Field Setting
3.1.7 Centralized Control Group No. Setting
BRC1C Type
1. When in the normal mode, push the
2. Set mode No. "00" with the
3. Push the
4. Set the group No. for each group with the
5. Push the timer
6. Push the
76
If carrying out centralized control by central remote controller or unified ON/OFF controller,
group No. must be set for each group individually by remote controller.
Group No. setting by remote controller for centralized control
enters the "field setting mode."
button to inspect the group No. display.
of 1-00, 1-01, ...,1-15, 2-00,...4-15. However, the unified ON/OFF controller displays only the
group No. within the range selected by the switch for setting each address.)
button to define the selected group No.
button to return to the normal mode.
Even if not using a remote controller, connect the remote controller when setting the group No.,
set the group No. for centralized control, and disconnect after making the setting.
Set the group No. after turning on the power supply for the central remote controller, unified ON/
OFF controller, and indoor unit.
button for 4 seconds or more, and operation then
∗
button.
button (The group No. increases in the manner
SiUS39-601
Test Operation
