Summary of Contents for Ford 2011 C-Max

  • Page 1 Feel the difference FordC-MAX Owner's handbook...
  • Page 2 This publication, or part thereof, may not be reproduced nor translated without our approval. Errors and omissions excepted. © Ford Motor Company 2011 All rights reserved. Part number: (CG3567en) 12/2010 20110125082809...
  • Page 3: Table Of Contents

    Table of contents Introduction Alarm About this handbook........7 Principle of operation......49 Symbols glossary........7 Arming the alarm........50 Parts and accessories......7 Disarming the alarm........50 Quick start Steering wheel Quick start..........10 Adjusting the steering wheel....51 Audio control..........51 Child safety Voice control..........52 Child seats..........19 Wipers and washers Booster cushions........20 Child seat positioning......21...
  • Page 4 Table of contents Electric exterior mirrors......74 Glasses holder........125 Auto-dimming mirror......75 Childminder mirror.........126 Blind spot monitor........75 Auxiliary input (AUX IN) socket....126 USB port..........127 Instruments Satellite navigation unit holder.....127 Gauges.............78 Floor mats..........127 Warning lamps and indicators....80 Starting the engine Audible warnings and indicators..82 General information......128 Information displays Ignition switch........128...
  • Page 5 Table of contents Rear under floor storage......165 Brakes Cargo nets..........165 Principle of operation......145 Roof racks and load carriers....167 Hints on driving with ABS.....145 Parking brake.........145 Towing Stability control Towing a trailer........170 Retractable tow ball......170 Principle of operation......146 Using stability control......146 Driving hints Hill start assist Running-in..........174...
  • Page 6 Table of contents Engine oil check........193 Audio system security Engine coolant check......193 Security code........229 Brake and clutch fluid check....194 Washer fluid check........194 Audio unit operation Technical specifications......195 On/off control........230 Sound button........230 Vehicle care Waveband button.........230 Cleaning the exterior......197 Station tuning control......230 Cleaning the interior......197 Station preset buttons......231 Repairing minor paint damage....198...
  • Page 7 Table of contents Bluetooth setup........241 Using TMC..........281 Telephone setup........241 Map updates Telephone controls......242 Map updates.........282 Using the telephone......243 Voice control Appendices Type approvals........283 Principle of operation......245 Type approvals........283 Using voice control.......245 Audio unit commands......246 Type approvals........283 Telephone commands......253 Type approvals........284 Climate control commands....258 Type approvals........284 Electromagnetic compatibility....285...
  • Page 9: Introduction

    Ford parts are Ford parts the range, sometimes even before they are generally available. It may describe Your Ford has been built to the highest options not fitted to your vehicle. standards using high quality Ford Original Note: Always use and operate your Parts.
  • Page 10 Introduction Look for the Ford logo on the following parts Sheet metal • Bonnet • Wings • Doors • Luggage compartment lid or tailgate E130166 Exterior mirror E130165 Bumper and radiator grille • Radiator grille • Front and rear bumper...
  • Page 11 Introduction E130168 Lighting • Rear lamps • Headlamp E130169...
  • Page 12: Quick Start

    Quick start QUICK START Instrument panel overview Left-hand drive Q P O E130098...
  • Page 13 Quick start Right-hand drive E130099 Air vents. See Air vents (page 101). Direction indicators. See Direction indicators (page 61). Main beam. See Lighting control (page 58). Information display control (all vehicles except right-hand drive vehicles with voice control). See Information displays (page 84). Information and entertainment display control (right-hand drive vehicles with voice control only).
  • Page 14 Quick start Information and entertainment display control (left-hand drive vehicles with voice control only). See Audio control (page 51). Information display control (right-hand drive vehicles with voice control only). See Information displays (page 84). Wiper lever. See Wipers and washers (page 53). Information and entertainment display.
  • Page 15 Quick start The luggage compartment lid can be One long flash of the direction indicators operated using the remote control, the confirms that all the doors and the centre console switch, the luggage luggage compartment lid have been compartment lid switch or the luggage unlocked and that the alarm has been compartment lid release handle.
  • Page 16 Quick start Autolamps E95179 E70719 See Adjusting the steering wheel (page 51). The headlamps will come on and go off automatically depending on the ambient Autowipers light. See Autolamps (page 59). Electric windows Note: To reduce wind noise or buffeting when just one window is open, open the opposite window slightly.
  • Page 17 Quick start Electric folding mirrors Manual climate control Heating the interior quickly E129884 Cooling the interior quickly E72623 E129887 See Electric exterior mirrors (page Defrosting and demisting the 74). windscreen Information displays E129888 See Manual climate control (page 102). E130248 Use the arrow buttons to navigate through the menus and press OK to make a selection.
  • Page 18 Quick start Automatic climate control Press and hold the start button for two seconds, or press three times within three seconds. Press the start button. See Keyless starting (page 130). Diesel particulate filter (DPF) WARNING Do not park or idle your vehicle over dry leaves, dry grass or other E91391 combustible materials.
  • Page 19 Quick start Manual transmission Selecting reverse gear E119080 Insert the fuel nozzle up to and including the first notch on the nozzle. Keep it resting on the cover of the fuel pipe E99067 opening. On some vehicles it is necessary to raise the collar whilst selecting reverse gear.
  • Page 20 Quick start E80836 Park Reverse Neutral Drive Sport mode and manual shifting See Automatic transmission (page 142). Speed limiter The system allows you to set a speed, to which the vehicle then becomes limited. See Speed limiter (page 162). Towing the vehicle on four wheels CAUTION For certain engine and transmission...
  • Page 21: Child Safety

    Child safety CHILD SEATS WARNINGS Do not leave unattended children in your vehicle. If your vehicle has been involved in an accident, have the child restraints checked by properly trained technicians. Note: Mandatory use of child restraints E133140 varies from country to country. Only child restraints certified to ECE-R44.03 (or later) have been tested and approved for use in your vehicle.
  • Page 22: Booster Cushions

    Child safety Child safety seat CAUTION When using a child seat on a rear seat, make sure that the child seat rests tightly against the vehicle seat. It may be necessary to lift or remove the head restraint. See Head restraints (page 111).
  • Page 23: Child Seat Positioning

    Note: When using a child seat on a front Please consult your Dealer for the seat, always adjust the front passenger latest details relating to Ford seat to its fully rearwards position. If it recommended child seats. proves difficult to tighten the lap section...
  • Page 24 Child safety Mass group categories Up to 10 Up to 13 9 - 18 kg 15 - 25 kg 22 - 36 kg Seating positions Child Booster seat or Baby safety seat safety cushion seat Second row seats - Grand C-MAX Second row seats - C- Third row seats - Grand C-MAX...
  • Page 25 ISOFIX child restraints. At time of publishing the recommended Group O+ ISOFIX baby safety seat is the Britax Romer Baby Safe. Please consult your Dealer for the latest details relating to Ford recommended child seats. At time of publishing the recommended Group 1 ISOFIX child seat is the Britax Romer Duo.
  • Page 26: Isofix Anchor Points

    Child safety Top tether anchor points - All ISOFIX ANCHOR POINTS vehicles WARNING Use an anti-rotation device when using the ISOFIX system. We recommend the use of a top tether or support leg. Note: When you are purchasing an ISOFIX restraint, make sure that you know the correct mass group and ISOFIX size class for the intended seating locations.
  • Page 27: Child Safety Locks

    Child safety WARNINGS Make sure that the top tether strap is not slack or twisted and is properly located on the anchor point. Note: Where applicable, remove the luggage cover to ease installation. See Luggage covers (page 165). 1. Route the tether strap to the anchor point.
  • Page 28 Child safety Electric child safety locks C-MAX Note: Pressing the switch will also disable the rear electric window switches. E112197 Grand C-MAX E124779 E130124 Left-hand side Turn anti-clockwise to lock and clockwise to unlock. Right-hand side Turn clockwise to lock and anti-clockwise to unlock.
  • Page 29: Occupant Protection

    Occupant protection Front airbags PRINCIPLE OF OPERATION Airbags WARNINGS Do not modify the front of your vehicle in any way. This could adversely affect deployment of the airbags. Extreme Hazard! Do not use a rearward facing child restraint on a seat protected by an airbag in front of it! E74302...
  • Page 30 Occupant protection Side airbags WARNINGS Never use a seat belt for more than one person. Use the correct buckle for each seat belt. Do not use a seat belt that is slack or twisted. Do not wear thick clothing. The seat belt must fit tightly around your body to achieve its optimum effect.
  • Page 31: Fastening The Seat Belts

    Occupant protection FASTENING THE SEAT BELTS WARNINGS Insert the tongue into the buckle until you hear a distinct click. You have not fastened the seat belt properly if you do not hear a click. In order to ensure that the centre belt works properly, the rear seatback must be correctly engaged.
  • Page 32 Occupant protection When in use, the rear seat belts should be placed in the belt guides on the outboard seatbacks. Second row centre seat belt E129523 Press the red button on the right buckle to release the belt. Let it retract. Press the button on the side of the black buckle to release the belt.
  • Page 33 Occupant protection Grand C-MAX Second row centre seat belt Second row centre seat belt anchor point E129522 The retractor for the rear centre seat belt is located in the roof. To fasten the seat belt: 1. Pull the belt out steadily. It may lock if you pull it sharply or if the vehicle is on a slope.
  • Page 34 Occupant protection E129524 E135424 Press the red button on the right buckle to release the belt. Let it retract. Unclip the spring hook to release the belt. Let it retract completely and smoothly to the retractor in the roof. Stow the tongue securely flat against the roof trim.
  • Page 35: Seat Belt Height Adjustment

    Occupant protection Deactivating the seat belt SEAT BELT HEIGHT reminder ADJUSTMENT See your dealer. Grand C-MAX only Rear seat belt reminder WARNING If multiple belts are unfastened within a few seconds of each other, only one audible chime will sound. Note: Press the OK button on the steering wheel control to confirm the message.
  • Page 36: Disabling The Passenger Airbag

    Occupant protection Note: The key switch is located at the WARNING end of the instrument panel on the side Position the seat belt correctly for of the glove compartment. The airbag your safety and that of your unborn deactivation lamp is located between the child.
  • Page 37 Occupant protection Enabling the passenger airbag WARNING Make sure that the passenger airbag is enabled when you are not using a child restraint on the front passenger seat. Turn the switch to position B.
  • Page 38: Keys And Remote Controls

    Keys and remote controls 3. Leave the key in position 0 and press GENERALINFORMATIONON any button on the remote control RADIO FREQUENCIES within 10 seconds. You will receive confirmation via a chime or LED that CAUTIONS programming has been successful. The radio frequency used by your Note: Further remote controls may be remote control can also be used by...
  • Page 39 Keys and remote controls Remote control with a folding 4. Turn the remote control over to key blade remove the battery. 5. Install a new battery (3V CR 2032) with the + facing upwards. 6. Replace the battery cover. Remote control without a folding key blade E128809 1.
  • Page 40 Keys and remote controls E119190 4. Carefully insert the screwdriver in the position shown to open the remote control. E125860 CAUTION Do not touch the battery contacts or the printed circuit board with the screwdriver. 5. Carefully prise out the battery with the screwdriver.
  • Page 41: Locks

