Impex IGS-5100 Owner's Manual

Iron grip strength deluxe smith machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
IGS-5100
Retain This
Manual for
Reference
08-15-06
OWNER'S
MANUAL
IRON GRIP STRENGTH
DELUXE SMITH MACHINE
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
IGS-5100
®
IMPEX
INC.

Advertisement

Table of Contents
loading

Related Manuals for Impex IGS-5100

Summary of Contents for Impex IGS-5100

  • Page 1 NOTE: Please read all instructions carefully before using this product IRON GRIP STRENGTH Table of Contents Safety Notice DELUXE SMITH MACHINE Hardware Identifier IGS-5100 Assembly Instruction Parts List Warranty Ordering Parts Model IGS-5100 Retain This Manual for Reference 08-15-06 OWNER'S MANUAL ®...

  • Page 2: Table Of Contents

    EXPLODED DIAGRAM…………………………………………………………….. MULTI-PURPOSE BENCH PARTS LIST………………………………………… WARRANTY....................… ORDERING PARTS..................BEFORE YOU BEGIN Thank you for selecting the IRON GRIP STRENGTH IGS-5100 Smith Machine ® by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine.

  • Page 3: Important Safety Notices

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.

  • Page 4: Warning Label Placement

    WARNING LABEL PLACEMENT The warning labels shown here have been placed on the Rear Stabilizer and Upper Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown.

  • Page 5: Smith Machine Hardware Pack

    SMITH MACHINE HARDWARE PACK...
  • Page 6 SMITH MACHINE HARDWARE PACK...
  • Page 7 SMITH MACHINE HARDWARE PACK...
  • Page 8 SMITH MACHINE HARDWARE PACK...

  • Page 9: Smith Machine Assembly Instructions

    SMITH MACHINE ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Do not tighten all nuts and bolts until instructed to do so. B.) Attach one Guide Rod (#12) onto a Base Frame (#1).
  • Page 10 DIAGRAM 1...
  • Page 11 STEP 2 (See Diagram 2) A.) Attach the Rear Vertical Frame Base (#7) to the Cross Brace (#8) from the bottom. Attach the Rear Vertical Frame (#6) onto the Cross Brace on the top. Align the holes and secure them together with two M10 x 2 ¾” Carriage Bolts (#70), Ø ¾” Washers (#86), and M10 Aircraft Nuts (#83).
  • Page 12 STEP 3 (See Diagram 3) A.) Attach the Weight Glide Post (#5) to the bracket on the Rear Vertical Frame Base (#7). Secure it with two M10 x 2” Carriage Bolts (#72), Ø ¾” Washers (#86), and M10 Aircraft Nuts (#83). B.) Slide the Sliding Weight Post (#22) onto the Weight Glide Post from the top.
  • Page 13 DAIGRAM 3...
  • Page 14 STEP 4 (See Diagram 4) A.) Attach the Butterfly Base (#14) to the front of Rear Vertical Frame (#6). Attach the Butterfly Pulley Bracket (#15) to the back of the Rear Vertical Frame. Align the holes and secure them with one M10 x 2 ¾” Carriage Bolt (#72), Ø ¾” Washer (#86), and M10 Aircraft Nut (#83) from the side.
  • Page 15 CABLE LOOP DIAGRAM...
  • Page 16 STEP 5 (See Diagram 5 & Cable Loop Diagram) A.) Attach the 133” Cable (#31) to the front opening on the Upper Frame (#11). Attach a Pulley (#38) to the opening. Secure it with one M10 x 2 1/8” Allen Bolt (#73), two Ø 1” x ¼” Pulley Bushings (#51), and one M10 Aircraft Nut (#83).
  • Page 17 STEP 6 (See Diagram 6 & Cable Loop Diagram) A.) Attach one end of the 78” Butterfly Cable (#32) to the clip on the Right Butterfly (#21). Draw the Cable to the right Butterfly Pulley Bracket (#15). B.) Attach a Pulley (#38) to the right Bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#77), two Ø...
  • Page 18 STEP 7 (See Diagram 7 & Cable Loop Diagram) A.) Insert the tip of the 133” Cable (#31) through the opening on the Foot Plate (#10) to the opening on the bottom of the Rear Vertical Beam (#6). B.) Attach a Pulley (#38) to the opening. Attach the Foot Plate (#10) to the Frame. Align the holes and secure the Foot Plate, Rear Vertical Frame, and the Pulley with one M10 x 2 ½”...
  • Page 19 DIAGRAM 7...
  • Page 20 STEP 8 (See Diagram 8) A.) NOTE: Help of another person is strongly recommended for this step. Place the Lifting Sleeve (#13) in between the two Safety Stop Frames (#26). Align the holes and insert the Weight Bar (#28) all the way through. Center the bar and secure it with two M8 x 3/8” Allen Bolts (#88) on each side.

