Impex IGS-6201 Owner's Manual

Impex IGS-6201 Owner's Manual

Iron grip strength dual station home gym
Hide thumbs
Table of Contents

Advertisement

Quick Links

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Resistance Chart
Model
IGS 6201
Retain This
Manual for
Reference
01-04-08
OWNER'S
MANUAL
IRON GRIP STRENGTH
DUAL STATION HOME GYM
IMPEX
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
IGS-6201
®
FITNESS PRODUCTS
www.impex-fitness.com
info@impex-fitness.com

Advertisement

Table of Contents
loading

Related Manuals for Impex IGS-6201

Summary of Contents for Impex IGS-6201

  • Page 1 NOTE: Please read all instructions carefully before using this product Table of Contents IRON GRIP STRENGTH Safety Notice DUAL STATION HOME GYM Hardware Pack IGS-6201 Assembly Instruction Parts List Resistance Chart Warranty Ordering Parts Model IGS 6201 Retain This Manual for...

  • Page 2: Table Of Contents

    RESISTANCE CHART………………………………………………………………. 43 WARRANTY....................… 44 ORDERING PARTS..................44 BEFORE YOU BEGIN Thank you for selecting the IRON GRIP STRENGTH IGS-6201 HOME GYM by ® IMPEX FITNESS PRODUCTS. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

  • Page 4: Warning Label Placement

    WARNING LABEL PLACEMENT The warning labels have been placed on the unit in location shown. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in location shown.

  • Page 5: Hardware Pack

    HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 6 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 7 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 8 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 9 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 10 HARDWARE PACK...

