Icom IC-910H Service Manual page 64

6-2 UX-910
[MAIN UNIT]
REF ORDER
NO. NO.
IC21 1150002020 IC
IC31 1110001220 S.IC
IC111 1110004080 S.IC
IC131 1110005150 S.IC
IC141 1110001890 S.IC
IC161 1180002040 REG
IC162 1180001070 S.IC
IC181 1110004080 S.IC
IC201 1110004080 S.IC
IC241 1110004470 S.IC
IC301 1130007570 S.IC
IC311 1130006800 S.IC
IC501 1130009370 S.IC
IC502 1130009580 S.IC
IC601 1130004830 S.IC
IC610 1130007260 S.IC
IC621 1130004830 S.IC
IC661 1140007880 S.IC
IC701 1110001900 S.IC
IC761 1110004460 S.IC
IC762 1130003830 S.IC
Q36 1560001090 S.FET
Q38 1560001140 S.FET
Q71 1540000470 S.TRANSISTOR
Q72 1590000430 S.TRANSISTOR
Q73 1530001950 S.TRANSISTOR
Q74 1530001950 S.TRANSISTOR
Q81 1530001950 S.TRANSISTOR
Q161 1590000430 S.TRANSISTOR
Q162 1590000430 S.TRANSISTOR
Q163 1510000500 S.TRANSISTOR
Q164 1590000430 S.TRANSISTOR
Q165 1590001980 S.TRANSISTOR
Q166 1520000510 TRANSISTOR
Q167 1590000720 S.TRANSISTOR
Q168 1530001950 S.TRANSISTOR
Q169 1590001980 S.TRANSISTOR
Q170 1520000460 S.TRANSISTOR
Q171 1590002030 S.TRANSISTOR
Q172 1590002030 S.TRANSISTOR
Q221 1580000680 S.FET
Q271 1530003660 S.TRANSISTER
Q281 1590002940 S.FET
Q282 1530001950 S.TRANSISTOR
Q283 1590000430 S.TRANSISTOR
Q301 1590001810 S.TRANSISTOR
Q501 1590000720 S.TRANSISTOR
Q502 1590001050 S.TRANSISTOR
Q503 1590001870 S.TRANSISTOR
Q511 1560000540 S.FET
Q512 1530002690 S.TRANSISTOR
Q531 1540000350 S.TRANSISTOR
Q541 1530003760 S.TRANSISTOR
Q542 1530003550 S.TRANSISTOR
Q551 1530003310 S.TRANSISTOR
Q601 1530002600 S.TRANSISTOR
Q681 1530003310 S.TRANSISTOR
Q701 1510000670 S.TRANSISTOR
Q731 1530003310 S.TRANSISTOR
Q741 1530003310 S.TRANSISTOR
Q751 1540000350 S.TRANSISTOR
Q761 1530003310 S.TRANSISTOR
Q771 1590000660 S.TRANSISTOR
Q772 1590000720 S.TRANSISTOR
D9 1750000580 S.DIODE
D13 1750000580 S.DIODE
D32 1750000520 S.DIODE
D51 1750000550 S.DIODE
D81 1790000620 S.DIODE
D82 1750000430 S.DIODE
D83 1750000580 S.DIODE
D130 1730002260 S.ZENER
D161 1790000620 S.DIODE
D162 1790000620 S.DIODE
D163 1790000620 S.DIODE
D164 1790000620 S.DIODE
DESCRIPTION
M57762-02
BA4558F T1
µPC2709T-E3
µPC8163TB-E3
µPC1678G-E2
BA09T
TA7805F (TE16L)
µPC2709T-E3
µPC2709T-E3
µPC2721GV-E1
BU4094BCFV-E2
TC7W08F (TE12L)
TB31242FN (EL)
TC7W66FU (TE12L)
TC7SU04F (TE85R)
TC7W74FU (TE12L)
TC7SU04F (TE85R)
TC190G08AF-0046-Z/SC-1246A
µPC4570G2-T1
µPB1509GV-E1
TC7S04F (TE85R)
2SK2854
2SK2855 (TE12L)
2SD1801S-TL
DTC144EUA T106
2SC2712-GR (TE85R)
2SC2712-GR (TE85R)
2SC2712-GR (TE85R)
DTC144EUA T106
DTC144EUA T106
2SA1162-GR (TE85R)
DTC144EUA T106
XP4315 (TX)
2SB1133 R
DTA144EUA T106
2SC2712-GR (TE85R)
XP4315 (TX)
2SB1132 T100 R
RN2425 (TE85R)
RN2425 (TE85R)
3SK241-R (TX)
2SC5454-T1 R54
NE34018-T1
2SC2712-GR (TE85R)
DTC144EUA T106
XP1113 (TX)
DTA144EUA T106
DTC114TUA T106
DTA114EE TL
2SK880-Y (TE85R)
2SC4116-GR (TE85R)
2SD2216-S (TX)
2SC5508-T2
2SC5193-T1
2SC5107-O (TE85R)
2SC4215-O (TE85R)
2SC5107-O (TE85R)
2SA1588-GR (TE85R)
2SC5107-O (TE85R)
2SC5107-O (TE85R)
2SD2216-S (TX)
2SC5107-O (TE85R)
DTC144TU T107
DTA144EUA T106
1SV307 (TPH3)
1SV307 (TPH3)
DAN222TL
1SS355 TE-17
MA77 (TX)
HSB88WSTR
1SV307 (TPH3)
MA8030-H (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
[MAIN UNIT] — UX-910
REF ORDER
NO. NO.
