Char-Broil 4101424 Assembly & Use Instructions

Turkey/fish fry set
Hide thumbs

Advertisement

Quick Links

Download this manual
Turkey/Fish Fry Set
Assembly, Use and Care
04101424
Tools required:
Phillips screwdriver • Adjustable wrench
To installer or person assembling this appliance: Leave this manual with
this appliance for future reference.
This instruction manual contains important information necessary for
the proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and
using the appliance.
Follow all warnings and instructions when using the appliance.
Keep this manual for future reference.
Turkey/Fish Fry Set / 42804051 / (08-19-04)
For Outdoor Use Only

Advertisement

loading

Related Manuals for Char-Broil 4101424

Summary of Contents for Char-Broil 4101424

  • Page 1 For Outdoor Use Only Turkey/Fish Fry Set Assembly, Use and Care 04101424 Tools required: Phillips screwdriver • Adjustable wrench To installer or person assembling this appliance: Leave this manual with this appliance for future reference. This instruction manual contains important information necessary for the proper assembly and safe use of the appliance.
  • Page 2 DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your Fire Department. Failure to follow these instructions could result in fire or explosion which could cause property damage, personal injury or death.
  • Page 3 WARNING Combustion by-products produced when using this product contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Safety Symbols The symbols and boxes shown below explain what each heading means. Read and follow all of the messages found throughout the manual.
  • Page 4 WARNING 1. Never leave the appliance unattended. Keep children and pets away from the appliance at all times. 2. The use of alcohol, prescription or non-prescription drugs may impair the consumer’s ability to properly assemble or safely operate the appliance. 3.
  • Page 5 WARNING Installation Safety Precautions • Use appliance only with LP (propane) gas and the regulator/valve assembly supplied. • Installation must conform with local codes, or in their absence with National Fuel Gas Code, NFPA 54/ANSI Z223.1. Handling and storage of LP cylinders must conform to LP Gas Code NFPA/ANSI 58.
  • Page 6 WARNING • Never use a cooking vessel larger than 30 qts. and taller than 15½ inches. • Never fill pot above upper fill line. Oil can splatter causing staining or discoloration to ground surface. • Never leave the appliance unattended. Keep children and pets away from the appliance at all times.
  • Page 7 DANGER • The safety relief valve on the LP tank could activate releasing gas and cause an intense fire with risk of death or serious injury. Therefore, follow instructions bulleted below exactly. • NEVER store a spare LP tank under or near appliance or in enclosed areas. •...
  • Page 8 LP tank valve must have: • Type 1 outlet compatible with regulator or appliance. • Safety relief valve. • UL listed Overfill Protection Device (OPD). This OPD safety feature is identified by a unique triangular hand wheel. Use only tanks equipped with this type of valve. OPD Hand Wheel LP tank must be arranged for vapor withdrawal and include collar to protect LP tank valve.
  • Page 9 LP Tank Leak Test For your safety • Leak test must be repeated each time LP tank is exchanged or refilled. • Do not smoke during leak test. • Do not use an open flame to check for gas leaks. •...
  • Page 10 5. Hold regulator, insert nipple (B) into LP tank valve. Hand tighten coupling nut, holding regulator in a straight line (C) with LP tank valve so as not to cross thread the connection. Nipple must be centered into the LP tank valve. Hold coupling nut and regulator as shown for proper connection to LP tank valve.
  • Page 11 WARNING • Do not use appliance until leak checked. • If leak is detected at any time, STOP • If you cannot stop a gas leak, immediately close LP tank valve, leave area of appliance, and call LP gas supplier or your fire department! Leak Testing Valves, Hoses and Regulator 1.
  • Page 12 Lighting Instructions Do not lean over LP cooker while lighting. 1. Turn regulator control valve to OFF position. 2. Fully open LP tank valve. 3. Slowly turn ON the regulator control valve. Push transmitter button or button on receiver. If ignition does not occur, light a match and place it over burner.
  • Page 13 Hose Check •Before each use, check to see if hoses are cut or worn. Replace damaged hose assembly before using appliance. Use only valve/hose/regulator specified by manufacturer. Cleaning the Burner WARNING Spiders’ nests or wasps’ mud inside the burner may cause fire at the air damper. If a fire occurs, immediately turn off gas supply at LP tank valve.
  • Page 14 Cleaning and Maintenance • Keep appliance area clear and free from materials that burn. • Do not block holes in bottom or sides of appliance. • Check burner flames regularly. • Use appliance only in well-ventilated space. NEVER use in enclosed space such as carport, garage, porch, covered patio, or under ANY overhead construction.
  • Page 15 Assembly Instructions Burner 1. Insert the burner into the cooker stand and through the cut-out opening in the side of the stand. 2. Insert the threaded pin on the bottom of the burner into the center hole in the burner bracket. Make sure the alignment pin is seated in the Alignment notch on the edge of the burner bracket.
  • Page 16 5. Thread wire hook through hole on side of regulator. 6. When transporting or storing LP cooker without tank attached, hook regulator onto burner or cooker stand to prevent damage to regulator. MODULE BATTERY INSTALLATION. Front of module. (Batteries not included.) 7.
  • Page 17 CAUTION A jumper wire is attached to receiver terminals to prevent shock during battery installation and receiver attachment to stand. Do not remove jumper wire until step 11 is completed. 9. Place module on flat Make sure rubber gasket remains in place. (2 AAA) surface and remove front cover.
  • Page 18 11. Attach ignitor module to ignitor panel using two Ignition Module Ignitor #8x1/2” self-tap screws. Ignitor Button must be panel CAREFULLY pulled through hole in Ignitor panel before fully tightening the screws. Remove and discard jumper wire on terminals. Keep discarded wire away from small children. Ignitor Button 12.
  • Page 19 TRANSMITTER BATTERY INSTALLATION (Batteries not included). Use a small screwdriver or paperclip to open battery door. (2 AAA) Using Your Thermometer Check the thermometer before each use inserting into a pot of boiling water and ensuring that it registers approximately 212°F +/–...
  • Page 20 WARNING nside this area remote ignitor may inadvertently be started by T.V. Remotes, garage door openers, remote controlled toys, remote car alarms, etc. Keep children and pets away from the appliance at all times. Receiver Box 3" 7’...
  • Page 21 The following safety measures are recommended when using your fry set. LOCATION MATTERS Select a safe place to fry your turkey. It should be in an open area, outside, and on a cement or brick surface. Place the liquid propane gas tank and fryer so that any wind blows the heat of the fryer away from the gas tank.
  • Page 22 Determining the maximum fill level when using a pot without a maximum fill line: • Place the turkey (or other food product) on the lifter. • Place the turkey and lifter into the empty pot. • Fill the pot with water just until the turkey is completely submerged.
  • Page 23 • Completely pat dry the inside and outside surfaces of the turkey. This is very important as it reduces the splattering of oil. After patting the bird dry, add herb rubs or seasonings to the skin. FRY WITH CARE • Check your hose at both ends for proper connection.
  • Page 24 • Light the burner unit and heat the oil to 325° F. Never leave the fryer unattended at any time • Check the oil using a deep fry temperature gauge. If it has reached 325° F, you are ready to start deep frying.

