Chapter 3. INTERFACE PINOUTS

3.1

Pinout Overview

The rear panel interface (Figure 3-1) provides all necessary external connections between the
MR-S2 and other equipment.
3.2

DC Power

Figure 3-1. Digicast Media Router S2 Receiver – Rear Panel
Pin
Center
Outer Ring
Definition
+5VDC
GND
3-1