  • Page 21: Exploded Diagram

    EXPLODED DIAGRAM...

  • Page 22: Smith Machine Parts List

    PARTS LIST KEY NO. DESCRIPTION Q’ty Base Frame Ø 1” x ¼” Pulley Bushing Front Vertical Frame Ø 1” End Cap Left Vertical Frame Ø 1” Cone-shaped End Cap Right Vertical Frame Ø 2” End Cap Weight Glide Post Ø 1 1/8” x 5/8” Bushing Rear Vertical Frame Ø...

  • Page 23: Multi-Purpose Bench Hardware Pack

    MULTI-PURPOSE BENCH HARDWARE PACK...
  • Page 24 MULTI-PURPOSE BENCH HARDWARE PACK...

  • Page 25: Multi-Purpose Bench Assembly Instructions

    MULTI-PURPOSE BENCH ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended this machine be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Front Post (#3) to the Front Stabilizer (#17). B.) Secure it with three M10 x 5/8”...
  • Page 26 STEP 2 (See Diagram 2) A.) Attach the rear of Main Seat Support (#1) to the Rear Stabilizer (#4). Secure it with two M10 x 2 3/8” Carriage Bolts (#47), one 5 1/8” x 2 3/8” Bracket (#21), two Ø ¾” Washers (#39), and two M10 Aircraft Nuts (#50).
  • Page 27 STEP 3 (See Diagram 3) A.) Attach the Leg Developer Holder (#2) to the Main Seat Support (#1). Secure it with one M10 x 5/8” Allen Bolt (#40) and Ø ¾” Washer (#39) from the top, two M10 x 3 ½” Carriage Bolts (#48), two Ø...
  • Page 28 STEP 4 (See Diagram 4) A.) Insert two Ø ½” Bushings (#52) into the holes on the Seat Bracket (#5) and align the holes to the pivot on the Main Seat Support (#1). B.) Attach the two Backrest Supports (#10) to the Seat Bracket and align the holes. Secure them with a M10 x 7 ¼”...
  • Page 29 STEP 5 (See Diagram 5) A.) Place the Seat Pad (#8) onto the Seat Bracket (#5). Secure it with four M8 x 1 5/8” Allen Bolts (#46) and Ø 5/8” Washers (#38). B.) Attach the Backrest Board (#9) to the Backrest Supports (#10). Secure it with four M8 x 1 5/8”...
  • Page 30 STEP 6 (See Diagram 6) A.) Insert two Foam Tubes (#16) halfway through the holes on Leg Developer (#12). B.) Push four Vinyl Foam Rolls (#27) onto the Tubes from both ends. C.) Push four Foam Roll End Caps (#31) into the ends. D.) Attach the Arm Curl Handle (#19) to the back holes on the Leg Developer.

  • Page 32: Multi-Purpose Bench Parts List

    MULTI-PURPOSE BENCH PARTS LIST KEY NO. DESCRIPTION Q’ty Main Seat Support Leg Developer Holder Front Post Rear Stabilizer Seat Bracket Arm Curl Stand Backrest Incline Support Seat Pad Backrest Board Backrest Support Arm Curl Pad Leg Developer Ø 2” Leg Developer Bushing Wheel T-shaped Lock Pin Foam Tube...

  • Page 33: Warranty

    ® IMPEX INC. LIMITED WARRANTY ® IMPEX Inc. ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser.
