Hunter 30550 Owner's Manual

Form# 44103-01
20110706
©2011 Hunter Fan Co.
SAFETY INSTRUCTIONS
Save These Important Instructions
1. This Air Purifier is designed for use on a flat, level surface and
may not work properly on an uneven surface. ALWAYS place
this Air Purifier on a firm, level surface. ALWAYS place the Air
Purifier at least six (6) inches away from walls and three (3) Ft.
from heat sources such as stoves, radiators, or heaters.
2. Place the Air Purifier in an area that is out of the reach of
children.
3. Before using the Air Purifier, extend the cord and inspect for
any signs of damage. DO NOT use the product if the cord has
been damaged.
4. ALWAYS UNPLUG the Air Purifier when it is not in operation,
while the filter is being changed, and while it is being cleaned.
5. DO NOT tilt or move the Air Purifier while it is in operation.
Shut off and unplug before moving.
6. DO NOT immerse the Air Purifier in water as permanent
damage will occur. Refer to and follow the MAINTENANCE
instructions.
7 . DO NOT run the ionizer if tobacco smoke, air fresheners,
dripless wax candles, or grease from cooking is present.
OPERATION
1. Remove the desktop purifier from its packaging and set it on a
flat surface.
2. Open the filter door and remove the plastic bag around
the filter. Replace the filter with the arrow next to "Airflow
Direction" facing the main part of the unit.
Desktop Desktop Desktop
3. Plug the DC adapter into the back of the unit then into a wall
Air Purifier
outlet.
Owner's Guide
4. Turn the unit on or off by pressing the
around it will glow green when the unit is on and red after
being shut off. When you press the ionizer button
around it will glow blue when on, and will stay off when the
ionizer is off.
1. Unplug the unit and turn it over.
Model
30550
2. Remove the door covering the filter and UV bulb by pushing
down on the arrow and sliding the door out.
3. Lift the filter out of the unit and replace it with a new one.
Note: The new filter should be positioned with the arrow next to
"Airflow Direction" facing the main part of the unit.
4. Slide the door back in place until it "locks" into place.
The filter should be replaced on average every 6 months
depending on use. DO NOT try and replace the UV bulb.
button. The ring
FILTER REPLACEMENT
the ring
