Vec013_Manual_060805
6/17/05
6:06 PM
DC to DC Recharge
Recharging the Jump-Starter from an external DC power source requires the use of
the DC/DC adapter. This adapter has a male DC connector at each end.
Unlike the AC recharge method, DC recharge does NOT automatically activate the
"battery status" display and provide a taper charge. Battery status can still be
monitored by pressing the battery status level pushbutton.
W W W W A A A A R R R R N N N N I I I I N N N N G G G G S S S S
• • • • D D D D O O O O N N N N O O O O T T T T D D D D C C C C c c c c h h h h a a a a r r r r g g g g e e e e f f f f o o o o r r r r m m m m o o o o r r r r e e e e t t t t h h h h a a a a n n n n 3 3 3 3 - - - - 4 4 4 4 h h h h o o o o u u u u r r r r s s s s m m m m a a a a x x x x i i i i m m m m u u u u m m m m . . . .
• • • • D D D D O O O O N N N N O O O O T T T T l l l l e e e e a a a a v v v v e e e e u u u u n n n n a a a a t t t t t t t t e e e e n n n n d d d d e e e e d d d d w w w w h h h h i i i i l l l l e e e e D D D D C C C C c c c c h h h h a a a a r r r r g g g g i i i i n n n n g g g g . . . .
12 Volt DC Charging
1. Insert the gold-tipped DC/DC charging adapter plug into the vehicle's 12 volt
DC accessory outlet.
2. Insert the silver-tipped end plug into the 12 volt DC accessory outlet on the front
panel of the unit.
3. Charge the unit until the green FULL indicator lights when the battery status level
pushbutton is pressed. DO NOT EXCEED 3-4 HOURS MAXIMUM.
4. When charging is completed, remove the charging cord and store in a safe place.
Note:
Make sure ON/OFF Safety Switch and Area Light are Turned OFF During
Recharge As This May Slow Recharge
Replacement Parts
For replacement parts (bulbs, batteries, charging adapters, etc.), contact Vector
Technical Support: toll free (866) 584-5504. There are no user serviceable parts
inside the unit. Periodically, the cables and connectors should be inspected for
damage, corrosion, dust, and dirt. If surfaces are dirty, they can be wiped clean
with a cloth moistened with water and a drop of detergent. Contacts can be wiped
clean with a dry cloth.
W W W W A A A A R R R R N N N N I I I I N N N N G G G G
Do not operate unit if there is any evidence of damage. The product
must be returned to Vector for testing and repair. Replace any
damaged charging adapters immediately before further use.
Battery Disposal
Contains a maintenance-free, sealed, non-spillable, lead acid
battery, which must be disposed of properly. Recycling is
required — contact your local authority for information. Failure
to comply with local, state and federal regulations can result in
fines or imprisonment. For more information on recycling this
battery, call toll-free (800) 822-8837.
C C C C A A A A U U U U T T T T I I I I O O O O N N N N
This plug uses an 8 amp fuse. For continued protection against risk of
fire, replace fuse only with same type and rating.
Page 6
6
W W W W A A A A R R R R N N N N I I I I N N N N G G G G S S S S
Do not dispose of the battery in fire, as this may result in an explosion.
Before disposing of the battery, protect exposed terminals with
heavy-duty electrical tape to prevent shorting (shorting can result in
injury or fire).
Do not expose battery to fire or intense heat, as it may explode.
TROUBLESHOOTING
Unit Fails to Jump-Start
• Make sure unit's power switch is in the ON position.
• Check that Jump-Starter has a full charge.
• Make sure a proper polarity cable connection has been established (see "Using
the Unit as a Jump-Starter," page 4).
12 Volt Outlet Fails to Deliver Power
• Make sure a proper 12 volt adapter connection has been established.
• Check that Jump-Starter has a full charge.
12 Volt Outlet Shuts Off
Disconnect unit and allow to cool for 10 minutes.
Note:
When pulling more than 5 amps from the 12 volt outlet, unit will shut off.
LED Area Light Does Not Come On
• Check that Jump-Starter has a full charge.
SPECIFICATIONS
Jump-Start Clamps:
400 amps – heavy-duty copper
Jumper Cables:
#6AWG welding cable
Battery Type:
12 volt, 17 Ah sealed, rechargeable, non-spillable lead
acid
LED Area Light:
Long-life white LEDs
DC Charging Adapter: 12 volt DC
AC Charting Adapter:
120 volt AC (700mA, 12 volt DC output)
12 Volt Outlet Output:
Overload protection
7
