Ryobi P200 Operator's Manual

Ryobi P200 Operator's Manual

18 volt drill-driver 2-speed
Hide thumbs Also See for P200:
Table of Contents

Advertisement

Quick Links

Download this manual
ACCEPTS ALL ONE+
BATTERY PACKS
BATTERiES ANd CHARGERS
SOLd SEPARATELY
Your drill-driver has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNiNG:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAvE THiS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
18 vOLT dRiLL-dRivER
2-SPEEd
P200

Advertisement

Table of Contents
loading

Related Manuals for Ryobi P200

Summary of Contents for Ryobi P200

  • Page 1 OPERATOR’S MANUAL 18 vOLT dRiLL-dRivER 2-SPEEd P200 ACCEPTS ALL ONE+ BATTERY PACKS BATTERiES ANd CHARGERS SOLd SEPARATELY Your drill-driver has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THiS WARRANTY COvERS: This warranty covers all defects in workmanship or materials in your RYOBI power ®...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES  Remove adjusting keys or wrenches before turning WARNiNG! the tool on. A wrench or a key that is left attached to a rotating part of the tool may result in personal injury. REAd ANd UNdERSTANd ALL iNSTRUCTiONS. Fail-  do not overreach.

  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES SERviCE  Use only accessories that are recommended by the manufacturer for your model. Accessories that may be  Tool service must be performed only by qualified suitable for one tool may create a risk of injury when used repair personnel.

  • Page 5: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper inter- pretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME dESiGNATiON/EXPLANATiON Volts Voltage Amperes Current Hertz...

  • Page 6: Symbols

    SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SiGNAL MEANiNG dANGER: Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNiNG: Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury.

  • Page 7: Features

    FEATURES PROdUCT SPECiFiCATiONS Motor ..................................18 Volt DC Switch ................................Variable Speed No Load Speed ..........................0-350/0-1300 r/min. (RPM) Torque ..................................400 in.lb. level two sPeed gear train (hi-lo) torque adjustment ring storage area Keyless ChuCK direCtion oF rotation seleCtor and Center loCK switCh trigger mag tray™...
  • Page 8 FEATURES FORWARd/REvERSE SELECTOR KNOW YOUR dRiLL-dRivER See Figure 1. (diRECTiON OF ROTATiON SELECTOR) Before attempting to use this product, familiarize yourself The drill-driver has a forward/reverse selector located above with all operating features and safety rules. the switch trigger. KEYLESS CHUCK BiT STORAGE The drill-driver has a keyless chuck that allows you to hand When not in use, bits provided with the drill-driver can be...

  • Page 9: Assembly

    Failure to do so could re- sult in objects being thrown into your eyes, resulting in This product will accept Ryobi One+ 18 V lithium-ion possible serious injury. battery packs and Ryobi One+ 18 V nickel-cadmium battery packs.
  • Page 10 OPERATiON TO iNSTALL BATTERY PACK See Figure 2.  Place the direction of rotation selector in center position.  Place the battery pack in your drill. Align raised rib on battery pack with groove in drill’s battery port.  Make sure the latches on each side of the battery pack snap in place and that battery pack is secured in drill before beginning operation.

  • Page 11: Installing Bits

    OPERATiON iNSTALLiNG BiTS See Figures 3 - 4. drill Bit ChuCK Body  Place the direction of rotation selector in center position. This will lock the switch trigger in the off position.  Open or close the chuck jaws to a point where the open- ing is slightly larger than the bit size you intend to use.
  • Page 12 OPERATiON WARNiNG: release (unloCK) Battery tools are always in operating condition. There- fore, switch should always be locked when not in use or ChuCK Collar carrying at your side. KEYLESS CHUCK See Figure 5. A keyless chuck has been provided with your drill to allow for easy installation and removal of bits.
  • Page 13 OPERATiON MAG TRAY™ See Figure 8. For your convenience, the drill has a Mag Tray™ to place small parts when doing a variety of tasks. BiT STORAGE See Figure 9. When not in use, bits provided with the drill can be placed in the storage area located on the top of the drill.
  • Page 14 OPERATiON SCREWdRiviNG TORQUE AdJUSTMENT (dRiviNG POWER OF THE dRiLL-dRivER) to deCrease See Figure 11. torque When using the drill-driver for various driving applications, it becomes necessary to increase or decrease the torque in order to help prevent the possibility of damaging screw heads, threads, workpiece, etc.

  • Page 15: Operation

    OPERATiON dRiLLiNG See Figure 12. level When drilling hard, smooth surfaces, use a center punch to mark the desired hole location. This will prevent the drill bit from slipping off center as the hole is started. However, the lower speed feature allows starting holes without center punching if desired.

  • Page 16: Maintenance

    MAiNTENANCE CHUCK REMOvAL WARNiNG: See Figures 13 - 15. When servicing, use only identical replacement parts.  Lock the switch trigger by placing the direction of rotation Use of any other parts may create a hazard or cause selector in center position. product damage.
  • Page 17 MAiNTENANCE TO RETiGHTEN A LOOSE CHUCK The chuck may become loose on spindle and develop a wobble. To tighten:  Lock the switch trigger by placing the direction of rotation selector in center position.  Open the chuck jaws.  Insert hex key into chuck and tighten chuck jaws securely. Tap hex key sharply with a mallet in a clockwise direction.

  • Page 18: Batteries

    MAiNTENANCE GENERAL MAiNTENANCE WARNiNG: Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of When servicing, use only identical replacement parts. commercial solvents and may be damaged by their use. Use Use of any other parts may create a hazard or cause clean cloths to remove dirt, dust, oil, grease, etc.
  • Page 19 NOTES...
  • Page 20 When ordering repair parts, always give the following information: P00 • MODEL NUMBER • SERIAL NUMBER Ryobi is a registered trademark of Ryobi Limited used under license. ® ONE WORLd TECHNOLOGiES, iNC. 148 Pearman Dairy Road, Anderson, SC 965 Phone 1-800-55-579 www.ryobitools.com...