    Locks Double locking is a theft protection feature LOCKING AND UNLOCKING that prevents someone from opening the doors from the inside. CAUTION Double locking with the key Check your vehicle is locked before leaving it unattended. Turn the key to the lock position twice within three seconds.
  • Page 42 Locks Reprogramming the unlocking WARNINGS function Careless opening and closing of the luggage compartment lid can The unlocking function may be override the protection function and reprogrammed so that only the driver’s cause injuries. door is unlocked ( See Programming the remote control (page 36).
  • Page 43 Locks Luggage compartment lid switch To stop the luggage compartment lid, you can either: • Press the button on the remote control. A further remote control operation will be delayed for approximately three seconds. • Press the centre console switch, the luggage compartment lid switch or the luggage compartment lid release handle.
  • Page 44 Locks Note: A recessed grip is incorporated C-MAX inside the luggage compartment lid to facilitate manual closing. To close the luggage compartment lid, you can either: • Press the button on the remote control twice within three seconds. • Press and hold the button on the remote control for at least three seconds.
  • Page 45: Keyless Entry

    Locks Unlocking Note: If the child safety locks have also been activated, pulling the internal lever will only deactivate the emergency locking and not the child safety lock. The doors can only be opened using the external door handle. Note: If the doors have been unlocked using this method, the doors must be locked individually until the central locking function has been repaired.
  • Page 46 Locks Note: If a second valid passive key is located within the rear exterior detection range, the luggage compartment lid can be closed. Unlocking the vehicle Note: If the vehicle remains locked for longer than three days, the keyless system will enter an energy-saving mode. This is to reduce the discharge of the vehicle battery.
  • Page 47: Global Opening And Closing

    Locks Locking and unlocking the One long flash of the direction indicators confirms that all the doors and the doors with the key blade luggage compartment lid have been unlocked and that the alarm has been disarmed. Unlocking only the driver's door If the unlocking function is reprogrammed so that only the driver’s door and the luggage compartment lid are unlocked (...
  • Page 48 Locks Global opening E71956 To close all the windows, press and hold E71955 the remote control lock button for at To open all the windows, press and hold least three seconds. Press the lock or the remote control unlock button for at unlock button to stop the closing function.
  • Page 49 Locks To close all the windows, press and hold the driver’s door handle for at least two seconds. The anti-trap function is also active during global closing.
  • Page 50: Engine Immobiliser

    If you lose a key, you can obtain a replacement from your Ford Dealer. If possible, provide them with the key number from the tag provided with the original keys. You can also obtain additional keys from your Ford Dealer.
  • Page 51: Alarm

    Alarm Battery back-up sounder PRINCIPLE OF OPERATION The battery back-up sounder is an extra Alarm system alarm system which will sound a siren when the alarm is triggered. It is armed Your vehicle may be equipped with one directly when you lock the vehicle. The of the following alarm systems: sounder has its own battery and will •...
  • Page 52: Arming The Alarm

    Alarm Note: False alarms can also be triggered ARMING THE ALARM by the auxiliary heater See Auxiliary heater (page 107). If you are using the To arm the alarm, lock the vehicle. See auxiliary heater, direct the air flow towards Locks (page 39).
  • Page 53: Steering Wheel

    Steering wheel ADJUSTING THE STEERING WARNING WHEEL Make sure that you fully engage the locking lever when returning it to its original position. WARNING Never adjust the steering wheel AUDIO CONTROL when the vehicle is moving. Select the required source on the audio Note: Make sure that you are sitting in unit.
  • Page 54: Voice Control

    Steering wheel Type 2 VOICE CONTROL E129463 E129464 Volume up Pull the button to select or deselect voice control. See Voice control (page 245). Seek up or next Volume down Seek down or previous Mode Press the mode button to select the audio source.
  • Page 55: Wipers And Washers

    Wipers and washers Automatic wiper system WINDSCREEN WIPERS Some models without autowipers are fitted with a speed-dependent front screen wiper system. When the vehicle is slowed to walking speed or is brought to a standstill, the wiper speed will automatically switch to the next lower wiper speed setting.
  • Page 56: Windscreen Washers

    Wipers and washers WARNING Do not operate the washer for more than 10 seconds at a time, and never when the reservoir is empty. Whilst the lever is pulled towards the steering wheel the washer will work in conjunction with the wipers. After releasing the lever, the wipers operate for a short time.
  • Page 57: Adjusting The Windscreen Washer Jets

    Wipers and washers Reverse gear wipe ADJUSTING THE WINDSCREEN WASHER The rear wiper will be activated automatically when selecting reverse gear JETS if the rear wiper is not already switched on and the front wiper is operating. Rear window washer E129194 E73425 The eye ball jets can be adjusted precisely...
  • Page 58: Checking The Wiper Blades

    Wipers and washers Note: The windscreen wiper blades are CHECKING THE WIPER different in length. See Technical BLADES specifications (page 57). If you install wiper blades of the wrong length, the rain sensor may not work correctly. Service position E129989 E66644 Run the tip of your fingers over the edge of the blade to check for roughness.
  • Page 59: Technical Specifications

    Wipers and washers E129990 1. Press the locking buttons together. 2. Rotate and remove the wiper blade. E130060 Note: Make sure that the wiper blade 2. Slightly rotate the wiper blade from the locks into place. wiper arm. 3. Install in the reverse order. 3.
  • Page 60: Lighting

    Lighting One side LIGHTING CONTROL Lighting control positions E130139 Right-hand side Left-hand side Main and dipped beam E70718 Side and tail lamps Headlamps Parking lamps CAUTION Prolonged use of the parking lamps will discharge the battery. E130140 Push the lever forward to switch between Switch off the ignition.
  • Page 61: Autolamps

    Lighting Home safe lighting Switch the ignition off and pull the direction indicator lever towards the steering wheel to switch the headlamps on. You will hear a short tone. The headlamps will go off automatically after 3 minutes with any door open, or 30 seconds after the last door has been closed.
  • Page 62: Rear Fog Lamps

    Lighting REAR FOG LAMPS HEADLAMP LEVELLING Note: Vehicles with Xenon headlamps are equipped with automatic headlamp levelling. E70720 WARNINGS Only use the rear fog lamps when visibility is restricted to less than 50 metres. Do not use the rear fog lamps when E70722 it is raining or snowing and visibility is more than 50 metres.
  • Page 63: Hazard Warning Flashers

    Lighting HAZARD WARNING DIRECTION INDICATORS FLASHERS E71943 For item location: See Quick start (page 10). E130141 Note: Tap the lever up or down to make the direction indicators flash only three times. CORNERING LAMPS E72898...
  • Page 64: Interior Lamps

    Lighting Headlamp beam Cornering lamp beam If you press and hold switch B for 3 The cornering lamps illuminate the inside seconds all lamps will stay off regardless of a corner when you are turning. of the doors or luggage compartment lid position.
  • Page 65: Changing A Bulb

    Lighting 4. Lift the outer side of the headlamp and CAUTIONS remove it. Only fit bulbs of the correct specification. See Bulb specification chart (page 70). Note: The following instructions describe how to remove the bulbs. Fit replacements in the reverse order unless otherwise stated.
  • Page 66 Lighting 2. Remove the cover. 3. Disconnect the electrical connector. 4. Release the clip and remove the bulb. Headlamp dipped beam CAUTION Do not touch the glass of the bulb. 1. Remove the headlamp. See Removing a headlamp (page 62). E130174 2.
  • Page 67 Lighting Side repeater E130177 E72263 2. Remove the cover. 1. Carefully remove the side repeater. 3. Disconnect the electrical connector. 4. Release the clip and remove the bulb. Side lamp 1. Remove the headlamp. See Removing a headlamp (page 62). E72291 2.
  • Page 68 Lighting Front fog lamps E72264 1. Insert a screwdriver into the gap E99405 between the mirror housing and the mirror glass and release the metal Note: You cannot separate the fog lamp retaining clip. bulb from the bulb holder. 1. Using a suitable implement, remove the cover.
  • Page 69 Lighting 4. Disconnect the electrical connector. 5. Turn the bulb holder anti-clockwise and remove it. Rear lamps Direction indicator, tail and brake lamp E130198 5. Remove the bulb holder. 6. Gently press the bulb into the bulb holder, turn it anti-clockwise and remove it.
  • Page 70 Lighting Central high mounted brake lamp E87619 E130200 1. Detach the clips. 2. Remove the wing nut. 3. Remove the lamp. E130235 2. Insert a suitable object into the holes. E130201 3. Carefully pull the lamp towards the front of the vehicle to release the 4.
  • Page 71 Lighting Number plate lamp E72789 1. Carefully release the spring clip. E130236 2. Remove the lamp. 4. Remove the lamp. 3. Turn the bulb anti-clockwise and remove it. Interior lamps Vehicles with LED lamps Note: The LED board is not a serviceable item, please consult your dealer if this fails.
  • Page 72: Bulb Specification Chart

    Lighting Luggage compartment lamp, 1. Carefully prise out the lamp. footwell lamp and tailgate lamp 2. Remove the bulb. E72784 BULB SPECIFICATION CHART Lamp Specification Power (watt) Front direction indicator PY21W Headlamp main beam Headlamp dipped beam Cornering lamp Front fog lamp Side lamp Side repeater WY5W...
  • Page 73 Lighting Lamp Specification Power (watt) Central high mounted stop lamp Luggage compartment lamp Fit a replacement with the same rating as the one you have removed.
  • Page 74: Windows And Mirrors

    Windows and mirrors Opening and closing the ELECTRIC WINDOWS windows automatically WARNING Press or lift the switch to the second action point and release it completely. Do not operate the electric windows Press or lift it again to stop the windows. unless they are free from obstruction.
  • Page 75: Exterior Mirrors

    Windows and mirrors The electric windows will stop 1. Lift and hold the switch until the automatically while closing and reverse window is fully closed. some distance if there is an obstacle in 2. Release the switch. the way. 3. Lift the switch again for one more second.
  • Page 76: Electric Exterior Mirrors

    Windows and mirrors Electric folding mirrors ELECTRIC EXTERIOR MIRRORS Automatic folding and unfolding Note: If the mirrors have been folded using the manual fold button they can only be unfolded using the manual fold button. The mirrors will fold automatically when you lock the vehicle with the key, the remote control or a keyless entry system request.
  • Page 77: Auto-Dimming Mirror

