JBL MSC1 Technical Manual

Technical Manual
JBL MSC1

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Frequency Range:
• Power Requirements:
• S/N, Dynamic Range:
• THD+N:
• A/D DA Converters:
• Internal Processing:
• Maximum Input Level:
• Maximum Output Before
Clipping:
• Dimensions:
W x D x H
PACKAGE
Warranty
59660
Gift Box
444593-001
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
20 Hz - 20 kHz (+/-0.3 dB)
12 VDC, 0.5A
106 dB typical, A-weighted
20 Hz - 20 kHz
<0.04% A/D/A, 20 Hz - 20 kHz
24 Bit
24 Bit, 48 kHz
+24 dBu (1/4" TRS Inputs);
+4 dBu (RCA Inputs)
+12.5 dBu
198 x 165 x 83 mm
(7.8 x 6.5 x 3.25 in)
Inner Box
444594-001
Filler, Top Pad
444609-001
Filler
Controller Left
444607-001
SUBWOOFER SETTINGS:
• Level:
• Selectable Crossover
Frequencies:
• Polarity:
Owners Manual
444307-001
CD, MSC1
444611-001
Filler
Accessories
444610-001
Filler
Controller Right
444608-001
+/- 10 dB from nominal in
5.8 dB increments
60 Hz, 80 Hz, 120 Hz
0 degrees / 180 degrees
Accessories Kit
444634-001
Includes:
Microphone
444635-001
Microphone Clip
444638-001
TRS, (2)
444637-001
1/8" to 1/4"
USB Cable
444636-001
RCA Jacks
444639-001
1/8"
TRS,Cable
444640-001
1/8" to 1/8"
Power Supply:
MSC1-US
444489-001
MSC1-AU
444492-001
MSC1-EU
444490-001
MSC1-UK
444491-001
11-09