  • Page 25: Limited Warranty

    • Remove the turkey from the oil and place it on paper towels in an aluminum pan. • Using a meat thermometer, check for an internal meat temperature of 180° F. • Remove turkey fry accessory and allow the turkey to “rest” for 15 minutes to allow the juices to settle into the turkey.
  • Page 28 Troubleshooting • Electronic Ignition System Solution Problem Possible Cause • If electrode sparks, troubleshoot No spark • Push button on receiver. transmitter. If electrode does not spark, using troubleshoot receiver. transmitter. • Reposition transmitter. • Transmitter out of range. • Check for obstructions between •...

  • Page 29: Parts List

    55700577 ELECTRONIC RECEIVER/IGNITION KIT 55700578 ELECTRODE KIT 55700579 ELECTRONIC RECEIVER MOUNTING KIT 55700580 ELECTRONIC RECEIVER HEAT SHIELD KIT 40011308 OUTER CARTON, 04101424 55700403 30 QT ANODIZED POT W/POUR SPOUT AND 12” GLASS LID 33200089 COOKER STAND 3/8” WIRE 41201241 STAINLESS STEEL TURKEY FRY T-STAR...
  • Page 31 Should you encounter any problem CALL US FIRST. Do not return this product to the store. WE CAN HELP. 24 Hours a Day, 7 Days a Week 1-800-232-3398 To insure your satisfaction and for follow-up service, register your product online at: www.grillregistration.com Tools required for assembly: Phillips screwdriver •...
