Additional Ports

Mount the supplied antenna/receiver to a clear spot on the vehicle's windshield

that will not block the driver's vision. A good location is usually high on the

windshield near the rear view mirror. Be careful not to mount the antenna/receiver

on any metallic window film, as this will effect system range. Route the antenna/

receiver cable to the control module and plug into the antenna port.

Data Bus Interface Port

This 4 pin port is used for Flashlogic Door Lock and Transponder Databus

Interfaces to communicate with the vehicle's Databus. When using the DBI port to

control the Flashlogic Door Lock and Transponder Interface modules the

following options may be available. Please refer to the D2D (Data to Data)

function list available per vehicle on the tech service web site.

Tach Input

Trunk/Hatch Open

Door Lock Control

Dome Light Supervision

Factory Alarm Arm / Disarm

Brake Safety Shut Down

Diesel Glow Plug Input

Passlock / Passkey Interface (GM Only)

Transponder Interface Activation

Manual Arm / Disarm Inputs (factory keyless

controls system)