    Windows and mirrors If you press the switch again while the The system is a convenience feature that mirrors are moving, they will stop and aids the driver in detecting vehicles that reverse the direction of movement. may have entered the blind spot zone (A). The detection area is on both sides of the Note: When the mirrors are operated vehicle extending rearwards from the...
  • Page 78 Windows and mirrors Note: On vehicles with automatic Detection limitations transmission, the system is active only in There may be certain instances where S, D and N. vehicles entering and exiting the blind spot The system is only active when you zones may not be detected.
  • Page 79 Windows and mirrors When you turn the system off no further Trailer towing false alerts alerts will be received. The BLIS warning CAUTION indicator will illuminate. See Warning lamps and indicators (page 80). Vehicles fitted with a trailer tow module not approved by us may not Detection errors correctly be detected.
  • Page 80: Instruments

    Instruments GAUGES Type 1 E130149 Information display. See Information displays (page 84). Speedometer Engine coolant temperature gauge Fuel gauge Tachometer...
  • Page 81 Instruments Type 2 E130150 Information display. See Information displays (page 84). Speedometer Engine coolant temperature gauge Fuel gauge Tachometer If the needle enters the red section, the Engine coolant temperature engine is overheating. Stop the engine, gauge switch the ignition off and determine the cause once the engine has cooled All vehicles down.
  • Page 82: Warning Lamps And Indicators

    Instruments Brake system lamp WARNING LAMPS AND INDICATORS It illuminates when the parking brake is engaged. The following warning lamps and indicators illuminate when the ignition is WARNING switched on: Reduce your speed gradually and • stop your vehicle as soon as it is safe to do so.
  • Page 83 Instruments Low fuel level warning lamp CAUTION If the engine warning lamp illuminates If it illuminates, refuel as soon as in conjunction with a message, have possible. the system checked as soon as possible. Main beam indicator Front fog lamp indicator It will illuminate when you switch the headlamp main beam on.
  • Page 84: Audible Warnings And Indicators

    Instruments Stability control (ESP) indicator 4. Highlight Information or Warning and press the OK button to switch While driving, it flashes during the chime on and off. activation of the system. After 5. Press the left arrow button to exit the switching on the ignition, if it menu.
  • Page 85 Instruments Low fuel Grand C-MAX rear seat belt reminder A warning chime will sound when the remaining fuel is less than 8 litres (1.8 WARNING gallons). If multiple belts are unfastened within a few seconds of each other, Luggage compartment lid - only one audible chime will sound.
  • Page 86: Information Displays

    Information displays Settings GENERAL INFORMATION Note: The information display will remain on for several minutes after you switch off Controls the ignition. Press the up and down arrow buttons Various systems on your vehicle can be to scroll through and highlight the options controlled using the information display within a menu.
  • Page 87 Information displays Trip Computer Trip odometer Dist to empty Instant fuel Average fuel Ford EcoMode Gear shifting Anticipation Speed Ford EcoMode Average speed Outside air All values Information Deflat detection Seatbelts Auto StartStop Settings Driver assist Traction ctrl BLIS Hill start assist...
  • Page 88 Information displays Measure unit l/100km Miles/Gallon °Celsius Temp unit °Fahrenheit Chimes Park slot found Information Warning Convenience Aux heater Park heater Time 1 Time 2 Once Heat now Full guard Alarm Reduced Ask on exit System check E130510 Menu structure - information and entertainment display You can access the menu using the buttons on the audio or navigation unit.
  • Page 89 Information displays All vehicles Radio FM AST DAB1 DAB2 AM AST Auxiliary iPOD Bluetooth audio Line in Phone Dial number Phone book Call lists Bluetooth Redial Select phone Reject all calls Menu Audio settings Adaptive volume Sound Nav audio mixing DSP settings DSP equaliser News...
  • Page 90 Information displays Vehicles with navigation system Navigation Route Active guidance Route sections list Block next section Unblock rt sectn Country Destination input City/postcode Street District Start guidance Traffic TMC messages Block next section Route sections list Unblock rt sectn Start guidance Home address Change address Last destinations...
  • Page 91 Information displays Eco settings Trailer Roof box Dynamic Motorway Tunnel Ferry/motorail Toll Seasonal roads Toll sticker Special functions GPS info System info Enter position Demo mode See separate menu structure Radio See separate menu structure Auxiliary See separate menu structure Phone See separate menu structure Menu...
  • Page 92: Trip Computer

    Information displays Assistance options Signs/lanes Speed limits Nav icons in lists Personal data Clear last destination Clear favourites Delete home address Clear all Reset all settings See separate menu structure Audio Settings Clock Settings See separate menu structure E130536 Outside air temperature TRIP COMPUTER Shows the outside air temperature.
  • Page 93: Information Messages

    Information displays Measure units To toggle between metric and imperial units, scroll to this display and press the OK button. Toggling the units of measure using this display will affect the following displays: • Distance to empty. • Average fuel consumption. •...
  • Page 94 Information displays Alarm Message Message Action indicator Alarm triggered check vehicle amber See Alarm (page 49). Alarm malfunction service Have the system checked by a required properly trained technician. Battery and charging system Message Message Action indicator Stop your vehicle as soon as it is safe to do so and switch off the Electrical system overvoltage ignition.
  • Page 95 Information displays Child power lock Message Message Action indicator Have the system checked by a Child lock malfunction service amber properly trained technician as required soon as possible. Doors open Message Message Action indicator Vehicle is moving. Stop the Driver door open vehicle as soon as safely possible and close.
  • Page 96 Stop your vehicle as soon as it is safe to do so and switch off the Steering malfunction stop safely ignition. Have the system checked by a properly trained technician as soon as possible. Ford KeyFree switch ignition off See Keyless starting (page press POWER 130).
  • Page 97 Information displays Message Message Action indicator Ford KeyFree key not inside car See Keyless entry (page 43). Ford KeyFree key inside vehicle amber Keyless system. Have the system checked by a Steering malfunction service now amber properly trained technician. Ford KeyFree no key detected See Keyless entry (page 43).
  • Page 98 Information displays Message Message Action indicator One or both of the headlamp dipped beam bulbs have blown. Dipped beam bulb fault Check the headlamp dipped beam bulbs. See Changing a bulb (page 63). One or both of the brake lamp bulbs on your trailer have blown.
  • Page 99 Information displays Message Message Action indicator Have the system checked by a Water detected in fuel service amber properly trained technician as required soon as possible. Have the system checked by a Engine malfunction service now amber properly trained technician as soon as possible.
  • Page 100 Information displays Message Message Action indicator Auto StartStop Have the system checked by a properly trained malfunction service amber technician. required The engine needs to be restarted, press the Auto StartStop Press clutch pedal to start. See Using start-stop clutch to start engine (page 134).
  • Page 101 Information displays Message Message Action indicator has cooled. Select N (NEUTRAL) or P (PARK) and apply the foot brake and parking brake until the transmission has cooled and the message disap- pears from the display. Have the system checked by a Transmission malfunction service properly trained technician as soon as possible.
  • Page 102 Information displays Tyre pressure monitoring system Message Message Action indicator The pressure in one or more tyres Check tyre pressures amber has dropped. Check as soon as possible. Permanent malfunction. Have Tyre pressure sys malfunction amber your vehicle checked by a prop- service required erly trained technician.
  • Page 103: Climate Control

    Climate control Warming the interior PRINCIPLE OF OPERATION Direct the air towards your feet. In cold or Outside air humid weather conditions, direct some of the air towards the windscreen and the Keep the air intakes forward of the door windows. windscreen free from obstruction (snow, leaves etc.) to allow the climate control Cooling the interior...
  • Page 104: Manual Climate Control

    Climate control Side air vent MANUAL CLIMATE CONTROL Air distribution control E129787 Second row air vents E74660 Face level Face level and footwell Footwell E129790 Footwell and windscreen Windscreen You can set the air distribution control to any position between the symbols.
  • Page 105 Climate control Blower Ventilation E129885 Set the air distribution control, blower and air vents to suit your requirements. Air conditioning Switching the air conditioning on and off E75470 Note: If you switch the blower off, the windscreen may mist up. If you turn the blower off, the air conditioning will turn off.
  • Page 106: Automatic Climate Control

    Climate control With the heater control in this position, the If you move the air distribution control to air conditioning and recirculated air will a position other than windscreen, the A/C switch on automatically. will remain on. You can switch the air conditioning and You can switch the air conditioning and recirculated air on and off.
  • Page 107 Climate control Mono mode Note: Avoid adjusting the settings when the vehicle interior is extremely hot or In mono mode, the temperature settings cold. The automatic climate control for both the driver’s and passenger’s side adjusts to the current circumstances are linked.
  • Page 108 Climate control Use the buttons to adjust the blower The blower speed and the temperature speed. control operate automatically and cannot be adjusted manually. The blower is set The blower setting is indicated in the to high speed and the temperature to HI. display.
  • Page 109: Heated Windows And Mirrors

    Climate control When switched off, the heating, ventilation AUXILIARY HEATER and air conditioning system is switched off and recirculated air is selected. Parking heater WARNINGS HEATED WINDOWS AND The parking heater must not be MIRRORS operated at filling stations, near sources of combustible vapours or Heated windows dust or in enclosed spaces.
  • Page 110 Climate control • It preheats the interior of the vehicle. • It keeps the windows clear of ice in Park Heater the event of frost and prevents condensation. Program 1 • It avoids cold starts and allows the engine to reach operating Program 2 temperature sooner.
  • Page 111 Climate control 1. Use the arrow buttons on the steering To deactivate the heater, uncheck the wheel to enter the main menu. Heat now function. 2. Select the first programme time list. Fuel operated heater 3. Highlight the day on which the heater (depending on country) should warm up the vehicle.
  • Page 112: Sitting In The Correct Position

    Seats • hold the steering wheel with your arms SITTING IN THE CORRECT slightly bent. POSITION • bend your legs slightly so that you can press the pedals fully. • position the shoulder strap of the seat belt over the centre of your shoulder and position the lap strap tightly across your hips.
  • Page 113: Head Restraints

    Seats Adjusting the lumbar support Adjusting the angle of the seatback E78058 E130250 Adjusting the height of the driver’s seat HEAD RESTRAINTS Adjusting the head restraint WARNINGS Raise the rear head restraint when the rear seat is occupied by a passenger.
  • Page 114: Electric Seats

    Seats Removing the head restraint Press the locking buttons and remove the head restraint. ELECTRIC SEATS E78060...
  • Page 115: Rear Seats

