Summary of Contents for Ford Transit Connect electric

  • Page 2: Introduction

    Introduction This publication is provided as a supplement to the 2011 Ford Transit Connect Owner’s Guide for reference use in operating the Transit Connect Electric. This supplement must be used in conjunction with the Ford Transit Connect Owner’s Guide for a complete reference to these vehicles.

  • Page 3: Table Of Contents

    Introduction INTRODUCTION INSTRUMENT CLUSTER CLIMATE CONTROLS TIRES, WHEELS & LOADING DRIVING ROADSIDE EMERGENCIES CLEANING MAINTENANCE & SPECIFICATIONS SCHEDULED MAINTENANCE HIGH VOLTAGE BATTERY CHARGING...
  • Page 4 ELECTRICAL OPERATION The Transit Connect Electric uses both High Voltage and Low Voltage systems. A conventional 12 V battery maintains normal vehicle systems, however it is maintained by the High Voltage Battery. All electrical power used comes from this High Voltage Battery, which is maintained by recharging the vehicle from an external source.
  • Page 5 Introduction VEHICLE HIGH VOLTAGE BATTERY CHARGING A charge port for external AC power is provided on the right side of the vehicle behind the filler door. An on-board charger is located under the hood and is electrically connected to the charge port and the High Voltage Battery. See the High Voltage Battery Charging chapter at the back of this Supplement for details.

  • Page 6: Instrument Cluster

    Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions.
  • Page 7 If the light does not turn on or begins to flash, have the system inspected by your authorized dealer. For more information on this system, refer to Tire pressure monitoring system (TPMS) in the Tires, Wheels and Loading chapter of the Ford Transit Connect Owner’s Guide.
  • Page 8 This lamp illuminates when the AdvanceTrac is active. If the light remains on, contact your authorized dealer as soon as possible. Refer to the Driving chapter of the Ford Transit Connect Owner’s Guide for more information. ® Anti-theft system: Flashes when the SecuriLock Passive Anti-theft system has been activated.
  • Page 9 A Belt-Minder chime will also sound to remind you to fasten your safety belt. Refer to the Seating and Safety Restraints chapter of the Ford Transit Connect Owner’s Guide to activate/deactivate the Belt-Minder® chime feature. Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on.
  • Page 10 Instrument Cluster Key-in-ignition warning chime: Sounds when the key is left in the ignition in the off or accessory position and the driver’s door is opened. Park warning chime: Sounds when the transmission is not in Park, the driver’s door is opened and the ignition is off or in accessory position.
  • Page 11 Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Range Gauge: Marked in increments showing approximate range remaining in miles or kilometers based on stored vehi- cle usage history. The range gauge is active after the vehicle has been started. NOTE: Vehicle range is affected by operating conditions.
  • Page 12 Instrument Cluster Temperature Gauge: High Voltage electrical components including the traction motor and High Voltage Battery are liquid cooled. The coolant temperature is maintained by the vehicle radiator and electric fans. At normal operating temperature, the needle will be in the normal range, below the red line and the H indicator.

  • Page 13: Climate Controls

    If use is needed during normal vehicle operation, use the minimum amount of heating and cooling consistent with occupant comfort. See the Climate Controls chapter of the Ford Transit Connect Owner’s Guide for details on heating and air conditioning controls and other general information.

  • Page 14: Tires, Wheels & Loading

    Tires, Wheels & Loading TIRE PRESSURES Refer to the Tire and Loading Information sticker on the Driver’s door-jam for tire infla- tion information. See the Tires, Wheels & Loading chapter in the Ford Transit Connect Owner’s Guide for details and other general information.

  • Page 15: Driving

    Driving STARTING PREPARATIONS Positions of the ignition (Off) — Locks the steering wheel and gearshift lever and allows key removal. This position also shuts off all the electrical accessories and disconnects all high voltage components from the high voltage battery pack. (Accessory) —...
  • Page 16 Driving With key in II (on) position, Range Indicator and State of Charge Indi- cators move to bottom of range only. VEHICLE IS NOT READY FOR DRIVING With the key in the III (start) posi- tion and released, both Range Indi- cator and State of Charge Indicator move.
  • Page 17 Driving STARTING UP—INITIALIZATION 1. Turn the key to II (On) without turning the key to III (Start). Some warning lights will briefly illuminate. See Warning Lights and Chimes in the Instrument Cluster chapter of this Supplement for more information regarding the warning lights. 2.
  • Page 18 Driving NOTE: Vehicle range is affected by operating conditions. For maximum range, avoid heavy acceleration and excessive vehicle speeds. The use of any vehicle electrical equipment will affect range as well. To maximize range, minimize use of heater and air conditioner whenever possible. To set the parking brake (1), pull the parking brake handle up as far as possible.
  • Page 19 Driving SHIFTER OPERATION This vehicle does not have a conventional multi-speed transmission, instead it uses a single-speed transmission to provide gear reduction and provide differential action for the front wheels. Driving the vehicle is the same as driving with an automatic transmission since the electric traction motor provides sufficient speed range without the need for gear changes.