  • Page 11: Assembly Instructions

    ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Butterfly Pulley Bracket (#13) to the Main Support Frame (#1) from the bottom. Secure it with two M10 x ¾”...
  • Page 12 STEP 2 (See Diagram 2) A.) Attach the Butterfly Base Frame (#3) to the Main Support Frame (#1) from the bottom. Secure it with two M10 x 3” Allen Bolts (#98), one Bracket (#2), four Ø ¾” Washers (#107), and two M10 Aircraft Nuts (#110). B.) Slide fourteen Weight Plates (#73) onto the two Guide Rods (#20).
  • Page 13 DIAGRAM 2...
  • Page 14 STEP 3 (See Diagram 3) A.) Attach the Vertical Frame (#7) onto the Main Support Frame (#1). Secure it with two M10 x 2 ¾” Allen Bolts (#97), four ¾” Washers (#107), and two M10 Aircraft Nuts (#110). Do not tighten the Nuts and Bolts yet.
  • Page 15 DIAGRAM 3...
  • Page 16 STEP 4 (See Diagram 4) A.) Attach the Front Press Base (#18) to the Upper Frame (#17). Align the holes and insert the 5 7/8” Front Press Axle (#81) through the holes. Secure the Axle with one M8 x ¾” Allen Bolt (#90), Ø...
  • Page 17 STEP 5 (See Diagram 5) A.) Insert the axle on the Left Butterfly (#8) into the left pivot on the Butterfly Base (#3) from the bottom. Secure it with one M8 x ¾” Allen Bolt (#90), Ø 5/8” Lock Washer (#124), Ø 1 1/8” Washer (#42), and D-shaped Washer (#29).
  • Page 18 STEP 6 (See Diagram 6) A.) Attach the Front Press (#19) to the Front Press Base (#18). Align the holes. Secure it with one M12 x 7 1/8” Allen Bolt (#105), two Ø 1” Washers (#108), and one M12 Aircraft Nut (#111). Cover the Bolt and Nut with two Cover Caps (#127).
  • Page 19 STEP 7 (See Diagram 7) A.) Attach the Leg Press Base Frame (#38) to the bracket on the Leg Press Rear Base Frame (#31). Secure it with two M10 x 2 ¾” Allen Bolts (#97), and two Ø ¾” Washers (#107). Securely tighten the Nuts and Bolts previously installed in Step-6, Procedure C.
  • Page 20 STEP 8 (See Diagram 8) A.) Attach the Leg Press Seat Support (#33) to the Leg Press Base Frame (#38). Secure it with four M10 x ¾” Allen Bolts (#94) and Ø ¾” Washers (#107). Do not tighten the Bolts yet. B.) Attach the Leg Press Seat Support to the Leg Press Backrest Support (#32).
  • Page 21 STEP 9 (See Upper Cable Loop & Diagram 9) A.) Attach the 142” Upper Cable (#44) to the open pulley bracket under the Upper Frame (#17). Attach a Pulley (#59) to the open bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#95), two Ø...
  • Page 22 UPPER CABLE LOOP DIAGRAM...
  • Page 23 DIAGRAM 9-1...
  • Page 24 DIAGRAM 9-2...
  • Page 25 STEP 10 (See Lower Cable Loop & Diagram 10) A.) Attach the 184” Lower Cable (#45) to the open bracket on the Leg Developer (#6). Attach a Pulley (#59) to the bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#95), two ¾”...
  • Page 26 LOWER CABLE LOOP...
  • Page 27 DIAGRAM 10...
  • Page 28 STEP 11 (See Leg Press Cable Loop and Diagram 11) A.) Connect one end of 123” Leg Press Cable (#47) to the Pulley pre-installed on the Leg Press Rear Frame (#31). Draw the Cable over the Pulley along the Leg Press Base Frame to the other end.
  • Page 29 LEG PRESS CALBE LOOP...
  • Page 30 DIAGRAM 11...
  • Page 31 STEP 12 (See Butterfly Cable Loop and Diagram 12) A.) Attach one end of 90” Butterfly Cable (#46) onto the open slot on the Left Butterfly (#8). B.) Draw the Cable to the left horizontal bracket on the Butterfly Pulley Bracket (#13). Attach a Pulley (#59) to the bracket.
  • Page 32 DIAGRAM 12...
  • Page 33 STEP 13 (See Diagram 13) A.) Attach the Leg Press Adjustment Frame (#36) to the Leg Press Plate (#35). Secure it with one M10 x 3” Allen Bolt (#98), two Ø ¾” Washers (#107), and one M10 Aircraft Nut (#110). Use a Leg Press Lock Pin (#26) to secure the Leg Press Plate at desired position.
  • Page 35 Step 14 (See Diagram 14) A.) Attach a Weight Stack Cover (#24) to the rear of the machine. Secure it to the Brackets and Upper Frame with four M8 x ¾” Allen Bolts (#90), Ø 5/8” Lock Washers (#124), and Ø 5/8” Large Washers (#43).
  • Page 37 Step 15 (See Diagram 15) A.) Attach the Leg Press Seat Pad (#50) to the Leg Press Seat Bracket (#37). Secure it with two M8 x ¾” Allen Bolt (#90) and two Ø 5/8” Washers (#106). Attach the Leg Press Seat Bracket to the Leg Press Seat Support (#33).
  • Page 39 Step-16 (See Diagram 16) A.) Connect the Lat Bar (#40) to the Upper Cable (#44) with one Short Chain (#88) and two Hooks (#89). B.) Insert one Butterfly Handle (#10) into the pivot on the Right Butterfly (#9). Secure it with one M8 x ¾”...

  • Page 42: Parts List

    PARTS LIST Lat Bar Holder Cover KEY NO. DESCRIPTION Q’ty Ø 1” End Cap Main Support Frame Foam Roll Bracket T-shaped Handle Butterfly Base Ø 1 ¼” End Cap Rear Base Frame 2” x 1” End Cap Foam Tube Foam Roll End Cap Leg Developer 2 3/8”...
  • Page 43 PARTS LIST KEY NO. DESCRIPTION M5 x ½” Philips Screw Seat Support Lock Pin Ø 2” Rubber Bumper Storage Bag Ø 5/8” Lock Washer Ø ½” Washer Weight Stack Cover Bracket Cover Cap M8 x 2 ¾” Allen Bolt Leg Press Support Frame M8 x 1”...

  • Page 44: Resistance Chart

    WEIGHT RESISTANCE CHART WEIGHT PLATE Station Front Press 105 120 135 150 Butterfly Lat Pull 100 110 Leg Developer Leg Press 110 130 150 170 190 210 WEIGHT PLATE Station Front Press 180 195 210 225 Butterfly 120 130 140 150 Lat Pull 130 140 150 160 Leg Developer...

  • Page 45: Warranty

    IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
