Sony CCD-TR618 Service Manual page 177

MI-040 MI-041
Ref. No. Part No. Description
< RESISTOR >
R757 1-216-825-11 METAL CHIP
R769 1-216-832-11 METAL CHIP
R774 1-216-836-11 METAL CHIP
R775 1-216-832-11 METAL CHIP
R776 1-216-864-91 SHORT
R779 1-216-857-11 METAL CHIP
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
R780 1-216-833-11 METAL CHIP
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
R782 1-216-833-11 METAL CHIP
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
R783 1-216-857-11 METAL CHIP
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
R785 1-216-835-11 METAL CHIP
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
R788 1-216-839-11 METAL CHIP
R797 1-216-824-11 METAL CHIP
R3901 1-216-839-11 METAL CHIP
R3902 1-216-829-11 METAL CHIP
R3903 1-216-839-11 METAL CHIP
R3904 1-216-834-11 METAL CHIP
R3905 1-216-857-11 METAL CHIP
R3907 1-218-879-11 METAL CHIP
R3908 1-216-815-11 METAL CHIP
R3909 1-216-821-11 METAL CHIP
R3912 1-216-819-11 METAL CHIP
R3913 1-216-847-11 METAL CHIP
R3914 1-216-847-11 METAL CHIP
R3915 1-216-818-11 METAL CHIP
R3916 1-216-831-11 METAL CHIP
R3917 1-216-817-11 METAL CHIP
R3919 1-216-823-11 METAL CHIP
R3920 1-216-817-11 METAL CHIP
R3921 1-216-817-11 METAL CHIP
R3922 1-216-864-91 SHORT
R3923 1-216-817-11 METAL CHIP
R3924 1-216-295-11 SHORT
R3925 1-216-001-00 METAL CHIP
R3925 1-216-027-00 METAL CHIP
R3926 1-216-800-11 RES-CHIP
PD-131
Remarks
2.2K 5% 1/16W
8.2K 5% 1/16W
18K 5% 1/16W
8.2K 5% 1/16W
0
1M 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
1M 5% 1/16W
15K 5% 1/16W
33K 5% 1/16W
1.8K 5% 1/16W
33K 5% 1/16W
(TRV98)
4.7K 5% 1/16W
(TRV98)
33K 5% 1/16W
(TRV98)
12K 5% 1/16W
(TRV98)
1M 5% 1/16W
(TRV98)
22K 0.5% 1/16W
(TRV98)
330 5% 1/16W
(TRV98)
1K 5% 1/16W
(TRV98)
680 5% 1/16W
(TRV98)
150K 5% 1/16W
(TRV98)
150K 5% 1/16W
(TRV98)
560 5% 1/16W
(TRV98)
6.8K 5% 1/16W
(TRV98)
470 5% 1/16W
(TRV98)
1.5K 5% 1/16W
(TRV98)
470 5% 1/16W
(TRV98)
470 5% 1/16W
(TRV98)
0 (TRV98)
470 5% 1/16W
0 (TRV98)
10 5% 1/10W
(TRV98)
120 5% 1/10W
(EXCEPT TRV98)
18 5% 1/16W
(TRV98)
Ref. No. Part No. Description
R3927 1-216-295-11 SHORT
R3929 1-216-027-00 METAL CHIP
R3931 1-216-834-11 METAL CHIP
R3948 1-216-295-11 SHORT
< COMPOSITION CIRCUIT BLOCK >
RB751 1-239-702-81 RESISTOR, NETWORK 22K
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
RB752 1-239-702-81 RESISTOR, NETWORK 22K
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
< SENSOR >
SE751 1-418-252-11 SENSOR, ANGULAR VELOCITY (PITCH)
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
SE752 1-418-252-21 SENSOR, ANGULAR VELOCITY (YAW)
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
************************************************************
A-7074-667-A PD-131 BOARD, COMPLETE (TRV98/TRV98E)
*************************************
A-7074-680-A PD-131 BOARD, COMPLETE
**************************************
A-7074-701-A PD-131 BOARD, COMPLETE (TRV88)
******************************
< CAPACITOR >
C5501 1-135-201-11 TANTALUM CHIP 10uF
C5503 1-125-777-11 CERAMIC CHIP
C5504 1-125-777-11 CERAMIC CHIP
C5505 1-164-943-11 CERAMIC CHIP
C5506 1-164-943-11 CERAMIC CHIP
C5507 1-164-943-11 CERAMIC CHIP
C5509 1-126-602-11 ELECT CHIP
C5510 1-164-943-11 CERAMIC CHIP
C5511 1-164-739-11 CERAMIC CHIP
C5512 1-125-777-11 CERAMIC CHIP
C5513 1-125-777-11 CERAMIC CHIP
C5514 1-119-750-11 TANTAL. CHIP
C5515 1-164-357-11 CERAMIC CHIP
C5516 1-162-927-11 CERAMIC CHIP
C5517 1-107-826-11 CERAMIC CHIP
C5518 1-107-826-11 CERAMIC CHIP
C5519 1-107-826-11 CERAMIC CHIP
C5520 1-124-779-00 ELECT CHIP
C5521 1-127-573-11 CERAMIC CHIP
C5522 1-125-777-11 CERAMIC CHIP
C5523 1-125-777-11 CERAMIC CHIP
C5524 1-127-573-11 CERAMIC CHIP
C5527 1-164-943-11 CERAMIC CHIP
C5528 1-126-193-11 ELECT
C5530 1-164-943-11 CERAMIC CHIP
6-14
Ver 1.4 2002. 05
Remarks
0 (EXCEPT TRV98)
120 5% 1/10W
(EXCEPT TRV98)
12K 5% 1/16W
(TRV98)
0 (EXCEPT TRV98)
(TRV49/TRV49E/TRV58/TRV58E/
TRV59E/TRV68/TRV78/TRV78E)
(Ref.No.;10000 Series)
20% 4V
0.1uF 10% 10V
0.1uF 10% 10V
0.01uF 10% 16V
0.01uF 10% 16V
0.01uF 10% 16V
3.3uF 20% 50V
0.01uF 10% 16V
560PF 5% 50V
0.1uF 10% 10V
0.1uF 10% 10V
22uF 20% 6.3V
0.001uF 5% 50V
100PF 5% 50V
0.1uF 10% 16V
0.1uF 10% 16V
0.1uF 10% 16V
10uF 20% 16V
1uF 10% 16V
0.1uF 10% 10V
0.1uF 10% 10V
1uF 10% 16V
0.01uF 10% 16V
1uF 20% 50V
0.01uF 10% 16V
