dbx iEQ 15 Specifications

iEQ 15
Dual 15-Band Digital Graphic Equalizer/Limiter with TYPE V™ NR and AFS™
TM
With an EQ heritage that has produced countless industry standard patents and dates
back more than 30 years, the dbx iEQ-31 easily lives up to the dbx legacy of uncom-
promised sonic integrity. In addition to unsurpassed equalization specs, the iEQ-15 also
offers the built-in necessities which include AFS™ feedback Suppression, Type V™ noise
reduction and PeakStopPlus
octave equalization, the iEQ-15 also offers +12 dB input gain range; switchable +6 or +15
dB boost/cut range, 40mm faders, XLR, 1/4'' and Euroblock inputs and outputs, noncon-
ductive nylon sliders; and an intuitive user interface with comprehensive output and gain
reduction metering. As always, the inevitable result of our meticulous attention to detail
and top-quality componentry is exceptional sound, performance, and reliability.
The iEQ series represents a major step forward in the performance of EQs. The iEQ series
is now able to offer state-of-the-art digital EQ performance and specs with an analog look
and feel. From its amazing 10Hz to 22kHz frequency response, to its 113dB dynamic range
and Advanced Feedback Suppression (AFS™), dbx proprietary Type V™ noise reduction
and PeakStopPlus ® limiting, the iEQ-15 offers out of this world specifications with a down-
to-earth price point. Sure to find a home in the studio, on tour and with installed sound
venues, the iEQ-15 is destined to take its rightful place in the lineage of great dbx
processors that are the professional's choice in signal processing. With such pristine design
and quality, the iEQ-15 offers the maximum sonic flexibility in a straight forward interface
and rock-solid construction. For more information please visit us at: www.dbxpro.com.
• Advanced Feedback
Suppression (AFS™)
• Type V™ Noise Reduction
• PeakStopPlus
• 2/3-octave Constant Q
frequency bands
• Switchable boost/cut ranges
of ±6 or ±15 dB
• 18 dB per octave 40Hz low-
cut filter
• ±12 dB input gain range
limiting. Besides including two 15-band channels of 2/3-
®
• XLR, TRS and Euroblock
• Internal Toroidal
Limiting
®
• Dynamic range of greater
• User Power Up Features
• Relay Bypass for Power
Inputs and Outputs
Transformer
than 113dB
Failure System Protection
A Harman International Company
®
® signal
8760 S. Sandy Pkwy.
Sandy, Utah 84070
Phone (801) 568-7660
Fax (801) 568-7662
Int'l Fax (801) 568-7583
customer@dbxpro.com
http://www.dbxpro.com
18-0296 -A 3/03
