QuickSpecs
Technical Specifications
HP StorageWorks
Modular Smart Array 50
Enclosure
Redundant Power
Supply, 180 watts
Protocol Support
O/S Support
Buttons/LED Indicators
(on front right panel-
listed top to bottom)
Drive LED Indicators
(on drive trays)
Enclosure Button/ LED
Indicators (back of unit)
Input Requirements
Relative Humidity (non-
condensing)
I/O Module Connector SAS SFF 8470 Connector
Power
Temperature Range
© Copyright 2007 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.
Shipping Dimensions
(HxWxD)
Weight (unloaded)
Weight (loaded)
Shipping Dimensions
(HxWxD)
3Gb/s SAS
1.5Gb/s SATA
Defined by specific HP array controller or SAS/SATA adapter used; please refer to the
QuickSpecs and/or User Guide of the specific array controller or adapter
UID Button (top)
System Field Replaceable Unit (FRU) LED
EMU Status LED
Fault LED (bottom)
Drive LED (top) - On-line/Activity
Drive Failure LED (bottom) - Drive Fault/Locate
UID Button (top)
System FRU (middle)
EMU Status LED (bottom)
Nominal Line Voltage
Range Line Voltage
Line Frequency
Typical Input Current
Operating
Shipping
180 Watts per supply (load)
Operating
Shipping
NOTE: To maintain proper cooling and airflow, a drive blank or drive must occupy all bays during
operation.
DA - 12245 U.S. QuickSpecs — Version 15 — 10/26/2007
HP StorageWorks Modular Smart Array 50 Enclosure
12 x 23.5 x 33 in (30.24 x 59.22 x 83.16 cm)
20 lb (9.07 kg)
30 lb (13.61kg)
12.75 x 8 x 3.75 in (32.13 x 20.16 x 9.45 cm)
110 to 240 V AC
90 to 264 V AC
47 to 63 Hz
2.3A at 120 V AC
10% to 90%
5% to 90%
50° to 94° F (10° to 35° C°)
-40° to 151° F (-40° to 66° C)
Page 10