    Seats 1. Remove the luggage cover. See REAR SEATS Luggage covers (page 165). WARNINGS When folding or unfolding the seats, take care not to get your fingers caught between the seatback and seat frame. Rock the seat backwards and forwards after moving to make sure that it is fully engaged in its catch.
  • Page 116 Seats Note: The complete seat will move Note: A table surface and cup holders rearwards as the seat cushion is folded are located on the rear of the centre seatback. 3. Fold the seat back until it engages. E78066 Remove the seat belts from the belt E78064 guides on the outboard seatbacks.
  • Page 117 Seats Pull the lever on the side of the seatback Note: If one or both outboard seats is to and fold the seatback forwards. Push it be folded forward together with the down until it engages. centre seat, fold the centre seat forward first.
  • Page 118 Seats E78071 Pull out and attach the retaining straps to the front head restraints to hold the folded seats in the upright position. Returning the seats to the seating E78073 position Before folding the seats back down, pull the lower bar on the rear of each seat and WARNINGS check that the latches are in the extended To avoid injury, take care when...
  • Page 119 Seats Fold the seats back down until they engage. Raise the seatbacks. See Folding the seatbacks up. Install the rear seatbelts in the belt guides on the outboard seatbacks. Removing the seats WARNING The rear seats are heavy. To avoid injury, take care when lifting the seats.
  • Page 120 Seats Second row seats - Grand C- Folding the seatback forwards or backwards E78077 E135422 Holding the seat at an angle of approximately 45 degrees to the floor, Lift the lever and push the seatback. It will lower the seat onto the retaining bar. move in steps.
  • Page 121 Seats E129302 E135801 1. Pull the lever on the back of the centre 3. Pull the strap to fold the centre seat seat and push the seatback down until over into the right-hand seat base. it locks. 4. Fold the right-hand seat cushion down.
  • Page 122 Seats CAUTION The centre seat must be stowed into the right-hand seat base before the right-hand seat is folded. E129296 1. Either pull the lever on the side of the seat cushion or pull the strap at the rear of the seat. The seat will move forward.
  • Page 123: Heated Seats

    Seats E129301 Pull the strap at the top of the seatback and fold the seatback forward. HEATED SEATS CAUTION Operating this function with the engine off will drain the battery. E130471 The maximum temperature is reached after five or six minutes. It is regulated thermostatically.
  • Page 124: Convenience Features

    Convenience features SUN BLINDS Side windows E125025 The sun blind is operated by a switch located between the sun visors. E74809 Opening and closing the sun blind Pull the blind up and attach it to the hooks (A). Roof WARNING Do not operate the sun blind unless it is free from obstruction.
  • Page 125: Instrument Lighting Dimmer

    Convenience features Opening and closing the sun blind 3. Press and hold switch B to the first automatically action point, until the blind fully opens. 4. Press and hold switch A to the first Press the switch to the second action action point, until the blind fully closes.
  • Page 126: Auxiliary Power Sockets

    Auxiliary power sockets are located in the 12 volt appliances that have a maximum centre console and in the luggage current rating of 15 Amperes. Use only compartment. Ford accessory connectors or connectors Power inverter specified for use with SAE standard sockets. CAUTIONS...
  • Page 127: Cup Holders

    Convenience features CUP HOLDERS STORAGECOMPARTMENTS Rear storage compartment WARNING Do not place hot drinks in the cup holders when the vehicle is moving. Seat back trays WARNING Do not use the trays when the vehicle is moving. Make sure that you secure the trays in the lowered position before setting off.
  • Page 128: Childminder Mirror

    Convenience features AUXILIARY INPUT (AUX IN) SOCKET E91508 CHILDMINDER MIRROR E91511 E75192 E130068 See Auxiliary input (AUX IN) socket (page 239).
  • Page 129: Usb Port

    Convenience features USB PORT SATELLITE NAVIGATION UNIT HOLDER Adjusting the holder E91511 E112711 1. Unlock. 2. Adjust the holder to the desired position. 3. Lock. Note: Make sure that the navigation unit holder is locked in position. FLOOR MATS E130070 WARNING See Connectivity (page 261).
  • Page 130: Starting The Engine

    Starting the engine II The ignition is switched on. All electrical GENERAL INFORMATION circuits are operational. Warning lamps and indicators illuminate. This is the key General points on starting position when driving. You must also If the battery has been disconnected the select it when being towed.
  • Page 131: Starting A Petrol Engine

    Starting the engine Vehicles with manual transmission If the engine does not start after three attempts, wait 10 seconds and follow the • Press the clutch pedal. Flooded engine procedure. If you have difficulty starting the engine STARTING A PETROL when the temperature is below -25ºC ENGINE (-13ºF), press the accelerator pedal...
  • Page 132: Starting A Diesel Engine

    Starting the engine STARTING A DIESEL ENGINE WARNINGS Always check that the steering Cold or hot engine wheel lock is deactivated before attempting to move your vehicle. All vehicles See Steering wheel lock (page 128). Note: When the temperature is below -15ºC (5ºF), you may need to crank the Note: A valid passive key must be engine for up to 25 seconds.
  • Page 133 Starting the engine 2. Press the start button. 3. If the engine does not start, fully depress the brake and clutch pedals and try again. Starting a diesel engine Note: Engine cranking may not commence until the engine glow plug cycle has been completed.
  • Page 134: Diesel Particulate Filter (Dpf)

    Starting the engine Press and hold the start button for two If you drive only short distances or your seconds, or press two times within two journeys contain frequent stopping and seconds. starting, where there is increased acceleration and deceleration, occasional trips with the following conditions will DIESEL PARTICULATE assist the regeneration process:...
  • Page 135 Starting the engine E135813 Connect the engine heater for 2 to 3 hours before starting the engine.
  • Page 136: Start-Stop

    Start-stop Note: The system is on by default. To PRINCIPLE OF OPERATION switch the system off, press the switch in the instrument panel. The system will only CAUTION be de-activated for the current ignition For vehicles with Start-stop the cycle. To turn it on, press the switch again. battery requirement is different.
  • Page 137 Start-stop • The outside temperature is too low or too high. • The driver's door has been opened. • Low engine operating temperature. • Low brake system vacuum. • If a road speed of 10 kph (6 mph) has not been exceeded. To re-start the engine Note: The gear lever must be in the neutral position.
  • Page 138: Eco Mode

    Eco mode Efficient speed PRINCIPLE OF OPERATION Higher speeds use more fuel. Reducing The system assists the driver to drive your cruising speed on open roads will more efficiently by constantly monitoring improve fuel consumption. characteristics of gear changing, anticipation of traffic conditions and USING ECO MODE speeds on motorways and open roads.
  • Page 139: Fuel And Refuelling

    Fuel spillage could be Note: The use of additives or other hazardous to other road users. engine treatments not approved by Ford Do not use any kind of flames or is not recommended. heat near the fuel system. The fuel Note: We do not recommend the system is under pressure.
  • Page 140: Fuel Filler Flap

    Fuel and refuelling Press the flap to open it. Open the flap CAUTIONS fully until it engages. Do not run the engine when a spark plug lead is disconnected. When you insert the fuel nozzle, a spring loaded inhibitor will open if the correct size Do not push-start or tow-start your nozzle is detected.
  • Page 141: Refuelling

    Use the funnel which is located in the glove box. Your Ford dealer can give you advice on improving your fuel consumption. REFUELLING CAUTION Do not attempt to start the engine if you have filled the fuel tank with the incorrect fuel.
  • Page 142: Transmission

    Fuel and refuelling CO2 emis- Urban Extra-urban Combined sions Variant l/100 km l/100 km l/100 km g/km (mpg) (mpg) (mpg) 1.6L EcoBoost SCTi (Sigma) 8 (35.3) 5.3 (53.3) 6.4 (44.1) Stage V, with start-stop 1.6L Duratorq-TDCi (DV) Diesel Stage V, without 5.4 (52.3) 4.1 (68.9) 4.6 (61.4)
  • Page 143: Transmission

    Fuel and refuelling CO2 emis- Urban Extra-urban Combined sions Variant l/100 km l/100 km l/100 km g/km (mpg) (mpg) (mpg) 1.6L Duratorq-TDCi (DV) Diesel Stage V, with start- 5.5 (51.4) 4.3 (65.7) 4.7 (60.1) stop 2.0L Duratorq-TDCi (DW) Diesel Stage V, manual 6.6 (42.8) 4.5 (62.8) 5.3 (53.3)
  • Page 144: Transmission Manual Transmission

    Transmission MANUAL TRANSMISSION Neutral Drive CAUTION Sport mode and manual shifting Do not engage reverse gear when the vehicle is moving. This can cause WARNING damage to the transmission. Apply the brakes before moving the selector lever and keep them applied until you are ready to move off.
  • Page 145 Transmission Sport mode and manual shifting Neutral - Vehicles with a 6 speed In this position, power is not transmitted transmission to the drive wheels but the transmission is not locked. You can start the engine Note: A shift will occur only when the with the selector lever in this position.
  • Page 146 Transmission Hints on driving with an automatic transmission CAUTION Do not idle the engine for long periods of time in drive with the brakes applied. Moving off 1. Release the parking brake. 2. Release the brake pedal and press the accelerator pedal. Stopping 1.
  • Page 147: Principle Of Operation

    Brakes PRINCIPLE OF OPERATION PARKING BRAKE All vehicles Note: Depending on applicable laws and regulations in the country for which your WARNING vehicle was originally built, the brake lamps may flash if you brake heavily. Vehicles with an automatic transmission should always be left Disc brakes with the selector lever in position P.
  • Page 148: Stability Control

    Stability control Stability control (ESP) warning lamp PRINCIPLE OF OPERATION The ESP warning lamp will flash when the Electronic stability programme system is operating. See Warning (ESP) lamps and indicators (page 80). WARNING Emergency brake assist ESP does not relieve you of your WARNING responsibility to drive with due care and attention.
  • Page 149 Stability control To turn the system off and on. See Information displays (page 84).
  • Page 150: Hill Start Assist

    Hill start assist PRINCIPLE OF OPERATION WARNINGS At all times you are responsible for The system makes it easier to pull away controlling the vehicle, supervising when the vehicle is on a slope without the the system and intervening, if need to use the parking brake.
  • Page 151 Hill start assist • Wait for a short time until the system deactivates automatically. • If a forward gear was selected when the system became active, select reverse gear. • If reverse gear was selected when the system became active, select a forward gear.
  • Page 152: Parking Aid

    Parking aid Note: The parking aid may emit false PRINCIPLE OF OPERATION tones if it detects a signal using the same frequency as the sensors or if the vehicle WARNING is fully laden. The system does not relieve you of Note: The outer sensors may detect the your responsibility to drive with due side walls of a garage.
  • Page 153: Using The Parking Aid - Vehicles With: Front And Rear Parking Aid

    Parking aid E130180 E130178 A trailer symbol indicates there is a trailer attached and the system is disabled. Distance Indicator. As the distance decreases the indicator USING THE PARKING AID - moves towards the vehicle. VEHICLES WITH: FRONT A continuous tone will start at a distance AND REAR PARKING AID of less than 30 centimetres (11 inches) to the rear bumper.
  • Page 154 Parking aid Manoeuvring with the parking Note: On vehicles with a tow bar fitted and approved by us the continuous tone will start at a distance of 45 centimetres (18 inches) from the rear bumper. You will hear an alternating tone from the front and rear if obstacles are closer than 30 centimetres (11 inches) to the front and rear bumpers.
  • Page 155 Parking aid E130180 A trailer symbol indicates there is a trailer attached and the rear sensors are disabled.
  • Page 156: Active Park Assist

