Page 6
REMOVE REAR COVER: 1. Place your hand through the sewing area of the machine and push rear cover to the back until it is released. (Drawing 2. Uft the back cover upward and remove from the permanent handle of the machine. (Drawing 4) REAR COVER AS AN EXTtNSION TABLE: Lower the back metal support leg.
Page 8
3. Place the rear cover over the handle of the machine and cover into snap the place on the back of machine. (Drawing 4. Align the front cover at the hinges. Release the top hinge into the cover then release the bottom hinge into the cover. (Drawing 91) 5.
Page 10
1. ADJUSTING TOP THREAD TENSION Decrease or increase the tension of the top thread by using this control. The higher the number, the tighter the tension. PRESSER FOOT LEVER There are three positions for your presser foot. 1. Lower the presser foot to sew. 2.
WINDING BOBBIN 1. Pivot spool pin into highest horizontal spool pin position. 2. Pass a spool of thread on the spool pin. Secure to place a spool of thread on the pin. Secure it with the spool cap to ensure smooth flow of thread. 3.
Page 16
INSERTING THE BOBBIN Raise the presser foot. 1. Raise the needle to its highest position by rotating the handwheel towards you. 2. Remove the bobbin cover plate by pressing down on the lower left corner of the bobbin cover plate while pressing the latch to the right that holds the bobbin cover in place.
Page 17
THREADING THE TOP THREAD 1. Raise the presser foot lever. 2. Raise the needle to its highest position by rotating the hand wheel towards you. 3. Thread the machine in the order as illustrated.
Page 19
PICKING UP BOBBIN THREAD 1. Raise the presser foot lever. Holding needle thread loosely with your left hand, turn hand wheel towards you one revolution with your right hand until the needle comes to its highest position. 2. Lightly pull up on the needle thread. This will pull a loop of bobbin thread through the needle plate slot.
Page 28
Stitch Selector B ZIGZAG STITCHING SATIN STITCH Stitch Mdth This is a closely spaced attractive stitch used for Stitch Length appliqué, bar-tacking, etc. Slightly loosen top thread tension for satin stitching. Stitch Indicator Use a backing stabilizer interfacing for the sheer materials avoid puckering.
Page 29
BLINDSTITCH Medium to heavyweight fabric Stitch Selector C,F Stitch Width Stitch Length Under side 1. First finish the raw edge. Do this by turning it under on fine fabrics and overcasting it on medium to heavyweight ones. Then turn the hem up the required depth, press and pin in place.
Page 36
DOUBLE OVERLOCK STITCH Stitch Selector G Stitch Width Stitch Length -S÷ Double overlock has a number of uses. It is perfect for attaching flat elastic when making or repairing lingerie. It is ideal for overcasting a single layer of fabric or seaming and overcasting in one step on slightly stretch fabric and non-stretch fabrics such as linen, tweed and medium to heavy-weight cotton.
Page 38
PROCEDURE 1. Stitch forward to the end of buttonhole mark. Stop sewing at the left stitch and raise needle. ® 2. Bartack 4 or 5 stitches. Stop sewing at the left stitch and raise needle to its highest position. 3. Stitch backword to the start of i l l i buttonhole mark to complete buttonhole.
