What's in the Box

VM9226BT Head Unit

Mounting Brackets

Custom Cosmetic Trim Ring

Hardware Bag

Speaker Output Harness

Power Input Harness

Accessory Harness

Installation Guide

External Microphone

NAV104 Interface Harness

WARNING! Never install this unit where operation and viewing could interfere with

safe driving conditions.

VM9226BT

You will need these tools and supplies to

install your VM9226BT:

• Torx type, flat-head and Philips

screwdrivers

• Wire cutters and strippers

• Tools to remove existing radio (screw

driver, socket wrench set or other

tools)

• Electrical tape

• Crimping tool

• Volt meter/test light

• Crimp connections

• 18 gauge wire for power connections

• 16 – 18 gauge speaker wire

Installation Guide

Tools and Supplies

Page 1 Installation Guide VM9226BT What’s in the Box Tools and Supplies VM9226BT Head Unit You will need these tools and supplies to Mounting Brackets install your VM9226BT: Custom Cosmetic Trim Ring • Torx type, flat-head and Philips Hardware Bag screwdrivers Speaker Output Harness •...
Page 2: Disconnecting The Battery
NOTE: If the VM9226BT is to be installed in a car equipped with an on-board drive or navigation computer, do not disconnect the battery cable. If the cable is disconnected, the computer memory may be lost. Under these conditions, use extra caution during installation to avoid causing a short circuit.
Page 3 Using the Cosmetic Trim Ring A cosmetic trim ring is packaged with the head unit for TRIM RING installation flexibility. This unit will fit into most import dashes with little or no modification to the dash board/cavity. Some US domestic vehicle dashes will accept a Double-DIN chassis, but there is usually a small gap between the radio and dash piece after installation is complete.
Page 4: Wiring Diagram
Wiring Diagram CAUTION! IMPORTANT: Incorrect wiring connections can damage the unit. Follow the wiring instructions carefully, or have the installation handled by an experienced technician. Need Help? For technical assistance, call the Jensen customer support line at 1-800-323-4815. RADIO ANT MICROPHONE External Power Ampliﬁer...
