Electro-Voice TS940S Specifications

Description
In the TS940S, Electro-Voice has combined
its expertise in constant-directivity horns, high-
frequency compression drivers and low-fre-
quency speakers and enclosures to produce a
compact, easily installed theatre stage system
with superior performance in all areas: uniform
dispersion to the highest frequencies, high ef-
ficiency, high power capacity and wide, smooth
frequency response, all in a small, compact
system.
The TS940S matches the only second-genera-
tion constant-directivity high-frequency to a
world class high-frequency driver, providing
accurate reproduction and coverage of fre-
quency from 500 Hz to 20,000 Hz. Electro-
Voice invented constant-directivity technology,
first introduced in our HR series horns in 1974.
The HP horn in the TS940S is a significant
refinement. Constant directivity means that all
frequencies are evenly spread over the horn's
rated coverage angle, so every seat in the house
can receive both clear dialogue and subtle high-
frequency effects. For low-frequencies, a single
15-inch woofer is used in an optimally vented
radiating enclosure. The high-excursion
woofer is, mounted in an optimally vented,
Thiele-Small enclosure, provide high-impact
bass from 40 through 800 Hz, at average pow-
ers up to 800 watts, when required. In the
field, the TS940S's combination of high- and
low-frequency reproduction has proven to be
an excellent choice for small to medium size
houses.
The TS940S incorporates a number of in-
staller-recommended features, for quick,
trouble-free and low-cost installations.
Among these features is a dedicated cross-
over/equalizer that is easily flush mounted
in the pre-sized, pre-drilled hole located on
the side of the low-frequency enclosure. Side
mounting provides easy wiring access when
the system is installed against a wall. Through
the use of the horn mounting kit and pre-
drilled holes in the low-frequency section is
easily mounted in the proper position on top
of the low-frequency enclosure. All pre-
drilled holes are T-nut loaded, including the
bass driver mounting holes. This means quick
and easy driver replacement. All components
of the TS940S are finished in matte black, to
eliminate any reflections back through the
screen.
TS940S
Theatre Stage System
Electro-Voice
Theatre Sound System ®
Atec Lansing
®
Voice of the Theatre
Limited Warranty
Electro-Voice products are guaranteed
against malfunction due to defects in mate-
rials or workmanship for a specified period,
as noted in the individual product-line
statement(s) below, or in the individual prod-
uct data sheet or owner's manual, beginning
with the date of original purchase. If such
malfunction occurs during the specified pe-
riod, the product will be repaired or replaced
(at our option) without charge. The product
will be returned to the customer prepaid. Ex-
clusions and Limitations: The Limited
Warranty does not apply to: (a) exterior fin-
ish or appearance; (b) certain specific items
described in the individual product-line
statement(s) below, or in the individual prod-
uct data sheet or owner's manual; (c) mal-
function resulting from use or operation of
the product other than as specified in the
product data sheet or owner's manual; (d)
malfunction resulting from misuse or abuse
of the product; or (e) malfunction occurring
at any time after repairs have been made to