    Active park assist PRINCIPLE OF OPERATION USING ACTIVE PARK ASSIST WARNINGS CAUTIONS The system does not relieve you of The sensors may not detect objects your responsibility to drive with due in heavy rain or other conditions that care and attention. cause disruptive reflections.
  • Page 157 Active park assist E130107 Note: To disable the chimes: See Note: The arrow symbols or graphics in Personalised settings (page 90). the display indicate on which side of the vehicle the system will park. The display The information and entertainment display will also advise you when to select reverse will inform you and a chime will be heard gear.
  • Page 158 Active park assist E130109 Move the vehicle forwards. Stop the vehicle when you hear a continuous tone. Repeat the above steps until the vehicle is satisfactory parked. The message centre will indicate when active park assist has finished the manoeuvre.
  • Page 159: Rear View Camera

    Rear view camera PRINCIPLE OF OPERATION The camera is a visual aid for use when reversing. WARNING The system does not relieve you of your responsibility to drive with due care and attention. CAUTIONS If you use a high pressure spray to wash your vehicle, only spray the camera briefly from a distance not E99105...
  • Page 160 Rear view camera Using the display CAUTIONS Obstacles above the camera position will not be shown. Inspect the area behind your vehicle if necessary. Marks are for general guidance only, and are calculated for vehicles in maximum load conditions on an even road surface.
  • Page 161 Rear view camera Amber - 2 metres (79 inches) Amber - centre line of the projected vehicle path Note: When reversing with a trailer, the lines on the screen are not shown. The camera will show the vehicle direction and not the trailer.
  • Page 162: Cruise Control

    Cruise control Setting a speed PRINCIPLE OF OPERATION Press the SET+ switch or the SET- WARNING switch to store and maintain your current speed. The cruise control indicator will The system does not relieve you of illuminate. See Warning lamps and your responsibility to drive with due indicators (page 80).
  • Page 163: Cruise Control

    Cruise control Note: The system will no longer control your speed. The cruise control indicator will not illuminate but the system will retain the speed that you previously set. Resuming the set speed Press the RES switch. The cruise control indicator will illuminate and the system will attempt to resume the speed that you previously set.
  • Page 164: Speed Limiter

    Speed limiter Switching the system on and PRINCIPLE OF OPERATION WARNING Press switch B. The information display will prompt for a speed to be set. When you are going downhill, your speed may increase above the set Setting the speed limit speed.
  • Page 165: Load Carrying

    Load carrying C-Max GENERAL INFORMATION WARNINGS Use load securing straps to an approved standard, e.g. DIN. Make sure that you secure all loose items properly. Place luggage and other loads as low and as far forward as possible within the luggage or loadspace. Do not drive with the tailgate or rear door open.
  • Page 166 Load carrying E130146 C-MAX C-MAX and Grand C-MAX Grand C-MAX C-MAX...
  • Page 167: Luggage Covers

    Load carrying LUGGAGE COVERS REAR UNDER FLOOR STORAGE WARNING WARNING Do not place objects on the luggage cover. When you are using a child restraint with a support leg on a second row seat, make sure that you locate the support leg securely on the under floor storage compartment lid.
  • Page 168 Load carrying Grand C-MAX WARNING Luggage retention net anchor points are not fitted behind the first row seats, but are fitted behind the second row seats. Luggage retention net Installing the net CAUTIONS Do not move the rear seats when the E130320 cargo net is installed.
  • Page 169: Roof Racks And Load Carriers

    CARRIERS Note: The side mounting tracks are Roof rack designed such that crossbars (for bicycle carriers, ski carriers etc.) from the Ford WARNINGS accessories range can be fitted. If you use a roof rack, the fuel Note: Before installing the crossbars,...
  • Page 170 Load carrying E130001 E130067 Note: Adhesive pads are supplied to help Note: Make sure there is no gap reduce the buffeting noise. between crossbar and rail (A). Note: Make sure the surface of the 4. Turn the handle a minimum of 3.5 crossbars is clean before attaching the revolutions.
  • Page 171 Load carrying Accessing the T-notch E98209 1. Pull the handle out. 2. Lower the cover. 3. Remove the sliding bar. Installing a roof box E130002 Make sure the adhesive pads are not in contact with the installation bolt.
  • Page 172: Towing

    Towing Change down a gear before you reach a TOWING A TRAILER steep downhill gradient. WARNINGS RETRACTABLE TOW BALL Do not exceed 100 km/h (62 mph). CAUTION The rear tyre pressures must be Only move the tow ball arm with your increased by 0.2 bar (3 psi) above hand.
  • Page 173 Towing Swivelling the tow ball in WARNINGS Keep your hands away from the handwheel as it rotates during the locking process. You will hear a warning tone when the tow ball arm is not in one of the locked positions. If you do not hear the tone when moving the tow ball arm, do not use the tow bar and have it checked by a properly trained technician.
  • Page 174 Towing E75179 E75177 3. Release the handwheel. The tow ball 4. Manually turn the tow ball arm steadily arm is not locked. This is indicated by from its midway position to the stop the warning tone and the handwheel in the stowage position. The tow ball projects about five millimetres (0.2 arm automatically locks in the end inch) from its housing.
  • Page 175 Towing Driving with a trailer WARNING If any of the conditions below cannot be met, do not use the tow bar and have it checked by a properly trained technician. Before starting your journey, make sure that the tow ball arm is properly locked. Check that: •...
  • Page 176: Driving Hints

    Driving hints RUNNING-IN DRIVING THROUGH WATER Tyres Driving through water WARNING CAUTIONS Drive through water in an emergency New tyres need to be run-in for only, and not as part of normal approximately 500 kilometres (300 driving. miles). During this time, you may experience different driving Engine damage can occur if water characteristics.
  • Page 177: Emergency Equipment

    Emergency equipment Pull the red handle and fold the seatback FIRST AID KIT forward. Space is provided in the under floor storage compartment to store a first aid kit. See Rear under floor storage (page 165). WARNING TRIANGLE E130151 Slide the front seat fully rearwards. See Seats (page 110).
  • Page 178: Fuse Box Locations

    Fuses Load compartment fuse box FUSE BOX LOCATIONS Engine compartment fuse box This fuse box is located in the engine compartment See Maintenance (page 187). Passenger compartment fuse E130147 CHANGING A FUSE WARNINGS E130170 Do not modify the electrical system of your vehicle in any way.
  • Page 179: Fuse Specification Chart

    Fuses FUSE SPECIFICATION CHART Engine compartment fuse box E129925 Ampere Fuse Circuits protected rating ABS pump ABS valve Headlamp washer Heater blower Not used Engine Control Relay Starter relay Heated windscreen (right-hand side) Not used...
  • Page 180 Fuses Ampere Fuse Circuits protected rating Heated windscreen (left-hand side) Fuel fired heater Windscreen wipers ABS ESP module Horn Stop lamp switch Battery monitoring system Relay coils, light switch module Rear power outlet Electric exterior mirrors Powertrain control module (PCM) Air conditioning clutch Not used Heated rear window...
  • Page 181 Fuses Ampere Fuse Circuits protected rating Rear window wiper Headlamp levelling Not used Heated washer jets Power windows (front) Heated exterior mirrors Vapouriser...
  • Page 182 Fuses Passenger compartment fuse box E129926 Ampere Fuse Circuits protected rating Fuel pump...
  • Page 183 Fuses Ampere Fuse Circuits protected rating Not used Not used Passive anti theft system (PATS) Interior lamp, driver's door switch pack, glove box Cigar lighter, second row power point Rain sensor module, interior mirror Not used Not used Liftgate release Driver's door lock, double locking Information and entertainment display Steering column lock...
  • Page 184 Fuses Ampere Fuse Circuits protected rating Central locking ground Driver's door lock and double locking ground Radio, navigation system, passenger airbag deactivation switch, heated front seats switch, parking heater, manual air conditioning heater module Restraint system Not used Not used Not used Load compartment fuse box E129927...
  • Page 185 Fuses Ampere Fuse Circuits protected rating Door module (right-hand front) (window up/down, central locking, electric folding mirror, heated mirror) Door module (left-hand rear) (window up/down) Door module (right-hand rear) (window up/down) Security Horn Electric driver's seat Not used Not used Not used Not used Not used...
  • Page 186 Fuses Ampere Fuse Circuits protected rating Rear view camera Power inverter Not used Heated driver's seat Heated front passenger seat Not used Sun blind system Not used Not used Not used Not used Not used Not used Not used Not used Not used...
  • Page 187: Vehicle Recovery

    Vehicle recovery Rear towing eye TOWING POINTS Towing eye location The screw-in towing eye is located in the spare wheel well. The towing eye must always be carried in the vehicle. Installing the towing eye CAUTION The screw-in towing eye has a left-hand thread.
  • Page 188 Vehicle recovery CAUTIONS Too much tension in the tow rope could cause damage to your vehicle or the vehicle that is towing. Select neutral when your vehicle is being towed. In the event of a breakdown or mechanical failure do not use individual axle carriers.
  • Page 189: Maintenance

    • Brake fluid level. See Brake and resale value. There is a large network of clutch fluid check (page 194). Ford Authorised Repairers that are there to help you with their professional • Washer fluid level. See Washer fluid servicing expertise. We believe that their check (page 194).
  • Page 190 Maintenance E135852 E87786 Move the catch to the left. Open the bonnet and support it with the strut. Closing the bonnet WARNING Make sure that the bonnet is closed properly. Lower the bonnet and allow it to drop from under its own weight for the last 20 –...
  • Page 191: Engine Compartment Overview - 1.6L Duratec-16V Ti-Vct (Sigma)

    Maintenance ENGINE COMPARTMENT OVERVIEW - 1.6L DURATEC-16V TI-VCT (SIGMA) E130030 : See Engine coolant check (page 193). Engine coolant reservoir Brake and clutch fluid reservoir (right-hand drive) : See Brake and clutch fluid check (page 194). Engine oil filler cap : See Engine oil check (page 193).
  • Page 192: Engine Compartment Overview - 1.6L Duratorq-Tdci (Dv) Diesel

    Maintenance Engine oil dipstick : See Engine oil check (page 193). Screen washer fluid reservoir : See Washer fluid check (page 194). For easy identification, filler caps and the engine oil dipstick are marked in colour. ENGINE COMPARTMENT OVERVIEW - 1.6L DURATORQ-TDCI (DV) DIESEL E130031 Engine coolant reservoir...
  • Page 193: Engine Compartment Overview - 2.0L Duratorq-Tdci (Dw) Diesel

    Maintenance Battery: See Vehicle battery (page 199). Engine compartment fuse box: See Fuses (page 176). Air cleaner: No maintenance necessary. Engine oil dipstick : See Engine oil check (page 193). Screen washer fluid reservoir : See Washer fluid check (page 194). For easy identification, filler caps and the engine oil dipstick are marked in colour.
  • Page 194: Engine Oil Dipstick - 1.6L Duratec-16V Ti-Vct

