External Features

Connector for the 3-button mouse

The top line, on the label on the

right hand side panel, gives the

number of processors installed,

the processor speed and the

series number.

Model XW 6/2x200 Series W1

Wty: WBK@

Prod: D5210N #ABA

Sup: SAB@

S/N:

FR63412345

HP PCI Integrated 10/100 BT

Interface RJ-45 connector

Display connector on AccelGraph-

ics 3D graphics board

The same system board is used on each member of the HP Vectra XW PC

Workstation family as was used on the HP Vectra XU 6/xxx PC.
