OPERATOR'S MANUAL
25cc String Trimmers
Your new trimmer has been engineered and manufactured to Homelite's high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual.
Thank you for buying a Homelite trimmer.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Trimlite model
UT20930
3
2
1
ST ST OP
Trim 'n Edge model
UT20933
3
2
1
ST OP
OP
Easy Reach model
UT20777