    Maintenance Engine coolant reservoir : See Engine coolant check (page 193). Brake and clutch fluid reservoir (right-hand drive) : See Brake and clutch fluid check (page 194). Engine oil dipstick : See Engine oil check (page 193). Brake and clutch fluid reservoir (left-hand drive) : See Brake and clutch fluid check (page 194).
  • Page 195: Engine Oil Check

    Do not top up further than the MAX CAUTION mark. Do not use oil additives or other engine treatments. Under certain Top up with fluid that meets the Ford conditions, they could damage the specification. See Technical engine. specifications (page 195).
  • Page 196: Brake And Clutch Fluid Check

    Note: The brake and the clutch systems cap. are supplied from the same reservoir. Top up with fluid that meets the Ford CAUTION specification. See Technical Do not top up further than the MAX specifications (page 195).
  • Page 197: Technical Specifications

    WSS-M6C57-A2 DOT 4 Brake Fluid Your engine has been designed to be used with Castrol and Ford Engine Oil, which gives a fuel economy benefit whilst maintaining the durability of your engine. For petrol engines only, Ford and Castrol have developed a low friction SAE-5W-20 oil which offers further fuel economy benefits over the standard SAE-5W-30 oil.
  • Page 198 Maintenance Variant Item Capacity in litres (gallons) Vehicles with a petrol Fuel tank 55 (12.1) engine - C-MAX 1.6L Duratorq-TDCi - C- Fuel tank 53 (11.7) 2.0L Duratorq-TDCi - C- Fuel tank 60 (13.2) Windscreen washer system 4.5 (1) - with headlamp washers Windscreen washer system - without headlamp 3 (0.7)
  • Page 199: Vehicle Care

    Vehicle care Cleaning the chrome trim CLEANING THE EXTERIOR CAUTION WARNING Do not use abrasives or chemical If you use a car wash with a waxing solvents. Use soapy water. cycle, make sure that you remove the wax from the windscreen. Body paintwork preservation CAUTIONS CAUTIONS...
  • Page 200: Repairing Minor Paint Damage

    You should repair paintwork damage caused by stones from the road or minor scratches as soon as possible. A choice of products is available from your Ford Dealer. Read and follow the manufacturer’s instructions.
  • Page 201: Vehicle Battery

    Vehicle battery 1. Position the vehicles so that they do USING BOOSTER CABLES not touch one another. 2. Switch off the engine and any CAUTIONS electrical equipment. Connect batteries with only the same nominal voltage. 3. Connect the positive (+) terminal of vehicle B with the positive (+) terminal Always use booster cables with of vehicle A (cable C).
  • Page 202: Battery Connection Points

    Vehicle battery Note: Where applicable, the audio system must be reprogrammed with the keycode. The battery is located in the engine compartment. See Maintenance (page 187). BATTERY CONNECTION POINTS CAUTION Do not connect to the negative (–) terminal of the flat battery. E130431 The ground connection point is located to the right of the battery near the engine...
  • Page 203: Wheels And Tyres

    Wheels and tyres Refer to the following information before GENERAL INFORMATION changing the road wheel. CAUTIONS WARNINGS Use only approved wheel and tyre Drive the shortest possible sizes. Using other sizes could distances. damage the vehicle and will make Do not fit more than one spare the National Type Approval invalid.
  • Page 204 Wheels and tyres Note: Vehicles with a tyre repair kit are Vehicles without tyre repair kit not equipped with a vehicle jack or a Your vehicle jack, wheel brace, screw-in wheel brace. towing eye and wheel trim remover are It is recommended to use a workshop located in the spare wheel well.
  • Page 205 Wheels and tyres Assembling the wheel brace Type one WARNING When returning the wheel brace extension to its original position, take care not to get your fingers caught. Note: Make sure that the wheel brace is fully extended. E93302 Small arrow-shaped marks on the sills A show the location of the jacking points.
  • Page 206 Wheels and tyres Removing the wheel trim WARNINGS If your vehicle has a manual Type one transmission, select first or reverse gear. If it has an automatic Insert the flat end of the wheel brace transmission, select park. between the rim and the trim and carefully remove the trim.
  • Page 207 Wheels and tyres CAUTION Do not install alloy wheels using wheel nuts designed for use with steel wheels. Note: The wheel nuts of alloy wheels and spoked steel wheels can also be used for the steel spare wheel for a short time (maximum two weeks).
  • Page 208: Tyre Repair Kit

    Wheels and tyres • Drive with caution and avoid WARNING making sudden steering or Have the wheel nuts checked for driving manoeuvres, especially if tightness and the tyre pressure the vehicle is heavily loaded or you are checked as soon as possible. towing a trailer.
  • Page 209 Wheels and tyres • Leave the engine running while the kit CAUTION is in use, but not if the vehicle is in an Screwing the bottle onto the bottle enclosed or poorly ventilated area (for holder will pierce the seal of the example, inside a building).
  • Page 210 Wheels and tyres Remove the power plug G from the Power plug with cable cigar lighter socket or auxiliary power Compressor switch socket. Label Quickly unscrew the hose C from the tyre valve and replace the Bottle lid protective cap A. Fasten the valve Sealant bottle cap again.
  • Page 211: Tyre Care

    Wheels and tyres 3. If the pressure of the sealant-filled tyre Empty sealant bottles can be disposed is 1.3 bar (19 psi) or more, adjust it to of together with normal household waste. the specified pressure. See Return remains of sealant to your dealer Technical specifications (page or dispose of it in compliance with local 211).
  • Page 212: Using Winter Tyres

    Wheels and tyres USING WINTER TYRES TYRE PRESSURE MONITORING SYSTEM CAUTION WARNINGS Make sure that you use the correct wheel nuts for the type of wheel the The system does not relieve you of winter tyres are fitted to. your responsibility to regularly check the tyre pressures.
  • Page 213: Technical Specifications

    Wheels and tyres System reset Note: The system will still function correctly, but there may be an increased Note: Do not reset the system when the detection time. vehicle is moving. If a low pressure warning message is Note: You should reset the system displayed in the information display, check following any adjustment to the tyre the tyre pressures as soon as possible...
  • Page 214 Wheels and tyres C-MAX Up to 160 km/h (100 mph) Normal load Full load Variant Tyre size Front Rear Front Rear bar (psi) bar (psi) bar (psi) bar (psi) Vehicles with a 2.1 (31) 2.1 (31) 2.5 (36) 2.8 (41) 205/55 R 16 petrol engine Vehicles with a...
  • Page 215 Wheels and tyres Normal load Full load Variant Tyre size Front Rear Front Rear bar (psi) bar (psi) bar (psi) bar (psi) 1.6L EcoBoost SCTi 205/55 R 16 2.3 (33) 2.1 (31) 2.5 (36) 2.8 (41) 1.6L Duratorq-TDCi 205/55 R 16 2.3 (33) 2.1 (31) 2.5 (36)
  • Page 216 Wheels and tyres Normal load Full load Variant Tyre size Front Rear Front Rear bar (psi) bar (psi) bar (psi) bar (psi) Vehicles with a 2.1 (31) 2.3 (33) 2.5 (36) 2.8 (41) 215/55 R 16 petrol engine Vehicles with a 2.3 (33) 2.3 (33) 2.5 (36)
  • Page 217 Wheels and tyres Normal load Full load Variant Tyre size Front Rear Front Rear bar (psi) bar (psi) bar (psi) bar (psi) Vehicles with a 215/55 R 16 2.4 (35) 2.3 (33) 2.6 (38) 3 (44) diesel engine Vehicles with a 215/50 R 17 2.3 (33) 2.3 (33)
  • Page 218: Vehicle Identification

    Vehicle identification Note: The vehicle identification plate VEHICLE IDENTIFICATION design may vary to that shown. PLATE Note: The information shown on the vehicle identification plate is dependant upon market requirements. E135662 Model Variant Engine designation Emission level Vehicle identification number Gross vehicle weight Gross train weight Maximum front axle weight...
  • Page 219: Vehicle Identification Number (Vin)

    Vehicle identification VEHICLE IDENTIFICATION NUMBER (VIN) E87496 The vehicle identification number is stamped into the floor panel on the right-hand side, beside the front seat. It is also shown on the left-hand side of the instrument panel.
  • Page 220: Technical Specifications

    Technical specifications TECHNICAL SPECIFICATIONS Vehicle dimensions E130083 C-MAX Item Dimension description Dimension in mm (inches) Maximum length 4 380 (172.4)
  • Page 221 Technical specifications Item Dimension description Dimension in mm (inches) Overall width including exterior mirrors 2 067 (81.4) Overall height - EC kerb weight 1 595 - 1 626 (62.8 - 64.0) Wheelbase 2 648 (104.2) Front track 1 544 - 1 559 (60.8 - 61.4) Rear track 1 554 - 1 569 (61.2 - 61.8) Grand C-MAX...
  • Page 222 Technical specifications Towing equipment dimensions E130084...
  • Page 223 Technical specifications Item Dimension description Dimension in mm (inches) Bumper – end of tow ball 111 (4.4) Attachment point – centre of tow ball 4 (0.1) (C-MAX) Attachment point – centre of tow ball 5 (0.2) (Grand C-MAX) Wheel centre – centre of tow ball 925 (36.4) Centre of tow ball –...
  • Page 224: Audio Introduction

    Audio introduction IMPORTANT AUDIO INFORMATION WARNINGS Due to technical incompatibility, E66257 recordable (CD-R) and rewritable Disc labels (CD-RW) discs may not function correctly. Audio CD These CD radio units will play compact discs that conform to the International Red Book standard audio specification.
  • Page 225: Audio Unit Overview

    Audio unit overview Note: Units have an integrated multi AUDIO UNIT OVERVIEW function display situated above the CD aperture. This shows important information regarding control of your audio unit. Additionally, there are various icons placed around the display screen which light up when a function is active (for example CD, Radio or Aux.) Type 1 E130324...
  • Page 226 Audio unit overview Seek up. CD track selection. See Station tuning control (page 230). See Track selection (page 235). On/off and volume control. Seek down. CD track selection. See Station tuning control (page 230). See Track selection (page 235). Menu select. Sound button.
  • Page 227 Audio unit overview E130142 CD eject. See Compact disc player (page 235). Navigation arrows. CD aperture. See Compact disc player (page 235). Information. Traffic announcement. See Traffic information control (page 231). Sound button. See Sound button (page 230). Telephone keypad and station presets. See Using the telephone (page 243).
  • Page 228 Audio unit overview On/off and volume control. Seek down. CD track selection. See Station tuning control (page 230). See Track selection (page 235). Function 2. Function 1. Menu select. Phone menu. See Telephone (page 241). Auxiliary, USB and iPod select. See Auxiliary input (AUX IN) socket (page 126).
  • Page 229 Audio unit overview E129074 On/off control. Display select. Telephone keypad and station presets. See Using the telephone (page 243). See Station preset buttons (page 231). CD aperture. See Compact disc player (page 235). Navigation arrows. DSP select. See Digital signal processing (DSP) (page 233). CD eject.
  • Page 230 Audio unit overview Mute. Traffic announcement. See Traffic information control (page 231). Function 4. Sound button. See Sound button (page 230). Function 3. Function 2. Menu select. Function 1. Phone menu. See Telephone (page 241). Auxiliary select. See Auxiliary input (AUX IN) socket (page 126). See Auxiliary input (AUX IN) socket (page 239).
  • Page 231: Audio System Security

