used to re-lock the vehicle's doors upon remote start if necessary.
2010 Audiovox Electronics Corporation. All rights reserved.
BATTERY 12V ( + )
IGNITION 1 ( + )
FACTORY DISARM /
PULSE BEFORE START ( - )
FACTORY ARM /
PULSE AFTER START ( - )
9
