Jensen VM9115 Installation Manual

Car audio

Hide thumbs Also See for VM9115:

VM9115 Head Unit

Single DIN Sleeve

Wiring Harness

Parking Brake Wire

You will need these tools and supplies to install your VM9115:

• Torx type, flat-head and Philips screwdrivers

• Wire cutters and strippers

• Tools to remove existing radio (screwdriver, socket wrench set or other tools)

• Electrical tape

• Crimping tool

• Volt meter/test light

• Crimp connections

• 18 gauge wire for power connections

• 16 – 18 gauge speaker wire

WARNING! Never install this unit where operation and viewing could interfere

with safe driving conditions.

VM9115

What's in the Box

Tools and Supplies

Installation Guide

Mounting Hardware

Cosmetic Trim Ring

Owner's Manual

Installation Guide

Table of Contents

Page 1: Tools And Supplies
Parking Brake Wire Installation Guide Tools and Supplies You will need these tools and supplies to install your VM9115: • Torx type, flat-head and Philips screwdrivers • Wire cutters and strippers • Tools to remove existing radio (screwdriver, socket wrench set or other tools) •...
Page 2: Disconnecting The Battery
To prevent a short circuit, be sure to turn off the ignition and remove the negative (-) battery cable prior to installation. NOTE: If the VM9115 is to be installed in a car equipped with an on-board drive or navigation computer, do not disconnect the battery cable.
Page 3: Final Installation
If there is no ACC available, connect the ACC lead to the power supply with a switch. NOTE: When replacing a fuse, be sure to use correct type and amperage to avoid damaging the radio. The VM9115 uses one 15 amp fuse, located in the black filter box in-line with the main wire harness.
Page 4: Wiring Diagram
GREY/BLACK - FRONT R PURPLE + BATTERY + PURPLE/BLACK - YELLOW REAR R BATT FUSE (15A) GREEN + Battery GREEN/BLACK - BLACK REAR L BATTERY Ground Need Help? For technical assistance, call the Jensen customer support line at 1-800-323-4815. 128-9059b...
