Agitate Speeds; Spin Speeds - Whirlpool Catalyst Troubleshooting & Repair Manual

CYCLES
HEAVY DUTY
NORMAL (see notes)
PERM PRESS/CASUAL
EXTRA DELICATE
QUICK WASH
HAND WASH
WHITEST WHITES
SOAK
RINSE/SPIN
SPIN ONLY
NOTES:
• Speeds are dependent on water level and cycle selected.
• Defaults are shaded areas.
• 4 Hi, Med/1 Hi, Med = 1st 4 minutes of core wash agitate = Hi, then remaining core wash
agitate = Med. Also 1st 1 minute of rinse agitate = Hi, then remaining rinse agitate = Med.
• Intermit = Intermittent agitate at low speed.
CYCLES
1 - HEAVY
2 - REGULAR
3 - PERM PRESS
4 - DELICATE
5 - HAND WASH
6 - QUICK WASH
7 - WHITEST WHITES
8 - SOAK
9 - RINSE/SPIN
10 - SPIN ONLY
NOTES:
• All Catalyst Cleaning Action takes place at 420.

AGITATE SPEEDS

WATER LEVELS

SPIN SPEEDS

SPIN SPEED
