Jensen VM9225BT Installation Manual
Car audio
Hide thumbs
Also See for VM9225BT:
- Operating instructions manual (80 pages) ,
- Operating instructions manual (82 pages)
Advertisement
Quick Links
What's in the Box
VM9225BT Head Unit
Left and Right Double DIN
Mounting Brackets
Double DIN Half Sleeve Install Bracket
Two Custom Cosmetic Trim Rings
Parking Brake Wire
Hardware Bag
Speaker Output Harness
Power Input Harness
Accessory Harness
Installation Guide
External Microphone
NAV104 Interface Harness
WARNING! Never install this unit where operation and viewing could interfere with
safe driving conditions.
VM9225BT
You will need these tools and supplies to
install your VM9225BT:
• Torx type, flat-head and Philips
screwdrivers
• Wire cutters and strippers
• Tools to remove existing radio (screw
driver, socket wrench set or other
tools)
• Electrical tape
• Crimping tool
• Volt meter/test light
• Crimp connections
• 18 gauge wire for power connections
• 16 – 18 gauge speaker wire
Installation Guide
Tools and Supplies
Advertisement
Related Manuals for Jensen VM9225BT
Summary of Contents for Jensen VM9225BT
- Page 1 Installation Guide VM9225BT What’s in the Box Tools and Supplies VM9225BT Head Unit You will need these tools and supplies to Left and Right Double DIN install your VM9225BT: Mounting Brackets • Torx type, flat-head and Philips Double DIN Half Sleeve Install Bracket...
-
Page 2: Optional Equipment
NOTE: If the VM9225BT is to be installed in a car equipped with an on-board drive or navigation computer, do not disconnect the battery cable. If the cable is disconnected, the computer memory may be lost. Under these conditions, use extra caution during installation to avoid causing a short circuit. - Page 3 Installation Using Half-Sleeve Step 1-b 1. Install half-sleeve in the dashboard. a. Install adapter if necessary (optional). b. Install half-sleeve into adapter or dashboard (use only the supplied screws). Do not force the sleeve into the opening or cause it to bend or bow. WARNING! Only connect the unit to a 12-volt power supply with proper grounding.
-
Page 4: Wiring Diagram
Wiring Diagram CAUTION! IMPORTANT: Incorrect wiring connections can damage the unit. Follow the wiring instructions carefully, or have the installation handled by an experienced technician. Need Help? For technical assistance, call the Jensen customer support line at 1-800-323-4815. RADIO ANT MICROPHONE External Power Amplifier...
