• Please refer to the Setup Manual for basic information ranging from monitor installation to using the monitor. • The latest User’s Manual is available for download from our web site: http://www.eizo.com...
Page 2
EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt to brush with tissues as this may scratch the panel.
Cleaning Attention • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the panel, and also quality deterioration of the image. • Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the panel. •...
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • 25.5″ LCD Provides a display area (vertical: over 340 mm) required for radar on large ships. • Supports a resolution of 1920 × 1200.
1-2. EIZO LCD Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and the overview of the software programs. ● Disk contents and software overview The disk includes adjustment software, touch panel software, and user’s manuals. Refer to Readme.txt file on the disk for software startup procedures or file access procedures.
Chapter 2 Monitor Adjustment and Settings 2-1. Setting the Resolution ● Display resolution For details on compatible resolutions, refer to “Compatible Resolutions” in the Setup Manual. ● Setting resolution When you connect the monitor to the PC and find that the resolution is improper, or when you want to change the resolution, follow the procedure below.
2-2. Adjusting Screens ● Digital Signal Input When digital signals are input, images are displayed correctly based on the preset data of the monitor. ● Analog Signal Input Attention • It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the monitor power has been turned on, and then adjust the monitor.
2-4. Resetting Brightness (Brilliance) Reset the setting value for the screen brightness (brilliance) to the default setting. Attention • Settings cannot be recovered once this function is executed. Procedure 1. Press while holding down on the front of the monitor. The setting value for the screen brightness (brilliance) is reset to the default setting.
Chapter 3 Touch Panel Settings (FDU2602WT) This chapter explains the settings for when the FDU2602WT is used in an environment that satisfies the following conditions. • The PC and monitor are connected with a USB cable • The OS is Windows 8 or Windows 7 Attention •...
Page 12
Click “Setup” in the “Display” tab. A touchscreen specification screen with a white background is displayed. Attention • If using the monitor in a multiple monitor environment, specify the touchscreen according to the message displayed on screen. Touch the screen with your finger. The touched screen is recognized as a touchscreen.
3-2. Configuring Touch Panel Operation Settings Open the Windows Control Panel. The method for opening the Control Panel differs depending on the OS (see page 11). Click “Hardware and Sound” - “Pen and Touch”. “Pen and Touch” window appears. Configure the touch panel operation settings in the “Pen and Touch” window. For detailed settings, refer to the settings on each tab and Windows Help.
3-3. Setting Touch Sound The sound output when the screen is touched can be changed or turned off. Open the Windows Control Panel. The method for opening the Control Panel differs depending on the OS (see page 11). Click “Hardware and Sound” - “Sound” - “Change system sounds”. “Sound”...
Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your EIZO representative. 4-1. No picture Problem Possible cause and remedy 1. No picture • Checkwhetherthepowercordisconnectedproperly. • Noneoftheoperationbuttons( / / ) • Turnthemainpowerswitchon. lightup. • Turnoffthemainpower,andthenturnitonagainafew...
Possible cause and remedy 1. The screen is too bright or too dark. • Adjustthebrightness(brilliance)ofthescreen(see“2- 3.AdjustingBrightness(Brilliance)”(page9)).(TheLCD monitorbacklighthasalimitedlifespan.Whenthescreen becomesdarkorbeginstoflicker,contactyourlocalEIZO representative.) 2. The screen suddenly became dark. / • Themonitoralwaysmonitorsitsinternaltemperature. The brightness (brilliance) of the screen Iftheinternalmonitorreachesahightemperatureand cannot be set to or higher than 77% or exceedsthespecifiedvalue,themonitorwillautomatically...
The cooling fan in this product can be replaced according to the following procedure. Attention • Be sure to follow the procedure when replacing the fan. Note that EIZO Corporation assumes no responsibility for any damages caused due to improper handling of this product.
Page 19
Install the new fan. Attention • Take care when handling the fan. Dropping or imparting physical shocks to the fan may damage it. • Pay attention to the orientation of the fan when installing it. 1. Fix the fan to the monitor using the screws removed in step 3 (page 18) (recommended torque: 8.0 ±...
● Pin Assignment D-Sub mini 15-pin connector 8 7 6 Pin No. Signal Pin No. Signal Pin No. Signal RedVideo RedVideoGround Ground GreenVideo GreenVideoGround Data(SDA) BlueVideo BlueVideoGround H.Sync Ground V.Sync Ground Clock(SCL) (NC:Notconnected) DVI-D connector Pin No. Signal Pin No. Signal Pin No.
Page 25
RS-232C port • D-Sub 9-pin (female, for monitor control) Pin No. Signal Pin No. Signal Pin No. Signal Attention • The monitor is the DCE side. • Use a straight-through cable (male to female) to connect with the PC. • D-Sub 9-pin (male, for touch panel control) Pin No.
5-3. Preset Timing The following table shows factory preset analog signal timing: Attention • Display position may be deviated depending on the PC connected, which may require screen adjustment. • If a signal other than those listed in the table is input, adjust the screen. However, screen display may still be incorrect even after the adjustment.
EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO ScreenSlicer, i • Sound, Screen Administrator, and UniColor Pro are trademarks of EIZO Corporation.
- NK (Nippon Kaiji Kyokai) - BV (Bureau Veritas) * For the latest information on approvals for ship classifications, please refer to our website. http://www.eizo.com For Europe, etc. (rated 200-240 Vac) Only Warning This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
