- Page 1 PT1945R Touch Screen LCD Monitor USER’S GUIDE www.planartouch.com...
-
Page 2: Important Recycle Instructions
The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission. -
Page 3: Table Of Contents
Table of Contents Usage Notice Precautions ... 1 Introduction About PT1945R ... 2 Touch Screen for PT1945R ..2 Package Overview ... 3 Installation Product Overview ... 4 Front View ... 4 Bottom View ... 4 Kensington Security Slot ... 5 VESA Mount Your Monitor ... -
Page 4: Usage Notice
Usage Notice Warning - To prevent the risk of fi re or shock hazards, do not expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 5: Introduction
Introduction About PT1945R The PT1945R is a 19" fl at panel screen with an active matrix, thin-fi lm transistor (TFT) liquid crystal display (LCD). Features include: • Direct Analog signal input • Active matrix TFT LCD technology • 1280 x 1024 SXGA resolution •... -
Page 6: Package Overview
Package Overview LCD Display VGA Signal Cable Power Cord RS-232 Cable Audio-in Cable USB Cable ( A to B) Touch Screen Driver Landing Strip User’s Guide Installation CD-ROM Screw... -
Page 7: Installation Product Overview
Installation Product Overview • Front View • Bottom View Audio AC IN RS-232 POWER SWITCH... -
Page 8: Kensington Security Slot
Kensington Security Slot The monitor can be secured to your desk or any other fi xed object with Kensington lock security products. The Kensington lock is not included. -
Page 9: Vesa Mount Your Monitor
fl at panel monitor mounting devices, such as wall and table arms. The VESA mounting interface is located on the back of your monitor. To mount the monitor on an UL-listed certifi ed swing arm or other mounting fi xture, follow the instructions included with the mounting fi xture to be used. -
Page 10: Start Your Installation
5. Position all cables under the cover lip as seen in the step 5 diagram. 6. Re-attach the cable cover . Remove the screw (CBM M3x6) from the accessory box, and insert the screw into the cable cover and monitor as seen in the step 5 diagram. Step 2... -
Page 11: Remove The Deskstand
To setup this display, please refer to the following fi gure and procedures. 1. Be sure all equipment is turned off. 2. Connect the AC power cord to the power connector on the monitor and the other end into an electrical outlet (11.1). -
Page 12: (Figure 11.1)
(Figure 11.1) -
Page 13: User Controls
User Controls Side Panel Controls Menu off status Menu appear Brightness Mute Enter/Select sub-item function Power On/Off Icon key Name Menu Down Enter Power Menu on status Menu disappear/ return to main item Main item select up/ Adjust up Main item select down/ Adjust down... -
Page 14: How To Use The Osd Menus
6. To Lock the OSD / Power menu buttons, please follow the instructions below. (Please note: the monitor has to be turned ON with a valid signal preset) (a). Press “Menu” key , the OSD menu will pops upon display. - Page 15 Volume ON / OFF Mute Function Description Adjusts the maximum luminance level of the monitor. Adjusts the backlight of the monitor. The screen is moved horizontally right and left (1 pixel pitch increment). The screen is moved horizontally right and left (1 pixel pitch increment).
-
Page 16: Appendix Troubleshooting
Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. ► Check that all the I/O and power connectors are correctly and well connected as described in the "Installation"... -
Page 17: Warning Signal
The LCD display is under the power saving mode. In addition, the LCD display will enter power saving mode when experiencing a sudden signal disconnecting problem. The monitor can be activated by pressing any keyboard, triggering the mouse or touching the screen. -
Page 18: Product Dimensions
Product Dimensions 431.8 Front View Side View 249.6 Bottom View... -
Page 19: Compatibility Modes
Compatibility Modes Mode Resolution IBM VGA 720 x 400 IBM VGA 640 x 480 VESA VGA 640 x 480 VESA VGA 640 x 480 VESA SVGA 800 x 600 VESA SVGA 800 x 600 VESA SVGA 800 x 600 VESA SVGA 800 x 600 VESA XGA 1024 x 768... -
Page 20: Touch Screen Driver Installation
PT1945R Driver Install Instructions: The PT1945R is available with both RS232 and USB connections. It is Microsoft® Windows® HID (Human Interface Device) compatible if you use the USB touch screen interface. No additional software driver is required for general operation of the touch screen. A calibration tool can be installed for improved touch position accuracy. - Page 21 If you are using a PC running Windows® 7, VISTA, XP, 2000, ME, 98, NT4.0, follow the instructions below: 1. Power on the PC 2. Be sure the USB or the RS-232 Serial cable is connected from the PC to the LCD display 3.
-
Page 22: Product Registration And Technical Support
Product Registration and Technical Support Register Your Planar Products Today Thank you for choosing Planar. To assure you receive all the benefi ts of your Planar product and services, register your Planar product today. Visit our website to register your product at http://www.planar.com/support/product_registration.html. - Page 23 Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-5799 outside the United States. Hours: 24 hours a day, 7 days a week © 2009 Planar Systems, Inc. 11/09 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners.