D165 1750000520 S.DIODE
D166 1750000550 S.DIODE
D167 1750000520 S.DIODE
D168 1790001250 S.DIODE
D169 1790001250 S.DIODE
D241 1750000580 S.DIODE
D281 1730002260 S.ZENER
D502 1720000360 S.DIODE
D503 1720000360 S.DIODE
D504 1790001610 S.DIODE
D531 1730002300 S.ZENER
D541 1720000470 S.VARICAP
D711 1720000260 S.VARICAP
D712 1720000260 S.VARICAP
D751 1730002300 S.ZENER
D771 1750000520 S.DIODE
FI1 2040001660 S.FILTER
FI101 2040001650 S.SAW
FI141 2040001660 S.FILTER
FI241 2040001650 S.SAW
FI271 2040001660 S.FILTER
FI281 2040001660 S.FILTER
L2 6200005660 S.COIL
L5 6200007740 S.COIL
L11 6200008180 S.COIL
L12 6200007740 S.COIL
L22 6200006990 S.COIL
L23 6200006990 S.COIL
L31 6200007670 S.COIL
L32 6200008280 S.COIL
L51 6200006990 S.COIL
L52 6200006990 S.COIL
L53 6200006990 S.COIL
L63 6200008910 S.COIL
L71 6200007730 S.COIL
L81 6200005010 S.COIL
L82 6200003270 S.COIL
L83 6200002610 S.COIL
L84 6140002550 S.COIL
L85 6140002550 S.COIL
L86 6200005010 S.COIL
L101 6200006990 S.COIL
L102 6200006990 S.COIL
L111 6200001980 S.COIL
L112 6200001980 S.COIL
L121 6200005710 S.COIL
L122 6200005700 S.COIL
L133 6200006990 S.COIL
L134 6200006990 S.COIL
L135 6200005630 S.COIL
L141 6200005620 S.COIL
L142 6200005630 S.COIL
L143 6200006990 S.COIL
L144 6200006990 S.COIL
L161 6200001980 S.COIL
L181 6200005640 S.COIL
L182 6200005630 S.COIL
L183 6200001980 S.COIL
L184 6200001980 S.COIL
L201 6200005730 S.COIL
L202 6200005730 S.COIL
L203 6200001980 S.COIL
L204 6200002630 S.COIL
L211 6200005660 S.COIL
L221 6200002840 S.COIL
L222 6200003280 S.COIL
L224 6200005010 S.COIL
L241 6200006990 S.COIL
L242 6200006990 S.COIL
L243 6200001980 S.COIL
L244 6200006990 S.COIL
L273 6200006990 S.COIL
L274 6200005590 S.COIL
L275 6200006040 S.COIL
L281 6200006990 S.COIL
L283 6200006040 S.COIL
6 - 25
DESCRIPTION
DAN222TL
1SS355 TE-17
DAN222TL
MA2S111-(TX)
MA2S111-(TX)
1SV307 (TPH3)
MA8030-H (TX)
HSU88TRF
HSU88TRF
1SS385 (TE85L)
MA8082-M (TX)
1SV239 (TPH3)
1SV214 (TPH2)
1SV214 (TPH2)
MA8082-M (TX)
DAN222TL
LFSN30N18C1280B
WF447B-T
LFSN30N18C1280B
WF447B-T
LFSN30N18C1280B
LFSN30N18C1280B
ELJRE 10NG-F
LQN21A 47NJ04
0.25-1.9-10TL 107N
LQN21A 47NJ04
ELJRE 56NG-F
ELJRE 56NG-F
LQN21A 10NJ04
0.30-1.7-7TL 50N
ELJRE 56NG-F
ELJRE 56NG-F
ELJRE 56NG-F
1812CS-122XKBC
LQN21A 39NJ04
NL 252018T-100J
NL 252018T-R56J
NL 252018T-R47J
B4F-617DB-1010=P3
B4F-617DB-1010=P3
NL 252018T-100J
ELJRE 56NG-F
ELJRE 56NG-F
NL 252018T-1R0J
NL 252018T-1R0J
ELJRE 27NG-F
ELJRE 22NG-F
ELJRE 56NG-F
ELJRE 56NG-F
ELJRE 5N6Z-F
ELJRE 4N7Z-F
ELJRE 5N6Z-F
ELJRE 56NG-F
ELJRE 56NG-F
NL 252018T-1R0J
ELJRE 6N8Z-F
ELJRE 5N6Z-F
NL 252018T-1R0J
NL 252018T-1R0J
ELJRE 39NG-F
ELJRE 39NG-F
NL 252018T-1R0J
NL 252018T-R10J
ELJRE 10NG-F
NL 252018T-R22J
NL 252018T-2R2J
NL 252018T-100J
ELJRE 56NG-F
ELJRE 56NG-F
NL 252018T-1R0J
ELJRE 56NG-F
ELJRE 56NG-F
ELJRE 2N7Z-F
LQP11A 5N6C00
ELJRE 56NG-F
LQP11A 5N6C00
S.=Surface mount