    Audio system security SECURITY CODE Each unit incorporates a unique code that is linked to the vehicle identification number (VIN). The system will automatically check that the audio unit and vehicle match before allowing operation. If a security code message appears, please see your dealer.
  • Page 232: Audio Unit Operation

    Audio unit operation Note: The system will automatically ON/OFF CONTROL change to another corresponding station if the current one becomes unavailable, Press the on/off control. This will also for example when leaving the coverage operate the unit for up to one hour with area.
  • Page 233: Station Preset Buttons

    Audio unit operation Type 1 AUTOSTORE CONTROL 1. Press the MENU button. Note: This will store up to a maximum of 2. Select RADIO mode and then SCAN. the 10 strongest signals available, either from the AM or the FM waveband, and 3.
  • Page 234 Audio unit operation Note: If TA is on and you select a preset or manual tune to a non TA station no traffic announcement will be heard. Note: When you are listening to a non TA station and turn TA off and on again a TP seek will occur.
  • Page 235: Audio Unit Menus

    Audio unit menus AUTOMATIC VOLUME NEWS BROADCASTS CONTROL Some audio units interrupt normal reception to broadcast news bulletins When available, automatic volume control from stations on the FM waveband or (AVC) adjusts the volume level to radio data system (RDS) and enhanced compensate for engine noise and road other network (EON) linked stations, in speed noise.
  • Page 236: Regional Mode (Reg)

    Audio unit menus When selected, the unit continually 1. Press the MENU button. evaluates signal strength and, if a better 2. Select AUDIO or AUDIO SETTINGS. signal becomes available, the unit will 3. Scroll to RDS REGIONAL and turn on switch to that alternative.
  • Page 237: Compact Disc Player

    Compact disc player COMPACT DISC PLAYBACK SHUFFLE/RANDOM Note: During playback, the display Random track playback, also known as indicates the disc, track and time that has shuffle, plays all tracks on the CD in elapsed since the start of the track. random order.
  • Page 238: Compact Disc Track Scanning

    Compact disc player When an MP3 CD is playing, options You can play MP3 files recorded on include REPEAT for the track, or to repeat CD-ROMs, CD-Rs, and CD-RWs. The disc all the tracks in the folder. Repeat presses must be in the ISO 9660 level 1 or level 2 of function button 1 will toggle these format, or Joliet or Romeo in the options.
  • Page 239: Compact Disc Player

    Compact disc player File formats Playback tip: To specify a desired playback order, before the folder or file • With formats other than ISO 9660 level name, input the order by number (e.g., 1 and level 2, folder names or file “01,”...
  • Page 240: Mp3 Display Options

    Compact disc player MP3 navigation • The disc name • The artist name MP3 tracks may be recorded on the CD • The track name in several ways. They can all be placed in the root directory like a conventional audio These display options are selected in the CD, or they can be placed in folders that same way as MP3 displays.
  • Page 241: Auxiliary Input (Aux In) Socket

    Auxiliary input (AUX IN) socket AUXILIARY INPUT (AUX IN) SOCKET Note: For optimum performance when using any auxiliary device set the volume on the device high. This will reduce audio interference when charging the device via the vehicle power supply socket. When fitted the Auxiliary input (AUX IN) socket permits an auxiliary device, such as an MP3 player, to be linked into the...
  • Page 242: Audio Troubleshooting

    Audio troubleshooting AUDIO TROUBLESHOOTING Audio unit display Rectification PLEASE CHECK CD General error message for CD fault conditions, such as cannot read the CD, data-CD inserted, etc. Ensure disc is loaded correct way up. Clean and re-try, or replace disc with known music disc. If error persists contact your dealer.
  • Page 243: Telephone

    CAUTION 2. In the Bluetooth menu on your phone, As no common agreement exists, search for Ford Audio and select it. mobile phone manufacturers are able to implement a variety of profiles in 3. Enter the code number shown on the their Bluetooth devices.
  • Page 244: Telephone Controls

    Telephone Bond another Bluetooth phone After start up access to the phonebook list can be delayed for several minutes, Bond a new Bluetooth phone as depending upon the size. described in the requirements for a Bluetooth connection. Phonebook categories Phones stored in the system are The category is indicated as an icon: accessible by using the phone list on the Phone...
  • Page 245: Using The Telephone

    Telephone Note: Press and hold the up/down arrow USING THE TELEPHONE buttons to search forwards or backwards within the phonebook. Note: Refer to your audio guide for details of the controls. See Audio unit 5. Press the OK button to dial the overview (page 223).
  • Page 246 Telephone 2. Press the up/down arrow buttons until Second incoming calls can be rejected by REDIAL is displayed. pressing function button 4. 3. Press the OK button. Muting the microphone Receiving an incoming call Note: During a call, it is possible to mute the microphone.
  • Page 247: Voice Control

    Voice control If you are not sure how to continue say PRINCIPLE OF OPERATION "HELP" for assistance or "CANCEL" if you do not wish to continue. CAUTION The "HELP" function provides only a Using the system with the engine off subset of the available voice commands.
  • Page 248: Audio Unit Commands

    Voice control • external device (USB): "TRACK" • Store up to 20 name tags per function. • external device (iPod): "TRACK" • The average recording time for each name tag is approximately 2-3 Start communicating with the seconds. system Before you can start talking to the system AUDIO UNIT COMMANDS you first have to press the VOICE button for each operation and wait until the...
  • Page 249 Voice control Track You can choose a track on your CD directly. Steps User says System answer "CD PLAYER" "CD PLAYER" "TRACK NUMBER PLEASE" "TRACK" "TRACK <number>" "<a number between 1 and 99>" * Can be used as a shortcut. ** Additionally, numbers can be spoken as up to four single digits (for example "2", "4", "5"...
  • Page 250 Voice control "RADIO" "STORE NAME" "PLAY" * Can be used as a shortcut. Tune frequency This function allows you to tune your radio by voice commands. Steps User says System answer "RADIO" "RADIO" "AM" "AM FREQUENCY PLEASE" "FM" "FM FREQUENCY PLEASE" "TUNE <frequency>"...
  • Page 251 Voice control Steps User says System answer "<name>" "STORING NAME" "<name> STORED" Tune name This function allows you to call up a stored radio station. Steps User says System answer "RADIO" "RADIO" "NAME PLEASE" "TUNE NAME" "<name>" "TUNE <name>" * Can be used as a shortcut. Delete name This function allows you to delete a stored radio station.
  • Page 252 Voice control Steps User says System answer "PLAY DIRECTORY" "PLAY <DIRECTORY>" Delete directory This function allows you to delete all stored radio stations at once. Steps User says System answer "RADIO" "RADIO" "DELETE DIRECTORY" "DELETE DIRECTORY" "CONFIRM YES OR NO" "YES"...
  • Page 253 Voice control External devices - USB Overview The overview below shows the available These voice commands support the voice commands. The following lists will functionality of an external USB device give further information about the which may be connected to the audio complete command menu in selected unit.
  • Page 254 Voice control USB Track You can choose a track on your USB device directly. Steps User says System answer "EXTERNAL DEVICE" "EXTERNAL DEVICE" "USB" "USB" "TRACK" "TRACK NUMBER PLEASE" "TRACK <number>" "<a number between 1 and 99>" * Additionally, numbers can be spoken as up to four single digits (for example "2", "4", "5"...
  • Page 255: Telephone Commands

    Voice control iPod Track You can choose a track off the all titles list of your iPod directly. Steps User says System answer "EXTERNAL DEVICE" "EXTERNAL DEVICE" "IPOD" "IPOD" "TRACK NUMBER PLEASE" "TRACK" "TRACK <number>" "<a number between 1 and 99>" * Can be used as a shortcut.
  • Page 256 Voice control "PHONE" "HELP" "MOBILE NAME" "DIAL NUMBER" "DIAL NAME" "DELETE NAME" "DELETE DIRECTORY" "PLAY DIRECTORY" "STORE NAME" "REDIAL" "ACCEPT CALLS" "REJECT CALLS" * Can be used as a shortcut. Phone functions Dial number Phone numbers can be dialled after giving the name tag voice command.
  • Page 257 Voice control Dial name Phone numbers can be dialled after giving the name tag voice command. Steps User says System answer "PHONE" "PHONE" "NAME PLEASE" "DIAL NAME" "<name>" "DIAL <name>" "CONFIRM YES OR NO" "YES" "DIALLING" "NO" "COMMAND CANCELLED" * Can be used as a shortcut. Redial This function allows you to redial the last dialled phone number.
  • Page 258 Voice control DTMF (Tone dialling) Note: DTMF can only be used during an ongoing call. Press the VOICE button and This function transfers spoken numbers wait for the system prompt. into DTMF tones. For example, to make Can only be used with vehicles installed a remote enquiry to your home answering with a dedicated VOICE button.
  • Page 259 Voice control Steps User says System answer "PHONE" "PHONE" "DELETE NAME" "NAME PLEASE" "<name>" "DELETE <name>" "CONFIRM YES OR NO" "YES" "<name> DELETED" "NO" "COMMAND CANCELLED" Play directory Use this function to let the system tell you all stored entries. Steps User says System answer...
  • Page 260: Climate Control Commands

    Voice control Steps User says System answer "PHONE" "PHONE" "REJECT CALLS" "REJECT CALLS" "ACCEPT CALLS" "ACCEPT CALLS" * use this command to turn the reject mode off Overview CLIMATE CONTROL The overview below shows the available COMMANDS voice commands. The following lists will give further information about the Climate complete command menu in selected...
  • Page 261 Voice control Steps User says System answer "CLIMATE" "CLIMATE" "FAN SPEED PLEASE" "‘FAN" "MINIMUM" "FAN MINIMUM" "<a number between 1 and 7>" "FAN <number>" "MAXIMUM" "FAN MAXIMUM" * Can be used as a shortcut. On vehicles fitted with an English language module the "FAN"...
  • Page 262 Voice control Steps User says System answer "MAXIMUM" "TEMPERATURE MAXIMUM" * Can be used as a shortcut. Auto mode Steps User says System answer "CLIMATE" "CLIMATE" "AUTO MODE" "AUTO MODE" * Can be used as a shortcut. Can be deactivated by selecting a different temperature or fan speed.
  • Page 263: Connectivity

    Cover the connection socket when not in use. • iPod media players (refer to Only use USB Mass-Storage device www.ford-mobile compliant devices. -connectivity.com for latest compatibility list). Always switch your audio unit to a different source (for example the The system is USB 2.0 full speed...
  • Page 264: Connecting An External Device