  • Page 20: Driving Through Water

    Driving R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be powered-up and is free to roll.

  • Page 21: Roadside Emergencies

    Roadside Emergencies HIGH VOLTAGE INERTIA SAFETY SWITCH In the event of an accident the safety switch will automatically deactivate the vehicle high voltage system—temporarily rendering the vehicle inoperative. WARNING: In the event of an accident, do not reset the high voltage inertia switch.
  • Page 22 Roadside Emergencies FUSE / RELAY ALLOCATION LOCATION FUNCTION SIZE LOCATION FUNCTION SIZE Hv Batt Pumps & Cabin Htr Cool Mini-7.5a Vac Pump Jcase-40a Pump Low Pwr Loads, Electronics Cool Batt Jcase-20a Pump Mini-10a Hv Batt Htr 1 Mini-20a Cool Fan Diode Hv Batt Htr 2 Mini-20a Start Signal...
  • Page 23 If towing with wheels on the ground, ensure that vehicle is placed in Neutral and that the Parking Brake is released. When towing the Transit Connect Electric, make sure that no tow chains or straps are allowed to make contact with, or hooked onto the High Voltage components or cabling.

  • Page 24: Cleaning

    Cleaning UNDERBODY WASHING PRECAUTION  Never pressure wash or spray the underbody with water.  Clean only with a dry cloth after powering down and waiting for five minutes.  Keep body, door, and High Voltage Battery Pack drain holes free from packed dirt.

  • Page 25: Maintenance & Specifications

    Maintenance & Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide/Customer Information Guide to find out which parts and services are covered.
  • Page 26 Maintenance and Specifications IDENTIFYING COMPONENTS UNDER THE HOOD ® 1. Electronics Coolant Reservoir (Motorcraft Specialty Orange Coolant only) ® 2. Cabin Heater Coolant Reservoir (Motorcraft Specialty Orange Coolant only) 3. High Voltage Charger (Backside of Traction Motor) 4. Brake Fluid Reservoir 5.
  • Page 27 Maintenance and Specifications When the vehicle is cold, check the level of the electronics coolant in the reservoir. • The coolant should be at the MAX level as listed on the reservoir.  Refer to scheduled maintenance information for service interval schedules.
  • Page 28 Maintenance and Specifications Do not mix coolants. Add the coolant type originally equipped in your vehicle. Refer to Maintenance product specifications and capacities in this chapter. Note: Do not use stop leak pellets or cooling system sealants/additives as they can cause damage to the cooling system and electronic components.

  • Page 29: Power Steering Fluid

    Maintenance and Specifications POWER STEERING FLUID Check the fluid. Refer to scheduled maintenance information. 1. Turn the steering wheel left and right several times. Power-down the vehicle. 3. Check the fluid level. 4. If the fluid is below the MIN line, add fluid in small amounts until it reaches the correct level (between the MIN and MAX lines).
  • Page 30 Maintenance and Specifications CHARGING THE HIGH VOLTAGE BATTERY See the High Voltage Battery Charging chapter in this Guide. SERVICING HIGH VOLTAGE COMPONENTS All high voltage components must be serviced by trained Technicians at an authorized AZD repair facility. WARNING: Exposure to high voltage may result in severe personal injury or death.
  • Page 31 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...

  • Page 32: Scheduled Maintenance

    Scheduled Maintenance MAINTENANCE SCHEDULE — NORMAL SCHEDULE General Maintenance Information The Normal Schedule applies to operation of the vehicle under typical, everyday driving conditions. The maintenance frequency in this schedule typifies what the vast majority of vehicles will require. The listed services should be carried out at specified mileage or time, whichever occurs first.
  • Page 33 Scheduled Maintenance Periodic Checks - Monthly Check each of the following items every month:  All interior and exterior lights for correct operation.  Tires for wear and correct air pressure.  Windshield washer fluid level. Periodic Checks - Six Months Check each of the following items every six months: ...
  • Page 34 Maintenance and Specifications 10,000 Mi 20,000 Mi 100,000 Mi 16,000 32,000 160,000 Normal Maintenance Schedule Intervals Intervals Intervals Perform multi-point inspection. • • • Rotate tires, inspect tires for wear, measure tread depth • • • and inspect wheel ends for end play and noise. Inspect control arms, steering linkage, steering ball •...

  • Page 35: High Voltage Battery Charging

    High Voltage Battery Charging CHARGING THE HIGH VOLTAGE BATTERY 1. Power-down the vehicle. 2. Unlock the charge port door with the key. 3. Release the catch to allow the charge port cap to open. 4. Plug the charger into the charge port and ensure that the latch on the top of the charger has engaged.
