ROUTING INFORMATION PROTOCOL (RIP) COMMANDS

The Routing Information Protocol (RIP) commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.
Command
config rip
enable rip
disable rip
show rip
Each command is listed, in detail, in the following sections.
config rip
Purpose Used to configure RIP on the Switch.
config rip [ipif <ipif_name 12>|all] {authentication [ enable <password 16> | disable ] |
Syntax
tx_mode [disable | v1_only | v1_compatible | v2_only] | rx_mode [v1_only | v2_only |
v1_or_v2 | disable] | state [enable | disable]}
Description This command is used to configure RIP on the Switch.
<ipif_name 12> − The name of the IP interface.
Parameters
all – To configure all RIP receiving mode for all IP interfaces.
authentication [enable | disable] − Enables or disables authentication for RIP on the Switch.
tx_mode − Determines how received RIP packets will be interpreted – as RIP version V1 only, V2
Only, or V1 Compatible (V1 and V2). This entry specifies which version of the RIP protocol will be
used to transfer RIP packets. The disabled entry prevents the reception of RIP packets.
rx_mode − Determines how received RIP packets will be interpreted – as RIP version V1 only, V2
Only, or V1 or V2. This entry specifies which version of the RIP protocol will be used to receive
RIP packets. The disable entry prevents the reception of RIP packets.
state [enable | disable] − Allows RIP to be enabled and disabled on the Switch.
Restrictions Only Administrator and Operator-level users can issue this command.
Example usage:
To change the RIP receive mode for the IP interface System:
®
DGS-3600 Series Layer 3 Gigabit Ethernet Managed Switch CLI Manual
Parameters
[ipif <ipif_name 12>|all] {authentication [ enable <password 16> | disable ] |
tx_mode [disable | v1_only | v1_compatible | v2_only] | rx_mode [v1_only |
v2_only | v1_or_v2 | disable] | state [enable | disable]}
{ipif <ipif_name 12>}
• <password 16> − Allows the specification of a case-sensitive password.
• disable − Prevents the transmission of RIP packets.
• v1_only − Specifies that only RIP v1 packets will be transmitted.
•
v1_compatible – Specifies that only RIP v1 compatible packets will be transmitted.
• v2_only − Specifies that only RIP v2 packets will be transmitted.
• v1_only − Specifies that only RIP v1 packets will be received.
• v2_only − Specifies that only RIP v2 packets will be received.
• v1_or_v2 − Specifies that only RIP v1 or v2 packets will be received.
