ASSEMBLY

Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the
included allen wrenches, assembly requires a phillips screwdriver
wrench , and a rubber mallet
As you assemble the elliptical exerciser, use the drawings below to identify the small parts used in assembly.
The number in parenthesis below each drawing refers to the key number of the part, from the PART LIST on
page 22. The second number refers to the quantity used in assembly. Note: Some small parts may have been
pre-assembled for shipping. If a part is not in the parts bag, check to see if it has been pre-assembled.
M8 Nylon M10 Nylon
Locknut (38)–4 Locknut (33)–6
Spring Bracket
Washer (35)–2
M8 x 45mm Button Bolt (50)–4
M10 x 27mm
Patch Screw (40)–2
1. Identify the Front Stabilizer (10). While another person
lifts the front of the Frame (1), attach the Front
Stabilizer to the Frame with two M10 x 75mm Carriage
Bolts (34) and two M10 Nylon Locknuts (33). Make
sure that the Front Stabilizer is turned so the
Wheels (22) are not touching the floor.
M10 Split
Washer (59)–7
M4 x 16mm
Screw (52)–2
M10 x 27mm
Button Screw (67)–3
.
M10 Wave Washer
Washer (65)–2 (79)–2
M8 x 25mm Button
Screw (56)–2
M10 Bolt Set (74)–2
M10 x 75mm Carriage
1
34
22
34
5
, an adjustable
Handlebar
Washer (55)–2
M10 x 29mm
Carriage Bolt (28)–2
M10 x 76mm Button
Bolt (7)–2
Bolt (34)–4
22
1
10
33
