QuickSpecs
Overview
1. Removable Media Bays
2. 48x IDE (ATAPI) CD-ROM
3. Four Hot-Plug Drive Bays
4. Four Expansion Slots (Two PCI-X, Two PCI Express)
What's New
Support for Dual-core Intel® Pentium® D 900 Series processors with 2 x 2M cache
DA - 12364 Worldwide QuickSpecs — Version 21 — 2-16-2007
HP ProLiant ML310 Generation 3
5. Processor Socket (Intel® Pentium® D or Pentium® 4)
6. Four DIMM Sockets for up to 8GB DDR2 memory
7. System Fan
8. 370W Power Supply
Page 1

Advertisement

loading

Related Manuals for HP ProLiant ML310 Generation 3

Summary of Contents for HP ProLiant ML310 Generation 3

  • Page 1 Support for Dual-core Intel® Pentium® D 900 Series processors with 2 x 2M cache DA - 12364 Worldwide QuickSpecs — Version 21 — 2-16-2007 HP ProLiant ML310 Generation 3 5. Processor Socket (Intel® Pentium® D or Pentium® 4) 6. Four DIMM Sockets for up to 8GB DDR2 memory 7.
  • Page 2 At A Glance The HP ProLiant ML310 G3 is an affordable, single processor tower server designed to provide the solid network foundation essential to fuel thriving small offices. Dual-core Intel Pentium D or Pentium 4 processing power combines with industry- leading management and essential data protection features for a secure, affordable platform that helps you run your business efficiently.

  • Page 3: Standard Features

    Expansion Slots Slot Number Storage Controllers The HP ProLiant ML310 G3 offers both SCSI and Serial models. SCSI models support U320 SCSI One of the following hard drives. Serial models support Serial Attached SCSI (SAS) and Serial ATA (SATA) hard depending on Model drives.
  • Page 4 ProLiant Essentials Foundation Pack Software DA - 12364 Worldwide QuickSpecs — Version 21 — 2-16-2007 HP ProLiant ML310 Generation 3 48x IDE (ATAPI) CD-ROM Drive Optional 1.44 MB Diskette Drive NOTE: A diskette device is required to configure the embedded SATA RAID feature.
  • Page 5 HP SIM is built on industry standards and is extensible with value-added ProLiant Essentials, Integrity Essentials and Storage Essentials software to meet individual management needs.
  • Page 6 Software and Drivers web pages and on the ProLiant Software Maintenance Pack. The most advanced configuration analysis, reporting and troubleshooting utilities used by HP and at your fingertips, available in SmartStart. Optional software offerings that selectively extend the functionality of an...
  • Page 7 NOTE: For a more complete and up-to-date listing of supported OSs and versions, please visit our OS Support Matrix at: NOTE: For an up-to-date listing of the latest drivers available for the HP ProLiant ML310, please see: http://h18023.www1.hp.com/support/files/server/us/index.html. NOTE: For more Linux OS support & certification information, please visit our the ProLiant &...
  • Page 8 HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.
  • Page 9 Standard Features Service and Support This product is covered by a global limited warranty and supported by HP Services and a worldwide network of resellers and service providers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase.
  • Page 10 Optical Drive Diskette Drive Form Factor DA - 12364 Worldwide QuickSpecs — Version 21 — 2-16-2007 HP ProLiant ML310 Generation 3 Dual-core Intel Pentium D 930 (3.0 GHz/800) 2 x 2MB L2 512 MB (1 x 512 MB) Embedded NC320i PCIe Gigabit Server Adapter...
  • Page 11 Optical Drive Diskette Drive Form Factor DA - 12364 Worldwide QuickSpecs — Version 21 — 2-16-2007 HP ProLiant ML310 Generation 3 Dual-core Intel Pentium D 930 (3.0 GHz/800) 2 x 2MB L2 512 MB (1 x 512 MB) Embedded NC320i PCIe Gigabit Server Adapter...
  • Page 12 3.0TB maximum (hot plug SATA) 48x IDE (ATAPI) CD-ROM Drive None ship standard (Optional 1.44 MB Diskette Drive) Tower (5U) (Tower to Rack Enabling Kit available) Australia Germany France Japan EURO Taiwan HP ProLiant ML310 Generation 3 Page 12...