    Plug in the device, and if necessary below: secure it to prevent movement within the • Create folders named with the vehicle. structure "Ford<*>" where <*> is a number 1-10. For example "Ford3" Connecting an iPod without an extension. For optimum convenience and audio •...
  • Page 265: Using A Usb Device

    Connectivity Bonding the device Folder To connect the device to the system E100022 follow the same procedure as for Playlist Bluetooth hands free phones. See Bluetooth setup (page 241). E100023 Operating the device Album Note: The seek buttons and file E100024 information will only work on certain Artist...
  • Page 266: Using An Ipod

    Connectivity The display will show the track • folder name information, together with other important • file name. information described below: • A vertical scroll bar on the right side of USING AN IPOD the display shows the current position of the folder view.
  • Page 267 Connectivity The iPod menu list for browsing contents Press function button 3 to scan the whole will be available through the radio display. device or a playlist if it is in operation. Navigation of the contents follows the Press the INFO button or function button same principles as for iPod standalone 4 to display the following: use (for example search by artist, title,...
  • Page 268: Navigation Introduction

    Navigation introduction GENERAL INFORMATION CAUTIONS Use only 12 cm (4.7 inches) discs or Press the relevant button on the unit bezel 8 cm (3.1 inches) discs with a suitable to access the system functions. This will adaptor. take you into the selected mode. Do not attempt to open the unit.
  • Page 269 Read and follow all stated safety precautions. Failure to do so may increase your risk of collision and personal injury. Ford Motor Company shall not be liable for any damages of any type arising from failure to follow these guidelines.
  • Page 270: Navigation Quick Start

    GPS receiver. an incompatibility can occur between the phone and hands-free system, which in Note: The Ford Mobile Navigation must some cases may significantly degrade the be installed and activated on your mobile system performance. To avoid this phone.
  • Page 271 2. Switch your mobile phone on and start 1. Select the option you require, or if it is the "Ford Mobile Navigation". not shown on the screen use the up 3. Choose "Select Destination".
  • Page 272 Navigation Quick start Destination input screen • Use the up and down arrow buttons and scroll to Destination input. • Press the OK button to activate your selection. Note: A list with several options is shown. • Starting from the top, select the country followed by either the postcode if available or city and street name.
  • Page 273: Navigation Unit Overview

    Navigation unit overview NAVIGATION UNIT Descriptions for function OVERVIEW buttons 1-4 Function buttons 1 to 4 are context dependent, and change according to the current unit mode. Descriptions for the functions are shown at the bottom of the screen display. E104157...
  • Page 274 Navigation unit overview Vehicles with CD-SD navigation system E129241 CD eject. Navigation arrows. CD aperture. Information. Map select. See Route displays (page 280). Menu select. See System settings (page 276). Telephone keypad and station presets. See Audio unit operation (page 230).
  • Page 275 Navigation unit overview Function 3. Seek up. CD track selection. See Station tuning control (page 230). See Track selection (page 235). On/off and volume control. See On/off control (page 230). Seek down. CD track selection. See Station tuning control (page 230). See Track selection (page 235).
  • Page 276 Navigation unit overview Vehicles with Sony CD-SD navigation system E129242 On/off control. See On/off control (page 230). Navigation select. See System settings (page 276). Telephone keypad and station presets. See Audio unit operation (page 230). See Audio unit menus (page 233). See Telephone (page 241). CD aperture.
  • Page 277: Loading The Navigation Data

    Navigation unit overview Seek up. CD track selection. end call. See Station tuning control (page 230). See Track selection (page 235). See Using the telephone (page 243). Home select. See System settings (page 276). Traffic announcement. See Traffic Message Channel (page 281). Function 4.
  • Page 278: System Settings

    System settings Last destinations SYSTEM SETTINGS This feature allows quick access to a Most of the important settings for your history of previous destinations entered navigation unit can be accessed via the in the system. A detailed display will show MENU or NAV button.
  • Page 279 System settings Special functions Nav audio mixing This feature allows you to select GPS and This feature allows you to adjust the system information or a demonstration of volume mix between the navigation voice the system functionality. output and audio source. Map display DSP settings This feature allows you to change the way...
  • Page 280 System settings Clock settings Set time This feature allows you to manually adjust the time. Set date This feature allows you to manually adjust the date, month and year. GPS time This feature allows you to, if in a suitable coverage area, automatically adjust the date and time using GPS.
  • Page 281: Navigation System

    Navigation system Eco settings ROUTE OPTIONS MENU Trailer You can set a number of options which alter the way a route is planned. Use this feature to change the economy settings of your journey relating to Using the up, down, left and right arrow whether or not you are towing a trailer buttons, you can select from the list which and if so the size of trailer being towed.
  • Page 282: Route Displays

    Navigation system Seasonal roads Junction zoom When switched on the system will look This feature will automatically increase the for seasonal roads on your route and zoom on the map display at times when automatically update your route distance you are required to make a turn, or and timings.
  • Page 283: Traffic Message Channel

    Traffic Message Channel You may either select a view which shows PRINCIPLE OF OPERATION messages only affecting your programmed route, or a view which Traffic message channel (TMC) stations shows all messages received. Press are broadcast on the FM waveband. TMC function button 1 to change the view.
  • Page 284: Map Updates

    Map updates MAP UPDATES The road network is constantly changing due to new roads, changes in road classification, etc. Therefore, it is not always possible to exactly match the map data in the system to the current road network. Map information is regularly updated, but all areas are not necessarily covered to the same level of detail.
  • Page 285: Appendices

    The Bluetooth word mark and logos are FCC/INDUSTRY CANADA owned by the Bluetooth SIG, Inc. and any NOTICE use of such marks by Ford Motor Company is under license. Other This device complies with Part 15 of the trademarks and trade names are those FCC Rules.
  • Page 286: Type Approvals

    Appendices E114220 TYPE APPROVALS TYPE APPROVALS EU Declaration Hereby, Valeo declares that this short range device is in compliance with the E97713 essential requirements and other relevant provisions of Directive 1999/5/EC. E97714 SD Logo is a trademark.
  • Page 287: Electromagnetic Compatibility

    Appendices Certificate for United Arab WARNINGS Emirates Radio frequency (RF) transmitter equipment (e.g. cellular telephones, amateur radio transmitters etc.) may only be fitted to your vehicle if they comply with the parameters shown in the table below. There are no special provisions or conditions for installations or use.
  • Page 288 Appendices Frequency Maximum output power Watt Antenna Positions Band MHz (Peak RMS) 1 – 30 50 W 3, 4 30 – 54 50 W 1, 2, 3 68 – 87.5 50 W 1, 2, 3 142 – 176 50 W 1, 2, 3 380 –...
  • Page 289 Index Audio unit commands......246 Auxiliary input..........250 CD Player............246 External devices - iPod......252 See: Climate control........101 External devices - USB......251 About this handbook........7 Radio............247 Audio unit menus........233 See: Brakes..........145 Audio unit operation......230 ABS driving hints Audio unit overview......223 See: Hints on driving with ABS....145 Auto-dimming mirror......75 Accessories Autolamps..........59...
  • Page 290 Index Changing a bulb........63 Approach lamp..........65 Central high mounted brake lamp....68 Battery connection points....200 Front fog lamps..........66 Blind spot monitor........75 Headlamp............63 Blind spot information system (BLIS)..75 Interior lamps..........69 Detection errors..........77 Luggage compartment lamp, footwell System detection and alerts......76 lamp and tailgate lamp......70 Turning the system on and off....76 Number plate lamp........69 Using the system..........75...
  • Page 291 Index Cleaning the interior......197 Disabling the passenger airbag....34 Instrument cluster screens, LCD screens, Disabling the passenger airbag....34 radio screens..........198 Enabling the passenger airbag....35 Rear windows..........198 Fitting the passenger airbag deactivation Seat belts.............197 switch............34 Climate control........101 Disarming the alarm........50 Principle of operation........101 Vehicles with keyless entry......50 Climate control commands....258 Vehicles without keyless entry....50...
  • Page 292 Index Engine oil check........193 Checking the oil level.........193 Topping up...........193 Gauges.............78 Engine oil dipstick - 1.6L Duratec-16V Engine coolant temperature gauge..79 Ti-VCT (Sigma)........192 Fuel gauge.............79 Engine oil dipstick - 1.6L Duratorq-TDCi Gearbox (DV) Diesel/2.0L Duratorq-TDCi (DW) See: Transmission........142 Diesel............192 General information on radio Exterior mirrors........73 frequencies..........36 Manual folding mirrors.........73...
  • Page 293 Index Important audio information....222 Audio unit labels.........222 Disc labels...........222 Keyless entry...........43 Information displays........84 Disabled keys..........45 General information........84 General information........43 Information messages......91 Locking and unlocking the doors with the Airbag..............91 key blade...........45 Alarm..............92 Locking the vehicle........43 Battery and charging system.....92 Passive key...........43 Blind spot monitor........92 Unlocking the vehicle........44 Child power lock...........93...
  • Page 294 Index Locks............39 Luggage anchor points......163 Luggage covers........165 Navigation introduction......266 General information........266 Navigation Quick start......268 Vehicles with CD-SD navigation system or Maintenance...........187 Sony CD-SD navigation system..269 General information........187 Vehicles with mobile navigation Technical specifications......195 system.............268 Manual climate control......102 Navigation system........279 Air conditioning..........103 Navigation unit overview......271 Air distribution control........102 Vehicles with CD-SD navigation...
  • Page 295 Rear view camera.........157 Look for the Ford logo on the following Principle of operation.........157 Rear window wiper and washers..54 parts .............8 Now you can be sure that your Ford parts Intermittent wipe..........54 are Ford parts..........7 Rear window washer........55 Personalised settings......90 Reverse gear wipe........55...
  • Page 296 Index Steering wheel lock.......128 Vehicles with keyless starting....128 Vehicles without keyless starting.....128 Safety precautions........137 Steering wheel.........51 Satellite navigation unit holder.....127 Storage compartments......125 Adjusting the holder........127 Rear storage compartment......125 Seat belt height adjustment....33 Sun blinds..........122 Seat belt reminder........33 Roof..............122 Deactivating the seat belt reminder..33 Side windows..........122 Grand C-MAX only........33 Switching off the engine.......132...
  • Page 297 Index Towing points.........185 Installing the towing eye......185 See: Using a USB device......263 Using active park assist......154 Towing eye location........185 Towing the vehicle on four Using an iPod........264 wheels..........185 Audio control..........265 All vehicles............185 Operation............264 Using a USB device......263 Vehicles with automatic transmission..........186 Audio control..........264 Towing.............170...
  • Page 298 Index Using the speed limiter......162 Intentionally exceeding the set speed limit............162 Warning lamps and indicators....80 Setting the speed limit.......162 ABS warning lamp........80 Switching the system on and off.....162 Airbag warning lamp........80 System warnings........162 Blind spot monitor indicator......80 Using the telephone......243 Brake system lamp........80 Changing the active phone......244 Cruise control indicator.......80...
  • Page 300 Feel the difference...

Table of Contents
