VEC021STC
®
JUMP-STARTER, AIR COMPRESSOR
AND 12 VOLT DC POWER SUPPLY
Portable • Cordless • Rechargeable
OWNER'S MANUAL
& WARRANTY INFORMATION
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION,
MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USING, READ AND UNDERSTAND
ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR VEHICLE'S
BATTERY MANUFACTURER GUIDELINES. FAILURE TO DO SO COULD RESULT IN INJURY AND/
OR PROPERTY DAMAGE.
4140 SW 28TH WAY, FT. LAUDERDALE, FL 33312
TEL: 954-584-4446 • TOLL FREE: 866-584-5504 • FAX: 954-584-5556
www.vectormfg.com
1

Advertisement

Table of Contents
loading

Related Manuals for Vector Power on Board VEC021STC

Summary of Contents for Vector Power on Board VEC021STC

  • Page 1 VEC021STC ® JUMP-STARTER, AIR COMPRESSOR AND 12 VOLT DC POWER SUPPLY Portable • Cordless • Rechargeable OWNER’S MANUAL & WARRANTY INFORMATION THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USING, READ AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR VEHICLE’S BATTERY MANUFACTURER GUIDELINES.
  • Page 2 NOTE: This unit is shipped in a partially charged state, charge for 24 hours using AC method. SAFETY INFORMATION WARNING: (Warning statements identify conditions or practices that may result in personal injury or loss of life) When working with lead acid batteries, always make sure immediate assistance is available in case of accident or emergency.
  • Page 3 10) Check unit periodically for wear and tear. Replace worn or defective parts immediately. Contact Vector Customer Service department toll-free 866-584-5504. 11) Do not attempt to jump-start a frozen battery. 12) Never submerge this unit in water.

  • Page 4: Table Of Contents

    CONTENTS 1. INTRODUCTION ... 5 2. USING POWER ON BOARD™ AS A JUMP-START SYSTEM ... 5,6 2.1 Easy, Step-by-Step Jump-starting Instructions ... 7,8 3. CHARGING/RECHARGING ... 9 3.1 110/120 Volt AC Charging ... 9 3.2 12 Volt DC Charging ... 10 3.3 Estimated Battery Life ...

  • Page 5: Introduction

    It can also be used as a safe, portable source of 12 Volt DC electric power in remote locations and/or emergency situations. It is ideal for use with Vector 12 Volt DC cordless, portable, rechargeable products and POWER ON BOARD®...
  • Page 6 FIGURE 1A (FRONT VIEW) Reverse connection indicator Good connection indicator 12 Volt DC Accessory Socket with 20 amp overload protection Battery Level Push Button LED Charging/Battery Level Indicators Heavy-Duty Welding Quality Jumper Cables Heavy-Duty 350 Amp Copper Clamps Exclusive Quick-Release Clamp Holsters 120 Volt UL approved AC/DC Charging Adapter 10.

  • Page 7: Using Power On Board™ As A Jump-Start System

    Check unit periodically for wear and tear. Replace worn or defective parts immediately contact Vector Customer Service Department toll-free: (866) 584-5504 or through our Internet address: www.vectormfg.com. Do not attempt to jump-start a frozen battery.

  • Page 8: Easy, Step-By-Step Jump-Starting Instructions

    EASY, STEP-BY-STEP JUMP-STARTING INSTRUCTIONS Turn OFF vehicle ignition and all accessories (radio, A/C, lights, cell phone, etc.). Place vehicle in park and set the emergency brake. Remove booster clamps from protective holster (Figure 2): simply squeeze the handles and pull down on the clamp. Procedure for jump-starting a NEGATIVE GROUNDED SYSTEM (NEGATIVE BATTERY TERMINAL IS CONNECTED TO CHASSIS).

  • Page 9: Charging/Recharging

    FIRST AID: • SKIN: If battery acid comes in contact with skin, rinse immediately with water, then wash thoroughly with soap and water. If redness, pain, or irritation occurs, seek immediate medical attention • EYES: If battery acid comes in contact with eyes, flush eyes immediately for a minimum of 15 minutes and SEEK IMMEDIATE MEDICAL ATTENTION CHARGING/RECHARGING For maximum battery life, we recommend the POWER ON BOARD®...

  • Page 10: 12 Volt Dc Charging

    12 VOLT DC CHARGING Insert one end of the DC/DC charging adapter into the 12 Volt DC accessory receptacle on the vehicle or boat. Insert the plug at the other end of this charging adapter into the 12 Volt DC accessory socket receptacle on the front panel of the unit.

  • Page 11: Compressor/Tire Inflator

    AIR COMPRESSOR/TIRE INFLATOR IMPORTANT: Read Instructions Carefully To Avoid Possible Injury Or Property Damage. The built-in 12 Volt DC air compressor is the ultimate compressor for all vehicles, trailer tires and recreational inflatables. Three different sized nozzles are supplied. Each nozzle will clip on the end of the standard tire valve connector located at the free end of the compressor hose.

  • Page 12: Inflate Other Articles (W/Out Valve Stem)

    235/85R 16” ICYCLE TIRES 27” X 1” (racing) Football Basketball Volleyball REPLACEMENT PARTS For replacement parts (bulbs, batteries, fuses, etc.), contact Vector Customer Service: (954) 584-4446 or toll-free (866) 584-5504. NFLATION PRESSURE ILLING TIME 2.5 min 4.5 min 6.5 min 16 min 40 sec.

  • Page 13: Battery Disposal

    5. Snap the lens cover back into place. 6. Replace (clockwise) the screws and carefully tighten. Do not over tighten! BATTERY REPLACEMENT It is recommended that the unit be returned to Vector Customer Service for batter y replacement: Contact (954) 584-4446 or toll-free (866) 584-5504.

  • Page 14: Warranty

    Vector Manufacturing. Any defective product, other than accessories, that is returned to Vector Manufacturing within 30 days of the date of purchase will be replaced free of charge. If such a product is returned more than 30 days but less than two years from the purchase date, Vector Manufacturing will repair the unit or, at its option, replace it free of charge.
  • Page 16 ® © 2003 VECTOR MANUFACTURING, Ltd. • FT. LAUDERDALE, FL 33312 MADE IN CHINA REV.DK051903...
