- Page 1 Kentucky Fried Chicken Computerized Control Installation, Operation, and Programming Instructions OPERATOR MANUAL...
- Page 3 During this time, any frypot that fails due to manufacturing or workmanship issues will be replaced at no charge for parts, labor, or freight. Henny Penny will either install a new frypot at no cost or provide a new or reconditioned replacement fryer at no cost.
-
Page 4: Table Of Contents
3-3. ERROR CODES ... 3-2 3-4. SPECIAL PROGRAMMING MODES ... 3-2 3-5. ONE STEP KFC PARAMETERSUSAGE REVIEW OPERATION ... 3-3 3-6. TEST PROCEDURE ... 3-3 3-7. SPECIAL FUNCTIONS ... 3-4 Henny Penny Distributor List (Domestic and International) Table of Contents... -
Page 5: Section 1. Introduction
1-1. SAFETY 1-2. ASSISTANCE SECTION 1. INTRODUCTION The Henny Penny pressure fryer has may safety features incorporated. However, the only way to ensure a safe operation is to fully under- stand the proper installation, operation, and maintenance procedures. The instructions in this manual have been prepared to aid you in learning the proper procedures. -
Page 6: Introduction
A. Remove the four screws holding the existing control panel in place. B. Position the control panel for servicing by placing the lower edge of the control panel on top of fryer frame and door. C. Identify the locations of the following wires. Reference wire diagram Figure 1. -
Page 7: Nine-Pin Connector Wiring
B. Remove the thermostat capillary tube from the cook pot as per section 5-11 of standard Henny Penny Service Manual. C. Install the reducer fitting, Henny Penny part number FP01-024 into the pot wall fitting. Use pipe sealant to seal the pipe threads. -
Page 8: Slot Cover
B. Bend the 4 tabs of slot cover over the top of the heat shroud. A. The new computerized panel is positioned and installed exactly like the existing electromechanical control panel. B. Place the computerized control panel on top of fryer frame and door. C. Mate the nine-pin connectors together. Refer to KFC gas wiring diagram. - Page 9 FIGURE 1...
- Page 10 FIGURE 2...
-
Page 13: Section 2. Operation
2.1 INTRODUCTION 2.2 SWITCHES AND INDICATORS SECTION 2. OPERATION The KFC Programmable Controller has two fundamental modes of operation: cook and program. In the cook mode the melt, stand-by, heat, and timer functions are active. In program, these modes are set by the operator. Melt Indicator - The display will read “LO”... -
Page 14: Fryer Power Up Mode
Power Switch in the “POWER” position. 1. If pot temperature is below the melt temperature of 185° the fryer will enter the melt mode. Display will read’ “LO”. 2. If the pot temperature is 185° F or higher the control will enter the stand-by mode and regulate to 250°... -
Page 15: Cooking Operation
2-5. COOKING OPERATION 1. Move the power switch to the POWER position. 2. If the display reads “LO” wait for it to change to “COOL” or display a temperature. 3. If the display reads “COOL” depress the EXIT COOL switch. 4. -
Page 16: Filtering The Shortening
As the shortening drains clean the inside of the frypot with a brush. The filter drain pan must be as far back under fryer as it will go, and the cover in place. Be sure the hole in the cover lines up with the drain before opening the drain. - Page 17 2-6. FILTERING THE SHORTENING (Continued) 7. When the pump is pumping air only, close the filter valve first and then move the main power switch to the OFF position. 8. Being sure there is sufficient shortening in the frypot, depress the EXIT FILL switch. 9.
-
Page 19: Programming
3-1. BASIC PROGRAMMING SEQUENCE 3-2. COOK CYCLE PROGRAMMING SECTION 3. PROGRAMMING To enter the program mode a password keystroke sequence is required. Note that when performing this sequence the switches must be depressed within one second of each other. If not, the control will not enter the program mode. -
Page 20: Error Codes
The following defines the error code number. If an error code occurs, the buzzer will sound until you depress a cycle switch. The control will continue to display the error code and fryer will be inoperative until error is corrected. -
Page 21: Test Procedure
3-4. SPECIAL PROGRAMMING MODES (Continued) 3-5. ONE STEP KFC PARAMETERS 3-6. TEST PROCEDURE 3. Select the desired special function by depressing either cycle switch 6 or 7. 4. Perform the desired operation. 5. Depress the EXIT FILL switch to exit the special program mode. -
Page 22: Special Functions
3-6. TEST PROCEDURE (Continued) 3-7. SPECIAL FUNCTIONS The table below shows the corresponding switch with the output. Switch Device Activated Product One Pressure Solenoid and Heat Control Select Time Product Indicators Select Function Function Indicators Change Switch Under Display 4 Change Switch Indicator Display Change Switch Under Display 3 Change Switch Indicator Display... - Page 28 3-10...
- Page 29 3-11...
- Page 30 3-12...
- Page 31 3-13...
- Page 32 3-14...
- Page 33 3-15...
- Page 34 3-16...
- Page 35 3-17...
- Page 36 3-18...
- Page 37 SN: AN0703021 & ABOVE 3-19...
- Page 38 SN: AN0703021 & ABOVE 3-20...
- Page 39 Part No. √ √ √ √ √ 73888RB √ √ √ √ √ 73889RB √ √ √ √ √ 30978 √ √ √ √ √ 14332 √ √ √ √ √ 14428 29887 30018 30094 36097 29898 √ √ √ √ √ 17635 √...
- Page 40 Part No. √ √ √ √ √ 73896RB √ √ √ √ √ 73897RB √ √ √ √ √ 29382 √ √ √ √ √ 36210 √ √ √ √ √ 28979 √ √ √ √ √ 16624 √ √ √ √ √ 54085 √...
