QuickSpecs
Product Highlights
Auto SAS ID Selection SAS ID is automatically set when a drive is inserted into a drive bay (See drawing on top of unit
LED Indicators
Rack Density
Environment
Monitoring Unit (EMU)
I/O Module
Fault Tolerance
Manageability
Compatibility and
Integration Testing
Product Kit Contents
for bay numbering).
Front panel LEDs indicate drive activity, required drive service, and power, giving a quick visual
assessment of overall system storage status.
The MSA50 Enclosure has a 1U height.
Each MSA50 model is equipped with an EMU that constantly monitors the enclosure, the power
supplies, and fans to ensure suggested operating tolerances are maintained.
The single I/O module installed allows one SAS controller to access all drives in the MSA50.
With redundant power supplies and fans, the MSA50 provides a high level of system availability.
Using an internal host based controller, the MSA50 can be configured for RAID levels 0, 1, 1 + 0,
5, 6 (RAID ADG) when using a HP Smart Array RAID controller.
The MSA50 is managed by HP Systems Insight Manager.
Intensive compatibility and performance testing with HP ProLiant servers ensures the highest level
of integration available in the industry. For a complete list of supported HP servers and
workstations, please refer to the QuickSpecs and/or User Guide of the array controller or Host Bus
adapter that you are planning to use. The list of supported array controllers and SAS adapters is
provided under "Related Options, Controllers".
Redundant power supplies, single I/O module, 9 drive blanks, warranty card, mounting hardware,
Enclosure user guide, HP SmartStart CD Kit, documentation CD, one 2 Meter SAS external cable
and two Nema 5-15 to C13 and two IEC320-C14 to -C13 power cords.
NOTE: The included SAS cable is only for the P600 controller.
If connecting to a Smart Array P800 or a Smart Array E500 controller one of the following cables
must be ordered:
SAS 4x to Mini SAS 4x 2M – 419571-B21
SAS 4x to Mini SAS 4x 4M – 419572-B21
SAS 4x to Mini SAS 4x 6M – 419573-B21
DA - 12245 U.S. QuickSpecs — Version 15 — 10/26/2007
HP StorageWorks Modular Smart Array 50 Enclosure
Page 3
