- Page 1 PLANAR LCD MONITOR PT120/PL120 MANUAL www.planar.com...
-
Page 2: Preface
Preface REFACE About this manual This manual is designed to assist you in setting up and using the LCD monitor. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. This document con- tains proprietary information protected by copyright. - Page 3 User’s Manual • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: To comply with the limits for an FCC Class B computing device, always use the shielded signal cord supplied with this unit.
- Page 4 Preface Important Safety Instructions Please read the following instructions carefully. This manual should be retained for future use. 1. To clean the LCD Monitor screen, first, make sure the Monitor is in the power off mode. Unplug the Monitor from its power source before cleaning it. Do not spray liquid cleaners directly onto the unit.
-
Page 5: Table Of Contents
User’s Manual ABLE OF ONTENTS PREFACE ..................................I TABLE OF CONTENTS .............................IV CHAPTER 1..................................1 Your New LCD Monitor!........................1 Unpacking.............................. 1 Identifying Components ........................2 The LCD Monitor — Front View......................... 2 The LCD Monitor — Rear View .......................... 3 Adjusting the Viewing Angle........................ -
Page 6: Chapter 1
Chapter 1 HAPTER The LCD Monitor Your New LCD Monitor! Your LCD Monitor has been designed to be versatile, ergonomic and user-friendly. The LCD Monitor is capable of displaying most standards, from 640 x 480 VGA to 1024 x 768 XGA. The digital controls lo- cated on the front panel allows the user to easily adjust the Monitor’s display parameters. -
Page 7: Identifying Components
User’s Manual Identifying Components The LCD Monitor has been designed to provide easy access to all controls and peripheral ports. The follow- ing figures will help you identify the LCD Monitor’s controls and ports. The LCD Monitor — Front View Figure 1-1: The LCD Monitor Panel and Controls LCD Screen The LCD Monitor Screen is capable of producing most display standards. -
Page 8: The Lcd Monitor - Rear View
Chapter 1 The LCD Monitor — Rear View Figure 1-2: LCD Monitor’s Rear Ports LCD Monitor’s VGA Connector This 1.5 meter cable has two 15-pin D-Sub VGA connectors used to connect the monitor to your PC’s VGA card. AC Power Jack Connect the AC adapter cable to this jack. -
Page 9: Adjusting The Viewing Angle
User’s Manual Adjusting the Viewing Angle Your LCD Monitor is designed to allow you to adjust it to a comfortable viewing angle. The LCD Moni- tor’s angle setting range is from -5° to 25°. Please see Figure 1-3. Figure 1-3: Angle Settings •... -
Page 10: Connecting Video
Chapter 1 Figure 1-5: Connecting Power to the LCD Monitor Connecting Video Turn off your PC and the LCD Monitor before connecting your LCD Monitor to the com- puter. Connect the VGA signal cable to the D-sub VGA connector located at the rear of the monitor. Connect the other end of the signal cable to the PC’s VGA port. -
Page 11: Connecting The Stereo Speakers (Optional)
User’s Manual Connecting the Stereo Speakers (optional) Please refer to the following instructions for connecting the LCD Monitor’s stereo speakers. Connect the 1.5M sound cable to the Line out of your PC’s audio card. Connect the other end of the 1.5M sound cable to the LCD Monitor’s line-in jack. Please re- fer to Figure 1-7. -
Page 12: Power Management System
Chapter 1 Connect the 9-pin RS232 connector end of the PS/2 to RS232 cable provided with the op- tional touch screen package to the 9-pin RS232 serial port at the back of your PC. Please refer to Figure 1-8. Power Management System The LCD Monitor complies with the VESA DPMS (version 1.0p) power management proposal. -
Page 13: Chapter 2
HAPTER The Display Controls The LCD Monitor’s Display Controls This chapter covers the LCD Monitor’s On Screen Display (OSD). Using the OSD, you can adjust the con- trast, brightness, display position, display clarity, and color temperature. You can also adjust the stereo speaker volume and set OSD parameters. - Page 14 Chapter 2 (Basic Setting) (CONTRAST) To adjust the contrast level of the display. (BRIGHTNESS) To adjust the brightness level of the display. (VOLUME) To adjust the speaker audio volume. (Exclude 12.1 Inch) (POSITION) To automatically adjust the picture quality and alignment. It is recommended that you use this function in (AUTO-ADJUST) the windows (This function does not work in the interlaced modes) or similar environments.
- Page 15 User’s Manual Note: 1. No Signal coming When the monitor is ON and there is no Video signal re- ceived, the following message will be displayed. 2. Signal out of monitor’s supported range (Please refer to tht attached Addendum) When the frequency range is out of the monitor’s specifications, the display will show the following message on two cases: Case 1: The incoming resolution is lower than or equal to1024x768.
-
Page 16: Tft Lcd Monitor Specifications
PPENDIX Technical Information TFT LCD Monitor Specifications Model MT121/MT121T LCD Panel 12.1”SVGA Control Functions Power Software Power switch with LED indicator (Press to turn off, over 1 sec. to turn on) On-Screen Display BASIC SETTING -----CONTRAST / BRIGHTNESS (OSD) POSITION --------------AUTO ADJUST / PHASE / CLOCK / H- POSITION / V- POSITION / GRAPH/TEXT / RESET MISCELLANEOUS ---OSD H-POSITION / OSD V-POSITION/ MENU TIMER... -
Page 17: Timing For Model Pt1212N (Svga Resolution)
PPENDIX Supported Timing Timing for Model PT1212N (SVGA Resolution) Vertical Horizontal Scanning Scanning Item Standards Resolution Dot Clock Frequency Frequency (MHz) (Hz) (kHz) NEC PC98 640x400 25.20 70.15 31.50 NEC PC98 640x400 21.05 56.42 24.83 MAC 13" mode 640x480 30.24 66.67 35.00 MAC 16"... -
Page 18: Troubleshooting Procedures
PPENDIX Troubleshooting Troubleshooting Procedures This LCD Monitor was pre-adjusted in the factory with standard VGA timing. Due to output timing differ- ences among various VGA cards, you may initially experience an unstable or unclear display when a new display mode or new VGA card is selected. This LCD Monitor Supports Multiple VGA Modes. - Page 19 User’s Manual If the PC doesn’t function with the CRT monitor neither, check BIOS to see if there is a dual scan setting under the display mode item. Set the BIOS display mode to Dual Scan or CRT and try again. If there is still no display, then there may be a problem with your system. Contact technical support.
- Page 20 Tel: 1-866-PLANAR-1 (1-866-752-6271) Hours: M-F, 7am - 6pm Pacific Time © 2002 Planar Systems, Inc. 05/02 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