  • Page 13: Step 1: Base Configuration

    1. Additional options selected in Step 4 will also be integrated when applicable. NOTE: Standard models of this product offering (see previous section of this document) do not support HP Factory Express Server Configuration Level 1.
  • Page 14 Hard Drive Cables HP 4-port SATA/SAS cable (target fan cable) NOTE: This cable is required when the HP 6-port SATA RAID controller is installed on hot plug SATA/SAS models of the ML310 G3. See the "Storage" section of these QuickSpecs for information on controllers and cables required to support SATA drive configurations.
  • Page 15 NOTE: For additional Integrated Light-Out Advanced Pack License Kits please see the QuickSpecs at: http://h18000.www1.hp.com/products/quickspecs/11052_div/11052_div.HTML DA - 12364 Worldwide QuickSpecs — Version 21 — 2-16-2007 HP ProLiant ML310 Generation 3 or the various ProLiant Essentials 436225-B21 436229-B21 435661-B21...
  • Page 16 (Worldwide) Serial-Attached SCSI (SAS) Hot Plug Hard Drive (SATA/SAS Hot Plug Models Only) HP 300GB 3G SAS 15K 3.5" SP HDD HP 146GB 3G SAS 15K 3.5" SP HDD HP 72GB 3G SAS 15K 3.5" SP HDD HP 36GB 3G SAS 15K 3.5" SP HDD Serial-ATA (SATA) Hot Plug Hard Drive (SATA/SAS Hot Plug Models Only) HP 750GB 1.5G SATA 7.2K 3.5"...
  • Page 17 NOTE: In compliance with the European Union's Reduction of Hazardous Substances (RoHS) initiative, the Smart Array 641, 642, 6402, and 6404 RAID controllers will not be installed in ProLiant ML310 G3 servers sold on or after July 1, 2006. Installation of these options into the ProLiant ML310 G3 would create a non-compliant server configuration.
  • Page 18 HP NC340T PCI-X 4-port 1000T Gigabit Server Adapter HP NC360T PCI Express Dual Port Gigabit Server Adapter NOTE: When either the standard NC7761 or the NC1020 is teamed with other HP NICs, Jumbo Frames and LSO features are automatically disabled.
  • Page 19 (Worldwide) For an up-to-date listing of the latest O/S and software support details for HP Ultrium tape drives, please visit: http://www.hp.com/go/connect. Internal DAT Drives HP StorageWorks DAT 72 SCSI Internal Tape Drive (Carbon)
  • Page 20 Tape Libraries HP StorageWorks MSL2024 Tape Library HP StorageWorks MSL2024 1 Ultrium 960 Drive Library HP StorageWorks MSL2024 1 Ultrium 960 4GB FC Drive Library HP StorageWorks MSL2024 1 Ultrium 920 Drive Library HP StorageWorks MSL2024 2 Ultrium 920 Drive Library...
  • Page 21 HP, R/T 2200 UPS INTL Rack Kits ProLiant Rack Enabling Kit (RoHS Compliant) NOTE: This is a 5U Rack Enabling Kit that supports the HP ProLiant ML110 and HP ProLiant ML310 servers. NOTE: Support for racks with round or square mounting holes (including all Compaq and HP Rack System /E and HP Systems), with an adjustment range of 24"...
  • Page 22 8am-5pm, M-F, excl. HP holidays, Electronic Support Plus Onsite HW support, 8am-9pm, M-F, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, Electronic Support Plus 24 Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl.
  • Page 23 HP ProLiant ML310 G3 Models Standard Memory All HP ProLiant ML310 G3 models ship with unbuffered, Advanced ECC PC2-4200 DDR2 SDRAM running at 533MHz. Standard models include a single 512 MB DIMM. Factory Integrated Models include the memory capacity of your choice.

  • Page 24: Drive Support

    Single Channel Ultra320 SCSI Adapter (SCSI Models) Smart Array 6404/256 Controller Smart Array 6402/256 Controller Smart Array 641 Controller Smart Array 642 Controller Position Supported Controller Smart Array P600/256 BBWC Controller HP 8 Internal Port SAS HBA with RAID HP ProLiant ML310 Generation 3 Page 24...
  • Page 25 160GB 1.5G SATA 7.2K 80GB 1.5G SATA 7.2K NOTE: Hot plug capability and drive LED status support requires installation of the HP 6-port SATA RAID Controller, the Smart Array P600 Controller, or a SAS HBA. NOTE: The HP 4-port SATA/SAS target fan cable (P/N 389653-B21) is required when the HP 6-port SATA RAID controller (P/N 372953-B21) is installed.
  • Page 26 64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2 64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2 USB 2.0 Port Please consult the EBS connectivity matrix at http://www.hp.com/go/ebs for detailed connectivity information. HP ProLiant ML310 Generation 3 374654-B21 374654-B21 374654-B21 374654-B21 Page 26...

  • Page 27: Technical Specifications

    Access Times (typical) Data Transfer Rate Cache Buffer DA - 12364 Worldwide QuickSpecs — Version 21 — 2-16-2007 HP ProLiant ML310 Generation 3 17.0 x 7-7/8 x 22 in (43.0 x 20.0 x 55.0 cm) 37 lb (16.8 kg) Range Line Voltage...
  • Page 28 Channel Transfer Rate SATA Protocols Internal SATA Connectors RAID levels supported RAID 0, RAID 1 DA - 12364 Worldwide QuickSpecs — Version 21 — 2-16-2007 HP ProLiant ML310 Generation 3 < 4seconds Type Semiconductor Laser GaA1As Wave Length 780 ± 25 nm Temperature 41°...
  • Page 29 The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
